Instruction
The oil filled radiator is manufactured to the highest specifications, utilizing the latest technology. It is finished
to a high standard and is safe and easy to use. To get the best from this product and prolong its life, please
spare a few minutes to read the user instructions.
Features
Large 7/9/11/13fins heating surface provides uniform radiation.
Automatic temperature controller for adjusting and maintaining the desired room temperature.
Special high-speed heat conducting oil is utilized.
Equipped with castor wheels for easy of movement.
Important! Safety Guidelines
1) The radiator should always be kept upright.
2) Don’t position your radiator near to the flammable materials. Allow a distance of at least 50mm between
furniture, curtain, walls, etc.
3) Don’t position your radiator immediately under a socket outlet.
4) If the cord becomes worn, it must be replaced by a qualified technician.
5) Don’t lay the cords over the radiator when not in use.
6) Don’t cover the radiator with anything.
7) The radiator must not be used in a bathroom or near a source of water.
8) It’s normal for the radiator to make a noise when it is being used for the first time.
9) In case of problems with the radiator, please don’t attempt any repairs. Refer repairs only to qualified
service personnel.
10) The oil used in this radiator is of a specification particular to this type of radiator and is manufactured with
a precisely measured quantity. Only approved agents must open up the oil container section to carry our
repairs. Any oil leak must be reported to and repaired by qualified service personnel.
11) Check that your supply voltage is the same as the shown on the rating label and that the socket is earthed.
Fitting the wheels for guidance
1) Turn the radiator upside down and rest on a soft surface to prevent scratching the radiator housing.
2) Screw the wheel plate onto the radiator, using the wire loops and wing nuts provided.
3) Push the castor wheels onto the wheel pins on the plate until they “click” into place.
4) Turn the radiator back to its correct upright position.
Operation
1) Turn the thermostat (B) to the highest setting and switch on the two power buttons (C). When the desired
temperature has been reached, turn back the thermostat until the indicator lamp goes out.
2) Simply adjust the thermostat to retain the desired temperature.
3) The indicator lamp indicates whether or not the radiator is working.
Warning
1）This appliance is not intended for use by persons (including children)with reduced physical ,sensory or
mental capabilities ,or lack of experience and knowledge , unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
2）If the supply cord is damaged ,it must be replaced by the manufacture ,its service agent or similarly qualified
persons in order to avoid a hazard.
3）The instructions for heaters marked：“ DO NOT COVER ” or with the “ DO NOT COVER ” symbol
shall contain the substance of the following :WARNING :in order to avoid overheating ,do not cover the
heater.
4）The instructions shall state that the heater must not be located immediately below a socket outlet.
