EtherWAN EX1624W Bedienungsanleitung

24-Port Web-Smart Ethernet Switch

User’s Manual 1

FCC Statement

The FCC (Federal Communications Commission) restricts

the amount of radio frequency emission and radiation coming

from computer equipment.

The equipment introduced in this manual has been tested

and found to comply with the limits for a Class A digital

device pursuant to Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment.

This equipment generates, uses, and can radiate radio

frequency energy, and if not installed and used in

accordance with the instruction manual, may cause harmful

interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user is required

to correct the interference at his/her own expense.

Any changes or modifications not expressly approved by the

manufacture would void the user’s authority to operate the

equipment.

Trademarks

Product names mentioned in this manual may be trademarks

or registered trademarks of those products.

All trademarks or brand names mentioned are properties of

their respective companies.

24-Port Web-Smart Ethernet Switch

User’s Manual

Preface

This manual describes how to install and use the 24-Port Web-

Smart Ethernet Switch. The TX ports of the switch introduced here

auto-negotiates the presence of 10/100Mbps and full/half-duplex

mode and auto-MDIX. In addition, it allows an optional 100Base-

FX multi-mode or single-mode fiber module, enabling long

distance connection.

To get the most out of this manual, you should have an

understanding of networking concepts such as bridging, IEEE

802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX/FX Fast

Ethernet, and local area networks (LANs).

For more information about these topics, please refer to the

Appendices.

In this manual, you will find:

•Introduction on the Switch

•Product features

•Illustrative LEDs functions

•Installation instructions

•Specifications

24-Port Web-Smart Ethernet Switch

User’s Manual 3

Table of Contents

FCC STATEMENT 1

TRADEMARKS 1

PREFACE 2

TABLE OF CONTENTS 3

PRODUCT OVERVIEW 5

FRONT VIEW 5

PACKAGE CONTENTS 5

PRODUCT FEATURES 6

FRONT PANEL DISPLAY 7

PHYSICAL PORTS 8

Understanding Front Panel Design 8

INSTALLATION 9

SELECTING A SITE FOR THE EQUIPMENT 9

INSTALLATION AND PLACEMENT INSTRUCTIONS 10

Mounted to 19-inch standard rack 10

Desktop or any flat surface 10

OPTIONAL FIBER MODULE INSTALLATION 11

CONNECTING TO POWER 12

CONNECTING TO YOUR NETWORK 12

Cabling 12

Network Segmentation 13

SWITCH CONFIGURATION 14

SETTING UP CONSOLE PORT CONNECTION (WEB-BASED BROWSER

INTERFACE) 14

LOGGING ON TO THE ETHERNET SWITCH 14

Switch IP Address 14

User Name 14

Password 14

MAIN MENU 15

System Change 15

IP Configuration 16

24-Port Web-Smart Ethernet Switch

User’s Manual

Port 17

VLAN 18

Trunking 19

Save Configuration 20

Load Default 21

TECHNICAL SPECIFICATIONS 22

PHYSICAL SPECIFICATIONS 23

CONNECTOR PINOUTS 24

ORDERING INFORMATION 25

24-Port Web-Smart Ethernet Switch

User’s Manual 5

Product Overview

Front View

Figure 1: 24-Port Web-Smart Ethernet Switch

Package Contents

When you unpack the product package, you shall find these items

listed below.

The 24-Port Switch

3One AC power cord

User’s Manual

Please inspect the contents, and report any apparent damage or

missing items immediately to your authorized reseller.

24-Port Web-Smart Ethernet Switch

User’s Manual

Product Features

♦PROVIDES 24 ×10/100MBPS PORTS USING RJ-45

CONNECTORS

♦AN OPTIONAL SINGLE-PORT FIBER MODULE ALLOWS:

-100BASE-FX MULTI-MODE FIBER WITH SC, ST, MT-RJ, VF-45 OR LC

CONNECTOR

-100BASE-FX SINGLE-MODE FIBER WITH SC CONNECTOR

♦AUTO-NEGOTIATION FOR SPEED AND DUPLEX MODE ON TX

PORTS

♦8192 MAC ADDRESSES,1.5M BITS BUFFER MEMORY

♦AUTO-MDIX FOR ALL TX PORTS

♦STORE-AND-FORWARD MECHANISM

♦TRUE NON-BLOCKING ARCHITECTURE

♦FULL WIRE SPEED FORWARDING RATE

♦BROADCAST STORM FILTERING CONTROL

♦BACK-PRESSURE AND IEEE 802.3X COMPLIANT FLOW

CONTROL

♦SYSTEM,IP CONFIGURATION,PORT,PORT-BASED VLAN,

AND PORT-BASED TRUNKING SETTING THROUGH THE WEB-

BASED CONSOLE PORT.

♦FRONT PANEL PUSH BUTTON TO CHOOSE 100BASE-FX OR

PORT 24

♦PRESS THE FRONT PANEL IP RESET PUSH BUTTON FOR

FIVE SECONDS TO RESET THE ETHERNET SWITCH BACK TO

THE DEFAULT IP ADDRESS.(THE PORT,VLAN, AND

TRUNKING SETTINGS WILL REMAIN THE SAME AS WHEN

THEY WERE LAST SAVED).

♦FRONT PANEL PORT AND POWER STATUS LEDS

♦STANDARD 19” RACKMOUNT SIZE,ONE-UNIT IN HEIGHT

24-Port Web-Smart Ethernet Switch

User’s Manual 7

Front Panel Display

The LED indicators on the front panel provide you with instant

feedback on each port status, and help you monitor and

troubleshoot the switch.

Figure 2: Front Panel LEDs

Power

This LED comes on when the switch is properly connected to power and

turned on.

Push Button

The push button is located at the right side of port 24 on the 24-Port Switch.

Depress this button to use twisted pair port 24, and press this button to use

the 100Base-FX module.

IP RESET Push Button

Press the Front panel IP RESET push button around five seconds to reset

the Ethernet Switch back with the default IP Address.

Port Status

The RJ-45 ports are numbered from 1 to 24 on the 24-Port Switch.

The LEDs are located on the ports of the switch, displaying status for each

respective port. Please refer to the table below for more information.

Consult the following table for details.

LBefore you use this table for troubleshooting, make sure the switch is

properly connected to power and turned on.

24-Port Web-Smart Ethernet Switch

User’s Manual

Physical Ports

The 24-Port Switch has twenty-four 10/100Mbps ports using RJ-45

connectors and provides one slot for the optional single-port fiber

module. The optional module allows fiber type (multi-mode or

single-mode fiber) and connector (SC, ST, MT-RJ, VF-45, or LC)

at user’s discretion.

UNDERSTANDING FRONT PANEL DESIGN

On Power feeding in

Power switched off

Power LED

Off

Improper connection

On A valid network connection

LNK stands for LINK

LNK

Off No connection

Flashing Transmitting or receiving data

ACT stands for ACTIVITY

Console

Port LED

ACT

Off Neither transmitting nor receiving

data

On A valid network connection

LNK stands for LINK

Flashing Transmitting or receiving data

ACT stands for ACTIVITY

LNK/ACT

Off Neither connection nor activity

On A valid 100Mbps connection

Port LED

SPEED

Off A valid 10Mbps connection

On A valid network connection

LNK stands for LINK

LNK

Off No connection

Flashing Transmitting or receiving data

ACT stands for ACTIVITY

100FX Port

LED

ACT

Off Neither transmitting nor receiving

data

24-Port Web-Smart Ethernet Switch

User’s Manual 9

Installation

Selecting a Site for the Equipment

As with any electric device, you should place the equipment where

it will not be subjected to extreme temperatures, humidity, or

electromagnetic interference. Specifically, the site you select

should meet the following requirements:

- The ambient temperature should be between 0 to 45 degrees

Celsius.

- The relative humidity should be less than 95 percent,

non-condensing.

- Surrounding electrical devices should not exceed the

electromagnetic field (RFC) standards for IEC 801-3, Level 2

(3V/M) field strength.

- Make sure that the equipment receives adequate ventilation.

Do not block the ventilation holes on each side of the switch or

on the rear of the equipment.

-The power outlet should be within 6 feet (1.8 meters) of the

switch.

24-Port Web-Smart Ethernet Switch

User’s Manual

Installation and Placement Instructions

MOUNTED TO 19-INCH STANDARD RACK

Locate the accessories supplied in the product package. Use the

rackmount brackets and screws to install the switch into any EIA

19” standard rack.

Step 1: Attach the brackets to each side of the chassis.

Step 2: Apply the screws to each side and secure them tightly.

Step 3: Carefully position the switch into the rack.

Step 4: Align the brackets to the side holes on the rack and use rack

screws to secure the chassis with the rack.

Step 5: Proceed to the “Connecting to Power” section.

DESKTOP OR ANY FLAT SURFACE

The switch can sit on desktop or any flat surface with adequate

space and ventilation. If you want to place it onto a shelf, make

sure the shelf can withstand the weight of the switch.

Step 1: Simply put the switch on the desired place.

Step 2: Ensure the switch receives good ventilation.

Step 3: Proceed to the “Connecting to Power” section.
