Fiio X3 Bedienungsanleitung

X3 User Guide

Be applicable to any versions beyond FW3.0

Preface

Thank you for purchasing our 192k/24bit portable lossless audio player, the X3.

In order to help you better take advantage of the X3 in enjoying music, we specially

designed this user guide and included answers to frequently askedquestions.

Ⅱ

Ⅲ Firmware upgrade

Ⅳ Illustrated guide to menu operation

Ⅴ Detailed literal guide to menu operation

Ⅵ Usage tips

Ⅶ FAQ Center

C. Transferring songs

D. Firmware upgrades

E. External microSD cards

F. Music Playback

G. Other operations

H. Connection with other audio devices

Ⅰ　Introduction

Basic operating instructions

A. Introduction

B. Charging

USB DAC [ Refer to“FiiO X3 User Guide-2(USB DAC)”］

Content

3-5

7-8

9-12

17-18

Ⅰ

The X3 is a high fidelity digital audio player which can support MP2, MP3, WAV,

WMA, APE, FLAC, AAC, ALAC, OGG, AIFF, DSD and other music formats at up to

192k/24bit sample rates, with support for CUE index playback and gapless playback.

It can also function as a USB audio decoder for external digital music sources.

. Product Overview:

Ⅱ. Basic operating instructions

1) 2.4inch TFT Screen (240*320)

13) Coaxial Out 15) Headphone Output

2) TF Card Slot

10) Micro USB Port 11) Line Out Port

12) HOLD

3) Menu/Back

5) Previous/

Downward

Selecting

4) Next

Upward

selecting

6) Vol“-”

7) Vol“+”

8) On/Off/

Play/Pause

9) Charging

Indicator

14) RESET

Rear cover in aluminum material

1. 2.4” TFT screen (240x320):

Displays user interface and related information.

2. Micro SD card slot:

Currently supports micro SD cards with up to 128G capacity.

3. Menu / back:

Short-press：

One short-press: Go back up the menu tree by one step.

Two short-presses: Go back twice.

Long-press:

In Now Playing screen: show Quick menu.

In any other screen: go directly to main menu.

In main menu: Both short-pressing and long-pressing shows the Now Playing

screen (if music is playing).

4. Next / Up, 5. Previous / Down:

In Now Playing screen: short-press Next to go to next song, hold to fast forward.

Short-press Previous to go to previous song, hold to rewind.

In any other screen: press Up to highlight the previous menu item and Down to

highlight the next menu item.

6. Vol“-”; 7. Vol“+”:

Volume is adjustable in and out of the Now Playing interface.

In Now Playing screen: Short-press “-” to decrease volume by one step, hold

to continuously decrease down to zero. Short-press “+” to increase volume

by one step, hold to continuously increase up to maximum.

In menus: If highlighted item is a setting, adjusts highlighted setting directly or

if OK button has been pressed to select setting with “>” mark for adjustment.

Otherwise, adjusts volume as normal.

8. On/Off/Play/Pause:

*On: Hold button for one second to turn on player.

*Off: Hold button for three seconds to turn off player.

*Forced shutdown: Hold button for ten seconds.

*In Now Playing screen: short-press for play / pause.

In menu screens: short-press to select highlighted item to go into submenu or

select setting for adjustment.

9. Charging Indicator:

urns red when charging and green after player is fully recharged.

10. Micro USB Port:

a. For data transmission and charging.

b. Connects to digital music sources to act as USB DAC

11. Line Out Port:

3.5mm stereo audio line out port for connection with external amplifiers.

12. HOLD:

Move HOLD lever down to lock all buttons from operation

(e.g. putting playerin pants pocket for playback without pressing buttons by accident);

move HOLD lever up to unlock player.

13. Coaxial Out:

Outputs coaxial digital signal to devices with coaxial digital input.

Note: Coaxial output has the highest output priority and would shut down

headphone output and line output when coaxial cable is plugged in.

14. RESET：

Reach inside the reset hole with a thin rod (e.g. a toothpick) to reboot the system.

15. Headphone Output:

3.5mm headphone port suitable for headphones with different impedances.

Ⅲ. Firmware Upgrade

USB Disk Function

It possesses standard USB disk function which supports windows XP, windows7,

windows8, Mac OS X 10.x or above (free from driver installation).

Firmware Upgrade

Firmware upgrades can improve and optimize the performance of the player,

however the player will continue to function normally without the latest firmware

upgrades (It is possible to disable the X3 if firmware updates are carried out

incorrectly, so please read the following instruction carefully before upgrading).

To check the firmware version loaded on the X3, go to System Settings->Info / Storage.

The latest firmware for the X3 is available here:

If you have determined that your X3 requires a firmware update, please follow the

below instructions:

A. Loading firmware onto micro SD card

The X3 supports firmware upgrades via update firmware loaded onto an external

micro SD card in FAT32 format. Follow the following instructions to load the firmware

on the SD card:

1. Use a computer to download the latest firmware for the X3 here:

Download the firmware with the highest version number.

2. Prepare a micro SD card for the firmware upgrade:

It is suggested to use a card with capacity of 32GB or lower, and it should be a blank

card in FAT32 format. To prepare such a card, insert it into the X3 and format it

using X3’s integrated formatting command (System settings->Storage formatting->Yes).

Warning: formatting will wipe all data from the card so please back up the data on

the card to your computer first.Then, extract x3.fw from the firmware zip and put it

in the root directory of the prepared micro SD card. This can be done by connecting

the X3 directly to the computer using the supplied USB cable; the micro SD card

inserted into the X3 should show up as a standard external drive with the label

“X3 TF”.(if the X3 shows the USB DAC interface instead you need to switch the

X3 to USB Storage mode first: System settings->USB mode->use volume keys to

change from “DAC” to “Storage”). Then disconnect and reconnect the USB

cable.)

https://www.mediafire.com/folder/f1ei0b27mfrsq/X3

updating... update success

Firmware upgrading now Upgrade completed

B. Running the firmware upgrade:

Please ensure that the X3 has sufficient battery power (optimally, full power).

Then turn off the X3 and then enter firmware update mode by holding the

Menu button (upper left key) while pressing the Power button until the

firmware upgrade screen shows. After the firmware upgrade is done, the

player would restart automatically.

If the firmware upgrade fails for the first time, please hold the power button

for 10s to reset the player and go back to the upgrading procedure again.

After the upgrade completes, please re-update the player’s media library

by selecting System Settings->Update Media Lib (press OK to update media

library), and delete the x3.fw file from the micro SD card.

Note: Different firmware versions of the X3 would lead to functionality that

may be different from that outlined in this User Guide. No further notice

of such differenceswould be given.

No TF card or musicStorage location

Choose music according to

albums, artists or genres.

The album, artist and genre info

of music files newly added to

the player would be added after

selecting “Update Media Lib”

(this can be set to Auto to run

each time the X3 is connected to

the computer)

Without a song playing, (1)

leads to various options for

electing music to play, as

shown here.

With a song playing, the Now

Playing screen is shown instead.

>Position丨Track丨OFF

>ON丨OFF

>20~120

>Memory丨Custom（1~120）

>Low丨High

>L10~R10,

List of “Favorites”

Button Operation

Press To go to the next menu “>”

Press To change the number or option

Press To highlight the previous or next

menu item

Press To go back to previous menu

Ⅳ. Illustrated guide to menu

operation: [Main Menu]

>Set system language

>OFF丨Shut down in 10-120min.

>Always on丨Screen off 10~60s

>OFF丨30/60/90/120/150/180/210s

>Select Theme

>Storage丨DAC

>External Storage formatting

① ②

③ ④

⑤ ⑥

>Shuffle Single Repeat Repeat All One cycle

>Available treble range: -10~10

>Available bass range: -10~10

>Manual丨Auto; Press OK to confirm

Status icons:

1. Current volume

2. Sleep mode

3. Repeat mode

4. Playing

5. Battery indicator

12345

Cover

Long press

menu button

Ⅳ. Graphical Introduction to Menu Operation: [Playing Menu]

Lyrics

Press To change the number or option

Press To choose menu item

Long Press To back to previous menu

*Long press “Menu” to exit USB DAC interface and go back into main interface and

shut down the USB DAC.

*Set System Settings->USB Mode to DAC for the X3 to function as a DAC connected to

digital sources, or Storage for the X3 to function as external storage and card reader.

The USB cable needs to be unplugged and replugged after each change.

*For working with Windows PCs as DAC, supporting drivers need to be installed on the

Windows PC before using with the X3 for the first time. For more information, please

refer to “FiiO X3 User Guide-2 (USB DAC)”.

Ⅳ. Graphical Introduction to Menu Operation: [USB DAC]

Delete Current File from memory

Choose different loop mode

Add to ( Remove from) Favorites list

Artist, album, code and other

Press “up” to rotate the selection

clockwise, down to rotate counterclockwise

Ⅴ. Detailed literal guide to menu operation

1. ON / OFF

Detailed literal guide to menu operation.

ON: Hold “OK” button for one second to turn on.

OFF: Hold “OK button for three seconds to turn off.

2. Playing

A. In main menu interface

a. “Memory Play” being set as “On” (Automatically play starting from where it stops)

Choose “Play” after it turns on, short press the “OK” button, it will bring you to the

playing interface

b. “Memory Play” being set as “Off” (When there is no music playing)

Choose “Play” after it turns on, short press the “OK” button, it will bring you to its

submenu where has options as follows: “Play All”, “Favorites”, ”Album”, “Genre”,

“Artist” and “Browse Files”.

B. Under playing interface

Long press the “Menu/Back” button, then you will see its submenu which includes:

“Information”, “Add to Favorites”, “Remove from Favorites”, “Treble”, “Bass”,

“Delete Current File“ “Play Mode” and “Back to Main Menu”.

3. Play All

Press the “OK” button to get to the full list of files. Then choose one song to bring you to the

playing interface.

4. Favorites

A. When there is no file in the folder, a prompt would pop up which reads “Playback Failure File

not found”.

B. If there are files in the folder, short press the “OK” button to get to the playing interface.

5. Category

It is divided into three categories: Album, Genre and Artist.

6. Browse Files

Short press the “OK” button, get into the “Local disk” and “Micro SD Card”.

If there is no TF card inserted in, the prompt would pop up and reads “Playback Failure File

not found”.

7. Play Mode

It includes four options: Normal, Shuffle, Single Repeat and Repeat All. Press vol+ or vol- button

to switch.

Andere Handbücher für X3

Inhaltsverzeichnis

Beliebte MP3-Player Handbücher anderer Marken

Blaupunkt

Blaupunkt Compact Drive MP3 Bedienungsanleitung

Memorex

Memorex MMP9008 - 8GB USB 2.0 Bedienungsanleitung

Meizu Electronic Technology

Meizu Electronic Technology E5 Bedienungsanleitung

Naxa

Naxa NMV-173NX Bedienungsanleitung

Philips

Philips PSA250 Bedienungsanleitung

Zipy

Zipy go! Waving Bedienungsanleitung

Sylvania

Sylvania SMPK4068 Bedienungsanleitung

Sony

Sony NW-MS7 - Memory Stick Walkman Bedienungsanleitung

Irradio

Irradio RF-42UC Bedienungsanleitung

NABAIJI

NABAIJI SWIM MUSIC 100 Bedienungsanleitung

Laser

Laser MP3-A9-4GB Bedienungsanleitung

Samsung

Samsung YP-T7F Bedienungsanleitung

Savant

Savant SMS-1001-00 Kurzanleitung

Trevi

Trevi XP 71 BT Bedienungsanleitung

AGPtek

AGPtek C2 Bedienungsanleitung

MobiBlu

MobiBlu DAH-1500i Bedienungsanleitung

Denver

Denver MPS-201 Bedienungsanleitung

Steren

Steren MP3-002 Bedienungsanleitung
