Fluance FiSDK500 Bedienungsanleitung
FiSDK500
Thank you for your purchase of this Fluance® product. Please read this instruction manual carefully before using product to
ensure proper use. Keep this manual in a safe place for future reference.
INSTRUCTION MANUAL
HIGH PERFORMANCE MUSIC SYSTEM
www.uance.com
iPod® not included.
®
For more product information visit www.uance.com
NEED
HELP?
DO NOT RETURN THIS
PRODUCT TO THE STORE
Please contact a FLUANCE® customer support representative rst regarding any additional
information on product features, specications or assistance with setup.
Please contact us via one of the methods below:
Toll-free telephone:
1.888.61.SOUND (1.888.617.6863)
Email:
sales@uance.com
Online live web chat:
Visit www.FLUANCE.com
Toll free fax:
1.888.771.1701
®
NEED
HELP?
DO NOT RETURN THIS
PRODUCT TO THE STORE
Please contact a FLUANCE® customer support representative rst regarding any additional
information on product features, specications or assistance with setup.
Please contact us via one of the methods below:
Toll-free telephone:
1.888.61.SOUND (1.888.617.6863)
Email:
sales@uance.com
Online live web chat:
Visit www.FLUANCE.com
Toll free fax:
1.888.771.1701
- 3 -
TABLE OF CONTENTS
NEED HELP?.............................................................................................................. 2
TABLE OF CONTENTS ................................................................................................. 3
WHAT’S INCLUDED ................................................................................................... 3
FEATURES ................................................................................................................ 3
IMPORTANT SAFETY INSTRUCTIONS ........................................................................... 4
BUTTONS AND CONNECTIONS .................................................................................... 6
SETUP ...................................................................................................................... 9
OPERATION .............................................................................................................. 11
SPECIFICATIONS ....................................................................................................... 13
FLUANCE WARRANTY ................................................................................................ 14
WHAT’S INCLUDED
• High Performance Music System for iPod/iPhone®
• Remote Control (Battery included)
• 6 iPod/iPhone Dock Adaptors
• 4.5ft RCA Audio Composite Connection Cable
• 4.5ft RCA Video Composite Connection Cable
• 2 Year Parts and Labour Warranty
• Lifetime Live Customer Support
FEATURES
• High delity sound quality.
• Experience room lling music that you can feel.
• Premium components ensure serious performance.
• Audiophile grade wood construction.
• Innovative design and high gloss nish.
• Allows you to recharge your iPod/iPhone.
• Full function of iPod/iPhone with remote control.
• Separate treble and bass adjustment controls.
• LED display.
- 4 -
1. Read all instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularily at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged. Liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. Apparatus shall not be exposed to dripping or splashing, and that not objects lled with liquids, such as vases,
shall be placed on the apparatus.
16. The battery shall not be exposed to excessive heat such as sunshine, re or the like.
17. The MAINS plug is used as the disconnect device, which shall remain readily operable.
18. The apparatus shall be connected to a MAINS socket outlet with a protective earthing connection.
19. WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.
This class[B] digital apparatus complies with Canadian ICES-003.
The lightning ash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sucient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
This symbol means that this unit is double insulated. An
earth or ground connection is not required.
WARNING: To reduce the risk of re or shock hazard, do not
expose this product to rain or moisture.
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
The CAUTION marking is located on the bottom panel.
IMPORTANT SAFETY INSTRUCTIONS
- 5 -
IMPORTANT SAFETY INSTRUCTIONS
FCC statement on regulation
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and sued in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on,the user is encouraged to try to correct the
interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
· Consult the dealer or an experienced radio TV technician for help.
iPod® and iPhone® are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.
- 6 -
BUTTONS AND CONNECTIONS
MUSIC SYSTEM − FRONT
MUSIC SYSTEM − TOP
1 2
1 2 3 4
1. INPUT/VOLUME INFORMATION DISPLAY
2. IR RECEIVER
1. STANDBY BUTTON
2. INPUT SELECTION
3. VOLUME − DECREASE
4. VOLUME + INCREASE
- 7 -
MUSIC SYSTEM − BACK
1. VIDEO OUTPUT
2. AUXILIARY AUDIO INPUT
3. POWER ON/OFF SWITCH
4. AC POWER CORD
REMOTE CONTROL− BACK
1. BATTERY COMPARTMENT 1
3 4
2
1
BUTTONS AND CONNECTIONS
- 8 -
1
2
3
4
5
6
8
10
7
9
11
13
12
14
1. STANDBY
2. MENU
3. iPod/iPhone MENU DOWN
4. ENTER/AUTO
5. PREVIOUS TRACK/REWIND
6. iPod/iPhone PLAY/PAUSE
7. iPod/iPhone INPUT
8. TREBLE +/−
9. BASS +/−
10. RESET
11. iPod/iPhone MENU UP
12. NEXT TRACK/FAST FORWARD
13. AUXILIARY AUDIO INPUT
14. MASTER VOLUME +/−
REMOTE CONTROL− FRONT
BUTTONS AND CONNECTIONS
- 9 -
SETUP
Setting up the remote control:
Battery installation:
1. Release the slide latch of the battery compartment on the back of the remote control.
2. Pull out the battery holder.
3. Install only a 3V CR2025 battery and ensure that the battery polarity "+" corresponds to the
"+" sign on the battery holder.
4. Replace the battery holder.
Please note:
• Use only the recommended size and type of battery specied.
• Please be sure to follow the correct polarity when installing the battery in the battery
compartment. A reversed battery may cause damage to the remote control.
• Do not drop or bump the remote control as this may damage the internal components of
the remote.
• When not using the unit for a prolonged period of time, please remove the battery to avoid
possible damage caused by a leaking battery.
Optimal range for the remote control:
1. When pressing the buttons on the remote control,
aim it at the IR receiver on the Music System.
2. The distance between the Music System and the
remote should be no more than 16.5 feet (5 meters)
and within 30° with an unobstructed view.
- 10 -
NOTE: To prevent any damages to the base connector, do not shake or bump the iPod/iPhone
during playback.
The remote control may be less eective if:
1. A strong light is placed near the IR receiver.
2. There are obstacles between the remote control and the IR receiver.
3. Other remote controls are being used in the area at the same time.
4. The remote control has a low battery.
Connecting your iPod/iPhone to your Music System:
1. Ensure that the iPod/iPhone and the Music System are turned o before docking your
iPod/iPhone.
2. Select the correct docking bracket that corresponds to the size of your iPod/iPhone. You can also
use the original universal bracket that came with your iPod/iPhone.
3. Insert the correct docking bracket into the iPod/iPhone connection area located on the top of
the Music System.
4. Ensure that the iPod/iPhone is securely connected to the Music System.
Connecting your Music System to a TV or CD/DVD/RECEIVER:
TV
CD/DVD/RECEIVER
SETUP
