Fishman MATRIX INFINITY - Bedienungsanleitung

USER GUIDE

MATRIX INFINITY™

3

Welcome

Thank you for making Fishman a part of your acoustic experience. We are proud

to offer the ﬁnest acoustic ampliﬁcation products available; high-quality

professional-grade tools which empower you to sound your very best.

4

Controls

Plug In • Connect the Matrix Inﬁnity to your ampliﬁer or PA with a ¼-inch

instrument cable. To conserve battery life, remove the instrument cable from the

guitar when the system is not in use.

Volume • For the cleanest noise-free sound, set the volume as high as possible

without causing your amp or mixer to distort.

Tone • This innovative one-knob tone control lets you choose between a natural,

undersaddle sound with no EQ (ﬂat) on up to a “Scooped” tone with empha-

sized treble and bass and reduced midrange.

• To make individual notes sound thicker and punchier, roll the Tone

control to the right.

• Try the Tone control in the middle position for ﬁngerpicking, when you

need just a bit of midrange cut.

• Roll the Tone control all the way to the left for more depth and

clarity to your sound, especially for hard strumming.

5

Tone

Volume

Bass

Boost Flat

Tone

Flat

Scooped

Louder

Voicing

6

Additional Controls

Voicing Switch

This switch selects how the pickup is voiced. Move the Voicing Switch away from

the soundhole for bass boost and towards the soundhole for a ﬂat response.

Choose the setting that works for your instrument and your performance require-

ments. Here are some guidelines.

• The boosted bass voicing (push switch away from soundhole) compli-

ments solo guitarists and singers who accompany themselves, espe-

cially with smaller

instruments.

• The ﬂat voicing (switch towards soundhole) cuts through the mix if

you play in a band. It does a good job controlling boominess and low

frequency feedback onstage, especially with full-size guitars.

7

Battery Replacement

A low battery LED is built into the preamp housing mounted inside the guitar.

When the Battery LED lights steadily, it is time to change the battery. To replace

the battery, remove the fabric battery bag that is mounted inside the guitar.

If you ship your guitar, we recommend you remove the battery as a precaution.

Although unlikely, it is possible for the battery to jar loose inside the instrument

during shipment.

Troubleshooting

Installation by a qualiﬁed professional is strongly recommended.

Should you have any problems, please check with your installer or refer to the

online installation guide for this product. Technical support, troubleshooting tips

and installation information can be found at http://www.ﬁshman.com/support/

www.ﬁshman.com

Fishman and Fishman Transducers are trademarks or tradenames of Fishman Transducers Inc. 513-300-132 Rev A 12-07
