Flash butrym 108 Bedienungsanleitung

www.flash-butrym.pl Strona 1

USER MANUAL

LED BEAM MOVING HEAD 108

Professional Entertainment Technology

www.flash-butrym.pl Strona 2

TABLE OF CONTENTS

1. Safety Instruction

2. Technical Specification

3. How To Set The Unit

4. How To Control The Unit

5. Troubleshooting

6. Fixture Cleaning

WARNING

Please keep this User Guide for future consultation. If you sell the unit to another us-

er.be sure that they also receive this instruction booklet

Unpack and check carefully there is no transportation damage before using the unit.

Before operating, ensure that the voltage and frequency of power supply match the

power requirements of the unit

It’s important to ground the yellow/green conductor to earth in order to avoid electric

shock.

The unit is for indoor use only. Use only in a dry location

The unit must be installed in a location with adequate ventilation, at least 50cm from

adjacent surfaces. Be sure that no ventilation slots are blocked

Disconnect main power before replacement or servicing.

Make sure there is no flammable materials close to the unit while operating as it is

fire hazard.

Use safety cable when fixes this unit. Don’t handle the unit by taking its head only,

But always by taking its base.

Maximum ambient temperature is ta:40°C. Don't operate it where the temperature is

higher than this.

Please read carefully the instruction, which includes important infor-

mation about the installation. usage and maintenance

www.flash-butrym.pl Strona 3

Unit surface temperature may reach up to 85°C .Dont touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to

cool down before replacing or serving.

In the event of serious operating problem, stop using the unit immediately. Never try

to repair the unit by yourself. Repairs carried out by unskilled people can lead to

damage or malfunction. Please contact the nearest authorized technical assistance

center. Always use the same type Spare parts.

Warning

To prevent or reduce the risk of electrical shock or fire, do not expose the unit the rain

or moisture.

Do not open the unit within five minutes after switching off.

The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly

damaged.

Caution

There are no user serviceable parts inside the unit. Do not open the housing or

attempt any repairs yourself. ln the unlikely event your unit may require service,

Please contact your nearest dealer.

Installation

The unit should be mounted via its screw holes on the bracket. Always ensure that

the unit is firmly fixed to avoid vibration and slipping white operating. And make sure

that the structure to which you are attaching the unit is secure and is able to support

a weight of 10 times of the unit’s weight. Also always use a safety cable hold 12

times of the weight of the unit when installing the fixture.

The equipment must be fixed by professionals. And it must be fixed at a place where

is out of the touch of people and has no one pass by or under it.

Fixture Cleaning

The cleaning of internal and external optical lens and/or mirrors must be carried out

periodically to optimize light output. Cleaning frequency depends on the environment

in which the fixture operates: damp, smoky or particularly dirty surrounding can cause

greater accumulation of dirt on the units optics

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully

Clean the external optics at least every 20 days. Clean the internal optics at least

every 30/60 days

www.flash-butrym.pl Strona 4

Another new edition of Led Moving Head 108 x 3W RGBW well-know has Strong, but

this time it came with CREE LED's and it very attractive light.

And it have 108 high-quality LED Red, Green, Blue, White, that make it to provides a

very good light and bright, in which make it have a strong and very concentrated light

beam.

The view Angle 5°, and You also get a complete additional filter that will turn wider

the wash angle to 25°.

FEATURES

High quality CREE LED's in four basic colors (RGBW)

Angle 5°- 25° additional filter

color Balance

Extremely fast and very good precise movement

Ultra compact design light

The device weight (8.4 kg)

PHYSICAL

Height: 390 mm

Width: 370 mm

Depth: 265 mm

Weight: 8.4 kg

DYNAMIC EFFECTS

RGBW color mixing

Liquid electronic dimmer (0-100 %)

Electronic strobe with variable speed (0 - 20hz ), or the result of random

PAN : 630o

TILT : 240o

Speed control PAN , TILT DMX

CONTROL AND PROGRAMMING

Control of the market definition PAN and TILT ( 8bit or 16bit )

DMX512 : 9, 12 or 16 channels

Sound control , master-slave

Setting and addressing : LCD with back-light

OPTICS

Viewing angle : 5 °

Light power : LUX : 66 000 @ 2m, 16 500 @ 4,5 m

CREE 3W LED's : 28xR , 28xG , 26xB , 26xW

EXECUTION

Aluminum construction with plastic

www.flash-butrym.pl Strona 5

Two side handles for transportation

Degree of protection: IP20

INSTALLATION

Two handles for screw hooks

Indoor use only

Mounting head in any position

Minimum distance to illuminated surfaces : 1 mouth

Keep a minimum distance from the surrounding area of the head : 0.5 m

CONNECTORS

Power connector IN: Neuritic Power-Con

Power connector OUT : Neuritic Power-Con

DMX512 signal connector : 3-pin XLR ( IN, OUT )

ELECTRICAL

Power supply : AC 110V - 240V , 50/60Hz

Maximum power consumption: 320W

Protection: T6 , 3A

ACCESSORIES INCLUDED

IN Power-Con power cable (blue connector )

Brackets for attaching the head to the structure ( 1pc )

Filter Wash - 25 °

User manual

USEFUL INFORMATION FOR ORDERING

Packaging ( 1unit ) : 410x390x285mm

Gross Weight: 9.8 kg

3. How To Set The Unit

3.1 Control Panel

Display

www.flash-butrym.pl Strona 6

To show the various menus and the selected functions

Led

Button

To select the programming functions

DOWN

To go backward in the selected functions

To go forward in the selected functions

ENTER

To confirm the selected functions

DMX

DMX input Present

MASTER

Master Mode

Slave

Slave Mode

Sound

Flashing

Sound activation

DMX Address

001

512

9CH

Channel Set

12CH

16CH

SHOW1

Show Mode

SHOW2

SHOW3

SHOW4

Slave Set

SLAVE1

SLAVE2

Black Out

YES

Sound Mode

OFF

Sound Sense

100

Pan Inverse

YES

Tilt Inverse

YES

www.flash-butrym.pl Strona 7

YES

DMX Controller

By using a universal DMX Controller to control the units, you will need to set DMX

address from 1 to 512 so that the units can receive DMX signal Press the MENU

button up to when the DMX Address is showing on the display. Pressing ENTER

White Balance

RED

125

GREEN

BLUE

255

PAN

TILT

RED

BLUE

255

DIMMER

Temp.

31*C

Pro Defaults

Defaults

YES

Auto Defaults

Fixture Reset

www.flash-butrym.pl Strona 8

button and the display will blink. Use DOWN and UP button to change the DMX512

address. Once the address has been selected, press the ENTER button to setup, to

go back to the functions without any change press the MENU button again. Hold and

press the MENU button about one second or wait for one minute to exit the menu

mode.

Please refer to the following diagram to address your DMX512 channel for the first 4

units.

Channel mode

Unit 1

Address

Unit 2

Address

Unit 3

Address

Unit 4 Address

9 channels

12 channels

16 channels

fit

4.4 DMX 512 Configuration 9 Channel Mode:

Channel List

Value

Function

CH1

000-255

Pan(0-630)

CH2

000-255

Tilt(0-240)

CH3

000-255

Strobe

CH4

000-255

Red (0%-100%)

CH5

000-255

Green (0%-100%)

CH6

/ 000-255

Blue (0%-100%)

CH7

000-255

White (0%-100%)

CH8

000-255

Dimmer (0%-100%)

CH9

240 - 255

Reset 240/255 Sound

12 Channel Mode:

Channel List

Value

Function

CH1

000-255

Strobe Effect

CH2

000-255

Dimmer (0%-100%)

CH3

000-255

Pan(0-630)

CH4

000-255

Pan Fine(Least significant bit)

CH5

000-255

Tilt (0-240)

CH6

000-255

Tilt Fine(Least significant bit)

CH7

000-249

Reset 250-255 Sound Activat

CH8

000-255

<TC7

Color Effect

CH9

000-255

Red (0%-100%)

CH10

000-255

Green (0%-100%)

CH11

000-255

Blue (0%-100%)

CH12

000-255

White (0%-100%)

16 Channel Mode:

Channel List

Value

Function

CH1

000-255

Pan(0-630)

CH2

000-255

Pan Fine(Least significant bit)

CH3

000-255

Tilt (0-240)

CH4

000-255

Tilt Fine(Least significant bit)

CH5

000-255

Pan & Tilt Speed

CH6

000-255

Pan & Tilt Auto Run

CH7

000-255

Auto Run Speed

CH8

000-240

Reset 240 / 255 Aoto run color

CH9

000-255

Dimmer (0%-100%) A

www.flash-butrym.pl Strona 9

CH10

000-255

Strobe

CH11

000-255

Red (0%-100%)

CH12

000-255

Green (0%-100%)

CH13

000-255

Blue (0%-100%)

CH14

000-255

White (0%-100%)

CH15

000-255

Color Auto Run

CH16

000-255

Color Auto Run Speed

Reset

Press the MENU button up to when the Reset is blinking on the display. Pressing

ENTER button and all channels of the unit will return to their standard position.

EC-Declaration of Conformity

We declare that our products (lighting equipment) comply with the following

specification and bears CE mark in accordance with the provision of the

Electromagnetic Compatibility (EMC) Directive

89/336/EEC.

EN55014-2:1997A1:2001;EN61000-4-2:1995;EN61000-4-3:2002; EN61000-4-

4:1995; EN61000-4-5:1995; EN61000-4-6:1996,

EN61000-4-11:1994

Harmonized Standard

EN60598-1:2000+ALL: 2000+A12:2002 Safety of household and similar electrical

appliances Part 1:General requirements
