FE Technologies V5 Bedienungsanleitung

V5 Self Loan Station

Architect Pack


This document is supplied as ‘Commercial In Confidence’ business documentation. The contents of this document
may not be released to a third party without prior consent of FE Technologies or its authorised representatives.
User Documentation © FE Technologies 2017 Issue No. 1.0 2

RFID your way



Table of Contents
System Features ........................................................................................................ 3
Exclusion Zones ......................................................................................................... 4
InstallationOptions.................................................................................................... 4
Children’s Height Self Loan Station................................................................................ 5
PhysicalDimensions................................................................................................... 6
Footprint ................................................................................................................... 8
Benchtop.................................................................................................................. 9
SystemRequirements............................................................................................... 10
Powersupply ........................................................................................................... 10
Network connection .................................................................................................. 10
Cableinlet options.................................................................................................... 10
Free standing Self Loan Station................................................................................... 10
Desktop Self Loan Station and wall mount .................................................................... 10
Free standing against the wall .................................................................................... 10
Environmentalspecifications .................................................................................... 10
InstallationRequirements ........................................................................................ 11
Clearances.............................................................................................................. 12
Levelling ................................................................................................................ 12
Wallmount ............................................................................................................. 12
InstallationResponsibilities...................................................................................... 14
The library’s responsibilities ....................................................................................... 14
Structural works ...................................................................................................... 14
Electrical connection ................................................................................................. 14
Network connection .................................................................................................. 15
FE Technologies’ responsibilities .................................................................................. 15
EM/RFID Hybrid V5 Self Loan Station ....................................................................... 16
Front: ................................................................................................................... 16
View of the unit from above: ................................................................................. 17
Base Plate: ........................................................................................................... 18


This document is supplied as ‘Commercial In Confidence’ business documentation. The contents of this document

may not be released to a third party without prior consent of FE Technologies or its authorised representatives.

User Documentation © FE Technologies 2017 Issue No. 1.0 3

RFID your way

System Features

The FE Technologies V5 Self Loan Station is a modern, state-

of-the-art system that can be used by library patrons to borrow

and return items, unlock media cases, check their borrowing

status and renew items.

The system has the following features:

•Blended customisable LED Halo

•Portrait oriented 23” touchscreen featuring SAW (Sound

Acoustic Wave) technology, able to list 20 items at a

time on one screen

•The ability to checkout up to 15 items at a time

•Integrated printer

•Integrated CCD barcode scanner, capable of scanning barcodes from library cards, mobile

phones and QR codes.

•Slim design with large robust tabletop

•Optional integrated DVD Unlocker, compatible with OneTime™ lockable DVD cases

•Optional integrated coin acceptor

•Optional Integrated EFTPOS payment facility

•Separate floor mounting plate for ease of installation

•Customer changeable table top insert

•AS/NZS1428 compliant.

This document is supplied as ‘Commercial In Confidence’ business documentation. The contents of this document

may not be released to a third party without prior consent of FE Technologies or its authorised representatives.

User Documentation © FE Technologies 2017 Issue No. 1.0 4

RFID your way

Exclusion Zones

The Self Loan Station can be affected if placed too close to a Smart Bin, Smart Shelf or a

Security Gate. Please see the Smart Bin, Smart Shelf and Security Gate Architect Information

Packs for details on the exclusion zones of these products.

Installation Options

The V5 Self Loan Station can be installed as free standing, leaning on a wall, desktop, back to

back or wall mounted.

Note that all required access to the unit (librarian administrative access, such as changing

receipt roll, and FE Technologies technician access to the internals of the hardware) is

performed via the front of the unit, allowing the unit to be installed against a wall or back to

back without requiring the unit to be moved at any time for service or maintenance.

Please note that the wall mount option requires special mounting hardware at additional

cost. The wall also needs to meet specific structural requirements. If you intend to mount the

Self Loan Station to a wall, please contact FE Technologies for more details.

Below –standalone, wall-mount and desktop installations.

This document is supplied as ‘Commercial In Confidence’ business documentation. The contents of this document

may not be released to a third party without prior consent of FE Technologies or its authorised representatives.

User Documentation © FE Technologies 2017 Issue No. 1.0 5

RFID your way

Children’s Height Self Loan Station

The V5 Self Loan Station is also available with a shortened pedestal –this version is identical to

the standard V5 Self Loan Station except it has a reduced height of the tabletop –from 806mm

to 695mm.

This document is supplied as ‘Commercial In Confidence’ business documentation. The contents of this document

may not be released to a third party without prior consent of FE Technologies or its authorised representatives.

User Documentation © FE Technologies 2017 Issue No. 1.0 6

RFID your way

Physical Dimensions

Note: all dimensions are in millimetres.

This document is supplied as ‘Commercial In Confidence’ business documentation. The contents of this document

may not be released to a third party without prior consent of FE Technologies or its authorised representatives.

User Documentation © FE Technologies 2017 Issue No. 1.0 7

RFID your way

This document is supplied as ‘Commercial In Confidence’ business documentation. The contents of this document

may not be released to a third party without prior consent of FE Technologies or its authorised representatives.

User Documentation © FE Technologies 2017 Issue No. 1.0 8

RFID your way

Footprint

Note that the holes indicated as "Dynabolt" are where the base plate is fastened to the floor, not

the mounting posts themselves.

This document is supplied as ‘Commercial In Confidence’ business documentation. The contents of this document

may not be released to a third party without prior consent of FE Technologies or its authorised representatives.

User Documentation © FE Technologies 2017 Issue No. 1.0 9

RFID your way

Benchtop

This document is supplied as ‘Commercial In Confidence’ business documentation. The contents of this document

may not be released to a third party without prior consent of FE Technologies or its authorised representatives.

User Documentation © FE Technologies 2017 Issue No. 1.0 10

RFID your way

System Requirements

Compliance with the following specifications will help ensure that the system performs as

designed.

Power supply

The Self Loan Station requires a standard 10AMP electrical point. A cable of 1.5m in length and

terminating in a standard three pin plug is supplied.

Power input: 240 V AC 50/60 Hz, 1.5 A max.

Power usage: 100W

Network connection

The V5 Self Loan Station requires a network point. The network cable inlet is via an opening in

the bottom rear of the stand. A cable of 1.5m in length is supplied.

Cable inlet options

Free standing Self Loan Station

There are three cable inlet openings at the lower rear of the Self Loan Station.

It is also possible to use under floor power and network points by threading the cables through

the base plate.

Desktop Self Loan Station and wall mount

There is one cable inlet opening at the lower left back corner of the Self Loan Station.

Free standing against the wall

There is a large opening in the lower pedestal allowing the internal exposure of a power point

and network point when installed at a compatible position.

Environmental specifications

Operating/storage temperature: 0°C to 40°C.

Operating/storage humidity: 0% to 85% (relative humidity, non-condensing).
