Fantec BeastVision HD Bedienungsanleitung
2
Table of contents
1. Precautions......................................................................................................................................3
2. Product Certification.........................................................................................................................3
3. Preface.............................................................................................................................................4
4. Product Overview.............................................................................................................................5
5. Function and Features......................................................................................................................6
6. Product Structure .............................................................................................................................8
7. Installation........................................................................................................................................9
8. Operating Instructions ....................................................................................................................10
9. Parameter & Settings..................................................................................................................... 14
10. Operation..................................................................................................................................... 20
11. File Storage and Playback............................................................................................................ 30
12. Additional Backup Battery Installation...........................................................................................31
13. Specifications & Parameters.........................................................................................................33
14. Appendix......................................................................................................................................34
15. Copyrights....................................................................................................................................35
16. Warranty ......................................................................................................................................36
3
1. Precautions
1. This camcorder is a precision product. Please do not drop it or hit it physically.
2. Keep the camcorder away from any object with a strong magnetic field, like magnet or electromotor,
or any object emitting strong radio waves, like antenna, as a strong magnetic field may cause failure to
the device or cause damage to image and audio data.
3. Do not expose the camcorder to high temperature or sunlight directly.
4. Keep the Micro SD card away from the strong magnetic field of TV, speaker, or magnet. Do not put
it in any place with potential static, or the data stored on it may be lost.
5. If the camcorder overheats, smokes or smells while charging, please disconnect the USB cable or
the USB power adapter immediately to avoid the risk of fire.
6. Put the device out of reach of any child while charging, as the power cord may cause an accidental
suffocation or electric shock to the child.
7. Please keep this product in a cool, dry, and dust-free place.
2. Product Certification
Certified by FCC and CE, this product complies with the recommended standards and guarantees the
user's safety.
4
3. Preface
Thanks for purchasing FANTEC’s BeastVision HD hands-free mini high-definition digital camcorder.
Due to its small size and design, the hands-free camcorder is easy to operate. Supported by high-
definition and dynamic image capturing technology, it can record real scenes and various activities
anytime and anywhere and you can share wonderful recording experiences with your family and
friends. This manual specifies how to use and install the device and provides detailed information,
including the instructions on use, operation and installation as well as the technical specifications.
Please read this manual carefully.
1. Repair
If the device has a problem, you should take it to an appointed repair center and let the specialists do
the repair, never repair the player yourself, you might damage the device or endanger yourself or your
data.
2. Disposing of the Camcorder
When you dispose the camcorder, be sure to dispose it appropriately. Some countries may regulate
disposal of electrical device, please consult with your local authority.
3. Others
Do not disassemble the camcorder, repair or change the design of it, any damage done will not be
included in the repair policy.
Do not press the buttons of the device too hard.
Avoid hitting the player with hard object, and stay away from magnetic fields.
During electrostatic discharge and the strong electromagnetic field, the product will malfunction, then
remove the battery and the product will return to normal performance next time it is powered on.
5
4. Product Overview
As a multifunctional high-definition digital sports video camcorder, this product provides many functions
such as high-definition recording, digital photographing, voice storage, real-time display, photo
shooting, time display, remote control, digital zoom, TFT color screen, multi-functional keys, laser
indication, high-speed USB data transmission, HDMI high-definition output function, low power
indication, memory card space display and USB charging.
Do not litter! Please recycle!
Note:
All the information contained in this manual was correct at the time of publication. However, as our
engineers are always updating and improving the product, your device’s software may have a slightly
different appearance or modified functionality than presented in this manual.
6
5. Function and Features
1. 170° extra-large wide-angle lens; Aperture f/2.8
2. Specialized HD Camcorder, supporting 1080I/1080P/960P/720P high-definition video
recording
3. Photo shooting function, supporting 8.0 Megapixels (3200x2400)
4. 10x digital zoom function
5. Various shooting modes available: Single shooting, three photos continuous shooting, auto
continuous shooting
6. Self-timer function
7. Voice recording function
8. Wireless remote control function
9. Image rotation of 180º (over head recording)
10. Laser indicating function
11. Video loop coverage function
12. With LCD segment screen and split TFT main screen, to display various working modes in
real time
13. With waterproof case, the waterproof grade is IP68, the waterproof depth is up to 60 meters,
and it has two back cover designs
14. TFT display screen, to play and playback videos, and photos
15. With built-in dismountable high-capacity lithium battery, it can be re-charged
16. Better image effect, three video output modes available
17. Battery power detection and Micro SD card free space detection
18. High-speed dynamic video recording, supports instant response for bright and dark
environments
19. Three photo metering modes for various shooting circumstances
7
20. Delicate and stylish exterior design
21. HDMI high-definition interface and AV output interface, to connect a high-definition display
device or TV to view files
22. Supporting a Micro SD card up to 64GB (Class 10 recommended)
23. High-quality color fidelity, clearer and more realistic image
24. Remote control for video recording, stopping and shooting by using wireless remote control
(unique code pairing function, avoiding interference with other remote control)
25. Recording MOV videos, can directly played by PC or uploaded onto video websites
26. Auto standby power-saving function
27. Supports fast forward and fast rewind (1/4x/1/2x/2x/4x/8x/16x)
28. Supports time setting (RTC function) and time superposition function
29. Supports USB2.0
30. Built-in stereo microphone, high-quality voice recording effect
31. Various sports accessories, truly enables sport video recording
32. Steady shot: maintain the normal function after being dropped or stricken
33. Good seismic resistance
34. Settings auto saving mode
8
6. Product Structure
1. TFT Display screen
10. Buzzer
19. LCD segment screen
2. MENU key
11. SD card slot
20. Shutter
3. Up key
12. Right key
21. Stop key
4. Left key
13. AV out interface
22. Camera lens
5. Down key
14. Record key
23. Recording/ shooting LED (blue)
6. Playback key
15. Video/Voice record LED (green)
24. Laser transmitter
7. OK key
16. Power switch
25. HDMI out interface
8. Remove TFT button
17. Microphone
26. USB device interface
9. Lanyard hole
18. Working/ Charging LED (red)
27. Thread interface
9
7. Installation
1. The device can be used in handheld or hands-free mode and combined with various non-hand-held
accessories. The camcorder can be installed wherever you like, even operation in the water by the
waterproof casing is possible.
The installation is shown as follows:
a) Installation and removal of the TFT
display screen and the main body
b) Installation of the main body without TFT display
screen into the waterproof case
2. Installation of remote control.
Please install the remote control onto the correct position based on the accessories below:
1. Velcro
2. Clip
3. Binding tape (optional)
10
8. Operating Instructions
1. Start up
Turn the power switch to “ON” to start up the device.
2. LCD segment screen icons:
a) Record mode: The current record mode can be viewed on the top left corner of the LCD segment
screen, this symbol “ ” indicates the video recording mode and this symbol “ ” indicates the voice
recording mode.
b) Photo shooting indicator: The shooting icon “ ” can be viewed on the LCD segment screen. The
icon will twinkle one time when shooting one photo.
c) Power icon: The power icon “ ” can be viewed on the top right corner of the LCD segment screen.
The icon is visible constantly after the device is running and the disappearance of the icon means the
device is shut down or has entered the standby mode.
d) Video recording duration: The duration of the current video recording is displayed on the middle line
of the LCD segment screen, and is indicated by this display “”. The video recording duration
will start displaying when pressing “Record” key, and it will stop when pressing “Record” key once
again.
Note:
The video recording duration on LCD segment screen and TFT display screen is displayed
synchronously.
