TECHNICAL BOOK

MDS SKYLINE DIGITISER REF. 2460

97694 I. V11_12

MDS DIGITIZER REF. 7460

+ - D1 D2 2 6

B -

PAG. 2PAG. %p

GENERAL INDEX

DESCRIPTION OF THE MDS DIGITISER REF. 7460--------------------------04

PROGRAMMING-------------------------------------------------------------------------10

EXAMPLES OF CHANNELING DIAGRAMS-------------------------------------21

GENERAL ENTRANCE DIAGRAMS -----------------------------------------------27

INTERIOR BLOCKS DIAGRAMS ---------------------------------------------------37

FLOOR DIAGRAMS --------------------------------------------------------------------51

PAG. 3

indice

The MDS DIGITISER Ref. 7460) is a device in the SKYLINE family, with the purpose of being able to configure

both MDS CITY and MDS DIRECT panels, since the device allows for both configurations.

It works in combination with both the keypad SKYLINE MODULES (Reference 7439) and buttons module (References

7371, 7372, 7376, 7367, 7368 and 7375), and even allows for both types of modules. Call extension modules are

not required.

The amplifier module to use for these types of panels is the 4+ n Amplifier Module Video Ref. 7406, for video door

entry systems, or the 4+n Amplifier modules Audio Ref. 7400 for door entry panels.

Both the MDS GENERAL ENTRANCE and INTERIOR BLOCK panels can be configured, and can be combined

with VDS panels to configure systems with the MDS GENERAL ENTRANCE combined with VDS.

This module is also integrated in the MDS DIRECT panels with continuous profile, Ref. 7287 (vídeo) and Ref. 7286

(audio).

It implements a OneToOne front panel, that provides visual information to each of the operating status (calling,

conversation, door open and system busy).

1. Call indicator. Lights up after a call is made.

2. "In conversation" indicator. Lights while a call is in process.

3. "Open door" indicator. Indicates that the door is opening.

4. "System busy" indicator. Indicates that another panel is in

use.

5. Programming display. To help programming.

6. Acoustic volume indicators regulator

7. CN1 Connector. Amplifier connections (*)

8. CN2 Connector. Button and/or Keyboard Module Connections

(*).

9. Installation connections block. MDS output

10. S Button (black). For programming

11. P Button (red). For programming

12. MDS input on the panels back. If available (*).

13. Audio switch. In order to manually enable the audio with

decoders.

DESCRIPTION OF THE SKYLINE MODULE REF. 7460

INTRODUCTION

(*) Module Ref. 7460 comes with the required cables for pre-assembly on the panel.

DESCRIPTION OF THE MDS DIGITISER REF. 7460

MDS DIGITIZER REF. 7460

+ - D1 D2 2 6

B -

1234

PAG. 4

ASSEMBLY OPTIONS

*Calls to residences are made by pressing the corresponding call button.

* You can program the phones both sequentially and individually (or

MDS/VDS decoders) for the MDS installations with the VDS).

* You can inversely program the buttons,that is, assign a button to an

already programmed telephone.

*The general parameters may not be configured, even though you can

check the status of said configuration.

*The maximum number of modules to insert depends on the systems

limitation (9999 terminals for MDS installations).

* You can "reset buttons," that is, put all buttons to a default configuration

(with the code "0000"). This is useful if you do not know the current

programming status, and want to start from a known configuration.

*Calls to residences are made by pressing the corresponding telephone

number on the keypad.

* You can program all of the system's configuration parameters.

* You program the telephones and decoders and change the number of a

specific telephone individually.

* You can also open the door by entering a 4 digit code. Even though to

activate this code for the first time you need to access the back of the

panel. You can change it from the keypad itself (without dismounting the

wall panel). This function can be deactivated from the keypad itself. This

way to activate it again, you must access the back of the panel.

* You can restore the system to night mode, in which case you need to put

it in this mode and then it isn't available or accessible at the Central Guard

Unit.

* You can reset the system's configuration parameters to default. This is

useful if want to start from a known status.

Depending on the modules it is combined with (keypad, buttons or both), the Digitiser offers different features.

BUTTON ONLY PANELS

KEYPAD ONLY PANEL

DESCRIPTION OF THE MDS DIGITISER REF. 7460

MDS DIGITIZER REF. 7460

+ - D1 D2 2 6

B -

AMPLIFICADOR 4 + N

4+N AMPLIFIER

AMPLIFICATERU 4+N

4 + N VERSTARKER

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

MDS DIGITIZER REF. 7460

+ - D1 D2 2 6

B -

AMPLIFICADOR 4 + N

4+N AMPLIFIER

AMPLIFICATERU 4+N

4 + N VERSTARKER

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

PAG. 5

*Calls to residences are made by pressing the corresponding telephone

number on the keypad.

You can also make a call to one or more of the homes via the corresponding

button, if assigned to a residence, since you can also assign telephone

numbers to buttons.

This is useful, for example, if you want certain homes, offices or shops

to be able to receive calls directly (via the button), instead of dialling a

numeric code.

*Assigning a telephone number to a button is done on the keypad itself,

not needing to access the residence.

*Just like on the keypad only panels, you can program all of the system's

configuration parameters and you can also reset the parameters and

buttons.

This configuration is basically the same as the previous one (button module/modules "before" the keypad). The only

difference is aesthetic.

KEYPAD + BUTTONS PANEL (keypad "before" the buttons)

DESCRIPTION OF THE MDS DIGITISER REF. 7460

BUTTONS + KEYPAD PANEL (buttons "before" the keypad)

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

MDS DIGITIZER REF. 7460

+ - D1 D2 2 6

B -

AMPLIFICADOR 4 + N

4+N AMPLIFIER

AMPLIFICATERU 4+N

4 + N VERSTARKER

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

OUTPUT

AMPLIFICADOR 4 + N

4+N AMPLIFIER

AMPLIFICATERU 4+N

4 + N VERSTARKER

MDS DIGITIZER REF. 7460

+ - D1 D2 2 6

B -

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

VDS/BUS2

CN1

INPUT

CN2

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

VDS/BUS2

CN1

INPUT

OUTPUT

CN2

PAG. 6

TECHNICAL FEATURES

The MDS Digitiser is an auxiliary device that allows you to configure a SKYLINE panel to be integrated in the MDS

DIGITAL installations or combinations of MDS DIRECT with MDS CITY or VDS.

The configuration of the mode in which it should function (GENERAL ENTRANCE or INTERIOR BLOCK), is done

via a simple programming after the system installation, keeping in mind the installation's characteristics, and in

which no tool or special equipment is required.

The following table specifies the limitations of each of the possible combinations:

The main technical characteristics of the MDS Digitiser are as follows:

*Programming via 2 buttons. With a digital display of 4 digits that help programming. This allows for the

programming of MDS DECODERS, MDS/VDS DECODERS when programming and changing already programmed

telephone numbers.

*Activation time of the lock release is programmable between 1 and 99 seconds, and indistinctly for the opening

from homes or from the button inside the entrance hall.

GENERAL ENTRANCES INTERIOR BLOCKS LIMITS

Observations:

* You can not configure the MDS DIGITAL combined with the Digitiser configured as GENERAL ENTRANCE,

since the management of the general entrances is done via the MDS Central Unit via the panel bus.

* "If the installations with MDS Digitiser that are not developments (only one block), the limit is 5 accesses and

9999 homes.

DESCRIPTION OF THE MDS DIGITISER REF. 7460

MDS DIGITAL

- 32 accesses to the General Entrance and/or DIGITAL

Guard Units.

- 99 interior blocks

- 99 telephones per block

Panel with Digitiser, configured

as an INTERIOR BLOCK.

Panel with Digitiser,

configured as GENERAL

ENTRANCE

- 5 accesses of MDS DIRECT General Entrance.

- 1 MDS DIRECT Guard unit

- 99 interior blocks. 9 accesses per block.

- 99 telephones per block

Digitiser panel, configured as

INTERIOR BLOCK

Digitiser panel, configured

as a GENERAL

ENTRANCE VDS Panel

- 5 accesses of MDS DIRECT General Entrance.

- 1 MDS DIRECT Guard unit (general)

- 1 VDS guard unit per each block (local)

- 99 interior blocks. 2 accesses per block

- 199 telephones per block (installations up to 9

blocks).

- 99 telephones per block (installations from 10 to

99 blocks)

- installations up to 9999 individual homes

PAG. 7

Digitiser general connections:

BUS OUTPUT

(to next panel or decoders)

+, - :Power supply 12 Vdc.

D1, D2: MDS BUS

2, 6: Audio

S: Video exchange control

B, - : Door Open Button

to the switcher's "S"

(if the panel is video)

Inside door open button

(optional)

For more details, see corresponding installation diagram.

BUS ENTRY from the

previous panel (if available).

* Maximum and minimum programmable conversation time according to the following sections:

SECTION 1: Maximum time = 60 seconds. Minimum time = 16 seconds

SECTION 2: Maximum time = 120 seconds. Minimum time = 32 seconds

SECTION 3: Maximum time = 180 seconds. Minimum time = 48 seconds

*Dynamic start-up routine: this automatically detects the type of modules (keypad and/or buttons) connected,

and adjusts the menu accordingly, since they are different depending on whether it is a button, keypad or mixed

panel.

TECHNICAL SPECIFICATIONS

- Power supply: 12 Vdc/ 150 mA (max)

- BUS: MDS FERMAX protocol on RS-485

- Operating temperature: -10º C, +40º C

- IP=43; IK=05

DESCRIPTION OF THE MDS DIGITISER REF. 7460

+, - , D1, D2, 2, 6

MDS DIGITIZER REF. 7460

+ - D1 D2 2 6

B -

+ - D1 D2 2 6

S B -

PAG. 8

START-UP ROUTINE

The MDS Digitiser has a start-up routine that allows the installer to verify if the modules connection has been

properly made, otherwise, if there is a problem with the connections, and the information on the incorporated

firmware version.

After powering it, the front display shows the firmware version and then indicates the type of modules detected and

their order, that is, the first information indicates what type of module is connected directly to the Digitiser, and the

following information indicates the next one's or module's type.

If no module is detected (due to a failure or if not connected), this routine will continue to repeat, until one is detected.

The digitiser's front indicators blink and the display only indicates the firmware version and the "Err" (error).

The type or types of modules detected will determine the panel's operating mode (MDS DIRECT, MDS CITY or

mixed). The following diagram schematically represents this start-up routine:

RESTORING DEFAULT SETTINGS

You can reset the Digitiser's configuration to its default values. This is useful, for example, if you don't know the

mode it's configured in and want to start from a known value.

The default configuration values are as follows:

- Panel number: 01

- Block number: 00

- Lock-release activation time (when opened from the residence): 3 seconds.

. Lock-release activation time (when opened from the entrance hall's button): 6 seconds

- Conversation time. Max.: 60 seconds. Min: 16 seconds

- NIGHT MODE Panel.

This operation can only be performed on panels with the keypad module, or those provisionally connected to one.

The steps for restoring are to power the system and enter "A-7-0-8-BELL-9" on the keypad in less than 1 minute's

time.

DESCRIPTION OF THE MDS DIGITISER REF. 7460

Before 1 minute

Button module/s detected

This is repeated as long as no module is detected

(keypad and/or buttons) connected to the Digitiser

The indicators blink

Keypad detected

Buttons + keypad module/s detected

No buttons or keypads detected

Version of the

Digititiser (1.0) Keypad + button module/s detected

708 9

PAG. 9

The MDS systems that have some type of Central Guard Unit may function in DAY MODE: The calls from the street

panels to the homes are only received in the Guard unit, or in NIGHT MODE, the calls are received in the homes.

Changing from one mode to another is done from the Central Guard Unit.

Asystem may be configured in DAY MODE, and not be able to make the change to NIGHT MODE, since the Central

Guard Unit isn't available or accessible. In this situation, the calls are not received in the homes, but are forwarded

to the Central Guard Unit (even if the central is not physically connected).

From the panel with Digitiser you can restore the NIGHT MODE panel and then allow for calls to homes.

This operation is only done via the panels with keypad module, or provisionally connected to a module.

The procedure is the following:

- Press the "A" key

- Mark the sequence "3 - 1 - 4 - 1"

- Mark the sequence "0 -0 -0 -0" (twice).

This resetting can also be done via the programming. See the SYSTEM PROGRAMMING section.

RESTORING NIGHT MODE

OPENING THE DOOR WITH THE PIN

The panels with keypad module have the front entrance door open function via a general 4-digit PIN. Upon entering

this code via the keypad, you can open the door.

This code is programmed and active via the SYSTEM PROGRAMMING (see the corresponding section), even

though it can be changed later from the keypad itself. It can be deactivated as well. To activate and program again,

you need to do so via the SYSTEM PROGRAMMING, that is, accessing the front part of the panel.

The way to open the door via the PIN is as follows:

- Press the A key

- Mark the PIN code. The "door" icon on the digitiser's front OneToOne is lit.

The procedure for changing the code via the keypad is as follows:

XXXX: Current code

DESCRIPTION OF THE MDS DIGITISER REF. 7460

3141 0000 0000

XXXX

PAG. 10

Inhaltsverzeichnis

Andere Fermax Steuereinheit Handbücher

Fermax

Fermax 5293 Benutzerhandbuch

Fermax

Fermax 2911 Bedienungsanleitung

Fermax

Fermax SKYLINE LYNX DUOX Benutzerhandbuch

Fermax

Fermax VDS PULL UP Kurzanleitung

Fermax

Fermax CITYLINE 4+n Bedienungsanleitung

Fermax

Fermax MEET 1490 Benutzerhandbuch

Fermax

Fermax CITYMAX 2498 Bedienungsanleitung

Fermax

Fermax 6030 Bedienungsanleitung

Fermax

Fermax 2440 Bedienungsanleitung

Fermax

Fermax OneToOne Benutzerhandbuch

Fermax

Fermax 4 + n Benutzerhandbuch

Fermax

Fermax 2426 Bedienungsanleitung

Fermax

Fermax 8819 Bedienungsanleitung

Fermax

Fermax LYNX SKYLINE Gebrauchsanweisung

Fermax

Fermax DUOX PLUS 1S Bedienungsanleitung

Fermax

Fermax AMPLIFIER MODULE CITYMAX Bedienungsanleitung

Fermax

Fermax OneToOne W/LOOP MODULE Benutzerhandbuch

Fermax

Fermax 2441 Bedienungsanleitung

Fermax

Fermax 2008 Bedienungsanleitung

Fermax

Fermax DUOX Bedienungsanleitung

Fermax

Fermax LOFT BUS2 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
