Fafnir UM-X Leitfaden

Technical Documentation

FAFNIR GmbH • Bahrenfelder Str. 19 • D-22765 Hamburg • Telephone: +49 (0)40-39 82 07-0 • Fax: +49 (0)40-3 90 63 39

10/2007

Edition: 1

Item No.: 207120

UM-X

Field display for continous level sensors

UM-X

Page 2/35

Reproduction and translation only with the written consent of the FAFNIR company.

FAFNIR reserves the right to make product modifications without prior notice.

Table of Contents

1 Features of the UM-X measurement analysis system ............................... 4

2 Safety instructions ....................................................................................... 5

2.1 Password ..........................................................................................................5

3 Design and operation .................................................................................. 6

3.1 Rating plate .....................................................................................................6

3.2 Function buttons .............................................................................................6

3.3 Display window ...............................................................................................7

3.4 Alarm lamp...................................................................................................... 7

3.5 Buzzer ..............................................................................................................7

4 Installation ................................................................................................... 8

4.1 Assembly and connections .............................................................................8

4.2 Pin assignment ................................................................................................9

5 Commissioning........................................................................................... 11

6 Operation ................................................................................................... 13

6.1 Layout of the display ....................................................................................13

6.2 Bar graph display (analogue filling level display) .......................................14

6.3 Relay status display .......................................................................................14

6.4 Main menu ....................................................................................................15

6.4.1 Navigation............................................................................................15

UM-X Page 3/35

6.5 Relays selection menu...................................................................................17

6.5.1 K1 to K5 selection menu .....................................................................17

6.5.2 Settings menu S-P On (switching-on point) .......................................18

6.5.3 Settings menu S-P Off (switching-off point) ......................................19

6.5.4 Settings menu On Delay......................................................................19

6.5.5 Settings menu Off Delay .....................................................................20

6.5.6 Settings menu Alarm ...........................................................................20

6.6 Settings menu Unit .......................................................................................21

6.7 Settings menu Height ...................................................................................21

6.8 Settings menu Offset (zero point offset) ....................................................22

6.9 Selection menu Span (Adjustment) .............................................................23

6.9.1 Settings menu Change ........................................................................24

6.9.2 Settings menu Reset ............................................................................24

6.10 Selection menu Test .......................................................................................25

6.11 Selection menu Reset .....................................................................................26

6.12 Information display ........................................................................................26

7 Alarms......................................................................................................... 27

7.1 Relay alarm ....................................................................................................27

7.2 Error ...............................................................................................................27

7.2.1 Meaning of the error codes .........................................................................27

8 Technical data ............................................................................................ 28

9 Menu structure with the factory settings ................................................ 29

Appendix ............................................................................................................ 31

1 EC-declaration of conformity .......................................................................31

2 EC-type examination certificate ...................................................................32

3 Operating instructions ..................................................................................34

UM-X

Page 4/35

1 Features of the UM-X measurement analysis system

The UM-X measurement analysis system is a standalone display for continuous

filling level sensors. It is powered directly by the mains voltage and provides the

power supply for the filling level sensor at the same time. The filling level can be

displayed as analogue and digital on the graphic display.

The UM-X measurement analysis system also provides five potential-free change

over contacts. The switching points of the five relays are adjusted via the display

using 4 buttons and the statuses of the relays can be checked using the display.

The UM-X measurement analysis system

• can be used for all filling level sensors with a 4-20 mA interface.

• can be supplied with ATEX approval (intrinsically safe electric circuit).

• can be supplied as approved overfill prevention.

• shows the filling level as digital and analogue display.

• has five potential-free change over contacts as binary outputs.

• provides simple, menu-driven operation using a graphical display.

• is installed in splash-proof case.

There are 4 equipment versions of the UM-X measurement analysis system:

UM-SUM-S

UM-S

Standard version: Measurement analysis with 5 relay outputs and connection of

a continuous filling level sensor and an external acknowledgement button.

UM-OUM-O

UM-O

Measurement analysis with 5 relay outputs and connection of a continuous filling

level sensor and an external acknowledgement button.

Also approved in accordance with German law as overfill prevention.

UM-ExUM-Ex

UM-Ex

Measurement analysis with 5 relay outputs and connection of a continuous filling

level sensor and an external acknowledgement button.

Also approved for the connection of an explosion protected sensor (intrinsically

safe sensor circuit).

UM-O ExUM-O Ex

UM-O Ex

Measurement analysis with 5 relay outputs and connection of a continuous filling

level sensor and an external acknowledgement button.

Also approved in accordance with German law as overfill prevention and for the

connection of an explosion protected sensor (intrinsically safe sensor circuit).

UM-X Page 5/35

2 Safety instructions

The UM-X measurement analysis system is used as a standalone filling level

display for continuous filling level sensors. Please only use the system for this

purpose. The manufacturer accepts no liability for any damage resulting from

other uses!

The UM-X measurement analysis system has been developed, manufactured and

inspected in accordance with state-of-the-art technology and with recognised

technical safety rules and regulations. Nevertheless, hazards may arise from its

use. Therefore, please observe the following safety instructions:

• Do not make any changes, add anything to or rebuild the system without

obtaining the manufacturer’s permission first.

• Allinstallation andmaintenance work, with the exception of the function test,

must only be carried out when the power supply is disconnected.

• The measuring transducer must be installed outside a potentially explosive

zone.

• Installation, operation, and maintenance of the UM-X measurement analysis

systemmustonlybeperformedbycompetentpersonnel.Specialised knowledge

must be obtained by undergoing regular training.

• Operators, setting up and maintenance personnel must observe all the

applicable safety regulations. This also applies to the local safety and accident

prevention regulations not mentioned in these operating instructions.

The safety instructions in this manual are identified as follows:

If you do not observe these safety instructions, there is a risk of an

accident or the measurement analysis system can be damaged.

Useful information that will guarantee proper function of the system

or facilitate your work.

2.1 Password

Youneedapassword for somemenuitemsin order tobeableto launch

the items or make changes.

The password will be provided on an accompanying sheet and must

only be used by instructed persons.

UM-X

Page 6/35

3 Design and operation

3.1 Rating plate

Among other things, the rating plate contains information about the version of

your measurement analysis system:

• Device type UM-S, UM-O, UM-Ex or UM-O Ex.

• Approval mark.

3.2 Function buttons

You navigate through the menu structure shown on the display and change

parameters in the settings menus using the four function buttons.

The functions of the buttons are shown in the function button field of the display

and change partially in the individual menus (see Chapter 6 "Operation" Section

6.1, "Layout of the display").

Fig. 1: Layout of the UM-X measurement analysis system, view from above

(3) Display window

(4) Alarm lamp

(2) Function button

(1) Rating plate

UM-X Page 7/35

3.3 Display window

The display is used for showing the filling level information and for setting the

parameters for the measurement analysis.

3.4 Alarm lamp

The measuring transducer is equipped with a red "Alarm" light emitting diode

(LED) for displaying alarms and system faults.

The red LED signalises the exceeding or dropping below the alarm thresholds set

using the software and the occurrence of faults (see the "Alarms" Chapter).

3.5 Buzzer

The buzzer is used for the acoustic alarm signal. The alarm tone is interrupted as

soon as the acknowledgement button has been pressed, the reason for the alarm

has been cancelled or the fault has been rectified. The buzzer volume cannot be

adjusted.

UM-X

Page 8/35

4 Installation

Installationmustonlybeperformedbycompetentpersonnelobserving

all the applicable safety regulations. This also applies to any local

safetyregulationsand accident prevention regulations not mentioned

in these operating instructions.

4.1 Assembly and connections

TheUM-X measurementanalysis systemis intended for wall mounting. It can only

be mounted and connected while it is open:

• Undo the four cover screws.

• Carefullyremove thecover. It is still connected to the printed circuitboard with

two ribbon cables.

• Unplug the connectors in order to be able to completely remove the cover.

• Now you can mount the measurement analysis system.

The measurement analysis system must be installed outside the

potentially explosive area. Sensors for the potentially explosive

atmosphere can be connected to the UM-Ex and UM-O Ex devices.

• Connect the cables for the auxiliary power and the filling level sensor to the

measurement analysis system after it has been mounted. An external

acknowledgement button and external control units can optionally be

connected.

See Section 4.2 "Pin assignment" in this Chapter.

Close the measurement analysis system again after mounting and connection of

all electrical cables.

• First, plug the wide ribbon cable back into its holder which has reverse polarity

protection.

• Now, connect the narrow ribbon cable back to the membrane keypad. Pay

particular attention here to the correct seating of the socket as this does not

have reverse polarity protection.

• Close the measurement analysis system using the four cover screws.

UM-X Page 9/35

4.2 Pin assignment

Wiring work must only be performed when the equipment is

disconnected from the power supply. The special VDE regulations and

the local installation regulations must be observed.

In doing so observe the maximum values for operating parameters

indicated on the wiring diagram.

Sensor connection

The sensor is connected to the terminals 1 (-) and 2 (+).

12 18 19 20 22

Fig. 2: Measurement analyser UM-X: Pin assignment

(1) Keyboard connection

(2) Display connection

(3) Sensor

(4) Acknowledgement button (5) Auxiliary power

UM-X

Page 10/35

Output circuits

The relays K1 to K5 (terminals 3 to 17) are used for limit monitoring. There are 5

potential-free change-over contacts available here.

Special features of the UM-O and UM-O Ex equipment versions:

• Overfill prevention relay cannot be acknowledged:

Relay K1 (terminals 3, 4 and 5)

• Overfill prevention relay can be acknowledged:

Relay K2 (terminals 6, 7 and 8).

Auxiliary power

The auxiliary power is connected to the terminals PE, N and L of the printed circuit

board. For the 24 V DC version, + must be connected to L and - to N.

External acknowledgement button

Itispossible to use an external acknowledgement button (potential-free normally

open contact). This is connected to the Quit terminals (18 and 19).

CAUTION! MAINS VOLTAGE!

Inhaltsverzeichnis

Andere fafnir Monitor Handbücher

fafnir

fafnir VISY-TD Leitfaden

Beliebte Monitor Handbücher anderer Marken

Linear Acoustic

Linear Acoustic LQ-1000 Bedienungsanleitung

AOC

AOC I2579V Bedienungsanleitung

Gateway

Gateway FPD1520 Bedienungsanleitung

Furuno

Furuno Mu 120c Bedienungsanleitung

Asus

Asus VB171D - 17" LCD Monitor Bedienungsanleitung

Dell

Dell S2230MX Gebrauchsanweisung

Philips

Philips 107C64 Bedienungsanleitung

Dell

Dell S2409WFP Bedienungsanleitung

EverFocus

EverFocus EN-7517E Bedienungsanleitung

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Bedienungsanleitung

Dell

Dell Precision 7680 Bedienungsanleitung

LG 50PM1M - - 50" Plasma Panel Bedienungsanleitung

Bosch

Bosch DDU 9 Bedienungsanleitung

Acer

Acer A231HL Bedienungsanleitung

Philips

Philips 86BDL4152T Bedienungsanleitung

NEC

NEC AccuSync LCD5V Bedienungsanleitung

Emay

Emay SleepO2 Bedienungsanleitung

IBM

IBM 6360 Montageanleitung

fafnir UM-X Leitfaden

Beliebte Monitor Handbücher anderer Marken
