18G HDMI Repeater w/ Audio Extraction.
1
Statement
Read this user manual carefully before using this product. Pictures shown in this manual are for
reference only, different model and specifications are subject to real product. This manual is for operation
instruction only, not for any maintenance usage. The functions described in this version are updated till
December, 2018. In the constant effort to improve our product, we reserve the right to make functions or
parameters changes without notice or obligation. Please refer to the dealers for the latest details.
Safety Precaution
To insure the best from the product, please read all instructions carefully before using the device. Save
this manual for further reference.
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
Do not dismantle the housing or modify the module to avoid electrical shock or burn.
Using supplies or parts not meeting the products’ specifications may cause damage, deterioration or
malfunction.
Do not expose the unit to rain, moisture or install this product near water.
Install the device in a place with fine ventilation.
Do not twist or pull by force ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before
cleaning.
Unplug the power cord when left unused for a long period of time.
Refer all servicing to qualified service personnel.
Customer Service
We provide limited warranty for the product within three years counting from the first day you buy this
product (The purchase invoice shall prevail).
Introduction
The CE-CVAD is a small-size HDMI2.0 audio de-embedder with 1 HDMI input, 1 HDMI output, and three
kinds of audio outputs. It is designed to extract audio from 4K HDMI signal via stereo balanced L/R
audio, analog RCA, and coaxial digital audio output ports.
It supports 4K@60Hz/4:4:4 HDR, EDID & CEC pass-through, and the transmission rate is up to 18Gbps.
Moreover, there are three audio modes can be chosen in order to be compatible with various audio
processing device.
