USERGUIDE



ModelDCP42

160WLaboratoryGradeConstantPower,

SwitchingModePowerSupply





DCP42‐en‐GB_V1.512/14

TableofContents

1.INTRODUCTIONANDFEATURES4

2.SAFETY5

3.POWERSUPPLYDESCRIPTION6

4.CONTROLMODES7

4.1NormalMode7

4.2PresetMode7

4.3SetMode7

4.3.1SettingtheΔV/Δtvalue7

4.3.2ActivatingtheRemoteControlMode8

4.3.3DeactivatingtheRemoteControlMode8

4.3.4FactoryDefaultReset8

5.OPERATION9

5.1PoweringtheSupply9

5.2SwitchingthePowerSupplyONandSelf‐TestInformation9

5.3UsingtheControlknobs9

5.4ConnectingthePowerSupplyandrunningaTest9

5.5KeypadLockoutfunction9

5.6ManualOutputON/OFF9

5.7Ammeter/WattmeterSelection9

6.SUPPLEMENTALFUNCTIONS10

DCP42‐en‐GB_V1.512/14

6.1ΔV/ΔtFunction10

6.1.2SettingtheDCgeneratorvoltagelevel10

6.1.2SettingtheΔt10

6.1.3GeneratingRamp‐UporRamp‐DownDCoutputcycles10

6.2FunctionA/B/CWaveformGenerator11

6.2.1SetFUNC(A/B/C):11

6.2.2GeneratingWaveForm11

6.3UpperVoltageandCurrentLimits12

6.4RemoteSensing12

6.4.1Connection12

6.4.2Disconnection12

6.5RemoteControlOperation13

6.5.1REMOTECONTROL–METHOD1:UsingtwoexternalDCvoltagesources13

6.5.2REMOTECONTROL–METHOD2:Usingtwo0to5KOhmvariableresistors13

6.5.3RemoteControlOutputON/OFF14

7.PCSOFTWAREPROGRAM14

8.AUTOMATICOUTPUTSTEPPROGRAMS14

8.1ExternalTimedProgramWindow15

8.2OutputON/OFFfunction15

8.3AutomaticTimedOutputOperation15

9.APPENDIX–ADDITIONALOPERATIONALEXAMPLES16

10.SPECIFICATIONS17

11.TROUBLESHOOTING19

DCP42‐en‐GB_V1.512/14

1. IntroductionandFeatures

ThankyouforselectingtheExtechDCP42SwitchingModePowerSupply.Thisnewlyre‐designed

laboratorygradepowersupplydiffersfromaconventionalpowersupplyinthatitcancalculate

andchangethevoltageandcurrentlimitpointsaccordingtotheavailablemaximumpower.

Thereforethemaximumlimitsofthevoltageandcurrentarechangeableaccordingtotherated

power.Aconventionalpowersupplyhasonlyasetmaximumvoltageandcurrentsuchthatallof

theoperatingV&Amustfallwithintheselimits.TheDCP42offerscostsavingandspacesaving

advantagesasoneconstant‐powerpowersupplycandotheworkofseveralconventionalpower

supplies.



TheDCP42ishighlyefficient,incorporatesupgradedSMPScircuitrywithsmallformfactor,benefits

fromanautomaticcross‐overforCCandCV,hasthree(3)Voltage/Currentpresets,andcanbe

remotecontrolled.TheDCP42isperfectforsolvingavarietyofloadingconditionsandapplications.

Featuresincludethefollowing:



Dualaction(Course/Fine)tuningprovidessmooth,accurate,andquicksettingof

Voltage/Current

Setting,changing,andverifyingthecurrentlimitlevelisconvenientandcanbe

performedwithoutoutputpolespiking

TheRemoteControlfeaturepermitsoutputON/OFFandVoltage/Currentadjustments

withouttheneedtotouchthefrontpanelofthepowersupply

TheUSBportoffersPCconnectivityforprogrammingandrunningramp/soakcycleswith

20programmablesetsofVoltage/Currentandvaryingtestdurations(upto999cycles)

TheDCrampandwaveformgeneratorcaneitherbepanelsetorsetbythesupplied

softwarewhichpreviewsthefinalwaveform.

ApplicationsandindustrieswheretheDCP42canbeemployedincludelaboratory,

telecommunications,productiontesting,fieldtesting,DCnetworkpowering,andmore

Three(3)userprogrammableVoltage/Currentsettingsofferquickrecalloffrequently

usedtestsettings.



Thisdeviceisshippedfullytestedandcalibratedand,withproperuse,willprovideyearsofreliable

service.Pleasevisitourwebsite(www.extech.com)tocheckforthelatestversionofthisUser

Guide,ProductUpdates,andCustomerSupport.



DCP42‐en‐GB_V1.512/14

2. Safety

Thismanualcontainsimportantsafetyandoperationinstructionsforcorrectuseofthepower

supply.Readthroughthemanualandpayspecialattentiontothemarkingsandlabelsofthisunit

andequipmenttobeconnected.

Payspecialattentiontothesetwotypesofnoticesusedinthismanual:

WARNING:Failuretoobservethiswarningmaycauseinjurytopersonsanddamagetopower

supplyorconnectedequipment.

CAUTION:Failuretoobservethiswarningmayresultindamagetoequipmentand

improperfunctioningofthepowersupply.

WARNING

Donotusethispowersupplynearwater

Donotoperateortouchthispowersupplywithwethands

Donotopenthecasingofthepowersupplywhenitisconnectedtoacmains

Referallservicingtoqualifiedservicepersonnelonly

BeforereplacingtheACfuse,determinethecauseandclearupthecausefirst

ReplacetheACfusewiththesametypeandratingastheoriginalfuse

ThemaximumoutputvoltageoftheDCP42exceeds60VDC,avoidtouchingthemetal

contactpartsattheoutputterminals

CAUTION

Useagrounded3pinACsource

Thisunitisintendedforindooruseonly

Donotoperateorplacethisunitinahumid,dustylocation

Donotoperatethisunitindirectsunlightornearanyheatsource

BeforepluggingintolocalACmains,checktheratinglabelatthebackoftheunit

Donotblockanyventilationopeningsoftheunit

Thisunitmustbeusedwithinthespecifiedrating;regularexcessivecontinuousloadingmay

causedamagetothepowersupply

Thegaugesizeoftheinputpowercablemustbeatleast0.75mm2andthetotallengthof

powercablemustnotexceed3m

InputFuseRecommended:T3AL250V(3ATime‐Lag)

ENVIRONMENTALCONDITIONSFOROPERATION

10‐80%R.H.(RelativeHumidity)

Altitudeupto2000m(6561ft.)

Installationcategory:CAT2

Pollutiondegree:2

Mainssupplyvoltagefluctuationupto±10%ofnormalvoltage



DCP42‐en‐GB_V1.512/14

3. PowerSupplyDescription



(1)LEDpanelmeterdisplaywithCC/CV/WIndictor

(2)RemoteControlIndicator(RemoteControl/USBmode)

(3)OutputVoltageControlKnob

(4)OutputCurrentControlKnob

(5)PowerON/OFFSwitch

(6)6buttonKeypad(withillumination):

‐PresetKeyd1,2&3

‐MenuKey(ShiftKey)

‐Lock/UnlockKey(A/WmeterKey)

‐OutputON/OFF(ΔV/ΔtKey)

(7)OutputSafetyJacks(Rated10A)

(8)USBRemoteControlport(Foraccesstocomputertoruncyclicaloperationwithprogrammable

voltage,current,periodtimeandcycle)

(9)RemoteSensingTerminal

Warning!Shortingtheremotesensingterminalorconnectingthesensingterminalwiththe

polarityreversedwilldamagethepowersupply

(10)RemoteControlTerminal

(11)ACInletsocket(withfuseholder)



DCP42‐en‐GB_V1.512/14

4. ControlModes

Therearefourcontrolmodesforthepowersupply:NORMAL,PRESET,SET,andREMOTECONTROL

modes.ThepowersupplyisfactorypresettoNormalModewithmaximumcurrentlevelCC.

4.1NormalMode

Thisisthefactorydefaultmode;thepowersupplyoutputVoltageandCurrentarecontrolledby

thedualactiongainknobs.

1. Pushtheknobstotogglethecoarseandfinetuning,noticethesubtlechangesin

brightnessoftherelatedLED.

2. Adjusttheknobstothedesiredvaluesusingcoarseandthenfinetuning.

3. Tocheckthepresetcurrentlevel,turntheCurrentKnoblightlyinanydirection.

4. Thedisplaywillresumeitsnormalbrightnessafterafewsecondstore‐affirmthe

adjustment.

4.2PresetMode

1. TherearethreepresetoutputsP1/P2/P3available.

2. PressthePresetbutton(1,2,or3)toenterthepresetmode(thebutton’slightwill

switchON).

3. Thepresetvaluesarefactorysetasshowninthetablebelowandareretainedevenafter

theunithasbeenpowereddown.

4. Theusercanchangetheseoutputsettingsusingthevoltageandcurrentknobs.



RecallNo.OutputVoltage OutputCurrent

P15VMaximum

P213.8VMaximum

P3 40VMaximum

4.3SetMode

EntertheSetModebypushingandholdingtheMENUbuttonfor3seconds.IntheSetModethe

usercanadjusttheΔV/Δtvalue,accesstheremoteControlmode,orperformaFactoryReset

recallfunction.Note:Ifnoselectionismadeafter10secondsthepowersupplydefaultstoits

priorsettings.



4.3.1SettingtheΔV/Δtvalue

a.PressandholdtheMENUbuttonfor3secondstoaccesstheSetMode.

b.TurntheVoltagecontrolknobuntilthepanelmeterdisplays“dudtSet”asshownbelowand

thenpresstheVoltagecontrolknobtoentertheΔV/Δtsettingmode.



c.AdjusttheVoltageandCurrentcontrolknobsasdesiredtosettheΔV/Δtvalue.Furtherdetails

areprovidedinthededicatedsectionforΔV/Δtmodelaterinthisguide.

d.Whenfinished,presstheVoltagecontrolknobtoconfirmandreturntoSetmenu

e.PresstheMenukeytoexittheSetmenu

f.TostarttheΔV/Δtfunction,presstheSHIFTbuttonandthenpresstheΔV/Δtbuttontorun,

g.TostoptheΔV/Δtfunction,presstheSHIFTbuttonandthenpresstheΔV/Δtbuttonagain.



DCP42‐en‐GB_V1.512/14

4.3.2ActivatingtheRemoteControlMode

a.PressandholdtheMENUbuttonfor3seconds.

b.TurntheVoltagecontrolknobuntilthepanelmeterdisplays“rCSet”asshownbelowand

thenpresstheVoltagecontrolknobtoconfirmentryintotheremotecontrolmode.



c.TurntheCurrentcontrolknobtoselectremoteYESorNO.

d.PresstheVoltagecontrolknobtoconfirmandtoreturntotheSetmenu.

e.PresstheMenubuttontoexittheSetmenu.

f.DetailsoftheremotecontrolmodearelocatedinthededicateRemoteControlsectionlaterin

thisguide.

Note:AfteractivatingtheRemoteControlMode,allfunctionkeyslocatedonthefrontpanelwill

belocked(theLock/UnlockbuttonlightswitchesON).



4.3.3DeactivatingtheRemoteControlMode

a. PresstheLock/Unlockbuttontounlockallofthefunctionkeys

b. Repeatstepsatocinthe‘ActivatingtheRemoteControlMode’sectionaboveandset

RemoteControltoNOandthenpressthevoltagecontrolknob.



4.3.4FactoryDefaultReset

a.PressandholdtheMENUbuttonfor3seconds.

b.TurntheVoltagecontrolknobuntilthepanelmeterdisplays“FACSSEt”asshownbelowand

thenpresstheVoltagecontrolknobtoconfirmentryintotheFactoryResetmode.



c.TurntheCurrentcontrolknobtoselectYesorNo.

d.PresstheVoltagecontrolknobtoconfirmandtoreturntotheSetmenu.

e.PresstheMenubuttontoexittheSetmenu.

f.ThePowerSupplywillrebootandreverttoitsFactoryDefaultsettings.



DCP42‐en‐GB_V1.512/14

5. Operation

Note:TheDCP42TotalOutputVoltageRangeis42VDCandtheTotalRatedCurrentis0to10ADC



5.1PoweringtheSupply

ChecktheratinglabelofthepowersupplyandensurethatitcomplieswiththeACmainsvoltage

thatistobeused.ConnectthepowersupplytotheACMainsusingtheprovidedpowercord.

5.2SwitchingthePowerSupplyONandSelf‐TestInformation

Thepowersupplywillperformaseriesofself‐testswhenitisswitchedON.TheLEDandother

indicatorsonthefrontpanelwillilluminateinsequence.Whenthecoolingfanisbeingchecked,

ahighspeedwindsoundcanbeheard.Aftertheself‐tests,theCV,VandALEDindicatorsarelit

andtheunitdisplaysvoltageand0.0current.TofindtheCCcurrentlevel,turnthecurrent

controlknoboneclickineitherdirection.Thecurrentdisplayreturnsto0.0afterafewseconds.

5.3UsingtheControlknobs

Therotaryencodercontrolknobshavefineandcoarsetuningwith‘clicking’movement.Push

theknobstotogglebetweencoarseandfinetuning,noticethesubtlechangesinbrightnessof

therelatedLED.Adjusttheknobstothedesiredvaluesbyusingcoarseandthenfinetuning.

Thedisplaywillresumeitsnormalbrightnessafterfewsecondstoconfirmanadjustment.

5.4ConnectingthePowerSupplyandrunningaTest

1. Connecttheequipmentundertesttothepowersupply.Red(+)isconnectedtothepositive

polarityinputoftheequipmentandBlack(‐)isconnectedtothenegativepolarityinputof

theequipment.

2. SwitchONthepowersupplyfirst;thepanelmeter&greenCVIndicatorshouldilluminate.

3. Next,switchONtheequipmentundertest;thepanelmeter&greenCVIndicatorshould

remainlitingreen.

4. Testingcannowbegin.

5. Whenfinished,switchOFFtheequipmentundertestfirstandthenswitchoffthepower

supply.

5.5KeypadLockoutfunction

1. PressLOCK/UNLOCKtolockorunlockallofthefunctionbuttonsandcontrolknobsonthe

frontpanel.

2. TheLOCK/UNLOCKbuttonlightswitchesONwhenthepush‐buttonsarelocked.

5.6ManualOutputON/OFF

1. PressOUTPUTON/OFFbuttontomanuallysettheoutputONorOFF.

2. TheOUTPUTON/OFFbuttonlightswitchesONwhentheoutputisON.

5.7Ammeter/WattmeterSelection

1. WiththeoutputONandallpresetsOFF,pressSHIFTandthenpressPRESET.

2. PresstheSHIFTbuttonagainandthenpresstheLOCK/UNLOCKbuttontochangefrom

AmmetermodetoWattmetermode.

3. TochangebacktoAmmetermodefromWattmetermode,presstheSHIFTbuttonandthen

presstheLOCK/UNLOCKbutton.

DCP42‐en‐GB_V1.512/14

6. SupplementalFunctions

6.1ΔV/ΔtFunction

Thereare3DCvoltagegeneratorsettings(A,B,andC).

Preset1=A

Preset2=B

Preset3=C

ΔVa‐b(fromvoltagelevelAtovoltagelevelB).

Δta‐b(timeinsecondsfromvoltagelevelAtolevelB,thistransittimeisadjustablefrom0to20

seconds)

6.1.2SettingtheDCgeneratorvoltagelevel

Thereare3generatorvoltagelevelspresets(A,B,andC).

PressthePresetbutton1,2and3andadjustthevoltagetothedesiredvalue.



6.1.2SettingtheΔt

Thereare6setsofΔtavailable,turningtheVoltagecontrolknobcyclesthroughthefollowing

sequence:AB→BA→AC→CA→BC→CB

UsingtheABsettingasanexample,turntheVoltagecontrolknobuntilA‐bappearsonthe

voltmeterdisplayandthenturntheCurrentcontrolknobtosettodesiredtransittimeΔt(5

secondsforexample).



6.1.3GeneratingRamp‐UporRamp‐DownDCoutputcycles

Rampupgeneratorexample:SetA=5V;B=10V;Δta‐b=5seconds

1. ConnectasuitableloadtotheoutputandturnONtheoutputbypressingthe“OUTPUT

ON/OFF”button;notetheoutputLEDindicator.

2. Push“Preset1”andnotetheoutputvoltageof5V.Press“Preset2”andnotethatthe

outputvoltagerisesto10Vin5secondsshowingarampupvoltage(theoutputwill

remainat10V).

3. Pressing“Preset1”willnowgeneratearampdownvoltagefrom10Vto5Vin5seconds

andwillremainatthe5Vlevel.



Note:Thefinaloutputvoltagelevelwillbethelastvoltagelevelgenerated.



Inhaltsverzeichnis

Andere Extech Instruments Stromversorgung Handbücher

Extech Instruments

Extech Instruments 382260 Bedienungsanleitung

Extech Instruments

Extech Instruments 382200 Bedienungsanleitung

Extech Instruments

Extech Instruments DCP60 Bedienungsanleitung

Extech Instruments

Extech Instruments DCP36 Bedienungsanleitung

Extech Instruments

Extech Instruments 382290 Bedienungsanleitung

Extech Instruments

Extech Instruments 382203 Bedienungsanleitung

Extech Instruments

Extech Instruments 382270 Bedienungsanleitung

Extech Instruments

Extech Instruments 382203 Bedienungsanleitung

Extech Instruments

Extech Instruments DCP60 Bedienungsanleitung

Extech Instruments

Extech Instruments DCP42 Bedienungsanleitung

Extech Instruments

Extech Instruments 382260 Bedienungsanleitung

Extech Instruments

Extech Instruments 382275 Bedienungsanleitung

Extech Instruments

Extech Instruments DCP60 Bedienungsanleitung

Extech Instruments

Extech Instruments 382280 Bedienungsanleitung

Extech Instruments

Extech Instruments 382280 Bedienungsanleitung

Extech Instruments

Extech Instruments 382200 Bedienungsanleitung

Extech Instruments

Extech Instruments 382270 Bedienungsanleitung

Extech Instruments

Extech Instruments 382203 Bedienungsanleitung

Extech Instruments

Extech Instruments 382275 Bedienungsanleitung

Extech Instruments

Extech Instruments 382222 Bedienungsanleitung

Beliebte Stromversorgung Handbücher anderer Marken

Monacor

Monacor PS-12CCD Bedienungsanleitung

VOLTIMA

VOLTIMA MagicBox 15 Bedienungsanleitung

Agilent Technologies

Agilent Technologies 6032A Bedienungsanleitung

Miller

Miller Auto Deltaweld 452 Bedienungsanleitung

BCP

BCP PUOUBK Merkblatt

HC 2210 Bedienungsanleitung

Puls

Puls CT5.241 Bedienungsanleitung

OCZ

OCZ ZX1250W Bedienungsanleitung

iseg

iseg ECH 238 Bedienungsanleitung

Power

Power XXL A Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies 6631B Bedienungsanleitung

Renogy

Renogy PHOENIX 300 Bedienungsanleitung

HP 6200B Service-Handbuch

Epson

Epson Stylus Scan 2500 Betriebsanleitung

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Bedienungsanleitung

Puls

Puls MiniLine ML50.100 Bedienungsanleitung

Puls

Puls AS-Interface SLA4.100 Bedienungsanleitung

Kenwood

Kenwood PS-60 Bedienungsanleitung
