iLOFT TELEPHONE OPERATION

RedLED

GreenLED

BlueLED

MICROPHONE

Buttons

PotentiometerButtons

Lock Release / Call Guard Unit Button

Pressing this button activates the lock-release. The door can be opened at any

time.

When you press this button with the telephone on the hook, a call will be made to the

guard (*where one exists).

Audio activation, hang up and auto-start button.

On receiving a call the user has 30 seconds to answer. The blue led flashes

during this time to indicate a call waiting.

· Audio activation: when a call is received, press and release this button to speak

to the visitor. The audio channel between the entry panel and the residence is

opened; operating in hands-free mode. The blue led will remain on indicating

that a conversation with the entry panel is underway.

· Hang-Up: press to end communication, if not the conversation will be

disconnected after 90 seconds. Once disconnected the blue led will turn off.

· Auto-start (main panel): on standby, press and release this button (the blue led

lights up).

Note:

- The conversation is private, no other terminal can hear it.

- «Handsfree» mode is default mode.

- While the audio channel is open the input audio can be regulated with the

potentiometer, without affecting the call volume. The selected setting will not be

altered if the call volume is subsequently adjusted.

- If the channel is busy an error tone «BEEP» will be generated and auto-start will not

activate.

- If the telephone is configured in «simplex mode», (press to speak and release to

listen), the audio channel will be activated to hear sound at street level.

- The auto-start function is always used on the main panel except where a call is

received on the secondary panel. Once the conversation is over auto-start will

activate on the secondary panel for 30 seconds. After this time it will activate on the

main panel.

- During the conversation «handsfree» can be adjusted to «simplex mode».

Page 16

iLiL

iLOFTOFT

OFTOFT

OFT TT

Teleele

eleele

elephonephone

phonephone

phone

iLiL

iLOFTOFT

OFTOFT

OFT TT

Teleele

eleele

elephonephone

phonephone

phone

F1: Button for Additional Functions.

No function in this model.

Led Signals

Green Led

slow intermittent

Blue Led

very slow intermittent

rapid intermittent

constant

slow intermittent

constant

STATUS (Telephone)

Not programmed

Standby

Call

Handsfree audio

Output Audio (simplex mode)

Input Audio (simplex mode)

Do not Disturb

Auto Opening (Doormatic)

Select Ringtone Panel 1

Select Ringtone Panel 2

Address Programming

Red Led

constant

slow intermittent

rapid intermittent

constant

AVAILABLEFUNCTIONS

••

•Door Opening and Automatic Door Opening (DOORMATIC)

••

•Call to Guard (where one exists)

••

•Call volume regulation (8 levels)

••

•Call Disconnection (Do not Disturb)

••

•Ringtone Selection (5 options)

••

•Doorbell

••

•Programming via the terminal and via the entry panel

••

•Input audio volume regulation

Page 17

iLiL

iLOFTOFT

OFTOFT

OFT TT

Teleele

eleele

elephonephone

phonephone

phone

iLiL

iLOFTOFT

OFTOFT

OFT TT

Teleele

eleele

elephonephone

phonephone

phone

Operation

Answering a call.

When the call button on the entry panel is pressed a call tone is emitted both from

the entry panel and the telephone.

On receiving a call on the telephone the user has 30 seconds to answer. The blue led

flashes during this time to indicate a call waiting.

· Audio activation: · When a call is received, press and release button to speak to the

visitor.The audiochannel betweenthe entrypaneland theresidenceis opened;operating

in hands-free mode. The blue led will remain on indicating that a conversation with the

entry panel is underway.

· Hang-Up: press to end communication, if not the conversation will be disconnected

after 90 seconds. Once disconnected the blue led will turn off.

· Auto-start (main panel): while on standby, press and release button (the blue led

lights up).

30"¸

While in simplex conversation mode (press the button to speak and release to listen).

When the call button on the Entry Panel is pressed a call tone is emitted both from

the entry panel and the telephone.

On receiving a call on the telephone the user has 30 seconds to answer. The blue led

flashes during this time to indicate a call waiting.

· Press and release the button, the blue led will continue to flash, the input audio will remain

active (you will hear the panel on the telephone).

From this point every time you press the button, the output audio channel will

activate (you will hear the telephone on the panel) and a constant blue led will light up.

On releasing the button the input audio channel will activate (you will hear the panel on the

telephone) and the intermittent blue led will light up.

· Hang-Up: press to end communication, if not the conversation will be disconnected after 90

seconds. Once disconnected the blue led will turn off.

· Auto-start (main panel): with the telephone on standby, press and release this button (short

press), the blue led lights up (indicates simplex mode).

Page 18

iLiL

iLOFTOFT

OFTOFT

OFT TT

Teleele

eleele

elephonephone

phonephone

phone

iLiL

iLOFTOFT

OFTOFT

OFT TT

Teleele

eleele

elephonephone

phonephone

phone

30"¸

audio channel

Entry Panel - Residence audio channel

Residence - Entry Panel

Opening the Door

When a call is received from the entry panel, you can open the

door at any time, by pressing the button

«AutomaticOpening» (DOORMATIC) Mode

With «Automatic Opening» activated, when a call is received from the entry panel, the

lock-release is activated once the ringtone stops.

The open door function is disabled by default. It must be pre-enabled (by the installer),

to be able to be activated by the user.

1. To activate thefunction,youmusthold down

the button and button simultaneously

until you see the green light flashing.

Once this is activated the door will

automatically open when a call is received.

2. To deactivate the function, you must

hold down button and button

simultaneously until you see the green

light turn off.

Important Note:

- The automatic door function CANNOT be activated if it has not be previously enabled.

Page 19

iLiL

iLOFTOFT

OFTOFT

OFT TT

Teleele

eleele

elephonephone

phonephone

phone

iLiL

iLOFTOFT

OFTOFT

OFT TT

Teleele

eleele

elephonephone

phonephone

phone

Canceling the Ring Tone

If during call volume regulation the potentiometer is turned down

to its minimum level, a constant red led will light up to indicate

that the call has been disconnected.

The disconnection option affects all ringtones generated by the

telephone:

To deactivate ringtone cancellation, you must move the

potentiometer above the minimum level. The led will return to its

previous status.

Note:

- The blue led flashes when a call is being received whether

enabled or not.

-Formoreoperating information: See «Call Volume Regulation».

Potentiometer
