Fisher & Paykel DD24DCB7 Bedienungsanleitung

US CA NZ AU GB IE

User guide

DishDrawerTM dishwasher

DD24, DD60

DD36, DD90 models

This user guide is an accompaniment to your ‘Quick start guide’ which is included

with your dishwasher.

For operating instructions, see your ‘Quick start guide’. If you no longer have your ‘Quick start

guide’, you can download it from our local website, listed on the back cover.

Refer to your ‘Quick start guide’ for information on:

Starting a wash

Wash programs and when to use them

Controls

Dos and don’ts of loading

Preference options and how to change their settings

Contents

Electrical connection (GB IE only)

Safety and warnings

Caring for your dinnerware

Racking features

Loading suggestions

Water hardness and dishwashing

Wash programs and detergent quantities

Adding detergent

Using rinse aid

Water softener

User maintenance instructions

Troubleshooting

If there is a fault

How to attend to a fault

Classic models

Designer models

Integrated models with badge

Integrated models with remote control

Warranty and service

Wash program data

Standards test

USA and Canada

New Zealand and Australia

Great Britain and Ireland

Important!

SAVE THESE INSTRUCTIONS

The models shown in this user guide may not be available in all markets and are

subject to change at any time. For current details about model and specification

availability in your country, please visit our local website listed on the back cover

or contact your local Fisher & Paykel dealer.

For Great Britain only

Important!

This appliance must be earthed.

Fuse replacement

The mains lead of this appliance is fitted with a

BS 1363A 13 A fused plug. To change a fuse in

this type of plug, use an ASTA approved fuse to

BS 1362 type and proceed as follows:

Remove the fuse cover and fuse.

Fit the replacement 13A fuse into the fuse cover.

Refit both into plug.

Important!

The fuse cover must be refitted when changing a fuse and if the fuse cover is lost, the plug

must not be used until a correct replacement is fitted.

Correct replacements are identified by the colour insert or the colour embossed in words on

the base of the plug.

Replacement fuse covers are available from your local electrical store.

For the Republic of Ireland

The information given in respect to Great Britain will frequently apply, but a third type of plug

and socket is also used: the 2-pin, side earth type.

Socket outlet / plug (valid for both countries)

If the fitted plug is not suitable for your socket outlet, please contact an Authorised Service

Agent. Please do not attempt to change the plug yourself. This procedure must be carried out

by a qualified service technician in compliance with the manufacturer’s instructions and current

standard safety regulations.

Fuse cover

Fuse

Electrical connection (GB IE only)

Safety and warnings

Your dishwasher has been carefully designed to operate safely during normal dishwashing

procedures. Please keep the following instructions in mind when you are using your dishwasher.

IMPORTANT SAFETY INSTRUCTIONS

WARNING! - When using your dishwasher, follow basic precautions, including the following:

Read all instructions before using the dishwasher.

The information in this manual must be followed to minimise the risk of fire or explosion or to

prevent property damage, personal injury or loss of life.

Use the dishwasher only for its intended function as described in this user guide and in your

‘Quick start guide’.

This appliance is intended to be used in household and similar applications such as:

– staff kitchen areas in shops, offices and other working environments;

– farm houses;

– by clients in hotels, motels and other residential type environments;

–

bed and breakfast type environments.

Use only detergents or rinse aid recommended for use in a domestic dishwasher and keep them

out of reach of children. Check that the detergent dispenser is empty after the completion of each

wash program.

When loading items to be washed, locate sharp items so that they are not likely to damage the

internal lid of the dishwasher and load sharp knives with the handle up to reduce the risk of cut-

type injuries.

Do not touch the filter plate (the round metal disc in the dishwasher base) during or immediately

after use, as it may be hot from the heater plate underneath.

Do not operate your dishwasher unless all enclosure panels are properly in place.

Do not tamper with the controls.

Do not abuse, sit on, stand in or on the drawer or dish rack of the dishwasher.

The drawer should not be left in the open position since this could present a tripping hazard.

The adjustable racks are designed to support cups, glasses and kitchen utensils. When the

adjustable racks are in the drawer do not lean on or use them to support your body weight.

To reduce the risk of injury, do not allow children to play in or on the dishwasher.

Under certain conditions, hydrogen gas may be produced in a hot water heater system that has

not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has

not been used for such a period, before using the dishwasher, turn on all hot water taps and let

the water flow from each for several minutes. This will release any accumulated hydrogen gas. As

the gas is flammable, do not smoke or use an open flame during this time.

Remove the door to the washing compartment when removing an old dishwasher from service

or discarding it.

Some dishwasher detergents are strongly alkaline. They can be extremely dangerous if

swallowed. Avoid contact with the skin and eyes and keep children away from the dishwasher

when the door is open. Check that the detergent receptacle is empty after completion of the wash

cycle.

4Safety and warnings

IMPORTANT SAFETY INSTRUCTIONS

Installation

This dishwasher must be installed and located in accordance with the Installation instructions

before it is used. If you did not receive Installation instructions with your dishwasher, you

can order them by calling your Authorised Repairer or download them from our local Fisher &

Paykel website, listed on the back cover.

Installation and service must be performed by a qualified technician.

If the power supply cord is damaged, it must be replaced by a dealer or Authorised Repairer or a

similar qualified trades person in order to avoid a hazard.

Ensure the dishwasher is secured to adjacent cabinetry using the brackets provided. Failure to do

so may result in an unstable product, which may cause damage or injury.

Do not operate this appliance if it is damaged, malfunctioning, partially disassembled or has

missing or broken parts, including a damaged power supply cord or plug.

Do not store or use petrol, or other flammable vapours and liquids in the vicinity of the

dishwasher.

Connect to a properly rated, protected and sized power supply circuit to avoid electrical overload.

Make sure that the power supply cord is located so that it will not be stepped on, tripped over or

otherwise subject to damage or stress.

Do not install or store the dishwasher where it will be exposed to temperatures below freezing or

exposed to weather.

Do not use an extension cord or a portable electrical outlet device (e.g. multi-socket outlet box)

to connect the dishwasher to the power supply.

This appliance must be grounded. In the event of a malfunction or breakdown, grounding will

reduce the risk of electric shock by providing a path of least resistance for electric current. This

appliance is equipped with a cord having an equipment-grounding conductor and a grounding

plug. The plug must be plugged into an appropriate outlet that is installed and grounded

in accordance with all local codes and ordinances. WARNING - Improper connection of the

equipment-grounding conductor can result in a risk of electric shock. Check with a qualified

electrician or service representative if you are in doubt as to whether the appliance is properly

grounded. Do not modify the plug provided with the appliance; if it will not fit the outlet, have a

proper outlet installed by a qualified technician.

If the dishwasher is installed as a permanently connected appliance:

GROUNDING INSTRUCTIONS - This appliance must be connected to a grounded metal, permanent

wiring system, or an equipment-grounding conductor must be run with the circuit conductors

and connected to the equipment-grounding terminal or lead on the appliance.

Safety and warnings

IMPORTANT SAFETY INSTRUCTIONS

Maintenance

Disconnect the appliance from the power supply before any cleaning or maintenance.

When disconnecting the appliance pull the plug rather than the power supply cord or junction of

cord to avoid damage.

Do not repair or replace any part of the appliance or attempt any servicing unless specifically

recommended in this user guide. We recommend that you contact Customer Care to arrange

service. See your ‘Service and warranty’ booklet for contact details.

Keep the floor around your appliance clean and dry to reduce the possibility of slipping.

Keep the area around/underneath your appliance free from the accumulation of combustible

materials, such as lint, paper, rags and chemicals.

Models with a remote control: Do not attempt to recharge, short-circuit, disassemble, heat or

throw the remote control battery into a fire. Dispose of an old battery responsibly, keeping it out

of reach of children.

Operational

Under no circumstances should you open the drawer whilst the dishwasher is in operation.

Always press the button to pause and wait until you hear the three additional beeps before

opening the drawer.

The dishwasher must be used with the motor assembly, filter plate, drain filter and spray arm(s) in

place. To identify what these parts are, see drawings in section ‘User maintenance instructions’ of

this user guide.

Take care when loading the drawer not to load dishware items so they prevent the internal lid

from properly sealing with the drawer. Items should be placed so they do not protrude above

and/or forced into the drawer, otherwise a service call may result.

Household appliances are not intended to be played with by children. Children or persons with a

disability which limits their ability to use the appliance, should have a responsible person instruct

them in its use. The instructor should be satisfied that they can then use the appliance without

danger to themselves or their surroundings.

Close supervision is necessary if this appliance is used by or near children. Do not allow children

to play inside, on or with this appliance or any discarded appliance.

If a dishwasher cleaner is used, we would strongly recommend a wash program with detergent

should be run immediately afterward, to prevent any damage to the dishwasher.

The dishwasher is designed for washing normal household utensils. Items that are contaminated

by petrol, paint, steel or iron debris, corrosive, acidic or alkaline chemicals are not to be washed in

the dishwasher.

If the dishwasher is not being used for long periods of time, turn the electricity and water supply

to the dishwasher off.

6Safety and warnings

IMPORTANT SAFETY INSTRUCTIONS

Operational - models with remote control

To prevent unauthorized use, keep the remote control out of reach of children.

Make sure that you keep the remote away from water and steam. Do not immerse and take care

not to drop the remote control into water. This may damage the parts or lead to malfunction.

Damage or malfunction caused by exposure to water or steam is not covered by warranty.

Do not drop, step on or otherwise impact the remote control. This may damage the parts or lead

to malfunction.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

Do not tamper with or modify the remote control or the dishwasher in any way, as doing so will

void the certification of the device.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject

to the following two conditions: (1) this device may not cause interference, and (2) this device

must accept any interference, including interference that may cause undesired operation of the

device.

SAVE THESE INSTRUCTIONS

Complies with

IDA Standards

DB104887

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Fisher & Paykel Spülmaschine Handbücher

Fisher & Paykel

Fisher & Paykel DishDrawer DD602 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DD24SDFT Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DD24STI9N Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel CONTEMPORARY DW60UNT4B2 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DD60DAW9 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DishDrawer DD24DT Series Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DW60U2I1 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DD60DAHX9 Betriebsanleitung

Fisher & Paykel

Fisher & Paykel DISHDRAWER DD24DDF 9 Series Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DishDrawer DD60DHI7 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel SINGLE DISHDRAWER DD24SCTB9 Betriebsanleitung

Fisher & Paykel

Fisher & Paykel DishDrawer DD24D Series Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DISHDRAWER DD24 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DISHDRAWER DD24STI9 Betriebsanleitung

Fisher & Paykel

Fisher & Paykel DishDrawer DS603 PREFINISHED Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DishDrawer DD36STI2 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel SINGLE DISHDRAWER DD60SCTHX9 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DishDrawer DD60DI9 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DishDrawer DD24SHTI7 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DishDrawer DD36STI2 Stücklistenhandbuch

Fisher & Paykel

Fisher & Paykel DOUBLE DISHDRAWER DD24DI Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DW60 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DishDrawer DD605 Series Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel DD60DCHB9 Bedienungsanleitung

Beliebte Spülmaschine Handbücher anderer Marken

Electrolux

Electrolux ESI5211LOX Bedienungsanleitung

KitchenAid

KitchenAid KUDB230B Bedienungsanleitung

Brandt

Brandt BDJ424DB Bedienungsanleitung

Asko

Asko DSD767UXXL.AU Bedienungsanleitung

Beko

Beko DFN26210W Bedienungsanleitung

NEFF

NEFF S153ITX00E Technisches Datenblatt

Midea

Midea SV 4.45 wi Bedienungsanleitung

LG LDF7932 Bedienungsanleitung

Gorenje

Gorenje GV63214 Bedienungsanleitung

Hotpoint

Hotpoint HDA1100ZWH Service-Handbuch

Blomberg

Blomberg LDFN2240W Bedienungsanleitung

AEG

AEG FFB83836PM Bedienungsanleitung

Cylinda

Cylinda DM3220RFD Bedienungsanleitung

Atag

Atag DW8214MB Bedienungsanleitung

GE GLD8000 Series Bedienungsanleitung

Siemens

Siemens SN23HI02KE Technisches Datenblatt

Omega

Omega ODW717X Bedienungsanleitung

BORETTI

BORETTI BVW-683 Bedienungsanleitung
