Extron electronics DVI-RGB 150 Bedienungsanleitung

Specifications — DVI-RGB 150 DVI Interface

Video

The DVI-RGB 150 converts a single link DVI signal to an analog RGB signal.

Using an adaptor (the Extron HDMI to DVI-D adapter, part #26-616-01), the DVI-RGB 150 can accept

HDMI signals. It converts HDMI digital RGB signals, but does not support the HDMI digital

component (YCrCb) signal format.

Video input and loop-through

Number/signal type ................... 1 single link DVI-D digital video input

1 single link DVI-D buffered loop-through

Connectors .................................... 1 DVI-D female (DVI input)

1 DVI-D female (DVI loop through)

TMDS nominal level ................... 0.4 V to 0.6 V swing

TMDS impedance ........................ 100 ohms

DC offset (max. allowable) ......... ±0.5 V

Video output

Number/signal type ................... 1 RGBHV, RGBS, RGsB

Connectors .................................... 6 BNC female

Nominal level ............................... 0.7 Vp-p for RGB

Level adjustment range .............. -3 dB to 6 dB (x0.7 to x2)

Peaking adjustment range.......... 0 dB to 6 dB (x1 to x2) at 100 MHz

Impedance .................................... 75 ohms

Output resolution ........................ Follows input, determined by the local DVI loop-through monitor or by the

selector on this product.

Resolution selector resolutions and rates

Setting Resolution Refresh Low Refresh High

0 640x480 60 Hz 75 Hz

1 800x600 60 Hz 75 Hz

2 852x480 60 Hz 75 Hz

3 1024x768 60 Hz 75 Hz

4 1024x852 60 Hz 75 Hz

5 1280x768 60 Hz 75 Hz

6 1280x1024 60 Hz 75 Hz

7 1365x768 60 Hz 75 Hz

8 1366x768 60 Hz 75 Hz

9 1400x1050 60 Hz 60 Hz

A 1600x1200 60 Hz 60 Hz

B 480p 60 Hz 60 Hz

C 576p 50 Hz 50 Hz

D 720p 50 Hz 60 Hz

E 1080i 50 Hz 60 Hz

F 1080p 50 Hz 60 Hz

Return loss .................................... -35 dB @ 5 MHz

DC offset ....................................... ±10 mV maximum with input at 0 offset

Output cable driving distance ... 150' (45 m) at 1600 x 1200 with Extron MHR cable

250' (60 m) at 1024 x 768 with Extron MHR cable

Sync

Output type .................................. RGBHV, RGBS, RGsB

Output level.................................. TTL (5 Vp-p, unterminated)

Output impedance ...................... 75 ohms

Polarity .......................................... Positive or negative (follows input)

1-2 DVI-RGB 150 DVI Interface • Specifications

General

Power............................................. 100 VAC to 240 VAC, 50/60 Hz, 25 watts, internal, autoswitchable.

Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Rack mount ................................... Yes, with an optional 1U rack shelf, part #60-190-01 or 60-604-01; or a 1U, 6" deep

rack shelf, part #60-190-10 or 60-604-10.

Also furniture mountable with an optional MBU 125 under-desk mounting kit,

#70-077-01; or MBD 129 through-desk mounting kit, #70-077-02.

Enclosure type .............................. Metal

Enclosure dimensions ................. 1.7" H x 8.7" W x 6.0" D (1U high, half rack wide)

4.3 cm H x 22.1 cm W x 15.2 cm D

(Depth excludes connectors and knobs.)

Product weight ............................. 1.6 lbs (0.7 kg)

Shipping weight ........................... 4 lbs (2 kg)

Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%.

Specifications are subject to change without notice.

(7.52-070606-D3)

DVI-RGB 150 DVI Interface • Specifications 1-3
