FAZUA Evation Bedienungsanleitung

pedelec drive system

EU Edition 2020

Quickguide

Kurzanleitung

Guía rápida

Guide de démarrage rapide

Guida veloce

version 05

| evation

English

Quickguide

pedelec drive system

4evation |

Contents

Fundamentals.......................................................................................5

Storage and transport ..........................................................................5

Overview: Components and part designations ..................................6

Handling steps before or during the trip .............................................9

Operating the drive system ................................................................11

Displays on the remote.......................................................................14

Bluetooth® function...........................................................................15

Notes ...................................................................................................16

| evation

Fundamentals

This quickstart guide is part of the FAZUA evation drive system. evation

is an electrical drive system designed for e-bikes, and consists of the

following different components:

→Drivepack (motor unit)

[incl. locker for locking to the frame],

B→Bottom Bracket [incl. speed sensor + spoke magnet],

C→Remote [models: Remote b, Remote fX, Remote bX],

D→Battery [models: Battery 250, Battery 250 X],

E→Charger [models: Charger A, Charger S (EU/US)].

Depending on the model, different variants of the individual components

are installed in your e-bike. Note, therefore, that for certain operating steps,

different instructions are described for the different model variants.

Detailed information on the drive system and the individual components,

as well as their model variants, can be found in the enclosed original

instructions.

WARNING

Serious hazards due to improper use!

If you do not completely read and observe the original instruc-

tions, hazards can arise which can sometimes result in serious

injuries or even death for you or others.

►Read and observe the enclosed original instructions for the

evation drive system, especially before using your e-bike

equipped with the drive system for the first time.

►Read and follow the manufacturer's instructions for your

e-bike.

Storage and transport

►Always transport and store the battery separately from the e-bike.

►Observe the detailed information on storage and transport in the orig-

inal instructions.

6evation |

Overview: Components and part designations

→The numbering of the individual parts within this quickstart guide may differ

in places from the numbering in the original instructions.

A3.1A3.2

Remote b

Remote fX

Remote b/Remote bX

Remote fX

Remote bX

Battery 250

D3D4

Battery 250 X

D3D4

D1D4

Battery 250/

Battery 250 X

| evation

E2E3

ADrivepack

A1→Interface (Bottom Bracket)

A2→Battery holder

A3→Push button (3.1)/locking lever (3.2)

BBottom Bracket

B1→Interface (Drivepack)

CRemote (Remote b/Remote fX/Remote bX)

C1→Button/touch sensor (top)

C2→Centre button

C3→Button/touch sensor (bottom)

C4→Status display

C5→Display of charging level/support level

DBattery (Battery 250/Battery 250 X)

D1→Interface (Drivepack)

D2→Pushbutton (battery lock)

D3→Charging socket

D4→On/off button

ECharger (Charger A, Charger S (EU/US))

E1→Mains adapter

E2→Charging plug

E3→Mains cable with mains plug

8evation |

Figure 1

Figure 2

Figure 3

A3.2

A3.1

Figure 4

E2D3

| evation

Handling steps before or during the trip

→see figures page 8.

Insert battery Din Drivepack A(→Figure 1)

1. Make sure that the battery is undamaged (visual check).

2. Press the on/off button D4once, to turn on the battery.

3. Carefully insert the battery as far as possible into the battery

holder A2.

The battery is automatically locked when you have inserted it correctly.

IMPORTANT: Do not use the drive system if the battery cannot be

locked.

Remove battery Dfrom Drivepack A(→Figure 1)

1. Secure the battery with one hand and press the push button D2

with the other hand to release the battery from the lock.

2. Hold down the push button D2, grasp the battery on the two side

handles and gently pull the battery out of the battery holder A2.

Insert Drivepack A(incl. battery) into the e-bike (→Figure 2)

1. Place the Drivepack on the interface B1of the Bottom Bracket.

2. Swing the upper end of the Drivepack into the downtube.

The Drivepack is automatically locked in the locker when you have

correctly placed the Drivepack and completely swivelled it into the

intended position in the downtube.

The push button A3.1or the locking lever A3.2automatically moves

to the closed position.

3. Check the Drivepack is securely in position.

IMPORTANT: Do not use the drive system if the Drivepack cannot be

locked to the e-bike.

10 evation |

Remote the Drivepack Afrom the e-bike (→Figure 3)

→If you press the Drivepack firmly against the frame before pressing the push

button or releasing the locking lever, it will be easier to release the Drivepack

from the locking device on the frame when removing it.

1. Secure the Drivepack with one hand and press the push button A3.1

or move the locking lever A3.2upwards as far as possible to release

the Drivepack from the lock.

2. Hold down the push button A3.1and carefully lower the Drivepack.

The locking lever A3.2automatically remains in the open position.

3. Remove the Drivepack from the interface B1of the Bottom Bracket.

Charge battery Dwith charger E(→Figure 4)

→The battery can remain in the Drivepack during charging, or you can remove

the battery from the Drivepack and charge it separately.

1. Before charging the battery, prepare the charger by connecting the

mains cable E3to the mains adapter E1.

IMPORTANT: Only use the corresponding FAZUA charger to charge

the battery.

2. Remove the Drivepack from the e-bike.

3. Insert the charging plug E2into the charging socket D3on the battery.

4. Plug the power plug into a suitable socket.The charging process starts

automatically after connection to the mains.

IMPORTANT: The charger may only be used in dry indoor areas!

5. Disconnect the charger from the mains by unplugging the mains plug

from the socket when charging is complete or to interrupt charging.

6. Disconnect the charger from the battery by pulling the charger plug E2

out of the charging socket D3on the battery.
