ESSENCORE KLEVV Bedienungsanleitung
OVERVIEW
BEFORE YOU BEGIN
SSD HANDLING PRECAUTIONS
DESKTOP INSTALLATION
- Install Migration Tool
- Migrate Your Data
- Swap or Install Your Drives
- Change the Boot Order of the Drives from BIOS
- Install Migration Tool
- Migrate Your Data
- Swap Your Drives
LAPTOP INSTALLATION
WARRANTY AND TECHNICAL SUPPORT
CONTENTS
KLEVV M.2 SSD
INSTALLATION
GUIDE
Ver. 1.0
Overview
This guide explains how to install a KLEVV Solid-State Drive (KLEVV SSD)
in a SATA-based desktop or notebook computer.
Observe the following before beginning the installation:
Handle the SSD with care. Do not touch the gold connectors.
To minimize static electricity, touch the computer case before handling the SSD.
Do not remove the encasement or disassemble the SSD
; these actions void the SSD warranty.
Hardware Item
1 USB to M.2 2280 SATA adaptor
and USB cable
2 Screwdriver
3 Screws
Laptop/desktop computers
to migrate your data
Laptop/desktop computers
Laptop/desktop computers
Required For
SSD Handling Precautions
Before You Begin
Conrm you have the following
hardware for installation
* These tools are not included in the package.
You may need to prepare by yourself.
Desktop Installation
Please make sure that you have installed the Migration Tool1.
2. Install the KLEVV M.2 SSD to the USB to M.2 2280 adaptor.
(You may need to consult the user manual of your USB to M.2 2280
adaptor)
Migrate Your Data
Swap or Install Your Drives
3.
Connect the KLEVV M.2 SSD to
your desktop using the USB to
M.2 2280 adaptor
* Please skip this step if you don’t need to migrate your data.
* You may also use your own software for the data migration.
Install Migraon Tool - Acronis True Image 2015
If your KLEVV SSD provides Migration Tool (Acronis True Image 2015),
please download the software and its user’s manual from the following
KLEVV website. (www.essencore.com or www.klevv.com)
1.
Follow the instructions to install the Migration Tool to your desktop.2.
Run the Migration Tool,
and follow the instructions
to migrate your operating .
4.
5.
6.
Safely remove your KLEVV M.2 SSD from USB when done.
Disconnect your KLEVV M.2 SSD from the USB to M.2 2280 adaptor.
Power off your desktop and disconnect the power cord.1.
Remove the existing M.2 SSD from the M.2 socket (if applicable).
Refer to your owner’s manual for how to safely remove the existing
M.2 drive.
4.
Align the notches on the KLEVV
M.2 SSD with the ridges in the
M.2 socket, then insert as shown.
5.
Hold KLEVV M.2 SSD along
the side edges and lower it
until it sits on top of the
support assembly.
6.
Insert screw into the support
assembly and securely
fasten the KLEVV
M.2 SSD in.
7.
Locate your computer’s M.2 socket on the motherboard (You may
need to consult your owner’s manual for the exact location)
3.
Open the cover of your computer.2.
* If needed please refer to the service
manual for your desktop to open the
cover safely.
Reattach the covers to your desktop.8.
Change the Boot Order of the Drives from BIOS
Migrate Your Data
Power on your computer.(You may also see a message prompting
you to update your system's conguration settings. Refer to your
owner's manual for instructions.)
While the computer is booting, press a special key such as ESC, F1,
or DELETE to enter the BIOS menu. Check your computer manufacturer’s
documentation for the correct key(s).
Go to the Boot or Startup screen and change the boot order so that
the KLEVV M.2 SSD appears before your old storage device.
Save the settings and exit the BIOS setup menu.
Restart the computer.
Now your computer boots to your KLEVV M.2 SSD.
1.
3.
4.
5.
6.
2.
Please make sure that you have installed the Migration Tool.1.
Install the KLEVV M.2 SSD to the USB to M.2 2280 adaptor.
(You may need to consult the usermanual of your USB to
M.2 2280 adaptor)
2.
Connect the KLEVV M.2 SSD to your desktop using the USB to
M.2 2280 adaptor
3.
Run the Migration Tool,
and follow
the instructions to
migrate your
operating system
and data to the
new KLEVV M.2 SSD.
4.
Safely remove your KLEVV M.2 SSD from USB when done.5.
Disconnect your KLEVV M.2 SSD from the USB to M.2 2280 adaptor.6.
If your KLEVV SSD provides Migration Tool (Acronis True Image 2015),
Please download the software and its user’s manual from the following
KLEVV website. (www.essencore.com or www.klevv.com)
1.
Follow the instructions to install the Migration Tool to your laptop.2.
* You may also use your own software for the data migration.
Laptop Installation
* Please skip this step if you don’t need to migrate your data.
Install Migraon Tool - Acronis True Image 2015
Power off your laptop.
Disconnect power cord
and remove the battery.
Remove the existing M.2 SSD from the M.2 socket (if applicable).
Refer to your owner’s manual for how to safely remove the existing
M.2 drive.
Align the notches on the KLEVV
M.2 SSD with the ridges in the
M.2 socket, then insert
as shown.
Hold KLEVV M.2 SSD
along the side edges
and lower it until it sits
on top of the support
assembly.
Insert screw into the support
assembly and securely
fasten the KLEVV M.2
SSD in.
Replace the cover and power on the computer
1.
2.
3.
4.
5.
6.
Swap Your Drives
KLEVV is a trademark of ESSENCORE Limited., registered in the United States and other countries.
© 2015 ESSENCORE Limited. All rights reserved. All trademarks are properties
of their respective owners.
KLEVV will not be responsible for providing free repairs if the product defect
is caused by any of the following factors:
– Damage caused by natural disaster or any inappropriate usage.
– Product has been repaired or taken apart by unauthorized technicians.
– Unauthorized modication of rmware.
– Serial number of product does not match or is not clear enough to be
identied.
– Products purchased from unauthorized agents.
This limited warranty covers only repairs or replacements of KLEVV products.
KLEVV is not liable for any loss of data or any cost incurred from determining
the source of system problems, removing, servicing or installing
KLEVV products.
For More information regarding the product warranty, please visit KLEVV
website for detailed terms.(www.essencore.com or www.klevv.com)
Limitaon of warranty
For more information about warranty, go to KLEVV website.
To apply for an RMA (Return Material Authorization), please contact
Warranty and Technical Support
INFORMACIÓN GENERAL
ANTES DE EMPEZAR
PRECAUCIONES A LA HORA DE MANIPULAR LA UNIDAD DE ESTADO SÓLIDO
INSTALACIÓN EN EQUIPO DE SOBREMESA
- Instalar la herramienta de migración
- Migrar los datos
- Intercambiar o instalar las unidades
-
Cambiar el orden de arranque de las unidades desde el BIOS
- Instalar la herramienta de migración
- Migrar los datos
- Intercambiar las unidades
INSTALACIÓN EN EQUIPO PORTÁTIL
GARANTÍA Y SOPORTE TÉCNICO
CONTENIDO
GUÍA DE INSTALACIÓN
DE LA UNIDAD DE
ESTADO SÓLIDO KLEVV
Información general
En esta guía se explica cómo instalar una unidad de estado sólido KLEVV (SSD KLEVV)
en un equipo de sobremesa o portátil basado en SATA.
Tenga en cuenta lo siguiente antes de iniciar la instalación:
Manipule la unidad de estado sólido con cuidado. No toque los conectores dorados.
Para minimizar la electricidad estática, toque la carcasa del equipo antes de manipular la unidad de estado sólido.
No quite la cubierta ni desmonte la unidad de estado sólido ya que, si lo hace,
la garantía de dicha unidad quedará anulada.
Antes de empezar
Asegúrese de que tiene las siguientes
herramientas y hardware para la instalación.
* Estas herramientas no se incluyen en el paquete.
Puede que necesite prepararlas usted mismo.
Elemento de hardware
1 Adaptador SATA USB a
M.2 2280 y cable USB
2 Destornillador
3 Tornillos
Equipos portáles y de sobremesa para
migrar los datos
Equipos portáles y de sobremesa
Equipos portáles y de sobremesa
Necesario para
Precauciones a la hora de manipular la unidad
de estado sólido
Instalación en equipo de sobremesa
Asegúrese de que ha instalado la herramienta de migración.1.
Instale la unidad de estado sólido KLEVV M.2 en el adaptador USB a M.2 2280.
(Necesita consultar el manual del usuario del adaptador USB a M.2 2280)
2.
Migrar los datos
Intercambiar o instalar las unidades
3.
Conecte la unidad de estado sólido
KLEVV M.2 al equipo de sobremesa
mediante el adaptador USB
a M.2 2280.
* Omita este paso si no tiene que migrar datos.
* También puede utilizar su propio software para la migración de datos.
Instalar la herramienta de migración - Acronis True Image 2015
Si la unidad de estado sólido KLEVV proporciona una herramienta de migración
(Acronis True Image 2015), descargue el software y su manual del usuario desde
el siguiente sitio web de KLEVV.
(www.essencore.com or www.klevv.com)
1.
Siga las instrucciones para instalar la herramienta de migración en el equipo
de sobremesa.
2.
Ejecute la herramienta de
migración y siga las instrucciones
para migrar el sistema operativo
y los datos a la nueva unidad
de estado sólido KLEVV M.2.
4.
Extraiga de forma segura la unidad de estado sólido KLEVV M.2
del puerto USB cuando haya terminado.
5.
Desconecte la unidad de estado sólido KLEVV M.2 del adaptador USB
a M.2 2280.
6.
Apague el equipo de sobremesa y desconecte el cable de alimentación.1.
