Troubleshooting
Symptom Cause of Failure Recommendation
Device not responding and
LED not displaying The device is not wired to
the mains power correctly Check if wiring is correct, or
voltage is too high or too low
LED displaying, but cannot
control On/Off status of
connected load
The connected load has its
own on/off switch Turn the switch of the connected
load to On.
Can press button to control,
but cannot control by RF Binding was not successful Repeat the steps in Binding with
HomeSys
Reset to Factory Settings
To reset the unit back to factory default state:
1. Make sure the LED on the unit is turned off. If it is on, press the Link key once to
turn it off.
2. Press and hold the Link key on the module for 3 seconds until the LED turns on
and then release. The LED will start to flash.
3. Press and hold the Link key again for more than 6 seconds until the LED turns
off, then release. The LED will flash every 2 seconds indicating the unit is now
reset back to factory default settings.
Auto Binding
Once reset back to factory settings and first powered up again, the unit will attempt
to automatically bind with any U-Net compatible gateway for 30 seconds. This is
called Auto-binding.
If binding is unsuccessful after 30 seconds, Auto-binding process will stop and the
LED indicator will flash slowly every 2 seconds, implying this unit has never paired
with any device.
Note: During Auto-binding, pressing the Control button will not turn on/off the
connected load.
Auto-binding can be restarted again by disconnecting and reconnecting power to
the unit.
Specifications
Frequency Range 868.3 MHz / 923.0 MHz
Power Input 220-240V/50Hz , 100-120V/60Hz
Maximum Power Load Resistive load Max.11A,
Incandescent load Max. 1200W,
Fluorescent load Max.320W
Working Temperature -10°C - 40°C
Specifications are subject to change without notice
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
FCC RF Radiation Exposure Statement:
1. This Transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator and your body.
WARNING:
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your health and well-being.
When replacing old appliances with new ones, the retailer is legally obligated to take back your old
appliance for disposal at least for free of charge.
