Fabyka FA Series Montageanleitung
Installation Guide
and Users Manual
Wall Mount Range Hood
FA Series
IMPORTANT:
Read and save these instructions.
NOTICE:
Installer: Leave this guide with the homeowner
Homeowner: Keep this guide for future reference
Important Safety Notice
Read all Instructions before Installing and operating this appliance
Installation
The installation in this manual is intended for qualied installers, service technicians or persons with
similar qualied background. DO NOT attempt to install this appliance yourself. Injury could result
from installing the unit due to lack of appropriate electrical and technical background.
All electrical wiring must be properly installed, insulated and grounded. Old duct work should be
cleaned or replaced if necessary to avoid the possibility of a grease re. Check all joints on duct work
to insure proper connection and all joints should be properly taped.
Operations
Read all instructions in this manual before operating the appliance. Save these instructions for fu-
ture reference.
Always leave safety grills and lters in place. Without these components, operating blowers could
catch on to hair, ngers and loose clothing.
NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into blowers.
NEVER leave cooking unattended. When frying or barbecuing, oil in the pan can easily overheat
and catch re. The risk of self combustion is higher when the oil has been used several times.
NEVER cook on “open” ames under the range hood. Check deep-fryers during use: superheated
oil may be ammable.
Cleaning
The saturation of greasy residue in the blower and lters may cause increased inammability. Keep unit
clean and free of grease and residue build-up at all times to prevent possible res.
Filters must be cleaned periodically and free from accumulation of cooking residue (see cleaning in-
structions inside). Old and worn lters must be replaced immediately. Do not operate blowers when l-
ters are removed. Never disassemble parts to clean without proper instructions. Disassembly is recom-
mended to be performed by qualied personnel only. Call our service center for removal instructions.
FABYKA and it’s Authorized Dealer declines all responsibility in the event of failure to observe the
instructions given here for installation, maintenance and suitable use of the product.
FABYKA and it’s Authorized Dealer further declines all responsibility for injury due to negligence
and the warranty of the unit automatically expires due to improper maintenance.
•
•
•
•
•
Page 1
Page 2
Before you start...
Your safety and the safety of others is very important. We have provided many important safety messages in this
manual and on your appliance. Always read and obey all safety messages. All safety messages will tell you what
the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instruc-
tions are not followed.
This is the safety alert symbol. This symbol alerts you to potential hazards that can hurt you and others. All
safety messages will follow the safety alert symbol and the word “WARNING”.
WARNING
WARNING — TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OB-
SERVE THE FOLLOWING:
Installation work and electrical wiring must be done by qualied person(s) in accordance with all applicable
Codes and Standards, including Fire Rated Construction. The combustion air ow needed for safe operation of
fuel-burning equipment may be affected by this unit’s operation. Follow the heating equipment manufacturer’s
guideline and safety standards such as those published by the National Fire Protection Association (NFPA), and
the American Society of Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code
authorities in your country.
When cutting or drilling into the wall or ceiling, do not damage electrical wiring and other hidden utilities.
Ducted fans must always be vented to the outdoors.
WARNING — To reduce the risk of re, use only metal or aluminium exible ductwork provided and this unit
MUST be grounded.
Table of Contents
INSTALLATION
Tools needed....................................................3
Parts supplied...................................................4
Venting requirements.......................................5
Mount heights & clearance...........................5-6
Calculating vent system length.......................6
Venting methods..............................................7
Electrical requirements....................................8
Preparation......................................................9
Installation................................................10-11
Installation overview.....................................11
USE AND CARE
Range hood operations.............................12-13
Troubleshooting...........................................14
Use and care information...............................15
Specications..............................................15
MAINTENANCE
Cleaning...............................................16
Replacing the lter & light bulb.....................16
WARRANTY
Coverage & exceptions.................................17
Service Note..................................................18
Tools needed:
Page 3
Level
Flat-blade and
Philips screw-
drivers
Powered
screwdriver
or drill
Measuring
tape
Utility knife
Marker or
pencil
Adjustable Wrench
Page 4
Screw Set
Grease cup
Range Hood (vary with model)
Optional Duct Tube
For sheet rock only
Parts supplied:
Lower standard chimney
Upper standard chimney
Mounting Bracket
Max*: 118” (3 m)
Venting Requirements
Page 5
Height & Clearance
Maximum* ceiling clearance
118” (3 m) at 33” (84 cm) hood
mounting height (may vary
with different model). Chimney
extensions available for higher
ceiling.
* Higher ceiling requires chim-
ney extension. Available at
FABYKA
Min:
28” (71 cm)
Max: 33” (84 cm)
Vent system must terminate to the out-
side (roof or side wall).
Do not terminate the vent system in an
attic or other enclosed area.
Do not use 4” (10.2 cm) laundry-type
wall caps.
Use metal/aluminum vent only. Rigid
metal/aluminum vent is recommended.
Do not use plastic vent.
For the most efcient and quiet
operation:
It is recommended that the range hood
be vented vertically through the roof
through 8” (20 cm) round metal/ alumi-
num vent work.
The size of the vent should be uniform.
Use no more than three 90° elbows.
Make sure there is a minimum of 24”
(61 cm) of straight vent between the
elbows if more than one elbow is used.
Do Not install two elbows together.
The length of vent system and number
of elbows should be kept to a minimum
to provide efcient performance.
The vent system must have a damper
on the roof or wall cap.
Use duct tape to seal all joints in the
vent system.
Use caulking or silicon to seal exterior
wall or roof opening around the cap.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Mounting
Bracket
Standard
Upper
Chimney
Extension available*
Standard
Lower
Chimney
Extension available*
Range hood
Base: 36” (90 cm)
Page 6
IMPORTANT:
A minimum of 8” (20 cm) round (standard for this range hood) must be used to maintain maximum airow
efciency.
Always use rigid type metal/aluminum ducts if available to maximize airow when connecting to provided
duct.
Please use Duct Run Calculation below to compute total available duct run when using elbows, transitions
and caps.
ALWAYS, when possible, reduce the number or transitions and turns. If long duct run is required, increase
duct size from 8” (20 cm) to 10” (25.4 cm). If a reducer is used, install a long reducer instead of a pancake
reducer. Reducing duct size will restrict airow and decrease airow, thus reduce duct size as far away from
opening as possible.
If turns or transitions are required: Install as far away from opening and as far apart, between 2, as possible.
Minimum mount height between range top to hood bottom should be no less than 28”.
Maximum mount height should be no higher than 33”
It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat
damage and re hazard; while hoods mounted too high will be hard to reach and will loose its performance
and efciency.
If available, also refer to manufacturer’s height clearance requirements and recommended hood mounting
height above range.
Minimum Duct Size:
Round- 8” (20 cm) minimum
•
•
•
•
•
•
•
•
•
•
Duct Run Calculation:
Recommended maximum run
8” (20 cm) 65 ft
Vent piece deduction
Each 90º elbow used 12 ft
Each 45º elbow used 6 ft
Side wall cap with damper 0 ft
Roof cap 0 ft
Duct Run Calcuation example:
One roof cap, two 90º elbow, and one 45º elbow used:
0 ft + 12 ft + 12 ft + 6 ft = 30 ft used.
Deduct 30 ft from 65 ft, 35 ft maximum available for
straight duct run.
Calculating vent system length
To calculate the length of the system you need, deduct the equivalent feet for each vent piece used in the system
from the recommended maximum duct run.
Venting Methods
Page 7
This range hood is factory set for venting through the roof or wall.
Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed.
IMPORTANT:
NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or
garages. All exhaust must be ducted to the outside.
Use metal/aluminum duct work only.
Fasten all connections with sheet metal screws and tape all joints with certied Silver Tape or Duct Tape.
Use caulking or silicon to seal exterior wall or roof opening around the cap.
•
•
•
•
•
•
Option 2:
Vertical roof venting
Horizontal wall venting
Option 1:
Side wall cap
Roof cap
Page 8
Electrical Requirements
IMPORTANT: For Europe and Other Countries with 220~240V/50Hz, please observe your local governing
codes and ordinances.
It is the customer’s responsibility:
To contact a qualied electrical installer.
To assure that the electrical installation is adequate and in conformance with National Electrical Code,
ANSI/NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code, Part 1 and C22.
2 No. 0-M91 - latest edition** and all local codes and ordinances.
If codes permit and a separate ground wire is used, it is recommended that a qualied electrician determine that
the ground path is adequate.
A 110~120V/60Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both
sides of the line.
Do not ground to a gas pipe.
Check with a qualied electrician if you are not sure that the range hood is properly grounded.
Do not have a fuse in the neutral or ground circuit.
IMPORTANT: Save Installation Instructions for electrical inspector’s use.
The range hood must be connected with copper wire/plug only.
The range hood should be connected directly to the fused disconnect (or circuit breaker) box through exible
armored or non-metallic sheathed copper cable. A U.L. - or C.S.A. - listed strain relief must be provided at each
end of the power supply cable.
Wire sizes (COPPER WIRE ONLY) and connections must conform with the rating of the appliance as specied
on the model/serial rating label. Wire sizes must conform to the requirements of the National Electrical Code
ANSI/NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code Part 1 and C22. 2 No.
0-M91 - latest edition** and all local codes and ordinances. A U.L. - or C.S.A. - listed conduit connector must
be provided at each end of the power supply cable (at the range hood and at the junction box).
Copies of the standards listed may be obtained from:
* National Fire Protection Association
Batterymarch Park
Quincy, Massachusetts 02269
** CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
•
•
Preparation
Page 9
Advanced Preparations:
Be familiar with the controls of the range hood by reading
through Range Hood Operations,Page 12.
Place the range hood on a at, stable surface. Connect the
range hood to a designated standard outlet, 110~120V/60Hz
(220~240V/50Hz for Europe & other countries), AC only
and turn on the range hood. Verify all operations of the
range hood by referring to Range Hood Operations, Page
12.
Place all supplied parts and required hardware on a at, stable surface and verify the existence of all sup-
plied parts listed on Page 4.
Carefully remove the white plastic protective coat from the chimney covers and range hood.
Preparations:
Determine and mark the center line on the ceiling where the range hood will be installed. Make sure there is
proper clearance within the ceiling or wall for exhaust vent.
Due to the weight and size of this unit, please make sure that the support system or framework being used is
stable and secure in the wall.
Put a thick, protective covering over counter top, cook top or range to protect from damage or dirt. Remove
any hazardous objects around the area when installing.
Mark the locations of the support mounting bracket holes, vent cutout (if used) and power supply cable cut-
out on the ceiling. Use drill and saber saw or keyhole saw to cut openings for power supply cable and vent
(see Venting requirements and Electrical requirements, Pages 5-8).
If venting to the outside install vent system (see Venting Requirements, Page 5). Use caulking to seal exte-
rior wall or roof openings.
Disconnect main electrical supply, prepare and run electrical wiring through ceiling or wall. Leave approxi-
mately 12” of electrical cord hanging from the ceiling. Do not restore power until wiring is completed.
Disconnect power cord, remove the stainless steel lters by pulling down toward the direction of solid ar-
row while holding both of the metal handles, gently pull the stainless steel lters toward the direction of
dashed arrow as shown in Figure 1.
Remove the grease cup by sliding it sideway, see Figure 2 for location of the grease cup.
Set aside the stainless steel lters and grease cup until the range hood is properly installed.
If the range hood comes with a glass canopy and has not already been mounted to the hood, loosen the four
canopy screws and washers from the hood top, carefully place the canopy on the hood top, and loosely tighten
the four canopy screws along with washers. DO NOT put excessive pressure against the glass.
1.
2.
3.
4.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Excessive Weight
Require three or more person to move and
install this range hood. Spinal or other bodi-
ly injuries could occur if it is not followed.
WARNING
WARNING
Severe Injury
Rotating fan can cause severe
injury. Stay clear of fan when
motor is running.
Figure 2
Figure 1
Inhaltsverzeichnis
Andere Fabyka Dunstabzugshaube Handbücher
