FANATEC G Wireless Controller Bedienungsanleitung
Wireless Controller
Manual
TABLE OF CONTENT
2 Important Safety Instructions
3 Introduction
Thank you very much!
4 Specifications
5 Installation
5 Operating Instructions
8 Troubleshooting
10 Contact and Support
10 Terms of guarantee
11 Certifications
Important safety instructions
Before using your °G WIRELESS Controller please read this
manual thoroughly. If you comply with all instructions and
tips, using the WIRELESS Controller is easy and comfortable.
Please retain this manual for future reference.
If you don’t want to lose your warranty please refrain from
opening the WIRELESS Controller – there are no user
serviceable parts inside. Inappropriate handling does
2
invalidate the warranty and often leads to malfunctions of
the device.
Keep your WIRELESS Controller away from liquids and liquid
containers such as vases, bottles, hot baths, jacuzzi tubs,
etc. Any damage occurring from liquids invalidates the
warranty.
Introduction
Thank you very much!
Congratulations for purchasing the °G WIRELESS Controller.
We really appreciate your trust in our fine products.
This controller was thoroughly produced under constant quality
inspection and according to international quality and safety
standards. Have fun with this controller.
If you follow this manual, set up, operation, and basic
maintenance of the WIRELESS Controller is simple. In case you
encounter any problems understanding this manual please
contact your dealer or our friendly customer support under
support@sunflex-europe.com.
3
Specifications
Official PlayStation®licensed Wireless Controller
Compatible with PlayStation®2
State-of-the-art 2.4 GHz wireless technology for comfortable
gaming within a range of up to 10 m
Digital-, Analogue-, and optional Turbo-Mode
Vibration feedback supported (please refer to game manual
to find out about game compatibility)
Vibration on/off Button
Fully analogue pressure-sensitive action buttons (only with
PlayStation®2, please refer to game manual to find out
about game compatibility)
Low latencies (< 16 ms) – virtually no transfer times
300 h battery life (w/o vibration; 100 h battery life with
vibration)
Requires 2 AA batteries (not included)
Technical data is subject to change without notice.
4
Installation
Connect your WIRELESS Controller’s receiver to your
PlayStation®2 console only when it is deactivated.
Pay attention to the correct placement of 2 AA batteries in the
controller, incorrect polarisation may render the WIRELESS
Controller defective. Turn on your PlayStation®2 console. To
ensure correct calibration of the analogue thumbsticks and the
action buttons, make sure that sticks and buttons remain in
their natural position when the controller is turned on using
the Vibration ON/OFF Button. Moving the sticks and/or pressing
the action buttons while the console starts up may result in
incorrect calibration and requires you to restart your
PlayStation®2 console and repeat the above steps.
Operating Instructions
Your WIRELESS Controller offers three operating modes, Digital,
Analogue and Turbo Mode. The LED entitled“ANALOG”indicates
the currently activated mode.
Use the ANALOG Button to switch between Analogue and
Digital Mode.
5
DIGITAL MODE: Thumbsticks are deactivated and buttons work
digitally only. There is no pressure sensitive functionality
whatsoever.
ANALOGUE MODE: Thumbsticks are operational and buttons
offer analogue, pressure sensitive functionality when used with
a PlayStation®2 console. Please refer to your game’s manual to
find out whether analogue functions are supported.
TURBO MODE: The WIRELESS Controller features a Turbo Mode
that comes in really handy in fast action games. It can be
assigned to any button of the WIRELESS Controller including
the D-Pad and L3/R3, making sure that the respective button’s
command is executed 16 times a second when the player
presses and holds this button. To program an action button
please press and hold the TURBO Button and then press the
button you would like to assign the turbo function to. You may
do this with as many buttons as you wish at once. To reset all
action buttons to normal operation, please hold Select and
Turbo simultaneously. The Analogue Mode LED also acts as an
indicator for TURBO Mode, flashing rapidly when TURBO Mode
is in use.
The °G WIRELESS Controller also features an advanced Turbo
Mode that goes even beyond regular Turbo operation: the
Turbo Hold function. This function allows you to not only
program action buttons to carry out their commands 16 times
6
a second when pressed, but also when the button is not pressed.
In order to achieve this, repeat the above programming steps
once. The WIRELESS Controller will then perform the buttons’
commands constantly until deactivated.
Please refer to the graphics below for a summary of the above.
Available Controls: [ , , , , L1, L2, L3, R1, R2, R3, up, down, left, right]
Note: When the WIRELESS Controller is set to Turbo Hold it will
enter Sleep Mode after an idle time of three minutes.
Vibration ON/OFF: When starting your PlayStation®2 console
the red LED of the WIRELESS Controller’s receiver will be lit up
while the green one flashes slowly, indicating that there currently
is no connection. Press the Vibration ON/OFF Button once for
less than one second to activate the controller. Within a few
seconds the green LED will stop flashing and light up constantly,
indicating a synchronised connection between console/receiver
and WIRELESS Controller. Your WIRELESS Controller is now ready
7
Ordinary Action
Turbo Function
Turbo Hold Function
“Turbo” Button + Control
“Turbo” Button + Control
“Turbo” Button + Control
for use. To deactivate your WIRELESS Controller manually, please
press and hold the Vibration ON/OFF Button for two seconds.
Your WIRELESS Controller features a battery-saving sleep mode
which turns off the controller after 30 seconds in case a receiver
can’t be detected. Furthermore, the controller will also turn off
after three minutes without any operation, even if a wireless
connection with the receiver is established or the controller is
in Turbo Hold Mode. To continue playing please reactivate the
controller by pressing the Vibration ON/OFF Button once.
In-game-vibration can be turned on and off at any time using
the Vibration ON/OFF Button. Vibration is activated by default.
To (de)activate please press the button twice in quick succession.
The WIRELESS Controller will vibrate for one second to indicate
the (de)activation of the Vibration Mode.
Troubleshooting
If you encounter any problems using the °G WIRELESS Controller
please read this section carefully before contacting our customer
support or your dealer.
8
1. My WIRELESS Controller does not work correctly at all.
Turn off your PlayStation®2 console and make sure your
WIRELESS Controller is properly connected. Make sure you’re
within range of the console and the controller’s receiver. Turn
on the console and try again.
2. My game seems to receive input signals although I do
not even touch the controller.
Turn off your PlayStation®2 console and make sure your
WIRELESS Controller is properly connected. Turn on the console
and try again ensuring that the thumbsticks remain in neutral
position and the action buttons are not pressed during the
console’s boot phase.
3. My WIRELESS Controller does not offer vibration feedback
although the game’s manual specifically mentions its
vibration compatibility.
Please make sure you did not deactivate the vibration of your
WIRELESS Controller by accidentally pressing the Vibration
Button.
9
Contact and support
If you still encounter problems that can not be solved by reading
the section “troubleshooting“, please contact us:
10
Support:
Sunflex Europe GmbH
Corunnastr. 6
58636 Iserlohn
Germany
Tel: +49-2371-9357-0
Fax: +49-2371-9357-11
suppor[email protected]
Distribution:
Endor AG
Seligenthalerstr. 16
84034 Landshut, Germany
Product Information:
www.zero-g.eu
Terms of guarantee
We issue a guarantee of two years after purchase of the
°G WIRELESS Controller. Please preserve your invoice together
with this manual.
In order not to invalidate the warranty and to protect your
health never try to repair and/or open the device. There are no
user serviceable parts inside. Furthermore, the danger of electric
shock or even fire is reduced considerably.
