1. Presentation
1.1. Switches and connectors
1) Active GPS antenna (SMA connector)
2) Radio antenna 868Mhz-915Mhz (SMA connector)
3) Validation switch (Orange)
4) Selection switch (Green)
5) Audio out
6) Input 1 / temperature sensor
7) Input 2 / Sync Output
8) RS232 / RS485
9) Power connector (12V-24V)
Only for model with SN <= 20
If SN > 20 power connector is on the back
1.2. MLED assembly
The most common configuration comprises of 3 or 4 x MLED panels adjoined to form a
display fully configurable to either a single full height line of characters or multiple lines as
below. Another configuration proposed is 2 rows of 6 modules which form a 192x32cm
display area.
The total display area is divided into 9 zones (A – I) as the schematic below. Be aware that
some zones share the same display area and should not be used together. A line number as
well as a color can be assigned to each zone via the IOS or PC setup application.
It is recommended to assign the value “0” to any unused zone.
The MLED-CTRL box must always be connected to the lower right MLED module.
A
B
C
D E
F G
H I
MLED-CTRL Box User manual
December 2021 - Version EN 1.2
www.fdstiming.com
Display with 3 x MLED panels (MLED-3C):
Zone A: 8-9 characters, height 14-16cm depending on the font type selected
Zone B - C: 16 characters per zone, height 7cm
Zone D - G: 8 characters per zone, height 7cm
Zone H - I: 4 characters per zone, height 14-16cm
Display with 2x6 MLED panels (MLED-26C):
Zone A: 8-9 characters, height 28-32cm depending on the font type selected
Zone B - C: 16 characters, height 14-16cm per zone
Zone D - G: 8 characters, height 14-16cm per zone
Zone H - I: 4 characters, height 28-32cm per zone
2. Operating Mode
Seven operating modes are available:
1) User Control via RS232
2) Time / Date / Temperature
3) Start-Finish
4) Speed trap
5) Counter
6) Count-Down
7) Start Clock
Modes can be selected and configured either via our iOS or PC setup application. The first two
modes are part of the basic firmware. Modes 3 - 6 belong to a 1st optional group and require an
activation key to operate. Mode 7 belongs to a 2nd optional group which also requires activation.
Modes 2-7 are optimized for MLED-3C and MLED-26C configuration. Some of them also work
with MLED-1C.
2.1. User Control Mode
This is the general display mode for which you can send data from your own preferred
software. Information can be displayed using either the RS232/RS485 port (using FDS / TAG
Heuer protocol) or via Bluetooth using our iOS application.
This is the only mode giving full access to the display zones described in chapter 1.2.
2.2. Time / Date / Temperature Mode
Alternating time, date and temperature, all controlled via GPS and external sensors. Each of
which can be pre-defined colors selected by the user for optimum and eye-catching visual
impact.
MLED-CTRL Box User manual
December 2021 - Version EN 1.2
www.fdstiming.com
The user can choose between Time, Date and Temperature or a mix of all 3 options scrolling
consecutively depending on the user selection.
Temperature can be displayed in either °C or °F.
During initial power up, the displays internal time is used. If GPS is selected as the default
synchro source in the settings, once a valid GPS signal is locked the information displayed is
synchronized accurately.
Time of day is put on hold when a pulse on input 2 (radio or ext) is received.
TOD at Input 2 pulse is also send to RS232 and printed.
2.3. Start-Finish Mode
Start-Finish mode is a simple yet accurate mode of displaying time taken between 2 positions
or inputs. This mode works either with the external Jack inputs 1 & 2 (wired solution), or
with WIRC (wireless photocells) signal.
Two input sequence modes are available:
a) Sequenced mode (Normal)
- On receiving an impulse on jack input 1 or wirelessly via WIRC 1, the running time
starts.
- On receiving an impulse on jack input 2 or wirelessly via WIRC 2, the time taken is
displayed.
b) No sequenced mode (Any Inputs)
- Starts and Finish actions are triggered by any Inputs or WIRC.
Besides Start/Finish impulse acquisition, jack inputs 1 & 2 have two other alternate functions
when using Radio inputs:
Alternate Function Short pulse Long pulse
1 Block/UnBlock
WIRC 1 or 2 Impulses Reset sequence
2 Block/UnBlock
WIRC 1 and 2 Impulses Reset sequence
- The Result is displayed for a predefined duration (or permanently) as per the user selected
parameter.
- Jack and Radio Inputs 1&2 lock time (delay time frame) can be changed.
- WIRC wireless photocells 1 & 2 can be paired to MLED-CTRL using the Menu buttons or via
our setup Apps.
- The running time / time taken can be any color pre-defined by the user.
MLED-CTRL Box User manual
December 2021 - Version EN 1.2
www.fdstiming.com
2.4. Speed trap Mode
Speed mode is a simple yet accurate mode of displaying speed between 2 positions or
inputs.
This mode works either with the external Jack inputs 1 & 2 (via a manual push button), or
with WIRC (wireless photocells) signal.
Distance measured, speed color and unit displayed (Km/h, Mph, m/s, knots) and can be
configured manually using the Menu Buttons or via our setup Apps.
Two input sequence modes are available:
a) Sequenced mode (Normal)
- On receiving an impulse on jack input 1 or wirelessly via WIRC 1, start time is recorded
- On receiving an impulse on jack input 2 or wirelessly via WIRC 2, finish time is
recorded. Speed is then calculated (using the time difference and distance) and
displayed.
b) No sequenced mode (Any Inputs)
- Start and Finish time stamps are triggered by impulses coming from any Input or WIRC.
- Speed is then calculated and displayed.
Besides impulse generation, jack inputs 1 & 2 have two other alternate functions when using
Radio inputs:
Alternate Function Short pulse Long pulse
1 Block/UnBlock
WIRC 1 or 2 Impulses Reset sequence
2 Block/UnBlock
WIRC 1 and 2 Impulses Reset sequence
- The speed is displayed for a predefined duration (or permanently) user selectable parameter.
- Jack and Radio Inputs 1&2 lock time (delay time frame) can be changed.
- WIRC wireless photocells 1 & 2 can be paired to MLED-CTRL using the Menu buttons or via
our setup Apps.
MLED-CTRL Box User manual
December 2021 - Version EN 1.2
www.fdstiming.com
2.5. Counter Mode
- This mode works either with the external Jack inputs 1 & 2, or with WIRC signals.
- User can chose between 1 or 2 counters and several predefined counting sequences.
- For single counter, Jack input 1 or WIRC 1 is used for counting up and Jack input 2 or WIRC
2 for counting down.
- For dual counter, Jack input 1 or WIRC 1 is used for Counter 1 count up and Jack input 2 or
WIRC 2 for Counter 2 count down.
- Depressing and holding for 3 seconds a jack input will reset the corresponding counter to
its initial value.
- All parameters as inputs lock time, initial value, 4 digits prefix, counter color can be set
using the Menu Buttons or via our setup Apps.
- WIRC 1&2 can be paired using the Menu Buttons or via our setup Apps.
- Settings allow the possibility to hide the leading ‘0’.
- If RS232 protocol is set to “DISPLAY FDS”, then each time the counter is refresh, a Display
frame is send on the RS232 port.
2.6. Count-Down Mode
- This mode works either with the external Jack inputs 1 & 2, or with WIRC signals.
- Jack input 1 or WIRC 1 is used to start/stop the countdown.
- Jack input 2 or WIRC 2 to reset it to its initial value.
- All parameters as inputs lock time, initial value and counter color can be set using the
Menu Buttons or via our setup Apps.
- WIRC 1&2 can be paired using the Menu Buttons or via our setup Apps.
- Settings allow the possibility to hide the leading ‘0’.
- Text color can be defined for 3 segments.
Segment 1 starts at the initial counter value.
Segments 2 and 3 threshold are defined by the user.
- A beep is generated 10 seconds before the end of countdown, then from 5 seconds: 1 beep
every second. Reaching zero a long beep with higher tone is generated.
- After a reset, the pre-defined counter value can either be displayed right away or hidden
until the next start.
- A time frame is sent on the RS232 port when the counter reach zero.
MLED-CTRL Box User manual
December 2021 - Version EN 1.2
www.fdstiming.com
2.7. Start-Clock Mode
This mode enables MLED Display to be used as a fully configurable start clock.
Different layouts with traffic lights, count-down value and text, can be selected according to
the user defined selections.
External Jack inputs 1 & 2 control the start/stop and reset functions. Full control is also
possible from our iOS App.
Guide line for a proper countdown sequence setting:
** For reference: TOD = Time of Day
1. Select whether a manual countdown or automatic start at a defined TOD value is
required. If TOD is selected, countdown will start before TOD value in order to reach zero
at the selected TOD.
2. Set the number of countdown cycles. If more than one cycle, the interval between cycles
has also to be defined. For proper operation, the interval value must be greater than
the sum of the countdown value and the « End of countdown time ». A value of ‘0’
means infinite number of cycles.
3. Set the countdown value, initial color and color change threshold, as well as audible
beep if required.
4. Select the desired countdown layout (see description below).
5. According to the selected layout, all other relevant parameters should be configured.
Before countdown:
After initial power-up, the display enters a “wait for synchro” state. The default synchro is
defined in the settings. Other synchronization methods can be initiated via our IOS
Application. Once the synchro completed, the state changes to “wait for countdown”.
According the selected parameters, the Countdowns will either be started manually or
automatically at a predefined time of day.
During the “wait for countdown” state, a predefined message can be displayed on the upper
and lower lines as well as TOD.
During countdown:
Depending on the selected layout, information like countdown value, lights and text will be
displayed. Countdown value and traffic light color will changes according to the following
rules:
When the countdown starts, the main color is defined by the parameter « Countdown
Color ».
Up to 3 color sectors can be defined. When the countdown reaches the time defined in a
sector, the color changes according to the sector definition. Sector 3 has priority over
sector 2 which has priority over sector 1.
Countdown will stop at the value defined by the parameter « Countdown end time» its
value can be set from 0 to 30sec after countdown reaches 0.
When the countdown reach zero, a time frame is sent on the RS232 together with a
synchro pulse.
When the countdown end time is reached, the TOD is displayed until the next
countdown.
MLED-CTRL Box User manual
December 2021 - Version EN 1.2
www.fdstiming.com
3 audio beeps can be programmed independently. A threshold for continuous beeps (every
second) can also be defined. Continuous beeps will sound until countdown reaches zero (0
will have a higher pitch and longer duration tone).
In some Layouts a text can be displayed during and at the end of the countdown. For
example “GO”
2.7.1. Parameters
Countdown layouts:
A) Counter only
Full size Countdown value is displayed.
B) Counter and text
Full size countdown value is displayed until it reaches zero. On reaching zero a Text is displayed
instead.
C) 5 Lights Off
Initially full size countdown value is displayed. At value = 5, five full traffic lights replace the value.
Traffic light colors are is defined according to the sectors definition. Every second a light is turned
off. At zero, all lights are turned back according to the sector’s color.
D) 5 Lights On
Initially full size countdown value is displayed. At value = 5, five empty traffic lights replace the
value. Traffic lights color is set according to the sectors definition. Every second a light is turned on
until zero is reached.
E) Cnt 2 Lights
Full size countdown value is displayed (max 4 digits) as well as 1 traffic light on each side.
F) Cnt Text 2 Lights
Full size countdown value is displayed (max 4 digits) as well as 1 traffic light on each side. When
zero is reached a text replaces the countdown.
G) TOD Cnt
Time of day is displayed on the upper left side.
A full size Countdown value is displayed (max 3 digits) on the right side.
H) TOD Cnt 5Lt Off
Time of day is displayed on upper left side.
A full size Countdown value is displayed (max 3 digits) on the right side.
When the countdown reaches 5, five full small traffic lights appear on the bottom left side under
the TOD. Light colors are set according to the sectors defined. Every second a light is turned off. At
zero, all lights are turned back on with sector’s color.
I) TOD Cnt 5Lt On
Time of day is displayed on upper left side.
A full size Countdown value is displayed (max 3 digits) on the right side.
When the countdown reaches 5, five empty small traffic lights appear on the bottom left side
under the TOD. Light colors are set according to the sectors defined.
Every second a light is turned On until zero is reached.
MLED-CTRL Box User manual
December 2021 - Version EN 1.2
www.fdstiming.com
J) 2 Lines Text Cnt
During countdown, the value is displayed on the bottom line with traffic lights on each side. The
upper line is filled out with a user defined text.
When the countdown reach zero, the upper line changed to a second user defined text, and the
countdown value on the bottom line is replaced by a third text.
K) Bib TOD Cnt
Time of day is displayed on upper left side.
A full size Countdown value is displayed (max 3 digits) or the right.
The bib number is displayed on the bottom left side under the TOD.
At the end of each cycle, the next Bib value is selected. The Bib list can be downloaded into the
display via the IOS app. It is also possible to enter manually on the fly each Bib with the app.
Start CntDown mode: Manual start or start at defined TOD
Manual start sync: Manual start can be defined to start at the next 15s, 30s or 60s. If 0 is set
the countdown start immediately
Cycles number: Number of countdown cycles performed automatically once the first is
started (0 = non stop)
Cycles time interval: Time between each countdown cycle
This value must be equal or greater than the “countdown value” plus the
“end of countdown time”
Countdown value: Countdown time in seconds
Countdown color: Initial color for countdown
Sector 1 time: Start of sector 1 (compared to countdown value)
Sector 1 color: Color of sector 1
Sector 2 time: Start of sector 2 (compared to countdown value)
Sector 2 color: Color of sector 2
Sector 3 time: Start of sector 3 (compared to countdown value)
Sector 3 color: Color of sector 3
End of Countdown: Time at which a countdown cycle is completed. Value goes from 0 to -
30sec. Sector 3 color is used
Beep 1 time: Countdown time of the first beep (0 if not used)
Beep 2 time: Countdown time of the second beep (0 if not used)
Beep 3 time: Countdown time of the third beep (0 if not used)
Continuous Beep: Countdown time at which a beep is generated every second until zero is
reached
For Layouts (B, F, J)
Final Text down: Text displayed in the center when countdown reaches zero
For Layout (J)
Up text CntDwn: Text displayed on upper line during countdown
Up text at 0: Text displayed on upper line when countdown reaches zero
Up text CntDwn color: Upper line text color during countdown
Up text at 0 color: Upper line text color when countdown reaches zero
MLED-CTRL Box User manual
December 2021 - Version EN 1.2
www.fdstiming.com
3. Menu & Settings
Display and Mode parameters can be defined via 2 different methods.
a) Navigating the display integrated menu using the onboard display push buttons
b) Using our iOS application
c) Using our PC application
3.1. Display Menu hierarchy
To enter the display menu, press the illuminated orange button for 3 seconds.
Once in the menu use the illuminated Green button to navigate through the menu and the
illuminated Orange button to make a selection.
Depending on the mode selected or activated options status some menu items may be not visible.
Main menu:
- MODE SETTINGS (Define the parameters of the selected mode)
- MODE SELECTION (Select a mode. Some modes need to be activated first with a code from your supplier)
- GENERAL SETTINGS (Display general settings)
- EXT INPUTS (Parameters of the 2 external inputs – Jack connectors)
- RADIO (Radio settings and WIRC wireless photocell pairing)
- EXIT (Leave the menu)
General Settings:
- DISP INTENSITY (Change the default display intensity)
- BIG FONTS (change the full height fonts)
- RS232 PROTOCOL (Select the RS232 output protocol)
- RS232 BAUDRATE (Select the RS232/RS485 baud rate)
- GPS STATUS (Display the GPS status)
- LICENSE CODE (Enter a license code to activate additional modes)
- EXIT (Leave the menu)
Mode Selection:
- USER CONTROL (Standard display mode to be used with iOS App or RS232 connection)
- TIME/TEMP/DATE (Display the time of date, time or temperature or all three scrolling)
- START/FINISH (Start / Finish - With running time)
- SPEED (Speed trap)
- COUNTER (Input 1 increments Counter, Input 2 decrements Counter, reset with Input2 long press)
- COUNTDOWN (Count Down Start/Stop with Input 1 impulse, reset with Input2)
- EXIT (Leave the menu)
Mode Settings (Display Mode)
- LINES ADDRESS (Set the line number for each zone)
- LINES COLOR (Set the color of each zone)
- EXIT (Leave the menu)
MLED-CTRL Box User manual
December 2021 - Version EN 1.2
www.fdstiming.com
Mode Settings (Time / Temperature & Date Mode)
- DATA TO DISP (Select what to display : temp, time, date)
- TEMP UNITS (Change the temperature unit °C or °F)
- TIME COLOR (Color of the Time value)
- DATE COLOR (Color of the Date)
- TEMP COLOR (Color of the Temperature)
- TOD HOLD COLOR (Color of the Time value when on hold by input 2)
- TOD HOLD TIME (Set the TOD holing duration)
- SYNCHRO (Re Synchronize the clock – Manual or GPS)
- EXIT (Leave the menu)
Mode Settings (Start/Finish Mode)
- DISP HOLDING TIME (set the time the information is displayed. 0 = always displayed)
- COLOR (Color of Running time and result)
- TIME FORMAT (Format of the time displayed)
- INPUTS SEQUENCE (Select the inputs sequence mode : Standard / Any Inputs)
- INPUT 1 FCN (Function of Input 1 : Std input / Auxiliary FCN 1 / Auxiliary FCN 2)
- INPUT 2 FCN (Function of Input 2 : Std input / Auxiliary FCN 1 / Auxiliary FCN 2)
- PRINT SETTINGS (Print the settings if RS232 Protocol is set to Printer)
- PRINT RESULTS (Print the time result if RS232 Protocol is set to Printer)
- EXIT (Leave the menu)
Mode Settings (Speed Mode)
- DISTANCE (Set the distance)
- DISTANCE UNITS (Select the distance unit – meters or feet)
- SPEED UNITS (Select the speed unit – Km/h, Mph, m/s or Knots)
- DISP HOLDING TIME (set the time the result is displayed. 0 = always displayed)
- COLOR (Color of the speed value)
- INPUTS SEQUENCE (Select the inputs sequence mode : Standard / Any Inputs)
- INPUT 1 FCN (Function of Input 1 : Std input / Auxiliary FCN 1 / Auxiliary FCN 2)
- INPUT 2 FCN (Function of Input 2 : Std input / Auxiliary FCN 1 / Auxiliary FCN 2)
- PRINT SETTINGS (Print the settings if RS232 Protocol is set to Printer)
- PRINT SPEEDS (Print the time result if RS232 Protocol is set to Printer)
- EXIT (Leave the menu)
Mode Settings (Counter Mode)
- DUAL COUNTER (selection between 1 and 2 counters)
- COUNTER SEQUENCE (counting sequence : 0-9999, 0-999, 0-99, 0-15-30-45, 0-1-2-X )
- INITIAL VALUE (Initial counter value after reset)
- COUNTER PREFIX (Prefix displayed before the counter – 4 digits max)
- LEADING 0 (Leave or remove the leading ‘0’)
- PREFIX COLOR (Color of the prefix)
- COUNTER 1 COLOR (Color of the counter 1)
- COUNTER 2 COLOR (Color of the counter 2)
- EXIT (Leave the menu)
Dieses Handbuch passt für folgende Modelle
3
Inhaltsverzeichnis
Andere FDS Datenlogger Handbücher
