Fantasea CP-4 Pro Leitfaden

General Introduction:

The Fantasea CP-4 Pro & Sport models are both designed for housing the Nikon

Coolpix 4300 and 885 digital cameras. The housing is dedicated to these two

cameras, which are physically identical, to insure the most compact design for easy

handling and accurate access to camera functions through the critical placement

of push-button controls on the housing. The only difference between the Pro and

Sport models is the number of controls on each.

The CP-4 Sport housing provides access to the cameras’ shutter release, zoom

control, and quick review functions. This model is ideal for outdoor and underwater

photographers who prefer to use the camera’s automatic exposure features, while

the CP-4 Pro accesses these same controls, it is also designed for those who prefer

to make exposure settings manually through access to shutter speeds and apertures.

The Pro also adds some additional function controls to assist photographers in the

creative process.

Fantasea CP-4 Uses:

The Fantasea CP-4 Pro & CP-4 Sport housings are both designed as

underwater/outdoor camera housings. Both models have a working depth of 130

feet/40 meters. Underwater photographers can dive or snorkel and capture all the

excitement of this fascinating world, while outdoor photographers also have the

option of capturing the action of such activities as white water and paddle sports,

sailing and boating, surfing, fishing and hunting, backpacking and camping, and

for family activities around the swimming pool or at the beach. The CP-4 will

protect the Coolpix camera from water, sand, dust, and other damaging elements.

General Camera Description:

The Nikon Coolpix 4300 is a 4 megapixel camera and the Coolpix 885 is a 3.2

megapixel camera. With this resolution and the outstanding quality of other Nikon

features, such as optical performance, you will be able to produce high quality

images of the thrilling outdoor activities in which you participate. These cameras

were selected

Fantasea CP-4 Pro & CP-4 Sport Camera Housings

For Nikon Coolpix 4300 & Coolpix 885 Digital Cameras

Housing Orientation & Nomenclature:

Shutter Release

Latch Buckle

Lanyard

Eyelet Tripod / Tray Mount

Tempered Glass

Lens Port

Flash Diffuser

Safety Release

as the basis for the housing design due to the combination of image quality

and consumer value. For specific features of each camera you should reference

your camera’s instruction manual or obtain product technical information

from Nikon or their dealers.

Front View:

Rear View:

CP-4 Pro Model:

CP-4 Sport Model:

Shutter Release

Zoom in/out

Shutter speed up

Aperture up/down

Shutter speed down

Quick Review

Macro Focus

Exposure Compensation

Delete

LCD Monitor

LCD Light Shade

Door Hinge 1

Optical Viewfinder

Shutter Release

Quick Review

LCD Monitor

LCD Light Shade

Door Hinge

Optical Viewfinder

Zoom in/out

Using the CP-4 Housing:

Opening Housing:

Using two hands, pinch the Latching Buckle Release together to unlock the

safety device. While holding the release in this position, pull the latch open

in a front to back direction. The latch is hinged on the front half of the clamshell.

Pulling the latch toward the rear of the housing, will unclip the latching buckle

and allow it to swing free, for opening.

Inserting Camera:

Since the CP-4 is designed specifically for the Coolpix 4300 and 885 digital

cameras, insertion is a simple matter of placing the camera in the housing.

Make sure the camera lens is properly aligned with the port and that the camera

is perfectly flat. There are no screws or mounts to worry about or any other

alignments once the camera is properly inserted.

Note: It is necessary to make some camera settings prior to inserting into the

housing. Please refer to the Coolpix owners manual for menu options and personal

preferences to choose from, that are not accessible through the housing push-button

controls. Turn the camera on before inserting in housing.

Checking the Gasket:

Each time the housing is opened, the gasket seal should be visually inspected.

If there is any debris present, including dirt, sand, dust, excess grease or other

matter, it must be cleaned to insure a proper water-tight seal. Cleaning the

gasket is a simple matter of wiping it with a damp, soft cloth to remove any

foreign matter. Be careful the cloth you use does not leave any of its own

material behind as this can also affect the effectiveness of the gasket. If this occurs,

be sure the surface of the housing is also clean and wiped free of any debris.

The gasket should also be checked visually for any cracks or perforations. If

any part of the gasket shows signs of wear or damage, it is imperative that it

be changed before going into the water.

Closing the Housing:

Make sure the camera is flat and that the back door of the housing closes easily

without interference. Once the door is closed, latch the buckle behind the ridge

on the back half of the housing. (If the camera is not flat, the door will not lie

closed, and the latching buckle will have a hard time catching the ridge on the

back door. In this case, open the back door and reposition the camera until it

is flat and the door closes correctly.) With the latch behind the ridge on the

back door, push the latch buckle forward until it lies flat against the front half

of the housing and the safety release snaps into place.

Test Dive:

It is recommended to make the first dive without the camera in the housing.

This in order to make sure that there was no damage to the housing during

transport or shipment. This is a good general rule for every periodic diving

trip. Please note that the housing is extremely buoyant without the camera

inside.

Viewing the Subject:

Underwater photographers and outdoor photographers will appreciate the large

LCD viewing monitor for composing photographs. The LCD monitor will

allow you to see your subject in sharp focus and framed properly. Hold the

camera housing in your outstretched arm at a position that is both comfortable

and also allows you to easily see the LCD monitor, for best compositional

options.

Taking the Picture:

Once you have composed your scene or subject in the LCD monitor, depress

the shutter release button to take the picture. A half depress will activate the

live viewing ability of the LCD monitor, and a full depression of the button

will take the picture. You may notice a pre-flash and slight delay in the shutter

release. This is to allow the camera to make its final focus and exposure

calculations before taking the picture. With a little practice, you will become

use to this and taking pictures of moving subjects will become easier.

Image Files:

There are several image file options to choose from that offer different resolution

and file sizes. This determination must be made prior to camera insertion from

menu options. Please refer to the Coolpix instruction manual for details on

setting these preferences.

Battery Life:

The rechargeable battery that comes with the Coolpix is very efficient

and lasts for more than enough time for a typical photo dive. However,

there are certain things that users can control to help with battery life.

The most important is to set the camera to turn the LCD off after a set

time, during periods of non-use. It can then automatically turned back

on if you depress the shutter release control half way. Please refer to the

Coolpix instruction manual for details on how to make this adjustment

setting.

Using Flash:

The Coolpix has a built-in flash, which will illuminate underwater subjects

that are close. For subjects that are farther away, an accessory slave strobe

is recommended. (See Below.) Due to the presence of suspended particles

in the water, the use of the supplied flash diffuser is recommended. This

is a static cling device that should be pressed against the inside of the

housing, and in front of the camera’s flash. It will widen and soften the

light, providing more coverage and less likelihood of “backscatter”, the

unattractive “snowstorm” affect of the flash reflecting off the suspended

particles.

Outdoor photographers do not have this same concern. There is no

backscatter to be concerned about, and due to the ability of the flash to

travel farther and more effectively in air as compared to in water, there

is normally not a need for an accessory flash to provide proper illumination

for most subjects.

Accessory Slave Strobes:

Using the Coolpix built-in flash as the master, you can trigger a second

slave strobe to provide more artificial light when needed. To do this, you

must use an accessory strobe that has a slave feature built in. The flash

from the Coolpix must be “bounced” toward the accessory strobe’s slave

sensor, or other fiber optic sensor. This will trigger the slave to fire. Be

sure to use a slave strobe that has the ability to ignore the built-in pre-

flash, and synchronizes with the shutter release.

Lens Accessories:

The CP-4 is designed to work with some of the wide-angle and macro

adapters that are currently on the market. For more information on these

items, see your local photo dealer.

Shooting Techniques:

Exposure Modes: (Pre-set before camera insertion)

You can either choose the A mode on the camera in which ambient light

and artificial light will be automatically controlled by the camera according

to the lighting conditions. Or you can choose the M mode, and adjust shutter

speeds and apertures manually for the maximum creative control. Please

reference the Coolpix instruction manual for details on which camera controls

are used for this purpose.

Other Controls: Please reference Coolpix instruction manual for details.

Shutter Speeds and Apertures: (Pro Model Only) Allows the photographer

to adjust for more or less light in the manual exposure mode.

Zoom Control: (Pro & Sport Models) Zoom in for telephoto photos and

larger subject size. Zoom out for wide-angle scenes.

Macro Focus: (Pro Model Only) For capturing the tiny and exotic subjects

that require close focus.

Quick Review: (Pro & Sport Models) Immediate review of most recent

images is available that will confirm that you captured the shot you want.

Image Delete Control: (Pro Model Only) If you want to delete unwanted

images to make room for others, use the +/- button in conjunction with the

UP & DOWN control buttons according to the menu options on the LCD

monitor.

ExposureCompensationControl(+/-):(ProModelOnly).Usedincombination

with UP & DOWN buttons. This will allow you to control the overall

brightness of the image in A auto exposure mode.

Care & Maintenance:

The CP-4 housing requires only a minimum amount of care for reliable

performance. The following are tips that will enable you to get the best

results.

1. Always soak your housing in fresh water for 20-30 minutes after every

dive to dissolve the salt water crystals from around the controls and openings

of the housing. Manipulate each of the movable controls to assist the removal

of salt particles from these tight areas.

2. Allow the housing to dry thoroughly before packing away for the day or for the

trip home. You may use a soft towel or cloth to dry the housing. Be sure there is

no grease or other debris on the towel.

3. Visually check the condition of the gasket before every dive. If it is dirty, clean

it with fresh water and dry it with a soft cloth as described above. If it is damaged

in any way, such as cut or perforated, replace it immediately.

4. Use a small amount of lubrication grease to keep the gasket from drying out.

Do not overuse grease.

5. Be careful not to get greasy fingerprints or dirt on the lens port. This will affect

the image quality. Wipe any dirt or grease off with fresh water and a soft cloth.

6. Do not drop the housing on hard surfaces. It is not a shock absorber, and could

crack, affecting its water-tight integrity. It could also cause damage to the camera

inside.

7. Travel with the housing protected in a padded case. It is best to remove the

camera from inside the housing when traveling and provide it with its own protective

case, or compartment.

8. Never dive with the CP-4 housing to a depth greater than 130 feet/40meters

9. Give your CP-4 an annual tune up as you would any tool that gets rugged use.

The Fantasea repair and maintenance facility will replace and lubricate all O-rings

on all controls and the main gasket. Then the housing will be pressure tested to

insure it is in good working order.

Flood Insurance:

YourCP-4housingcomeswithaFloodinginsuranceapplicationformsuppliedby"Divers

EquipmentInsuranceProgram".Thispolicyonceactivated, isgoodforoneyearfrom

purchasedateofthehousing. Ifyourhousingexperienceswaterleakageduringthistime

yourcameraandhousingmaybereplacedaccordingtothetermsandconditionsofthe

policy.Onlyasmallshippingandhandlingchargewillapply.Afterthefirstyearyouhave

theoptiontorenewtheprogramonyourownandatyourownexpense.

All insurance policies must be activated by filling out the product registration

form, included in the box, and sending it along with a photo copy of the bill

of sale to Fantasea Products. These documents can also be faxed to expedite

activation of the insurance policy. The policy will go into effect immediately

upon receipt of completed documents.

Contact Information: Fantasea Line

www.fantasea.com

[email protected]

Nikon and Coolpix are registered trademarks of Nikon Corp

Dieses Handbuch passt für folgende Modelle

Andere Fantasea Kamerazubehör Handbücher

Fantasea

Fantasea Nano Fiber Bedienungsanleitung

Fantasea

Fantasea Nano Flash Bedienungsanleitung

Fantasea

Fantasea FG15 Bedienungsanleitung

Fantasea

Fantasea EyeGrabber MPK Series Bedienungsanleitung

Fantasea

Fantasea Fiber Optic Cable Leitfaden

Fantasea

Fantasea Line FP7000 Housing Bedienungsanleitung

Fantasea

Fantasea FRX100 VA Bedienungsanleitung

Fantasea

Fantasea FS 1 Bedienungsanleitung

Fantasea

Fantasea F350D Bedienungsanleitung

Fantasea

Fantasea FFL 50 Bedienungsanleitung

Fantasea

Fantasea EyeDaptor F67 Bedienungsanleitung

Fantasea

Fantasea EyeDaptor G Series-F67 Bedienungsanleitung

Fantasea

Fantasea FS-600 Bedienungsanleitung

Fantasea

Fantasea EyeDaptor S90 Bedienungsanleitung

Fantasea

Fantasea FD-50 Bedienungsanleitung

Fantasea

Fantasea EyeDaptorGSeries?F67 Bedienungsanleitung

Fantasea

Fantasea Nano Ray Lighting Sets Bedienungsanleitung

Fantasea

Fantasea BigEye Bedienungsanleitung

Fantasea

Fantasea Blue Ray Tray Bedienungsanleitung

Fantasea

Fantasea FD-50N Bedienungsanleitung

Fantasea

Fantasea FD-70N Bedienungsanleitung

Fantasea

Fantasea BlueRay Action Bedienungsanleitung

Fantasea

Fantasea F400D Bedienungsanleitung

Fantasea

Fantasea FL-6 Bedienungsanleitung

Beliebte Kamerazubehör Handbücher anderer Marken

Viltrox

Viltrox EF-NEX Montageanleitung

Calumet

Calumet 7100 Series CK7114 Bedienungsanleitung

Ropox

Ropox 4Single Series Bedienungsanleitung

Cambo

Cambo Wide DS Digital Series Betriebsanleitung

Samsung

Samsung SHG-120 Bedienungsanleitung

Ryobi

Ryobi BPL-1820 Bedienungsanleitung

Aegis

Aegis ABL-36020P Bedienungsanleitung

Pentax

Pentax Data Back Fc Bedienungsanleitung

Honeywell

Honeywell HDZ20HD Bedienungsanleitung

EGO

EGO BA1400T Bedienungsanleitung

Sima

Sima SRW-62 Bedienungsanleitung

Shape

Shape A7SSMKIT Bedienungsanleitung

Slide Kamera

Slide Kamera HST-2 Bedienungsanleitung

Power works

Power works 2902613 Bedienungsanleitung

SES

SES SE-2047-2 Bedienungsanleitung

Olympus

Olympus PT-EP05L Bedienungsanleitung

Starlite

Starlite OctoDome nxt Bedienungsanleitung

Custom Brackets

Custom Brackets Digital PRO-M Bedienungsanleitung
