Operation Instruction for Infant
Put on the protective gloves.
Unfold mask and check that
filter is firmly in place.
Use the rim of the mask to
retract the lower lip so the
patient’s mouth remains
open under the mask. Use
thumbs to hold the mask and
your fingers to grasp the lower
jaw. Position end (nose) under
the patient’s chin.
Other ventilation equipment, e.g. a bag-valve resuscitator or
oxygen powered resuscitator, may be coupled to the 15 mm
connection port (without the One-way Valve) of the Pocket
Mask.
At lower temperatures the Pocket Mask can be harder to unfold.
Use with oxygen: The mask may be used with supplemental
oxygen. Attach the oxygen tubing to the optional oxygen inlet
and set the flow rate. If the patient is spontaneously breathing,
use the head strap to position the Mask on the patient’s face.
If the patient is NOT breathing, begin mouth to mask ventilation
immediately.
Always keep mask in storage case when not in use.
With face mask sealed as
described above, blow slowly
into Non-Rebreathing Valve.
Allow patient to exhale. Repeat
as CPR guidelines.
1
1
2
3
4
2
3
4
Oxygen Concentration (%)
O2 Flow (LPM)
0
LPM
2
LPM
4
LPM
6
LPM
8
LPM
10
LPM
12
LPM
14
LPM
O2
Concentration
%
16.4 34.6 43.2 49.2 53.5 56.7 63.6 67.5
Dimension 123mm x 101mm x 86mm
Inspiratory resistance 0.40KPa-0.49KPa (at 50l/min)
Expiratory resistance 0.20KPa-0.30KPa (at 50l/min)
Operation Temperature -18℃～ 40℃
Storage Relative Humidity ＜ 85%
Storage Temperature -40℃～ 60℃
