THE OUTDOOR REFRIGERATED

DRAWER

Use and Care and Installation Guide

MODELS:

RF24-D

Thank you for selecting this DCS Outdoor Refrigerated Drawer. Because of these appliances’ unique features we

have developed this Use and Care and Installation Guide. It contains valuable information on how to properly

install, operate and maintain your new appliance for years of safe and enjoyable operation.

Tohelp serve you better, please fill out and submit your Product Registration by visiting our website at

www.dcsappliances.com and selecting “Customer Care” on the home page and then select “Product

Registration”. In addition, keep this guide handy, as it will help answer questions that may arise as you use your

new appliance.

For your convenience, product questions can be answered by a DCS Customer Care Representative at

1-888-936-7872, or email:

customer[email protected]

PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE.

AMESSAGE TO OUR CUSTOMERS

NOTE: Please write the Model, Code, and Serial Numbers on this page for references (the serial plate is located on

the upper left side, inner wall).

MODEL NUMBER CODE SERIAL NUMBER

SERIAL PLATE LOCATION

NOTE:Inspect the product to verify that there is no shipping damage. If any damage is detected, call the shipper

and initiate a damage claim. DCS by Fisher & Paykel is not responsible for shipping damage.

DO NOTdiscard any packing material (box, pallet, straps) until the unit has been inspected.

TABLE OF CONTENTS

SAFETY PRACTICES AND PRECAUTIONS 3

INSTALLATION - ESSENTIAL REQUIREMENTS 4

INSTALLATION

Electrical connection 5

How to install your outdoor refrigerated drawer 6

Anti-tip installation instructions 7

USING THE REFRIGERATED DRAWER

Startup 9

Set temperature 9

Set controls 9

Adjust temperature control 9

Interior light 9

Warning alarm 9

Door ajar alarm 9

High and low temperature 9

Power failure 10

Reset alarm 10

Holiday mode 10

Defrosting instructions 10

MOVING OR STORING YOUR REFRIGERATED DRAWER 11

CARE AND MAINTENANCE

Replaceinterior lightbulb 12

Things toremember 12

Energy saving tips 12

How toclean and maintain your unit 13

TROUBLESHOOTING 14

SERVICE 15

WARRANTY 16-17

SAFETY PRACTICES & PRECAUTIONS

To reduce the risk of fire, electric shock, or injury to persons read these SAFETY PRACTICES AND PRECAUTIONS

before installing or operating this appliance. Use this appliance only for its intended purpose as described in this

Use and Care and Installation Guide.

WARNING

When using this appliance always exercise basic safety precautions including the following:

DANGER!

■This appliance is not intended for use by young children or infirm persons without supervision. Young children

should be supervised to ensure they do not play with the appliance.

■Risk of child entrapment. Before you throw away your old refrigerated drawer:

1. Take off the doors.

2. Leave the shelves in place so that children may not easily climb inside.

ELECTRICAL

■This appliance must be properly installed in accordance with the installation instruction before it is used.

■Never unplug your refrigerated drawer by pulling on the power cord. Always grip the plug firmly and pull straight

out from the outlet.

■Repair or replace immediately all electric service cords that have become frayed or otherwise damaged. Do not

use a cord that shows cracks or abrasion along its length or at either the plug or appliance end. If the power

supply cord is damaged, it must only be replaced by your Fisher & Paykel Appliances Authorized Service Center

because special purpose tools are required.

■Unplug your refrigerated drawer before cleaning, or replacing the light bulb.

STORING FOOD AND DRINKS

■Never store volatile or flammable materials in your refrigerated drawer as they may explode.

■Never freeze liquids in glass containers. Liquid expands during freezing which may cause the container to explode.

■Do not consume food if it is too cold. Food removed from the freezer compartment may be cold enough to cause

damage when broughtintocontact with bare skin, e.g. frozen ice cubes.

POWER FAILURE – FOOD SAFETY

■Do not refreeze foods that have thawed completely. Follow the recommendations below if you discover food

that has thawed:

1. Ice crystals still visible –food may be refrozen but should be stored for a shorter period than recommended.

2. Thawed but refrigerator cold –refreezing generally not recommended. Fruits and some cooked food can be

refrozen but use as soon as possible.

Meat, fish, poultry –use immediately or cook, then refreeze.

Vegetables –discard as they usually go limp and soggy.

3. Thawed but warmer than 4ºC/40ºF– red meatcan be cooked immediately to well done and refrozen but use as

soon as possible. Discard all other frozen foods.

■Do not refreeze frozen foods that have thawed completely. The food may be dangerous to eat.

CLEANING

■Many commercially available cleaning products contain solvents which may attack plastic components of your

refrigerated drawer and cause them to crack. Please refer to the Care and Maintenance section of this booklet for

further advice (see pages 11-12).

DISPOSAL

■Extreme care must be taken when disposing of your old appliance to avoid hazards. The refrigerant gas must be

safely removed.

■Your Fisher & Paykel Appliances Authorized Service Center will be able to give advice on environmentally friendly

methods of disposing of your old refrigerated drawer.

INSTALLATION – ESSENTIAL REQUIREMENTS

POWER

■The appliance must be installed so the power plug is accessible.

■To ensure that the appliance is not accidentally switched off, connect your refrigerated drawer to its

own power point. Do not plug in any other appliance at this power point or use extension cords, or double

adapters, as the combined weight of both power cords can pull the double adapter from a wall outlet socket.

■For power requirements, refer to the information on the serial plate located at the upper left side, inner wall

when the door is open.

■It is essential that the appliance be properly grounded (earthed) with a three prong receptacle. Never cut or

break off the grounding prong to fit a two-prong outlet.

SELECT LOCATION

■The proper location will ensure peak performance of your appliance. Choose a location where the unit will be out

of direct sunlight, away from heat sources and moisture.

■Units with fan cooled condensers can be built into an under counter cabinet or freestanding.

■Your refrigerated drawer should be operated in a properly ventilated area with ambient temperatures not to

exceed below 40 degrees and above 100 degrees Fahrenheit.

■Installation should be such thatthe unit can be moved for servicing if necessary.

CABINET CLEARANCE

■Ventilation is required from the bottom front section of the unit. Keep this area open and

clear of anyobstructions.

■The adjacent cabinets and counter top can be built around the unit as long as no top trim

or counter top is installed lower than the top of the upper drawer.

STABILITY

■It is important that all four corners of the refrigerated drawer base are supported firmly on

asolid level surfaceto eliminate any cabinet movement.

■Installing the appliance on a soft or uneven or unlevel floor may result in twisting of the cabinet and poor

sealing of the doors. If the doors do not seal properly, warm air will enter the food storage areas causing the

temperature to increase, resulting in food spoilage and food loss.

■Position your refrigerated drawer. Turn front leveling legs clockwise (Fig. 01) to lower the front leveling leg. Raise

the frontof the applianceuntil it is stable and level.

■The front leveling legs should take the majority of the weight of the cabinet and the cabinet should be stable,

i.e.cabinet should not rock or wobble.

WARNING

Afree standing refrigerated drawer must have an anti-tip device installed for safety.

■See anti- tip bracket installations (page 7 and 8).

BEFORE PLACING FOOD IN THE FRESH FOOD COMPARTMENTS

■Remove all packaging. Ensure that all transit tape is removed from the refrigerated drawer.

■Clean the inside of the appliancewith warmwater and a little liquid detergent to remove manufacturing and

transportation dust.

■Allow the refrigerated drawer to run empty for 2 - 3 hours to allow each compartment to cool to the

appropriate temperature.

■The appliance may have an odor on its initial operation, but this will go away when the refrigerated drawers have

cooled sufficiently.

Fig. 01 Leveling Leg

INSTALLATION

HOW TO INSTALL YOUR OUTDOOR REFRIGERATED DRAWER

24” Outdoor Refrigerated Drawer

■120V 60Hz

■1800 watt

■3wireoutlet

■15 amp circuit

AC Interface

ELECTRICAL CONNECTION:

Check serial plate for correct power supply. Use only electrical power supply as specified on your appliance

serial nameplate. Do not use an extension cord!

WARNING!

Do not splash or spray water from a hose onto the refrigerated drawer! Doing so may cause an electrical shock,

which may result in severe injury or death.

GROUNDING METHOD

This product is factory equipped with a power supply cord that has a three-pronged grounded plug. It must be

plugged into a mating grounding type receptacle in accordance with the National Electrical Code and applicable

local codes and ordinances. If the circuit does not have a grounding type receptacle, it is the responsibility and

obligation of the customer to exchange the existing receptacle in accordance with the National Electrical Code

and applicable local codes and ordinances. The third ground prong should not, under any circumstances, be cut

or removed. All UL listed refrigerated products are equipped with this type of plug.

Aground fault circuit interrupter (GFI) electrical receptacle is to be used to supply electrical power to the refrig-

erated drawer for outdoor applications. Contact an electrician if you need to install one to supply electrical

power to your outdoor refrigerated drawer.

POWER REQUIREMENTS:

Note:

The plug shown is for 120V units.

Grounding Type

Wall Receptacle

Power Supply Cord

with 3-Prong

Grounding

Plug

Fig. 02 Fig.03

SELECT LOCATION:

The proper location will ensure peak performance of your appliance. Choose a location where the unit will be out

of direct sunlight, away from heat sources and moisture. Units with fan cooled condensers can be built in. Unit

should be operated in a properly ventilated area with ambient temperatures above 40 degrees and below 100

degrees Fahrenheit.

Installation should be such that the cabinet can be moved for servicing if necessary.

CABINET CLEARANCE

■Ventilation is required from the bottom front section of the unit. Keep this area open and clear of any obstructions.

■The adjacent cabinets and counter top can be built around the unit as long as no top trim or counter top is

installed lower than the top of the upper drawer. See Fig. 04a.

SIDE TRIM INSTALLATION:

Prior to installation, align trim with the refrigerated drawer height and mark the screw hole locations. Attach side

trim to the inner side of the cabinet so that the trim faces outward (away from the appliance’s door) and fasten

with appropriate screws suitable for the type of cabinet material (Fig. 05).

INSTALLING DRAWERS

■Place the unit in front of the counter opening. Make sure that the floor is protected when sliding the drawer unit

intoplace.

■Determine the minimum height of the counter top opening (Fig. 04a).

■Lower the front and rear leveling legs (Fig. 04a) so the top of the drawer cabinet is 1/8” lower in the back of the

cabinet and 1/2” lower in the front of the cabinet than the counter top opening.

■Make the electrical connection by plugging the unit into the power outlet and locating the power cord so it will

not be damaged when the refrigerated drawer is installed.

■Slide the refrigerated drawer into cabinet location and adjust the front legs until the unit is level and there is the

same amount of load on each leg.

INSTALLATION

HOW TO INSTALL YOUR OUTDOOR REFRIGERATED DRAWER

Fig.04

24” Outdoor Refrigerated Drawers

DIMENSIONS ISLAND PREPARATION WITH NO SIDE TRIM

15-1/8

3-1/2” 24-1/8

ISLAND PREPARATION WITH SIDE TRIM INSTALLATION

Mounting

screw not

provided

Fig. 05

Fig. 04a

Afree standing refrigerated drawer must have an anti-tip device installed as per these instructions. If the drawer is

removed from its location for any reason, make sure that the device is properly engaged when you push the drawer

back into the original location. If device is not properly engaged, there is a risk of the drawer tipping over, causing

property or personal injury if you or a child stand, sit, or lean on an open drawer.

FLOOR MOUNT INSTALLATION

The anti-tip bracket can be located on the floor in the left or right

rear corner of the refrigerated drawer as shown in Figure 06.

Step by step instructions for locating the position of the

bracket:

1. Decide where you want to place the Drawer. Make a temporary

line on the floor in line with the drawer face, “A” as shown in

Figure 06.

2. At the center point where the drawer will be, draw a center line

“B” (Fig. 06) perpendicular to line “A” to the rear of the unit. Make

amark on line “B “ 24-1/2 inches from line “A”.

3. Then make another perpendicular line “C”at

this mark. Make a mark on line “C” 11-1/2

inches from line “B” either right or left.

4. At this mark, drill 1/8” diameter pilot hole in

the floor.

5. Fasten the bracket tothe floor thru the slotted

hole (see Fig. 07) using the appropriate

fasteners for the type of floor.

6. Position the unit so that the leveling leg

engages into the anti-tip bracket (Fig. 07).

7. Check for proper installation of the drawer and

anti-tip device by grasping the back of the

unit and carefully attempting to tilt the drawer

forward.

INSTALLATION

ANTI-TIP INSTALLATION INSTRUCTIONS

WARNING

• ALL DRAWERS CAN TIP

• INJURY COULD RESULT

• INSTALL ANTI-TIP

BRACKET PACKED

WITH UNIT

• SEE INSTRUCTIONS

11-1/2”

24-1/2”

23-7/8”

Center line

24”

BOTTOM VIEW OF DRAWER

Anti-tip Bracket

Refrigerated

Drawer

Front

11-1/2”

CENTER LINE

PERPENDICULAR LINE

Leveling Leg

Slotted hole for

floor installation

Open slot

Fig. 06

Fig. 07

INSTALLATION

ANTI-TIP INSTALLATION INSTRUCTIONS

WALL MOUNT

1. Remove the bracket from its original shipping position on the

back of the unit (Fig. 08 and 09).

2. Reattach the bracket to the back of the unit using the existing

screws from the unit’s back panel (Fig 10).

3. Push the unit against the wall so the bracket is flush with the

wall adjacent to the back panel.

4. Using a pencil and the bracket as a template, trace the bracket

on the wall, making sure 2 of the screw holes are aligned with a

stud in the wall.

5. Pull the unit away from the wall.

6. Remove the screws that connect the upper and lower sections of the

Anti-Tip Bracket. Mount the lower section of the bracket that is not

attached to the unit to the wall where you had marked and drilled

pilot holes in the wall/wall stud for mounting. Attach the lower

bracket to wall.

7. Push the unit back against the wall and align the upper section with

the lower section of the Anti-Tip Bracket such that you can refasten

the original screws that secure the upper and lower sections of the

Anti-Tip Bracket (Fig. 11). Your installation is now complete.

Drawer Refrigerator

To Wall

ADJACENT WALL

DRAWER REFRIGERATOR

Fig. 08

Fig. 09

Fig. 11

Fig. 10

SIDE VIEW

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Fisher & Paykel Kühlschrank Handbücher

Fisher & Paykel

Fisher & Paykel RB90S64MKIW1 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel RB2470BRV Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel RS36W80 series Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel ACTIVESMART RF172G Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel ACTIVESMART RF605Q Fehlerbehebungshandbuch

Fisher & Paykel

Fisher & Paykel RX256DT7X1 Montageanleitung

Fisher & Paykel

Fisher & Paykel ActiveSmart E522B Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel RS90A Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel RS6121FRJK2 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel RB2470BRV Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel RS6121FLJK2 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel RS6121SLK2 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel E522BLT-21926A Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel ACTIVESMART RF605QDUVX1 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel E522BLXU Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel ACTIVESMART RF203Q Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel ActiveSmart E372B Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel RF610ADW4 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel ActiveSmart RF522A Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel RS6019B Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel E522BRXU Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel ACTIVESMART RF500QNUB1 Bedienungsanleitung

Fisher & Paykel

Fisher & Paykel ActiveSmart E402B Montageanleitung

Fisher & Paykel

Fisher & Paykel RS90A Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
