EverFocus EP4CQ Bedienungsanleitung
EverPlex 4CQ
USER'S MANUAL
Set
Seq
NEXT P. DEFAULT
+
Freeze
EverPlex 4CQ
Real Time Color Quad Processor
High Resolution, Broadcast Quality
Playback Zoom Function
RS232 Remote Control
Connect Up To 4 Cameras
Ver. 1.0
Table of Content
Notice.........................................................................................................................1
Important Messages..................................................................................................2
Introduction...............................................................................................................3
Specification..............................................................................................................4
Chapter I Functional Description....................................................................5
1. Front Panel Keypads..........................................................................................5
1.1 Full Screen ....................................................................................................5
1.2 Quad Display ................................................................................................5
1.3 Freeze ........................................................................................................5
1.4 Sequential Switching.....................................................................................5
1.5 VCR Play Back.............................................................................................5
1.6 Set ........................................................................................................6
1.6.1 Date, Time Setting, and OSD display on/off setting...............................7
1.6.2 Alarm Records ........................................................................................7
1.6.3 Set the Brightness, Contrast, Color, Tint for each channel.....................8
1.6.4 Set the camera titles................................................................................8
1.6.5 Set sequential switching parameters.......................................................8
1.6.6 Set alarm parameters...............................................................................9
Chapter II Back Panel Connection ...............................................................10
1. BNC Connectors..............................................................................................10
1.1 Monitor .......................................................................................................10
1.2 VCR out ......................................................................................................10
1.3 VCR In ....................................................................................................10
1.4 Video input..................................................................................................10
2. Alarm Connectors (DB-15) .............................................................................10
2.1 Alarm out ....................................................................................................11
2.1.1 Normally open connection....................................................................11
2.1.2 Normally closed connection .................................................................11
2.2 Alarm in and alrm reset...............................................................................12
2.2.1 Alarm in................................................................................................12
2.2.2 Alarm reset............................................................................................13
3. RS232 Connector.............................................................................................13
3.1 The pin assignment of the 9 pin D-SUB connector.....................................14
3.2 Transmission setting....................................................................................14
3.3 Remote control protocol..............................................................................14
3.4 Alarm message sent via RS232...................................................................15
1
Notice
This manual is presented to the users of EverPlex 4CQ by EverFocus
Electronics Corp. With years of engineering researches, EverFocus has
spared no effort to provide the high quality products to the worldwide
users. For the policy of continual product improvement, EverFocus
reserves the right to make changes to the product specifications and
documentation without notice. All the components of the products,
including accessories, components, and outlook, are based on the
agreements if each deals to satisfy all kinds of users. Meanwhile,
please be advised that every step of operation must follow the
instruction of this manual to keep EverPlex 4CQ working under the best
condition. Please notice that EverFocus will not be charged any claims
or renewing cases resulted from inappropriate operation.
2
Important Messages:
1. To prevent fire or shock hazard, do not expose this equipment to the
environment of high humidity and dust. So, do not use it in an
unprotected outdoor installation or any area classified as a wet area.
2. Installation environment: The temperature should be kept between
-10oC ~ +50oC, humidity under 90%. For safety sake, do not
disseminate the unit or put it on an unstable base.
3. Ventilation: Openings in the enclosure are provided for ventilation
and to ensure reliable operation of the unit and to protect it from
overheating. These openings must not be blocked or covered. This
unit should not be placed in a built-in installation unless proper
ventilation is provided.
4. Cleanse: Unplug the unit from the outlet before cleansing. Do not
use liquid cleaners or aerosol cleaners. Use a damp cloth to clean
it.
5. Overload: Do not overload outlets and extension cords as this may
result in a fire or electric shock.
6. Power-cord Protection: Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
appliance.
7. Object and Liquid Entry: Never push objects of any kind into this
unit through openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. Never
spill liquid of any kind on the unit.
8. Service: Do not attempt to service this unit yourself as opening or
removing covers may expose you to dangerous voltage of other
hazards. Refer all servicing to qualified service personnel.
3
Introduction
EverPlex 4CQ, a real time color Quad and 4 channel auto switcher, is the best
choice for multiple monitoring and recording.
The superior video quality is achieved by adopting the advance multi-media
technology. The picture of Quad display is sharp and clear because Everplex
4CQ is featured with CCIR601 full resolution and 16 million colors.
Main Features:
Real-time Quad display.
High Resolution 720 x 576 (PAL), 720 x 480 (NTSC).
16 million colors.
Up to 4 camera inputs and quad display.
Video loss detection.
Different border colors indicate page selection.
Independent brightness, contrast, color and tint adjustments for every
channel.
Built-in timer and and title generator.
Alarm input with built-in buzzer.
Programmable Quad and 4 channel auto switcher outputs.
Playback Zoom and Freeze function.
RS232 Remote Control.
User-friendly front panel design.
4Specification
Video input: 4 cameras + 1 VCR inputs
Video output: Video output x 2, 1V p-p/75 ohm
Title: Up to 6 characters
Timer: Built-in real time clock
Alarm input: 4 alarm inputs and 1 alarm reset input
Alarm output: 2 Alarm Out (1 Normally Open, 1 Normally Closed)
Dimension: 239 x 166 x 55 mm
Power source: AC 24V or DC 12V
Power consumption: 17W max.
5
Chapter I Functional Description
Set
Seq
NEXT P. DEFAULT
+
Freeze
EverPlex 4CQ
1. Front Panel Keypads
1.1 Full Screen
Press any key of FULL SCREEN, the picture of the corresponding quadrant will
fill the whole screen of the monitor display. Press the same key again, the quad
display will come out.
1.2 Quad Display
Press the Quad Display, the picture of the quadrant video will fill the whole screen
of the monitor display.
1.3 Freeze
During quad display mode, you can press FREEZE key to freeze the video on the
monitor. Press this key again to de-freeze the video. If you press any Full Screen
Key, there will be merely that video input de-frozen. Judging by the channel title
blinking, users can be aware of freezing status.
1.4 Sequential Switching
Press SEQ key will enter the auto sequential switching mode, the switching
sequence is programmed in SET function. It can be displayed live quad and full
screen sequentially on the main monitor according to the programmed switching
sequence. Press the SEQ key again to exit the auto sequential mode and stay the
last screen display.
1.5 VCR Play Back
Press PLAY BACK key to play back the recorded video from VCR. There are two
special functions implemented in the play back mode.
A. ZOOM function
Pressing any FULL SCREEN key during playback will zoom in the picture of the
corresponding quadrant to the whole screen of the monitor display. Press the same
key again to stop the zoom function and go back to the normal playback video.
B FREEZE function
Press the FREEZE key during zoom mode to freeze the current frame. Pressing
this key again to de-freeze the video.
6
1.6 Set
Press the SET key to set time/date, title on/off, picture, camera titles, switching
sequence, switching time period, alarm sensor type, alarm hold time, and the
alarm/video loss records displaying.
There are 6 pages in the setting mode :
Page 1 : Set Time and Date.
Turn ON/OFF the time, date, title display for Quad or Full screen
display.
Page 2: Display the alarm records.
Page 3: Set the brightness, contrast, color, and tint for each camera.
Page 4: Change the title name of each camera.
Page 5: Program the sequential switching sequence and switching hold
time. Set the screen refresh mode.
Page 6: Set the alarm sensor type, alarm hold time, buzzer on/off and
Security.
The following keys are re-defined in setting mode (Definition under the keypad).
NEXT P.
Press “NEXT P.” to go to the following
pages for setting.
DEFAULT Press the “DEFAULT” to reset the setting.
Press the +/- keys to set the value.
+
Press the cursor key to select the item to set.
7
1.6.1 Date, Time setting, and OSD display on/off setting
DATE: 2000-01-01
TIME: 01:01:01
QUAD SCREEN DATE: ON
QUAD SCREEN TIME: ON
QUAD SCREEN TITLE: ON
FULL SCREEN DATE: ON
FULL SCREEN TIME: ON
FULL SCREEN TITLE: ON
VERSION N.NN
DATE data format is CCYY-MM-DD, where
CC : Century code from 19 to 20
YY : Year data from 00 to 99
MM : Month data from 01 to 12
DD : Day data from 01 to 31
TIME data format is HH-MM-SS, where
HH : Hour data from 00 to 23
MM : Minute data from 00 to 59
SS : Second data from 00 to 59
VERSION shows current firmware version
1.6.2 Alarm Records
ALARM RECORDS
C A DATE TIME
3 S 1997-03-24 10:00:00
The Alarm Record format is : (C A DATE TIME)
C : the channel number from 1 to 4 which invokes the alarm
A : Alarm type, 'S' - alarm from sensor input, 'V' - alarm from video loss detection
DATE, TIME : the date and time when the alarm happens
8
1.6.3 Set the Brightness, Contrast, Color, Tint for each channel
Video Display Set Up
BRIGHT: 32 BRIGHT: 32
CONTRAST:27 CONTRAST:27
COLOR: 31 COLOR: 31
TINT: 32 TINT: 32
BRIGHT: 32 BRIGHT: 32
CONTRAST:27 CONTRAST:27
COLOR: 31 COLOR: 31
TINT: 32 TINT: 32
1.6.4 Set the camera titles
Camera Title Setup
CH1: CH1
CH2: CH2
CH3: CH3
CH4: CH4
CH1 - CH4 to turn each channel ON or OFF in the sequential switching
QUAD to turn QUAD display ON or OFF in the sequential switching
SWITCH TIME : The time period to switch for each switching item
REFRESH MODE : To set the screen refresh by 'FRAME' or by 'FIELD'.
1.6.5 Set sequential switching parameters
Sequential Switch Menu
CH1: ON
CH2: ON
CH3: ON
CH4: ON
QUAD: ON
SWITCH TIME : 03 SEC
REFRESH MODE : FIELD
