Fisher & Paykel Soft Touch electronic Bedienungsanleitung

Built-in oven

User guide

supplement

NZ AU

Soft Touch electronic models

Contents

Introduction

Clock and timer

Operating the oven

Cooking functions

One Touch Cooking (OTC)

Automatic cooking

Soft Touch meat probe

Important!

SAVE THESE INSTRUCTIONS

2Introduction

About your new oven

Thank you for buying a Fisher & Paykel Soft Touch electronic built-in oven.

This model has some special features, which are explained in this supplementary user guide.

Before using your new oven, please read the main user guide first, which gives you important safety

and other information for all built-in oven models.

Clock and timer

Setting the clock

To set the clock, press the CLOCK button, and then press the HOURS and MINUTES buttons until the

clock shows the correct time.

You can choose between 12 or 24 hour clock displays. To do this, press and hold down the CLOCK

button and CLEAR button at the same time. Each time these buttons are pressed together the clock

alternates between 12 and 24 hour displays.

Using the timer

You can use the timer at any time, even when the oven is not in use. The timer does not turn the

oven off.

To set the timer, press the MINUTE TIMER button, then the HOURS and MINUTES buttons to set the

time you want. The display will show the remaining time, counting down in minutes and seconds.

To see the time of day while the timer is running, press CLOCK. The display will briefly show the time

of day, then return to showing the countdown of time remaining.

When the time is up, the timer will beep and TIMER will flash in the display. To turn it off, press any

clock button.

To cancel the timer at any time, press CLEAR.

Limiting the number of ‘beeps’

You can limit the number of times your oven beeps to five beeps. To do this, press the CLOCK and

FUNCTION buttons together. Do the same again to return to a longer beep time of approximately

five minutes.

Fig.1 Electronic Soft Touch control panel and clock

Turn the oven on with the ON/OFF button.

Your oven has been pre-set to FAN BAKE 160 °C.

Scroll to the required function with the

FUNCTION and buttons.

Scrolling down, the order of functions is:

FAN BAKE  FAN  BAKE  WARM  DEFROST  GRILL H9  GRILL E9  FAN GRILL

Adjust the temperature in 5 °C steps with the TEMP and buttons. Each cooking function has a

pre-set temperature which can be adjusted, except for WARM. The temperature display will alternate

between the set and actual temperature, and the red oven indicator light will glow until the oven

has reached the set temperature. The oven beeps twice when it reaches the set temperature.

When you have finished cooking, turn the oven off by pressing the ON/OFF button.

Note: the oven cooling fan comes on automatically at different stages of the cooking cycle. It blows

out warm air above the door. When the oven is turned off, the cooling fan may stay on until the

oven cools down.

Locking the control panel

For extra safety, you can lock the control panel to guard against accidental bumps, for example when

you are cleaning the oven, or to stop children using the oven when they should not.

To lock or unlock the control panel, press and hold the KEY LOCK button for two seconds.

Note: for safety reasons, you can still turn your oven off when KEY LOCK is on.

Operating your oven

Fig.2 Electronic Soft Touch control panel, display and clock

Cooking functions

FAN BAKE Fan plus top and bottom

elements

FAN BAKE circulates hot air from the

top and bottom elements. Food cooks

faster than in BAKE, so you may need to

lower the oven temperature by 5-10 °C.

FAN BAKE is good for crisping food, eg

pastry products, and it is also the best

method for heating your pizza stone.

Press the ON/OFF button.

The default temperature is 160 °C. Adjust this using the

TEMP and buttons.

Preheat the oven before use.

FAN (FAN FORCED) Fan plus fan

element

Heat from the element around the fan

is forced throughout the oven. FAN

is perfect for multi-shelf cooking and

batch baking, casseroles and baked

potatoes.

Press the ON/OFF button.

Press the FUNCTION button once.

The default temperature is 180 °C. Adjust this using the

TEMP and buttons

Preheat the oven before use.

BAKE Top and bottom elements

BAKE is the traditional method of

cooking. It is best to cook on only one

shelf at a time in this function. Use

BAKE for delicate food and foods that

require long cooking, eg fruit cakes,

bread and roasts.

Press the ON/OFF button.

Press the FUNCTION button twice.

The default temperature is 180 °C. Adjust this using the

TEMP and buttons.

Preheat the oven before use.

WARM Top and bottom elements

WARM is a constant low heat, useful

for keeping hot food warm or warming

plates. It should not be used to reheat

food as the food will not reach a

temperature high enough to kill any

harmful bacteria.

Press the ON/OFF button.

Press the FUNCTION button three times.

The default temperature is 75 °C. This cannot be

adjusted.

DEFROST Fan only

The fan circulates air around the oven,

speeding up the defrosting process by

approximately 30%.

Press the ON/OFF button.

Press the FUNCTION button four times.

The default temperature is 50 °C. You can adjust this

between 50 °C and 30 °C, using the TEMP and

buttons.

Preheat the oven before use.

GRILL-HI Inner and outer top

elements

GRILL-HI uses both of the top elements

and is ideal for grilling a large area of

food. For best results leave the door

open at the first stop position. Grilled

vegetables are quick to cook and full

of flavour.

Press the ON/OFF button.

Press the FUNCTION button five times.

The default temperature is H9, the hottest. Adjust this

using the TEMP and buttons.

Preheat the grill before use.

GRILL-ECO Top inner element

GRILL-ECO uses the inner area of the

top element and is useful when you

need to grill single servings or small

pieces of food. For best results leave

the door open at the first stop position.

Press the ON/OFF button.

Press the FUNCTION button six times.

The default temperature is E9, the hottest. Adjust this

using the TEMP and buttons.

Preheat the grill before use.

FAN GRILL Fan plus top elements

FAN GRILL circulates hot air from the

top elements and is excellent for food

that would normally be fried. Large

cuts of meat can be cooked using this

function with results similar to using

a rotisserie. Use FAN GRILL for dishes

such as lasagne and moussaka. Fan-

grilled whole chicken is excellent.

Fan grill with the oven door closed.

Press the ON/OFF button.

Press the FUNCTION button seven times.

The default temperature is 180 °C. Adjust this using the

TEMP and buttons.

Cooking functions

One Touch Cooking (OTC)

About OTC

OTC allows you to save a cooking function and temperature in the oven’s memory.

To save OTC

Turn the oven on and set the function and temperature.

Press the OTC button. OTC will light up in the display indicating that the settings are saved.

Turn the oven off if OTC is not required immediately. OTC will remain lit in the display.

To recall OTC

Press the OTC button. The oven will display your saved settings and start automatically.

To clear OTC

Press the OTC button twice quickly. The OTC light will go out, showing the memory is cleared.

Notes:

OTC can be saved as an automatic cooking function. See the ‘Automatic cooking’ section.

You can change the oven function and temperature while the oven is cooking, and this will not

change your saved OTC settings.

If the power is turned off at the wall, you will lose your saved OTC settings.

Use automatic cooking to turn the oven on, cook and then turn the oven off.

Check the clock shows the correct time.

Turn the oven on and select the function and

temperature. The red oven indicator light will glow

and the oven will come on.

Decide how long the food will take to cook,

allowing time for preheating if necessary.

Press the button. 0.00 will show. Using the

HOURS and MINUTES buttons, set the cooking time,

eg 1 hour. COOK TIME will flash and AUTO will show

in the clock display.

Select the time you would like the oven to turn off

by pressing the button. STOP TIME will flash in

the display. Enter the time you would like the food

to finish cooking using the HOURS and MINUTES

buttons eg 7.45 pm.

If you are already at home to turn the oven on and only want the oven to turn off automatically, start

cooking as normal, then follow step 5 to set a time for when you want the oven to turn off.

If there is time to wait before automatic cooking starts, the current

time of day and AUTO will show in the clock display. The red oven

indicator light will go out, and the oven will switch off, but the oven

lights will remain on. The oven is now set for automatic cooking.

Note: the cooling fan may remain on.

When automatic cooking starts, AUTO and the remaining cook time will be displayed and the oven

will turn on.

To see the stop time, press the STOP

TIME button.

To cancel automatic cooking at any time, press the CLEAR button, and then the ON/OFF button to

turn the oven off.

When the stop time is reached, the oven will turn off, the timer will beep and AUTO will flash in the

display. Press any button to stop the beeping and return the oven to manual mode.

Automatic cooking
