EverFocus EDR810M Bedienungsanleitung

INSTRUCTION MANUAL

Digital Eight Channel Recorder

About this manual

Before installing and using this unit, please read this Manual carefully.

Be sure to keep it handy for later reference.

V 1.0

EDR810H/810M/

410H/410M

Date: Aug. 29th 2005

WARNING

TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Note:

This equipment has been tested and found to comply with the limits for a Class A digital device,

The changes or modifications not expressly approved by the party responsible for compliance

could void the user's authority to operate the equipment.

Notice:

The information in this manual was current when published. The manufacturer

reserves the right to revise and improve its products. All specifications are

therefore subject to change without notice.

Safety Warning

Note:

This is a class A product. In a domestic environment this product may cause radio interference

In which case the user may be required to take adequate measures.

Refer all work related to the installation of this product to qualified service

personnel or system installers.

Do not block the ventilation opening or slots on the cover.

Do not drop metallic parts through slots.This could permanently damage

the appliance. Turn the power off immediately and contact qualified service

personnel for service.

Do not attempt to disassemble the appliance.To prevent electric shock,

do not remove screws or covers. There are no user-serviceable parts

inside. Contact qualified service personnel for maintenance. Handle the

appliance with care. Do not strike or shake, as this may damage the

appliance.

Do not expose the appliance to water or moisture, nor try to operate it in

wet areas. Do take immediate action if the appliance becomes wet.

Turn the power off and refer servicing to qualified service personnel.

Moisture may damage the appliance and also cause electric shock.

Do not use strong or abrasive detergents when cleaning the appliance

body. Use a dry cloth to clean the appliance when it is dirty. When the

dirt is hard to remove, use a mild detergent and wipe gently.

Do not overload outlets and extension cords as this may result in a risk of

fire or electric shock.

Do not operate the appliance beyond its specified temperature, humidity

or power source ratings. Do not use the appliance in an extreme

environment where high temperature or high humidity exists. Use the

appliance at temperature within indoor type DVR for 0oC ~ +40oC and a

humidity below 90%.

The input power source for this appliance is AC100~240V.

Safety Precautions

The exclamation point within an equilateral triangle is

intended to alert the user to presence of important operating

and maintenance(servicing)instructions in the literature

accompanying the appliance.

Warning :

To prevent fire or shock hazard, do not expose units not

specifically designed for outdoor use to rain or moisture.

Safety Precautions

The lightning flash with an arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the presence

of uninsulated ” dangerous voltage” within the product’s enclosure

that may be of sufficient magnitude to constitute a risk of electric

shock to persons.

Attention:

Installation should be performed by qualified service personnel only

in accordance with the National Electrical Code or applicable local codes.

Power Disconnect:

Units with or without ON-OFF switches have power supplied to the unit

whenever the power code is inserted into the power source; however, the

unit is operational only when the ON-OFF switch is in the ON position.

The power cord is the main power disconnect for all units.

External Power Supplies

Use only the recommended power supplies.

Power supplies must comply with the requirement of

the latest version of IEC 60065/CNS 13439. Substitutions

may damage the unit or cause a fire or shock hazard.

AC100~240V Power Cords

AC100~240V power cords

Warning:

Electrostatic-sensitive device. Use proper

CMOS/MOSFET handing precautions to avoid

electrostatic discharge.

Safety Precautions

Do not place on uneven or unstable work surfaces.

Seek servicing if the casing.

Important Safeguards

Read Instruction---All the safety and operating instructions should be read before the unit is operated.

Retain Instructions---The safety and operating instructions should be retained for future reference.

Heed Warnings—All warnings on the unit and in the operating instructions should be adhered to.

Follow Instructions—All operating and use instructions should be followed.

Cleaning—Unplug the unit from the outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.

Use a damp cloth for cleaning

Attachments—Do not use attachment not recommended by the product manufacturer as they may cause hazards.

Water and Moisture—Do not use this unit near water-for example, near a bath tub, wash bowl, kitchen sink,

or laundry tub, in a wet basement, near a swimming pool, in an unprotected outdoor installation, or any area which is

classified as a wet location.

Servicing—Do not attempt to service this unit by yourself as opening or removing covers may expose you to dangerous

voltage or other hazards. Refer all servicing to qualified service personnel.

Power Cord Protection—Power supply cords should be routed so that they are not likely to be walked on or pinched by

items placed upon or against them, playing particular attention to cords and plugs, convenience receptacles, and the point

where they exit from the appliance.

Object and Liquid Entry—Never push objects of any kind into this unit through openings as they may touch dangerous

voltage points or short-out parts that could result in a fire or electric shock.Never spill liquid of any kind on the unit.

Important Safeguards

Table of Contents

1. PRODUCT

INTRODUCTION …………………………………………………………….…………

1.1 FEATURES …………………………………………………………………..…………..………….

1.2 SPECIFICATIONS…………………………………………………………………………….

………

1.3 FRONT PANEL

KEYPADS …………………………………………………………..…….………

1.4 BACK PANEL

CONNECTORS …………………………………………………………….………

1.5 MONITOR

DISPLAY ……………………………………………………………………….………

2. INSTALLATION …………………………………………………………………………….

…………

2.1 PACKING

LIST ………………………………………………………………………...…….………

2.2 SYSTEM

FLOORPLAN ………………………………………………………..…………….………

2.3 BASIC

CONNECTIONS ………………………………………..…………………….…….………

2.4 BOOT UP

EDR810 …………………………………………………………..……………….………

2.5 QUICK INSTALLATION GUIDE FOR EDR810M & EDR410M

ONLY……….…………………

3. MENU

SETUP…………………………………………………………………………………………

3.1 TIME/DATE SETUP

MENU …………………………………….……………………………….…

3.2 CAMERA SETUP MENU ……………………………………………………………………….….

3.3 RECORD SETUP

MENU ………………………………………..…………………………….……

3.4 ALARM SETUP

MENU ……………………………………………………………………….……

3.5 MOTION SETUP

MENU ………………………………………..……………………………………

3.6 VLOSS SETUP

MENU ………………………………………….…………………………….……

3.7 NETWORK SETUP

MENU ……………………………………..…………………………….……

3.8 SCHEDULE SETUP

MENU …………………………………………………………………………

Table of Contents

5. PLAYING BACK……………………………..……………………………………………..………...

5.1 NORMAL

PLAYBACK……………….………………………………………………………………

5.2 SEARCH

PLAYBACK …………………………………………………….…………………………

6. COPY TO A VIDEO

FILE ………………………………………………….…………………………

7. CALL ………………………………………………………………………..……….…………

………

8. SCREEN DISPLAY

SETTING …………………………..………………..…………………………

9. SCREEN DISPLAY

MODE ………………………………….…………….…………………………

10. REMOTE

VIEWER ……………………………………..………………..…………………………

APPENDIX A: RS232

specifications …………………………………………….……………………

APPENDIX B: RS485

specifications ……………………………………………….…………………

APPENDIX C: Alarm I/O

Assignment ………………………………………….…………….………

APPENDIX D:

Troubleshooting ……………………………………….……….…………….………

Duplex Operation for Recording & Playback

Built-in MPEG4 Codec with Configurable Quality

Variable Recording Speeds up to 60/50 Images per second for NTSC/PAL

Audio Recording Capabilities

Motion Detection Capabilities

One 3.5”Hard Disk with Hot-Swap Tray for Internal Storage

Ethernet Interface for Remote Network Viewing and Controlling

Optional Wireless LAN Interface for Data Transmission

RS232 and RS485 for Remote Control

Shuttle/Jog Dial for Picture-by-Picture or Fast/Slow Viewing

Easy-to-use Control Panel with Common VCR and Multiplexer Functions

On-Screen Menus Operations with Multi-Language Support

Real-Time Live Display for all Cameras

Archiving via USB or Compact Flash

1. PRODUCT INTRODUCTION

1.1 FEATURES

The Digital Video Recorder is the industry’s first full-featured digital video recorder

designed specifically for use in security industry. The Digital Video Recorder

incorporates all the benefits of digital video recording, is simple to install, and operates

just like a VCR. Highly efficient compression technology and superior resolution of

recorded images make the Digital Video Recorder stand out from the competition as the

best choice for security surveillance.

1.2 SPECIFICATIONS

Video Format NTSC/EIA or PAL/CCIR

Video Input 4/8 camera inputs (BNC), 1Vp-p/75ohm

1 BNC video out (1Vp-p/75ohm) for Main Monitor

1 BNC video out (1Vp-p/75ohm) for CALL Monitor

Video Output 4 video out (1Vp-p/75ohm) for Looping (4 Channels

only)

Video Compression MPEG4

Recording Resolution 720x240, 720x480 or 360x240 for NTSC

720x288, 720x576 or 360x288 for PAL

Video Display Full, PIP, 4, 7, 8/9 and 2x2 Zoom for Live Viewing

and Playback

Display Resolution 720x240, 720x480 or 360x240 for NTSC

720x288, 720x576 or 360x288 for PAL

Video Pause Yes

4/8 Alarm Inputs 4/8 Alarm Inputs

2 Alarm Outputs 2 Alarm Outputs

Hard Disk Storage One Hot-Swappable 3.5” IDE Hard Disk

Recording Rate Up to 60/50 Images per second for NTSC/PAL

Recording Mode Continue, Time-lapse, Schedule,

Event recording (Motion and Alarm)

Playback Rate Up to 60/50 Images per second for NTSC/PAL

Playback Search By Date/Time or Event (Motion, Video Loss, Alarm)

Motion Detection Yes, with MULTIPLE configurable detection areas &

sensitivity

Video Loss Detection Yes

Event Log Yes

User Interface User-friendly Menu Driven

Setup On screen display setup

User Input Device Front panel keypad with Shuttle/Jog, Keyboard

(optional)

Timer Built-in real time clock and Auto Time

Synchronization with global NTP server through

Internet

Watch Dog Timer Yes

Title 12-characters title generator for each camera

Ethernet RJ45 connectors for network communication

Archive Compact Flash Slot and USB for archiving

and Archive through Wireless transmission (Optional)

RS-232 9-pin female connector for local communication

RS-485 for Keyboard connection

Audio 2 mono (MIC) inputs, 2 mono (SPEAKER) outputs

Power Rate DC 12V/DC 24V

Dimension Half size: 320 mm (L) x 215mm (W) x 100mm (H)

Mobile : 320.8mm (L) x 215mm (W) x 109.9mm(H)

Weight 4.85 KG

Operating

Temperature 0oC ~ +50oC

Remote Controller IR Remote Controller

IR Remote Controller with Extension Wire(optional)

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere EverFocus Diktiergerät Handbücher

EverFocus

EverFocus EDSR-900 Bedienungsanleitung

Beliebte Diktiergerät Handbücher anderer Marken

Sony

Sony ICD-UX533F Bedienungsanleitung

RCA

RCA VR5230 Bedienungsanleitung

Ramsey Electronics

Ramsey Electronics BULLSHOOTER ENDLESS LOOP BS2C Benutzerhandbuch

Sony

Sony TCM-400DV Bedienungsanleitung

LogTag

LogTag TREL30-16 Bedienungsanleitung

SVAT

SVAT CVP800 Bedienungsanleitung

Marantz

Marantz PMD620 Bedienungsanleitung

Zoom

Zoom H4next Bedienungsanleitung

Roland

Roland BR-900CD Bedienungsanleitung

JVC

JVC ProHD GY-HMZ1U Bedienungs- und Wartungshandbuch

Panasonic

Panasonic PQT8531-P Bedienungsanleitung

Sanyo

Sanyo TRC-6400 Bedienungsanleitung

Tascam

Tascam DR-07 Bedienungsanleitung

Olympus

Olympus DW-90 Bedienungsanleitung

Sanyo

Sanyo ICR-B150 Bedienungsanleitung

Korg

Korg D4 Bedienungsanleitung

Sony

Sony ICD-SX46 - Ic Recorder Bedienungsanleitung

Olympus

Olympus DIGITAL VOICE RECORDER WS-200S Montageanleitung
