EVOC PDS--1902 Bedienungsanleitung
PDS1902
19″FlatLCDDisplay
Version:A0
Announcement
What containedinthis User Manualdoes not represent the commitments of EVOC
Company. EVOC Company reserves the right to revise this User Manual, without
priornotice,andwillnotbeheldliableforanydirect,indirect,intendedorunintended
lossesand/orhiddendangersduetoinstallationorimproperoperation.
EVOC is a registered trademark of EVOC Intelligent Technology Co., Ltd. All
trademarks, registered trademarks, and trade names used in this User Guide are the
propertyoftheirrespectiveowners.
EVOCIntelligentTechnologyCo.,Ltd.©2009,CopyrightReserved.Nopartofthis
manual can be reproduced in any form or by any means, such as in electronic or
mechanicalway,without permissioninwritingfromEVOC.
SafetyInstructions
1. Pleasecarefullyreadtheusers’manualbeforehandlingtheproduct;
2. Pleasedonotusethe displaywithpowersupplyexceedingthe specifiedrange;
impropervoltagemaycausefailureandeventhedangeroffireorelectricshock;
3. Pleasedonotusethedisplaywiththecoveropen;
4. Pleasedonotinsertanythingintothedisplay;
5. Pleasedonottouchtheplugwithdamphands;
6. Please do not installthe display where temperature might change suddenly, or
withgreathumidity,dustorsmog;
7. Pleaseensureexcellentheatdispersionandventilationforsystem;
8. Before connecting the display with the PC, please power off the PC and the
display;
9. Before moving the display, please make sure it ispowered off and the display
plugandthesignalcableareremoved.
Contents
Chapter1ProductIntroduction ................................................................................ 1
Overview ....................................................................................................... 1
MainPerformance .......................................................................................... 1
EMCCompliance........................................................................................... 1
Reliability ...................................................................................................... 1
Safety ............................................................................................................ 1
EnvironmentalandMechanicaladaptability .................................................... 2
RequirementsofTransportationandStorage.................................................... 2
Chapter2Installation .............................................................................................. 3
ProductOutline .............................................................................................. 3
ProductOutlineandDimension ...................................................................... 4
ExternalControllingInterfaces ....................................................................... 5
Chapter3Instructions.............................................................................................. 6
OSDAdjustment ............................................................................................ 6
InstructionsforFunctionControl .................................................................... 7
Specifications................................................................................................. 8
Chapter1ProductIntroduction
PDS1902 1
Chapter1ProductIntroduction
Overview
PDS1902 is a sort of 19″ flat LCD display, which adopts 19″ AU LCD screen and
possesses functions like screen luminance, contrast adjustment and menu function,
whilethetouchscreenfunctioncouldbeorderedaccordingtorequirement.Itswayof
installation is compatible with panel style, wallmounted style and VESA standard
supportingarm,etc.
PDS1902isa sortofindustriallevelflatdisplaywithhighperformancepriceratio,
which could be widely used in the fields like telecommunication, electric power,
multimedia, national defense, industrial automation devices and manufacturing as
monitoringdevices.
MainPerformance
EMCCompliance
l LimitsofradiodisturbanceiscompliantwithGB92541998,classA;
l ImmunitytodisturbanceiscompliantwiththelimitsofGB/T176181998.
Reliability
l MTBF≥50000h;
l MTTR≤0.5h.
Safety
MeettherequirementofGB4943.
Chapter 1 Product Introduction
2 PDS1902
EnvironmentalandMechanicaladaptability
l Antivibration:amplitude519Hz/1.0mm;acceleration19200Hz/1.0g;
l Antishock:acceleration10g,duration11ms.
RequirementsofTransportationandStorage
l Transportation
Wellpackaged products suit for transportation by truck, ship, and plane. During
transportation, products should not be put in open cabin or carriage. When
transshipping in route, products shouldnot be stored in the open without protection
from the atmospheric conditions. Products should not be transported together with
inflammable,explosiveandcorrosivesubstancesandarenotallowedtobeexposedto
rain,snowandliquidsubstancesandmechanicalforce.
l Storage
Products should be stored in package box when it is not used. And warehouse
temperature should be 0°C~40°C, and relative humidity is 20%~85%. In the
warehouse, there should not be harmful gas, inflammable, explosive products, and
corrosive chemical products, and strong mechanical vibration, shock and strong
magneticfieldaffection.The packageboxshouldbeovergroundatleast10cmheight,
and50cm awayfromwall,thermalsource,andvent.
Chapter2Installation
PDS1902 3
Chapter2Installation
ProductOutline
Chapter 2 Installation
4 PDS1902
ProductOutlineandDimension
Unit:mm
Chapter2Installation
PDS1902 5
ExternalControllingInterfaces
FrontView
1.Switch 2.PowerIndicator
3.Menu/Selection 4.Contrast
5.Luminance 6.AutoAdjust/Exit
RearView
1.RS232TouchScreenInterface
2.VGAInterface
3.PowerInterface
Chapter 3 Instructions
6 PDS1902
Chapter3Instructions
OSDAdjustment
1． PressOKtoactivateOSDwindow.
2．Press<or>tobrowsefunction.Ifyouwanttoadjusthighlightfunction,pressOK
toactivatethemenu.Ifsubmenusareincludedinthechosenfunction,press<or
>againmaybrowsethefunctionsofthesubmenu.
3． Press<or>tochangethesettingforthechosenfunction.
4． To exit or save, please choose off function. If you want to adjust any other
functions,pleaserepeatstep23.
