EVGA Z97 FTW Bedienungsanleitung
- 1 -
User Guide
EVGA Z97 FTW
Specs and Initial Installation
(Part 1)
- 2 -
Table of Contents
Before you Begin……………………………………………………………………..…………3
Parts Not in the kit………………………………………………………………………….…..4
Intentions of the kit…………………………………………………………………..…………4
Motherboard Spe ifi ations ...................................................................................................................... 5-6
Unpa king and Parts Des riptions ............................................................................................................... 7
Equipment ....................................................................................................................................................... 7
Hardware Installation ..................................................................................................................................... 8
Component legend ...…………………………………………………….………..…..................8
PCI-E Slot Breakdown ...…………………………………………...................................................9
Rear I/O Panel legend ...…………………………………………..................................................10
Preparing the Motherboard .........................................................................................................................11
Installing the CPU ................................................................................................................................... 11-12
Installing the Cooling Devi e ......................................................................................................................12
Installing System Memory (DIMMs) .........................................................................................................13
Complian e Information ..............................................................................................................................14
- 3 -
Before You Begin…
Wel ome to a new lass of high performan e motherboards that boast 4
th
and 5
th
Generation Intel® Core™ Pro essor ompatibility. The Z97 platform takes you to a
new level of performan e and effi ien y. We have refined the GUI BIOS interfa e,
reimagined power VRM that fo uses on effi ien y, added M.2 support and loaded with
features like 2-Way-SLI, Intel Gigabit LAN, native SATA 6G/USB 3.0 and more. All
sitting on a 6 layer PCB to improve performan e and effi ien y.
Did we also mention that this motherboard is designed for the over lo ker? Built from
the ground up to give you all the essentials that you need for over lo king, with a GUI
BIOS that is fo used on fun tionality, ultra high quality omponents and robust PCI-E
3.0 and memory tra e layout.
With these features and more, it is lear that the EVGA Z97 motherboards are
engineered to ex eed the best.
- 4 -
Parts NOT in the Kit
This kit ontains all the hardware ne essary to install and onne t your new
EVGA Z97 FTW Motherboard. However, it does NOT ontain the following
items that must be pur hased separately in order to make the system fully
fun tional and install an Operating System:
Intel Socket 1150 Processor
DDR3 System Memory
CPU Cooling Device
PCI Express Gr phics C rd
Power Supply
H rd Drive or SSD
Keybo rd / Mouse
Monitor
(Option l) Optic l Drive
EVGA assumes you have pur hased all the ne essary parts needed to allow for
proper system fun tionality. For a full list of supported CPUs on this
motherboard, please visit www.evga. om/support/motherboard
Intentions of the Kit
This kit provides you with the motherboard and all onne ting ables ne essary
to install the motherboard into a PC ase.
When repla ing a motherboard in a PC ase, you will need to reinstall an
operating system even though the urrent storage drive may already have one
installed.
- 5 -
EVGA Z97
Motherboard
Motherboard Specifications
Size:
ATX form fa tor of 12 in hes x 9.6 in hes
Microprocessor support:
Intel So ket 1150 Pro essor
Oper ting Systems:
Supports Windows 8 / 7
Cont ins Intel Z97 chipset
System Memory support:
Supports Dual hannel DDR3 up to 2666MHz+.
Offi ially supports up to 32GB of DDR3 memory.
USB 2.0 Ports:
6x from Intel Z97 PCH – 4x external, 2x internal
Supports hot plug
Supports wake-up from S1 and S3 mode
Supports USB 2.0 proto ol up to a 480 Mbps transmission rate
USB 3.0 Ports:
6x from Intel Z97 PCH – 4x external, 2x internal
Supports transfer speeds up to 5Gbps
Ba kwards ompatible USB 2.0 and USB 1.1 support
SATA Ports:
Intel Z97 PCH Controller
6x SATA 3 Ports up to 6G (600 MB/s) data transfer rate
- Support for RAID 0, RAID 1, RAID 0+1, RAID 5, AND RAID 10
- 6 -
- Supports hot plug
2x SATA3/6G Marvell 88E9182
Onbo rd LAN:
1x Intel i217 Gigabit PHY
Supports 10/100/1000 Mb/se Ethernet
Onbo rd Audio:
Realtek Audio (ALC898)
Supports 8- hannel (7.1) audio
Supports Ja k-Sensing fun tion
Supports Opti al Output
PCI-E 3.0 Support:
Low power onsumption and power management features
Power Functions:
Supports ACPI (Advan ed Configuration and Power Interfa e)
Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4
(Suspend to disk - depends on OS), and S5 (soft - off)
Exp nsion Slots:
4x PCI-E 16x slot 1x16/8, 1x8/4, 1x4, 1x1
1x PCI-E 1x slot
1x M.2 slot
1x Displ y Port (Full size)
1x HDMI Port (Full Size)
- 7 -
Unpacking and
Parts Descriptions
Equipment
The following a essories are in luded with the EVGA Z97 FTW
Motherboard:
The EVGA Z97 FTW Motherboard
This PCI-E motherboard contains the Intel Z97 chipset.
I/O Shield
Installs in the system case to block radio frequency
transmissions protect internal components from dust foreign
objects and aids in proper airflow within the chassis.
4 x SATA 3G/6G Data ables
Used to support the SATA protocol and each one connects a
single drive to the motherboard.
I/O over
This optional cover attaches to the PCB and covers the I/O
area
Installation D
Contains drivers and software needed to setup the
motherboard.
User Manual
The user manual you are reading right now!
- 8 -
Intel Z97 FTW Motherboard
The EVGA Z97 FTW Motherboard with the Intel Z97 and PCH Chipset. Figure 1
shows the motherboard and Figure 2 shows the ba k panel onne tors
FIGURE 1. Z97 FTW Motherbo rd L yout
- 9 -
1. CPU Socket 1150 13. USB 2.0 Headers 25. M.2 Slot
2. Intel Z97 South ridge 14. USB 3.0 Headers 26. Front Panel Audio Connector
3. CPU Fan Headers (1 amp PWM) 15. CMOS Battery 27. EVGauge
4. DDR3 Memory DIMM Slots 1-4 16. CMOS Reset Button 28. Back Panel Connectors (Figure 2)
5. 24-pin ATX power connector 17. Power Button 29. 8 pin EPS Connector
6. Fan Headers (1 amp DC) 18. Reset Button 30. Supplemental PCI-E 6pin Power
7. PCI-E Disa le Dipswitches 19. PC Speaker 31. Pro e It Header
8. Intel Sata 6G/3G Ports 20. PCI-E Slot 16x/8x 32. BIOS Selector Switch
9. Marvell Sata 6G Ports 21. PCI-E Slot 8x/4x 33. Remova le BIOS Chip
10. S/PDIF Out 22. PCI-E Slot 4x (16x physical) 34. De ug Jumper
11. Front Panel Connectors 23. PCI-E Slot 1x (16x physical)
12. De ug LED / CPU Temp Monitor
24. PCI-E Slot 1x
PCI-E Lane Distribution
PE1 – x16 (x8 if PE2 is used)
PE2 – x8 (x4 if PE3 is used)
PE3 – x4
PE4 – x1
PE5 – x1 (x16 Physi al)
- 10 -
Figure 2. Ch ssis Re r P nel Connectors
1. USB 2.0 4. NIC Port (Intel i217) 7. Optical Out
2. USB 3.0 5. Display Port 8. Analog Audio Output Jacks
3. BIOS/CMOS Reset 6. HDMI
Analog Audio Port Breakdown
2/2.1
(Channel) (4.0/4.1 Channel)
5.1 (6 Channel) 7.1 (8 Channel)
Blue Line in Line In Line in Side channel
Green Line Out/
Speaker Out
Front Speaker/
Speaker+Su Out
Front Speaker/
Speaker+Su Out
Front Speaker/
Speaker+Su Out
Pink Mic In Mic In Mic In Mic In
Black
Rear Speaker Out Rear Speaker Out Rear Speaker Out
Orange
Center/Voice
channel
Center/Voice
channel
Only used in 7.1 and is changed via Realtek Software from within Windows.
