E) Attention:
FE-MR18 Ring Flash
Instruction Manual
D) Technical Specifications
Guide No. 5.6m (ISO 100/21° , Full Power)
Illumination Angle 2×[Height:60 ×Width:45] (Angle adjustable)
Recycling Time ≤ 3 seconds (Full power); ≤ 1.5 seconds (Half power M/2)
Flash Duration 1/2000 seconds
No. of flash approx. 300 times (New alkaline batteries, full power)
Color Temperature ~5600K (Daylight)
Shooting Distance 20-100cm
Modeling Lamp Turn off automatic off after 25 seconds
Triggering Low Voltage Triggering
Maximum size of lens Φ77mm
Power Source 4 x 1.5V AA batteries
Dimensions
Lamp Head (L x W x D): 150cm x 130cm x 25cm
Control Panel (L x W x D): 65cm x 60cm x 92cm
Weight 264g ( Batteries excluded)
1．Turn off the flash when not in use. Remove the batteries if the flash unit is not
to be used for a period of time.
2．Avoid any scratch or worn on the lamp’s protector, so as to ensure the light
effect and guide no. would not be affected.
3．To ensure the guide no. quality, only press the shutter when the ready signal -
charge indicator lights up.
4．The flash should be stored in a cool, dry and well ventilated place. Before
shooting, please trigger the flash several times in order to restore the energy
storage capacitor to the best status.
5．Please do not clean the flash with petrol, alcohol or organic detergent.。
6．Please DO NOT open or repair the unit yourself. If there is any defect, please
contact the experienced technician.
Adepter ring size:
52/55/58/62/67/72mm
FM1109_FE-MR18_eng
Thank you for purchasing FalconEyes’ products.
For further details of our related products, please contact your
local distributor or visit our webpage at www.falconeyes.com.hk
Thank you.
Please read this manual carefully before using this product.
A) Product Features C) Instructions
1
2
B) Functional Diagram
1
2
FE-MR18 Ring Flash for Marco Shooting can be used with most of the digital cameras
(except Sony) that equipped with hot shoe. It is designed with the advanced electronic
technology, with outstanding performance and favorable modeling. Also, the operation
is simple and flexible. The largest size of adaptor ring is dia. 77mm. This macron ring
flash will be the best partner for your photography creation.
Flash Head Section
Control Section
Upper Modeling Lamp
Adaptor Ring Lock
Left Flash Tube
Right Flash Tube
Lower Modeling Lamp
Flash Power Control Button
Battery Cover
Exposure Value Table
Test Button
Modeling Lamp ON/OFF Button
Ready Indicator Light
Main Power
ON/OFF Switch
Contact Point For
Flash Synchronization
Hot Shoe Locking Screw
1．Before operation：
Turn the power switch to the position of “M”, and it produces sound of charging
the capacitors. After a few seconds, the “READY” lamp turns on and the flash
could start working.
When the “READY” lamp does not turn on after 60 sec, the batteries should be
changed to new ones.
2. Operation Tips：
A. Adjust the camera's shutter speed:
Set the shutter speed within the range of the flash synchronization speed.
B. Determine the aperture according to the Exposure Value Table.
Example: When the setting of the camera are as follows: ISO 100, Flash Power is
M/2 and shooting distance is 50cm
In the Exposure Value Table, find the distance figure “50” in the second row on
the top. Then find “M/2” in the row of ISO 100 on the left. Read the figure "4.0" at
the intersection point of “50” & “M/2” which is the appropriate aperture value.
3．Angle adjustment:
According to different photography purpose, adjust the illumination angle of the
left and right flash tubes and/or choose to trigger the dual flash tubes
simultaneously or separately.
4．Use of the modeling lamp:
When the image of the object cannot be seen clearly or in a low-light
environment, turn on the “Modeling Lamp ON/OFF Button”, the upper and lower
modeling lamp will light up for 25 seconds.
Exposure reference
