EVGA CLX Series Bedienungsanleitung
All-In-One CPU Liquid Cooler with LCD Display
COMPONENT LIST
ACLX 360mm / CLX 280mm / CLX 240mm x1
BLCD Cap with USB Cable x1
CIntel LGA 12XX / 115X Stando (M3 thread) x4
DIntel LGA 17XX Stando (M3 thread) x4
EAM5/AM4 Stando (UNC 6-32 thread) & Collar x4
FIntel Retention Bracket LGA x1
17XX / 12XX / 115X (Pre-installed)
GAMD Retention Bracket x1
AM5 / AM4
HIntel Backplate x1
LGA 17XX / 12XX / 115X
IScrew Nuts (M3 thread) x4
COMPONENT LIST
J30mm & 20mm UNC 6-32 Fan Screw
CLX360: 30mm x12, 20mm x12
CLX280: 30mm x8, 20mm x8
CLX240: 30mm x8, 20mm x8
K5mm UNC 6-32 Screw
CLX 360 : x12
CLX 280 : x8
CLX 240 : x8
NPWM Fan Splitter
CLX 360 : 1-to-3 x1
CLX 280 : 1-to-2 x1
CLX 240 : 1-to-2 x1
LFan Washer
CLX 360 : x12
CLX 280 : x8
CLX 240 : x8
COMPONENT LIST
MEVGA ARGB Fan & Sleeve
CLX360: 120mm x3, Sleeve x12
CLX280: 140mm x2, Sleeve x8
CLX240: 120mm x2, Sleeve x8
O16 Pin 1-to-4 Cable
PHex Key
SATA POWER
MB fan PWM
Fan PWM
Fan ARGB
Install EVGA CLX
Backplate Installation
Install the mounting backplate part on the back of the motherboard if you are using an Intel LGA 17XX,
12XX or 115X socket motherboard. Slide the standos to line up with the cooler mounting holes on your
motherboard.
*Please skip this step for AMD motherboards as you will use the existing motherboard’s backplate.
H
Standos
Next, screw the stando into the backplate. Fasten the standos to the backplate you installed in the
previous step for LGA 12XX / 115X motherboards part and LGA 17XX motherboards part .
For AMD platforms, remove the stock AMD mounting bracket, keep the original backplate. After aligning the
collars, screw in the stando to the collars and stock AMD Backplate .
*The collars have marked “AM5” and “AM4” on each side, facing up the correct side of collars according
your AMD platform.
C
E
D
Intel LGA 17XX Intel LGA 12XX
Intel LGA 115X
DE
C
AMD
Intel
Intel LGA 12XX / 115X Stando (M3 thread)
Intel LGA 17XX Stando (M3 thread)
AM5/AM4 Stando (UNC 6-32 thread) & Collar x4
C
D
E
A
M
5
A
M
5
A
M
5
A
M
4
A
M
5
A
M
5
Retention Ring
Make sure the correct retention ring is installed on the pump / cooler. Both Intel and AMD retention rings are
included with your CLX, with the Intel ring preinstalled.
To change the retention ring, push down on ring and turn counter-clockwise to remove the ring from the pump.
Intel Retention Bracket LGA 17XX / 12XX / 115X (Pre-installed)
AMD Retention Bracket AM5 / AM4
F
G
Pump Installation
Thermal paste is pre-applied to the contact surface of the pump. Install the pump by aligning the mounting
holes on the retention ring with the standos and lower the pump evenly over the CPU. Secure the
retention ring using screw nuts part .
I
GF
Fans and Radiator Installation
Install fans and radiator according to your system setup and airflow design. Use screws to attach the fan
to the radiator, use screws to attach the radiator to the case, and hex key to fasten the screws.
EVGA recommends that the pump should always be below the highest point of the radiator.
Install fans and radiator according to your system setup and airflow design. Use screws and fan washers
to attach the fan to the radiator, use screws to attach the radiator to the case, and hex key to
fasten the screws.
EVGA recommends that the pump should always be below the highest point of the radiator.
*Warning – The CLX Cooler is not a passive cooler. Fans must be installed to the radiator for proper operation
of the CLX Cooler, and failure to do so may cause irreparable damage to the pump and other connected
hardware.
*Warning – The CLX Cooler is not a passive cooler. Fans must be installed to the radiator for proper operation
of the CLX Cooler, and failure to do so may cause irreparable damage to the pump and other connected
hardware.
*Install to the top of the case
J
K P
J
LK P
*Install to the front of the case
30mm UNC 6-32
Fan Screw
Sleeve
20mm UNC 6-32
Fan Screw
3
2
1
1
2
3
2
1
3
Push the latch to remove the LCD Cap
*Warning – Removing the LCD Cap while your system
is running may cause irrepairable CLX damage.
Install LCD Cap
Align the hooked tab and 3 raised circles below LCD cap to the 3 indents on top of the pump, then gently
press down the LCD cap into the latch to secure it.
Install the USB cable to enable PWM-tuning via CLX software. Connect the cable from the LCD Panel to the
USB 2.0 front panel header on your motherboard.
MB Fan PWM
Fan PWM
Fan ARGB
Install The
LCD CAP
SATA POWER
PSU SATA
MB
MB
N
USB
CPU Fan
O16 Pin 1-to-4 Cable
Cable Connections
Important Information
EVGA CLX CPU Closed Loop Water Cooling Kit is an AIO (All-In-One) cooling system. With AIO Water Cooling
Systems, you do not need to add any coolant, and the system is completely self-contained. All EVGA CLX
CPU Closed Loop Water Cooling Kits are leak tested at the factory, and are ready to install when received.
Warranty for the EVGA CPU Closed Loop Water Cooling Kit
Your EVGA CLX CPU Closed Loop Water Cooling Kit comes with a 5 (five) Year Limited Warranty. Refer to
your motherboard’s warranty information before installing the EVGA CLX CPU Closed Loop Water Cooling
Kit. Should you damage your motherboard during the installation process, EVGA will not be held liable for
the physical damage of your EVGA CLX CPU Closed Loop Water Cooling Kit, case, motherboard or any
associated hardware when damage is caused by improper installation.
Full Control with EVGA CLX SoftwareEVGA ARGB Fan
ARGB Cables
FAN PWM Cables
16 Pin 1-to-4 Cable
MB fan PWM
FAN PWM
FAN ARGB
SATA Power
PWM Fan Splitter
M
N
O
Connect cable part to the CLC, then connect the SATA power cable to the SATA power cable from
your power supply.
Connect the MB Fan PWM to the 4pin CPU_FAN or AIO_PUMP header on your motherboard.
Connect cable part to the Fan PWM on cable part then connect the fans to each of the
connectors on cable part .
Connect each of the ARGB from the fans to each other and then connect the end to the Fan ARGB on
cable part .
O
O
O
N
N
•
•
•
•
The LCD display orientation can be rotated via “EVGA CLX” software.
Cable Connections
The CLX includes additional cables, part and required for RGB and fan control through the
CLX software.
NO
