EchoICON and EchoEDGE Manual

Introduction:

Thank you for your purchase. The EchoICON/EchoEDGE RGBWA+UV LED is a DMX

intelligent LED par light. This LED par light is for the serious production company looking

for high powered LED output with (8) 18Watt 6in1 RGBWA+UV LEDs.

Unpacking: Thank you for purchasing the EchoICON/EchoEDGE RGBWA+UV light fixture.

Every EchoICON/EchoEDGE RGBWA+UV has been thoroughly tested and has been

shipped in perfect operating condition. Carefully check the shipping carton for damage that

may have occurred during shipping. If the carton appears to be damaged, carefully inspect

your fixture for any damage and be sure all accessories necessary to operate the unit has

arrived intact. In the case damage has been found or parts are missing, please contact the

manufacturer or your dealer for further instructions. Do not return this unit to your dealer

without first contacting them.

Contents in each package: (1) EchoICON or EchoEDGE , (1) IEC power cord, (1)Bracket, (2)

knobs, (4) washers.

FIRST CHARGE YOUR FIXTURE FOR 6-8 HOURS.Securely, plug the IEC power

cord in the Power Input on the side of the light fixture, and then plug into a powerstrip or

wall outlet that supports 100-220V/50-60Hz.

IMPORTANT NOTE: Do Not LINK Power in to Power out more than 3 Units at a time.

You will blow a fuse and the light will not charge.

Warning! To prevent or reduce the risk of electrical shock or fire, do not expose this unit to

rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs

yourself; doing so will VOID your manufactures warranty. In the unlikely event your unit

may require service please contact the manufacturer or your dealer. Also, when operating

the EchoICON or EchoEDGE fixture in battery mode, have the Red power button OFF. Do

not have the battery button on and the Red Power button on at the same time.

Caution: Do not operate in Color50 with all colors at 255 other than Testing for short time.

The CUBE Series including the CUBE3, CUBE4, CUBE5, CUBEecho, CUBEechoUV, EchoICON

and EchoEDGE as well as the ElitePar Series are Designed in Houston, TX.

EchoICON and EchoEDGE Manual

Features & Technical Specifications:

(8) 18 Watt All in One RGBWA+UV LEDs

All in One LEDs RGBWA+UV Fixture - RED, GREEN, BLUE, WHITE, AMBER and

UV!

3CH, 4CH, 5CH, 8CH, 11CH or 13CH DMX Modes

Flicker Free Refresh Rate >400 Hz (HDTV Video, Guaranteed No Flicker)

Ideal for ideal for HDTV recordings with Flicker Free operation

Sound Active with 2 Sound Active Modes (1 Without Strobe/1 With Strobe)

Auto Mode with 8 Speed Settings

Smooth Color Mixing

Fade mode with 8 Speed Settings

50 built in PRE-SET Colors

Manual Color Mix Mode on Push Button Display

Built In Color Macros, Auto & Manual control

16 Digit, 2 Line, Full Text read out Back-Lit LCD Push Button Display

Ability to create & store into memory 5 Custom/manual Colors.

Power In & Power Out

Master/Slave Control

Up to 20 Hours of Battery Life

Flush Mounted Wireless DMX Antenna recessed to keep the antenna safe

2.4gHz Wireless DMX Receiver that is also a Transmitter (Up to 300ft Line of Sight)

Simultaneous master signal transmitting from Master to all other lights in range

IR Remote control. Also the Signal Received from the IR Remote can Transmit to the

other lights by Wireless DMX.

(Compatible with CUBE5, ElitePar5, CUBEecho & EchoEDGE)

Dual Mount Bracket for hanging or sitting on the floor

Rubber feet for non intrusive lay flat design.

PHOTOMETRICS: 19,345 LUX @ 1meter (Full Power)

EchoICON and EchoEDGE Manual

Start Up

Welcome to

ETERNAL LIGHTING

Switch to Display

CUBEecho RGBWAI (Note: I = UV: Ultra Violet) Version 1.0

DMX addr

CH mode

DMX addr: 001-512

CH-mode: 3 / 4 / 5 / 6 / 8 / 11 /13

Mast/Slave

Mast / Slave

Manual

R/G/B/W/A/I (000-255)

SHND

Color

Color 01-50 NOTE:

Do not operate in Color50 with all colors at 255 other than

Testing for short time.

Auto

Auto Speed 01-08

Custom Color A

Custom Color B

Custom Color C

Custom Color D

Custom Color E

Sound

S01

S02

Fade

00-10

Boot time

Work time

Operating Time

Total Operating Time

Battery Capacity

Battery Test

LCD Display time

Full on

10s/11s/12s…60s

IR INFA

Enable/Disable

EchoICON and EchoEDGE Manual

Menu:

DMX Address and Channel Mode –Press Enter to move up and down between

DMX Addr and CH also press Enter to save a command.

Master/Slave –Press Up or Down to change the command of Master or Slave, Enter

to save the command. (NOTE: In order to use the IR Remote, put the CUBEecho in

Master Mode. The CUBEecho will not respond to the IR Remote if it is in Slave

Mode.)

Manual Color Mix –Press Enter to go through Red, Green, Blue, White, and Amber.

Press Up or Down to adjust color brightness on a scale of 0-255. Enter to save. This

color can be found in Color 50.

SHND –Press Up to scroll through options: Color, Sound, and Fade. Enter to select

choice.

oColor –Pre-set colors 1-50, after color 50 is AUTO change (Speed 1-8). After

AUTO, is Custom Color A –E; Enter make a custom color. You can make 5

custom colors that will be saved under A through E.

oSound –Sound 1 (auto change when hears sound & Fade when quiet). Sound

2 (Strobe effect when hears sound & Fade when quiet).

oFade –Color Fade 1 through 10. Fast (1) to slow (10).

Boot Time and Work Time –Current operating time and total run time

Battery Capacity –Percentage left on the battery

LCD Display Time –Full On

IR INFA –Enable or Disable

Receiver button –ON/OFF

ID Code Selector –Red (1), Green (2), Yellow (3), Blue (4), Purple (5), Cyan (6), White (7)

To Master/Slave the EchoEDGE or EchoICON, put one fixture in Master Mode and the rest

of the fixtures in Slave Mode. Turn on the Receiver button and put all fixtures on same ID

Code Color. You now control the Master fixture and all the Slave fixtures will do what the

Master is doing.

Trick: To Master Reset your EchoICON or EchoEDGE, press Menu and Enter button at the

same time for 5 seconds. This will put Address back to 1, Channel back to 5, Slave Mode,

Manual Colors back to 255, and put all custom colors (A-E) to 0.

EchoICON and EchoEDGE Manual

Infrared remote control:

To control the fixture you must aim the controller at the front of the fixture. To use the

remote control, you must first activate the fixture’s infrared receiver. To activate the

fixtures infrared receiver you should press the button MAST on the remote control, when

the display screen show “yes” means the light is on mast mode, Press “Slav” to chose the

slave mode.

ON/OFF turn on /off the light, If you don’t need the light for a while, you could press OFF

to save electric energy.

PRO Auto program aim UP or DOWN to chose auto mode.

SOU sound active mode press UP or Down to chose sound active mode 1 or 2

STRO strobe mode

SPEE speed

MAST master mode press and then the display screen show “yes” means the light is on

master mode,

SLAV slave mode Press “Slav” to chose the slave mode.

CH addr / channel

FULL all leds light up

SHUT all leds turn off

Red = red color

GREE = green color

BLUE = blue color

WHIT = white color

AMBE = amber color

PINK = pink color

ORG = orange color

GYAN = cyan color

PURP = UV color

EchoICON and EchoEDGE Manual

DMX Values and Functions: DMX Cannel Mode 3ch / 4ch / 5ch / 6ch / 8ch / 11ch / 13ch

3CH Mode EchoEDGE & EchoICON

4CH Mode EchoEDGE & EchoICON

5CH Mode EchoEDGE & EchoICON

Value

RGBWA+UV 8pc 18 Watt x 6in1

CH1

0-255

RED dimmer (0-255)

CH2

0-255

GREEN dimmer (0-255)

CH3

0-255

BLUE dimmer (0-255)

Value

RGBWA+UV 8pc 18 Watt x 6in1

CH1

0-255

RED dimmer (0-255)

CH2

0-255

GREEN dimmer (0-255)

CH3

0-255

BLUE dimmer (0-255)

CH4

0-255

WHITE dimmer (0-255)

Value

RGBWA+UV 8pc 18 Watt x 6in1

CH1

0-255

RED dimmer (0-255)

CH2

0-255

GREEN dimmer (0-255)

CH3

0-255

BLUE dimmer (0-255)

CH4

0-255

WHITE dimmer (0-255)

CH5

0-255

AMBER dimmer (0-255)

EchoICON and EchoEDGE Manual

6CH Mode EchoEDGE & EchoICON

8CH Mode EchoEDGE & EchoICON

Value

RGBWA+UV 8pc 18 Watt x 6in1

CH1

0-255

RED dimmer (0-255)

CH2

0-255

GREEN dimmer (0-255)

CH3

0-255

BLUE dimmer (0-255)

CH4

0-255

WHITE dimmer (0-255)

CH5

0-255

AMBER dimmer (0-255)

CH6

0-255

Ultra Violet/I dimmer(0-255)

Value

RGBWA+UV 8pc 18 Watt x 6in1

CH1

0-255

RED dimmer (0-255)

CH2

0-255

GREEN dimmer (0-255)

CH3

0-255

BLUE dimmer (0-255)

CH4

0-255

WHITE dimmer (0-255)

CH5

0-255

Auto

CH6

0-255

Auto Slow to Fast (0-255)

CH7

0-255

R, G, B,W STROBE from slow to fast (0-255)

CH8

0-255

SOUND (Off 0-15 ON 16-255)

EchoICON and EchoEDGE Manual

11CH Mode EchoEDGE & EchoICON

Value

RGBWA+UV 8pc 15 Watt x 6in1

CH1

0-255

RED dimmer (0-255)

CH2

0-255

GREEN dimmer (0-255)

CH3

0-255

BLUE dimmer (0-255)

CH4

0-255

WHITE dimmer (0-255)

CH5

0-255

AMBER dimmer (0-255)

CH6

0-255

R, G, B, W dimmer (0-255)

CH7

0-255

R, G, B, A dimmer (0-255)

CH8

0-255

Auto

CH9

0-255

Auto Slow to Fast (0-255)

CH10

0-255

R, G, B,W, A STROBE from slow to fast (0-255)

CH11

0-255

SOUND 1 (Off 0-15, ON 16-100 Color change, Fade and Strobe,

ON 101-255 Color Change & Fade)

13CH Mode EchoEDGE & EchoICON

Value

RGBWA+UV 8pc 15 Watt x 6in1

CH1

0-255

RED dimmer (0-255)

CH2

0-255

GREEN dimmer (0-255)

CH3

0-255

BLUE dimmer (0-255)

CH4

0-255

WHITE dimmer (0-255)

CH5

0-255

AMBER dimmer (0-255)

CH6

0-255

Ultra Violet/I dimmer (0-255)

CH7

0-255

R, G, B, W dimmer (0-255)

CH8

0-255

W, A dimmer (0-255)

EchoICON and EchoEDGE Manual

CH9

0-255

Ultra Violet/I dimmer (0-255)

CH10

0-255

Auto

CH11

0-255

Auto Slow to Fast (0-255)

CH12

0-255

R, G, B,W, A STROBE from slow to fast (0-255)

CH13

0-255

SOUND 1 (Off 0-15, ON 16-100 Color change, Fade and Strobe,

ON 101-255 Color Change & Fade)

For more information, please contact Support by email at support@eternallighting.com

Andere Handbücher für EchoICON

Dieses Handbuch passt für folgende Modelle

Andere Eternal Lighting Beleuchtungsausrüstung Handbücher

Eternal Lighting

Eternal Lighting CUBEecho RGBWA Bedienungsanleitung

Eternal Lighting

Eternal Lighting EventCUBE CW Bedienungsanleitung

Eternal Lighting

Eternal Lighting FlatParPro-10W Bedienungsanleitung

Eternal Lighting

Eternal Lighting CUBEecho RGBWA+UV Bedienungsanleitung

Eternal Lighting

Eternal Lighting EchoICON Bedienungsanleitung

Eternal Lighting

Eternal Lighting ULTRA170 CW/WW Bedienungsanleitung

Eternal Lighting

Eternal Lighting EchoMATE Bedienungsanleitung

Eternal Lighting

Eternal Lighting EliteParHEX Bedienungsanleitung

Eternal Lighting

Eternal Lighting STELLAR6OXT Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Laserworld

Laserworld Evolution Series ES-400RGB Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung
