Extron electronics System 5cr Plus Bedienungsanleitung

1-2 System 5crcr

crcr

cr Plus • Specifications

Specifications — System 5crcr

crcr

cr Plus Switcher

Video

Gain ............................................... Unity

Bandwidth .................................... 250 MHz (-3dB)

Frequency response..................... < ± 0.1dB @ 30 MHz

Differential phase error .............. 0.01º, 0 to 10 MHz

Differential gain error ................. 0.01%%, 0 to 10 MHz

Crosstalk ....................................... -50dB @ 5 MHz

Video input

Number/signal type ................... 2 RGBHV/RGBS/RGsB computer video

1 RGBHV/RGBS/RGsB computer video or S-video or composite video

2 S-video or composite video

Connectors .................................... 1 15-pin HD female (RGB computer video)

2 x 5 BNC female (RGB computer video; RGB/S-video/composite video)

2 x 2 BNC female (S-video or composite video)

Minimum/maximum levels ...... Analog ....... 0.3Vto 2V p-p with no offset

Impedance .................................... 75 ohms

Horizontal frequency .................. 15 kHz to 150 kHz

Vertical frequency ....................... 30 Hz to 150 Hz

Return loss .................................... -45dB @ 5 MHz

Maximum DC offset .................... 1.5V

Video output

Number/signal type ................... 1 RGBHV/RGBS/RGsB, or

1 S-video, or

1 composite video

Connectors .................................... 1 x 5 BNC female (RGB computer video)

1 x 2 BNC female (S-video

1 x 1 BNC female (composite video)

Minimum/maximum levels ...... 0.3V to 2.0V p-p

Impedance .................................... 75 ohms

Return loss .................................... -38dB @ 5 MHz

DC offset ....................................... ±5mV maximumwith input at 0 offset

Switching type ............................. Triple-Action

Sync

Input type ..................................... RGBHV, RGBS, RGsB

Output type .................................. RGBHV, RGBS, RGsB

Standards ...................................... TTL (RGB), NTSC and PAL (S-video and composite video)

Input level ..................................... 0.5V to 5V p-p

Output level.................................. 0.5V to 5V p-p

Input impedance.......................... 75 ohms

Output impedance ...................... 75 ohms

Max input voltage ....................... 5V p-p

Max. propagation delay.............. 20 nS

Polarity .......................................... Positive or negative (follows input)

Audio

Gain ............................................... Unbalanced/balanced -78dB to +40dB

Frequency response..................... 20 Hz to 20 kHz, ±0.05dB

THD + Noise ................................ <0.1% @ 1 kHz at rated maximum output drive

S/N ................................................ >95dB, at rated maximum ourput drive

Crosstalk ....................................... <-80dB @ 1 kHz, fully loaded

Stereo channel separation .......... >90dB @ 1 kHz

CMRR ............................................ >75dB @ 20 Hz to 20 kHz

1-3System 5crcr

crcr

cr Plus • Specifications

Audio input

Number/signal type ................... 5 stereo, balanced/unbalanced

Connectors .................................... 1 3.5 mm mini stereo jack (PC 1)

4 3.5 mm captive screw connectors, 5 pole

Impedance .................................... >50 kohms unbalanced, 25 kohms balanced

Maximum level ............................ +20dBu, (balanced or unbalanced) at stated %THD+N

Input gain adjustment................. –10dB to +6.5dB, adjustable per input

Audio output — line out

Number/signal type ................... 1 stereo, balanced/unbalanced

Connectors .................................... 1 3.5 mm captive screw connector, 5 pole

Impedance .................................... 50 ohms unbalanced, 100 ohms balanced

Maximum level (Hi-Z) ................ >+21dBu, balanced or unbalanced at stated %THD+N

Maximum level (600 ohm) ......... >+15dBm, balanced or unbalanced at stated %THD+N

Audio output — power amp

Number/signal type ................... 1 stereo, unbalanced

Connectors .................................... 2 spring-loaded captive terminals, L/R, +/-

Protection ...................................... Thermal, short circuit, open circuit, overload

Maximum level (full power out) .. At less than 0.5% THD from 20-20kHz:

24 watts; 12 watts per channel @ 4 ohm load

12 watts; 6 watts per channel @ 8 ohm load

0dBu = 0.775 volts (RMS).

Control/remote — switcher

Serial control port ........................ RS-232, 9-pin female D connector

Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity

Serial control pin configurations 2 = TX, 3 = RX, 5 = GND

Extron remote key pad control .. 2 5 mm, 5-pole captive screw connectors (Aux ports)

IR controller module ................... 30 kHz to 60 kHz input frequency compatibility

Program control ........................... Extron’s control program for Windows

Extron’s Simple Instruction Set™ – SIS™

Control — room relay

Number/type ............................... 1 momentary or latching

Connectors .................................... 1 3.5 mm captive screw connector, 5 pole

Contact rating ............................... 24V, 1 A

Control — projector

Projector control port (IR) .......... 1 3.5 mm captive screw connector, 5 pole

General

Power............................................. 100VAC to 240VAC, 50/60 Hz, 70 watts, internal, auto-switchable

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing

Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing

Rack mount................................... Yes, with included brackets

Enclosure type .............................. Metal

Enclosure dimensions ................. 1.75" H x 17.5" W x 9.4" D (1U high, full rack width)

4.4 cm H x 44.4 cm W x 23.9 cm D

(Depth excludes connectors.)

Product weight ............................. 6.1 lbs (2.7 kg)

Shipping weight ........................... 11 lbs (5.0 kg)

1-4 System 5crcr

crcr

cr Plus • Specifications

Specifications — System 5cr Plus (continued)

Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Certifications ................................ CE

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

Specifications are subject to change without notice.

(7.32-111501-D1)
