Drain Hose

Drain Hose Placement in a Stand Pipe

or Tub

1. To guide the drain hose over the tub or standpipe

the hose guide must be fitted to the drain hose.

The height of the standpipe or tub should be

between 800 – 1200mm.

2. Secure the hose guide so it cannot become

dislodged from the standpipe or tub.

• If the drain hose is placed

on the ground or if the

standpipe or tub is less

than 800mm high, the

washing machine will

continuously drain while

being filled (siphon).

• Regularly check that your

standpipe or tub is free

from lint or other

obstructions, which may

affect how your machine

works or may cause

flooding.

Fitting the drain hose guide

https://producthelp.fisherpaykel.com/eu/Wash/Front_Loaders/FabricSmart/WM1490F1/Installation_Guide_WM1490F1/06_Dr…

Updated: Thu, 11 Nov 2021 20:35:09 GMT

Powered by

1

Attaching Drain Hose to Spigot

1. Guide drain hose through hose guide

2. Secure hose guide to back wall of cupboard

using a screw. The height of the drain hose

should be between 500 – 800mm from ground

level.

3. Attach drain hose to spigot and secure using a

hose clamp ensuring the blanking insert is

cleared from spigot.

4. Check for leaks.

• The drain hose should be checked from time to

time and replaced if any damage (eg wear, cuts,

bulges, kinks, leaks, etc) is found. Do not bend the

drain hose sharply, as this may cause it to split.

• In multi-storey apartments or any upper floor, the

machine should be installed on a floor equipped

with a drain.

• Draining must comply with local by-laws. Attaching drain hose to spigot

https://producthelp.fisherpaykel.com/eu/Wash/Front_Loaders/FabricSmart/WM1490F1/Installation_Guide_WM1490F1/06_Dr…

Updated: Thu, 11 Nov 2021 20:35:09 GMT

Powered by

2
