Flowzone FZSAAE Bedienungsanleitung

OPERATION GUIDE

FZSAAE

™

4-GALLON BACKPACK & ROLLER

LITHIUM-ION SPRAYER

Let’s get spraying!

You have chosen one of the leading multi-purpose sprayers available today. It can be used either as a

backpack or rolling sprayer to emit any number of solutions and solvents for both home and

professional use. Please read this manual carefully to ensure that you get the

most out of your new sprayer.

Because FlowZone™ sprayers are distributed exclusively by WESSOL™,

you can rest assured that you are working with a world-class

sprayer and friendly customer service.

If you need assistance with the assembly or operation of

your sprayer, please don’t hesitate to contact us:

www.fzspray.com/support

spraysquad@fzspray.com

+1 803 339 2500

FlowZone FZSAAE SPECIFICATIONS

Model number

FZSAAE

Pump type

gear pump

Battery type

Lithium-ion

Continuous working

time

45 min

Battery voltage

3.6V

Working pressure

45 psi

Battery capacity

2600mAH

Spray distance

15 feet

Battery charging time

2 hours

Tank capacity

4 gallons

Battery cycle life

1000 cycles

Liquid ﬂow

0.17 gallon/min

Battery charger

5V / 1A

Pump life

200 hours

Here’s what your sprayer is capable of doing.

This FlowZone sprayer is a highly eﬃcient sprayer that is suitable for spraying many kinds of water-soluble chemicals

such as fertilizers, pesticides, cleaning products, etc. Never operate the sprayer with strong acids, strong bases or ﬂammable

liquids. Powered by a 3.6V lithium-ion battery, this sprayer results in 3-4x more eﬃciency than a manual sprayer. This sprayer

can be operated continuously for up to 45 minutes and spray more than 7 gallons per battery charge at a distance of 15 feet.

WARNING

THIS PRODUCT IS DESIGNED TO APPLY

CHEMICALS THAT MAY BE HARMFUL

AND COULD CAUSE SERIOUS PERSONAL

INJURY IF INHALED OR BROUGHT INTO

CONTACT WITH THE USER. FAILURE TO READ

AND FOLLOW OPERATION GUIDE BEFORE

USE AND/OR MISUSE OF THIS PRODUCT

COULD RESULT IN INJURY.

1. SPRAY GUN

2. HOLSTER (ROLLER)

3. HOLSTER (BACKPACK)

4. TANK (4 GAL)

5. ROLLER HANDLE

6. BATTERY CHARGER

7. COILED HOSE

8. SCREW, BOLTS & NUTS

9. TANK CAP / HOSE

10. BACKPACK STRAPS

11. INTAKE FILTER

12. EXTENSION WAND

13. ROLLER HANDLE BAR

14. ROLLER BASE

What’s in the box.

Attach roller

handle to top

of bar and

thread bolt and

nut through the

slot. Tighten both

top and bottom

knobs to the bar.

Slide the roller

holster onto

the middle

of the

roller

handle

bar and

screw into the bar.

Aﬃx tank to

roller base

& tighten

the knob

on back

of roller base.

Continue to Step 2.

Insert roller

handle bar into

roller base so the

end with 2 holes

is in the base.

Remove the

nuts and bolts

from liquid

intake cap.

Determine the

best bar height

for you and

thread bolt

and nut

through slot.

STEP 1a: Set up as a rolling sprayer.

Remove the

nuts and bolts

from liquid

intake cap.

STEP 1b: Set up as a backpack sprayer.

Place the spray gun/

extension wand

holster over the tank

outlet hole.

Loop each fabric strap

through the top loop of the

tank and thread back

through the bottom

side of the buckle.

Attach each metal loop

on the backpack straps

to the bottom two

loops on the tank.

Determine which nozzle

is appropriate for your

project and connect

nozzle by pulling down

quick-connect on gun.

1. Short nozzle = adjustable, ranging from a jet

spray to a conical spray.

2. Extension wand =conical misting spray

STEP 2: Get started spraying.

Fully charge the battery prior to

ﬁrst operation.

Fill the tank with pre-prepared

liquid through intake ﬁlter and

securely tighten tank cap.

Disengage handle lock and ON/OFF

switch and press down on the spray

gun trigger to begin spraying.

NOTE: Can spray continuously or on-command.

Connect coiled hose with on/oﬀ

switch end attached to spray gun &

other end connected to tank cap.

STEP 3: After you spray.

Rinse out the solution you sprayed with water and spray

water through the sprayer for 3-5 minutes to

completely rid tank of chemicals.

NOTE: Many spray materials will harden if left in the sprayer and

plug up the nozzle, shut-oﬀvalve or supply tube.

Dry sprayer tank completely.

For long-term storage, regular discharging and

recharging of the battery is required (with an

interval of either every 2 weeks, one month,

or two months) to maximize battery life.

Clean the nozzle.

Always store tank in a clean, empty and shady

location protected from extreme heat or frost.

Disconnect coiled hose from tank (not gun) and

spray to completely empty hose and gun of liquid.

Other important considerations.

Do not operate the spray gun without

liquid in it. This may damage the pump.

After long periods of time without use,

the battery may have a low voltage and

will require extended charging.

Always wear protective clothing,

respirator, gloves, eye protection, etc.

when using chemicals.

Never spray chemicals against the wind

or towards humans, animals or food.

Don’t operate sprayer in temperatures

exceeding 100°F or lower than 32°F.

Never operate with strong

acids, strong bases or

ﬂammable liquids.

Never ﬁll the sprayer with hot

liquids (max. temp. = 85°F).

Do not leave the sprayer in

reach of children or persons

not qualiﬁed to handle it in a

proper fashion.

Always use FlowZone original

replacement parts.

Do not dispose of lithium-ion

battery with household waste,

recycle where facilities exist.

FlowZone Limited Warranty

To register your sprayer, visit:

fzspray.com/register

WESSOL, LLC warrants (to the original purchaser) that this product will continue to function as intended if used in

accordance with operating instructions (under normal consumer use) for a period of one year.

If the product fails to function as intended DO NOT RETURN IT TO THE STORE,call our customer support hotline at +1

803-339-2500 or email spraysquad@fzspray.com. We will, at our option, repair or replace any non-functioning parts without

charge (shipping & handling charges will apply). WESSOL, LLC shall have the option of requiring the return of the non-

functioning product; together, with the proof of purchase, to establish a claim under this warranty. This warranty does not

apply to damage resulting from accident, misuse, neglect, alterations, or operation not in accordance with instructions,

commercial use, or normal wear.

ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR CONSUMER USE,

ARE LIMITED TO THE DURATION SPECIFIED ABOVE. WESSOL, LLC’S LIABILITY IS LIMITED SOLELY TO THE REPAIR OR

REPLACEMENT OF THE NON-FUNCTIONING PRODUCT OR PART. WESSOL, LLC EXCLUDES LIABILITY UNDER THIS WARRANTY

FOR ANY AND ALL INCIDENTAL AND CONSEQUENTIAL LOSS OR DAMAGE.

Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or

consequential damages, so these limitations or exclusions may not apply to you. This warranty gives you speciﬁc legal rights

and you may have other rights which vary from state to state.

FOR ANY QUESTIONS OR CONCERNS:

www.fzspray.com/support

spraysquad@fzspray.com

+1 803 339 2500
