Page 1 of 3

PSB.2005.06.001

EPSON PRODUCT SUPPORT BULLETIN

Date: 06/06/2005 Originator: JD

PSB #: PSB.2005.06.001 Authorization:

Reference: N/A Total Pages: 3

Product(s): Powerlite 8300/8300 with EasyMP.net/9300 series Projectors

Subject: Filter-Cleaning Procedures

This bulletin was created to inform users about the filter-cleaning procedures necessary for

maintaining proper airflow and reducing the potential for overheating.

Reason:

The PowerLite 8300 and 9300 series projectors have five (5) filters that must be cleaned on a regular

basis. Cleaning the filters is critical to maintaining proper airflow inside the projector and reducing

possible overheating issues. Incomplete or infrequent filter-cleaning maintenance can cause one or

more filters to accumulate excessive dust over time. This can inhibit proper airflow so that the

projector begins to overheat during operation and eventually shut down. The next section provides

information on the location of the filters on the projector, cleaning instructions and recommended

maintenance schedules.

Action:

The following filters should be cleaned after every 100 hours of use. For dusty environments, filter

cleaning should be performed more frequently.

1) Wire mesh filter (inside lamp housing shutter):

Hold shutter open and use a computer vacuum to remove dust.

Page 2 of 3

PSB.2005.06.001

2) Air intake filters (2)--located at bottom of projector:

Use a computer vacuum to clean both filters. If you don’t have one, then use a soft brush and gently

clean the filters. If the dirt is difficult to remove or either filter is damaged or broken, replace the

filter(s).

Note: Both filters should be replaced when the lamp is replaced.

3) Power supply intake filter (located on side of projector—opposite handle side)

Use a computer vacuum to clean dust from the filter and vents.

Page 3 of 3

PSB.2005.06.001

4) Lamp intake filter (circular filter located at bottom of projector)

Use a computer vacuum to clean dust from the filter and vents.

Page 1 of 2

PSB.2005.05.005

EPSON PRODUCT SUPPORT BULLETIN

Date: 05/11/2005 Originator: JAM

PSB #: PSB.2005.05.005 Authorization:

Reference: N/A Total Pages: 2

Product(s): PowerLite 8300i

Subject: 1400 x 1050 DVI Compatibility Support

Reason:

This bulletin is to inform you of the testing results for 1400 x 1050 DVI full-screen resolution

with the Epson PowerLite 8300i Projector.

Question:

1. Has the Epson PowerLite 8300 projector been tested for 1400 x 1050 DVI

full-screen display compatibility?

2. What type of DVI port is on the PowerLite 8300 and PowerLite 9300 Projectors?

Answer:

1. The Projector has native resolution of 1280 x 1024. Its maximum “DVI” resolution is 1280 x

1024. This Projector can only support 1400 x 1050 DVI full-screen display using a DVI-D

to VGA 15HD cable. Detailed information listed below.

2. The port on the rear A/V module is DVI-D (DVI Digital) dual link. It is not an analog port

and does not have the 4 extra analog pins for DVI-I (DVI Digital and Analog). A DVI-I cable

cannot physically attach to the port since it can cause damage to the cable.

Operating Systems tested:

System Version(s): Mac OS X 10.2.8

Hardware tested:

Computer(s): Apple PowerMac G5

Video Chip Set: NVidia, GeForce FX 5200

Video Test Generators tested:

Make: Extron

Model #: VTG 400

Page 2 of 2

PSB.2005.05.005

Projector Resolution “About” information:

Source: DVI

Input Signal: Digital-RGB

Resolution 1280 x 1024

Refresh Rate: 60 Hz

Input Device: PowerMac G5

Source: Computer 1

Input Signal: Analog-RGB

Resolution 1400 x 1050

Refresh Rate: 60 Hz

Input Device: Extron VTG 400

Tested by:

J.A.Madrigal

Epson America Inc.,

Advanced Product Support

Long Beach, CA

Page 1 of 2

PSB.2005.05.003

EPSON PRODUCT SUPPORT BULLETIN

Date: 05/11/2005 Originator: JAM

PSB #: PSB.2005.05.003 Authorization:

Reference: N/A Total Pages: 2

Product(s): PowerLite 8300i and PowerLite 9300i

Subject: 1400 x 1050 Compatibility Support

Reason:

This bulletin is to inform you of the testing results for 1400 x 1050 full-screen resolution with

the Epson PowerLite 8300i and PowerLite 9300i video projectors.

Question:

1. Have the Epson PowerLite 8300 and PowerLite 9300 Projectors been tested for

1400 x 1050 full-screen display compatibility?

2. Why do some laptops undersize the screen and perform in a pan-and-scan function on

projectors with 1400 x 1050 native resolutions?

Answer:

1. Yes, the Projectors have been confirmed functional with various video sources and

software operating systems for full-screen display performance. Detailed information

listed below.

2. Various laptop manufacturers use ATI RagePro or ATI Radeon chipsets for the built-in

LCD screen. The “Advanced Settings” of the video driver function in pan-and-scan

mode when re-directing video to the external video port. The true output at the VGA

15-HD port is only 1280 x 1024 as verified using by a VGA monitor that can sense and

display the video settings from the monitor’s menu options.

Operating Systems tested:

System Version(s): Windows 98SE and Windows XP Service Pack 2

Mac OS X 10.2.8

Hardware tested:

Mother Board(s): ASUS P4BGL-VM ATX Motherboard

Video Chip Set: Intel 8284G/GL Graphics Controller

Computer(s): Apple PowerMac G5

Video Chip Set: NVidia, GeForce FX 5200

Page 2 of 2

PSB.2005.05.003

Video Test Generators tested:

Make: Extron

Model #: VTG 400

Projector Resolution “About” information:

Source: DVI

Input Signal: Digital-RGB

Resolution 1400 x 1050

Refresh Rate: 60 Hz

Input Device: PowerMac G5

Source: Computer 1

Input Signal: Analog-RGB

Resolution 1400 x 1050

Refresh Rate: 60 Hz

Input Device: Extron VTG 400

Tested by:

J.A.Madrigal

Epson America Inc.,

Advanced Product Support

Long Beach, CA

Page 1 of 14

PSB.2004.10.002

EPSON PRODUCT SUPPORT BULLETIN

Date: 10/08/2004 Originator: DS

PSB #: PSB.2004.10.002 Authorization:

Reference: TI 04-46e Rev. A Total Pages: 14

Product(s): EMP NS Connection, EMP Network Manager, EMP Monitor,

EMP Multi Screen Adjustment, Cinema Color Editor, VCOM Driver

Subject: Evaluation results of Epson Projector PC applications tested in Windows XP

with SP2.

The purpose of this bulletin is to provide information on Epson PC projector applications tested

under the Windows XP SP2 (Service Pack2) environment.

Description:

Information is provided about the evaluation results and recommendations for Epson PC

projector applications functionality in Windows XP SP2 Firewall environment.

Reason:

Compatibility testing for functionality of EMP NS Connection, EMP Network Manager, EMP

Monitor, EMP Multi Screen Adjustment, Cinema Color Editor, VCOM Driver in the Windows

XP SP2 environment.

Results of Windows XP SP2 installation:

Installing SP2 on PCs did not disturb the installation of the above software applications.

Also, the application software can be installed on PCs where SP2 or earlier versions are

installed without any issues.

The information contained in the following pages provides details for executing the

applications in Windows XP SP2.

Page 2 of 14

PSB.2004.10.002

Executing the Software:

When executing the software noted below for the first time after SP2 installation completes,

the following security alert messages are displayed:

[EMP NS Connection]

Security alert screen (EMP NS Connection)

[EMP Network Manager]

Security alert screen (EMP Network Manager)

Page 3 of 14

PSB.2004.10.002

[EMP Monitor]

Security alert screen (EMP Monitor)

[EMP Multi Screen Adjustment]

Security alert screen (EMP Multi Screen Adjustment)

The Security Alert screen for EMP Multi Screen Adjustment is shown after clicking the

Auto button of Network or clicking the Add button after entering an IP address in the

IP Address box.
