EQD Auria EQ2488F Bedienungsanleitung
MODEL EQ2488F
24"
Features:
• 1080p FHD resolution
• Crystal clear picture and sound
• Perfect PCTV to replace a computer monitor
• Perfect for the kithcen, bedrooms or college
LCD
FULL HDTV
AURIA_DataSheet_24_v1.indd 1 12/29/08 11:23:54 AM
LCD Display:
23.6" diagonal, Full HD TFT LCD TV
Panel model name:
CMO M236H1-L01
Display Size (H*V):
521.28(H) x 293.22(V)
Pixel Pitch (H*V):
0.2715(H) x 0.2715(V)
Max. Resolution:
1920 x R.G.B. x 1080
Max. Display Colors:
16.7 millions
Brightness (typ.):
300 cd/m2 (Center 1point ,Typ.)
Contrast Ratio (typ.):
1000 : 1 (Typ.)
Viewing Angle (CR≧10):
Horizontal (typ.) 170o
Vertical (typ.) 160o
Response Time (Tr+Tf) (typ.):
5 ms (Gray to Gray)
OSD Controls:
Keypad 7 Buttons ( VOL-, VOL+, Menu, Power, CH-, CH+, Input)
OSD Functions:
Picture: Picture Mode, Brightness, Contrast, Sharpness, Tint,
Color, Color Mode, Zoom Mode, Noise Reduction
Audio: Sound Mode, Treble, Bass, Prefer Language, Surround
Sound, Audio Only
Time: Sleep Timer, Time Zone, DST, Time Format, Auto Sync, Clock
Option: Menu Language, Transparency, SOD Time Out, Closed
Caption, Basic Selection, Advanced Selection(ATSC), Option(ATSC), DCR,
Restore Default
Channel: TV Source, Auto Scan, Favorite, Show/Hide, Channel no.,
Channel Label, DTV Signal
Lock: Enter Password"
OSD Language:
Three Languages (English / Spanish / Franch)
Operating Conditions:
Temperature 0C to +40C
Humidity 10% ~ 65% non-condensing
Storage Conditions:
Temperature -200C to +60C
Humidity 0 ~ 90% non-condensing
Altitude 0 meter to 12,000 meters above sea level
Unit Dimensions (W*H*D):
566.7mm x 442.7mm x 216.0mm
Package Dimensions (W*H*D):
615.0mm x 510.0mm x 145.0mm
Net Weight:
6.5 kgs
MODEL EQ2488F
SPECIFICATIONS
Gross Weight:
8.6 kgs
Container Load:
40"H 1160
40' 1160
20' 544
Certication:
UL/CUL, FCC, BETS-7 NOM / EnergyStar 3.0
Others:
Embedded Full-Range Power Supply
Terminator:
Tuner Module INPUT 1 (One Tuner build-in ATSC + NTSC,QAM is supported
under ATSC
HDMI 1.2 INPUT 1 (HDMI 1.3)
PC D-SUB 3.5mm AUDIO INPUT 1
CVBS/S-Video Audio L/R INPUT 1
YPbPr Audio L/R INPUT 1
Earphone (3.5mm) OUTPUT 1
Audio:
Speaker 5W x 2
Sound Effect Yes
MTS Stereo Yes
Feature:
Comb Filter 3D (ATV)
Aspect Ratio Control 16:9 4:3 Zoom Wide Yes
Noise Reduction Yes
Auto Sleep Timer Y e s
Child Lock Yes, V-Chip. Parent control
PIP No
Peripheral:
Keypad: 7Keys (Down) Power, input, Menu, CH Next, CH Previous, Volume
Up, Volume Down
IR Off axis ±15° 5m
On axis 7m
LED Power On Blue
Standby Orange
Power Requirement:
Input Range 100VAC~240VAC, 50Hz~60Hz
Power Conumption Standby < 1W
On (typical) <60W
AC in Without Switch
Tuner Module:
ATSC+ NTSC tuner
Accessory:
AC power cord, Remote control, Bettery, User's manual, QSG
Warranty:
Two-year limited warranty on parts, labor and backlight
LCD TECHNOLOGIES
We proudly support the Armed Forces Foundation and Miracles for Kids by donating a
percentage of our prots. Please nd out more today at www.eqdcorp.com/giving-back
as well as www.armedforcesfoundation.org and www.miraclesforkids.org.
26045 Acero | Mission Viejo, CA 92691 | 877.375.1065 | www.eqdcorp.com
Pro duction Notes:
PMS 295 UC - Dark Blue
PMS 292 UC - Light Blue
AURIA_DataSheet_24_v1.indd 2 12/29/08 11:24:10 AM
