Fluke 62 MAX Bedienungsanleitung
PN 4060712
April 2012 Rev. 1, 11/12
© 2012 Fluke Corporation. All rights reserved. Printed in China.
Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
62 MAX/62 MAX +
Infrared Thermometer
Users Manual
LIMITED WARRANTY AND LIMITATION OF LIABILITY
This Fluke product will be free from defects in material and workmanship for three
years from the date of purchase. This warranty does not cover fuses, disposable
batteries, or damage from accident, neglect, misuse, alteration, contamination, or
abnormal conditions of operation or handling. Resellers are not authorized to
extend any other warranty on Fluke’s behalf. To obtain service during the warranty
period, contact your nearest Fluke authorized service center to obtain return
authorization information, then send the product to that Service Center with a
description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH
AS FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED.
FLUKE IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR
THEORY. Since some states or countries do not allow the exclusion or limitation of
an implied warranty or of incidental or consequential damages, this limitation of
liability may not apply to you.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
11/99
i
Table of Contents
Title Page
Introduction.................................................................................................................1
How to Contact Fluke ................................................................................................. 1
Safety Information ...................................................................................................... 2
Maintenance............................................................................................................... 6
How to Change the Battery ....................................................................................6
How to Clean the Product ......................................................................................6
Specifications .............................................................................................................7
Standards and Agency Approval................................................................................ 9
The Product ................................................................................................................10
62 MAX/62 MAX +
Users Manual
ii
1
Introduction
The Fluke 62 MAX and 62 MAX + Infrared Thermometers (the Product) can determine the
surface temperature by measuring the amount of infrared energy radiated by the target’s
surface. Note that the Japanese models indicate Celsius only.
Warning
Read all safety information before you use the Product.
How to Contact Fluke
To contact Fluke, call one of the following telephone numbers:
•Technical Support USA: 1-800-44-FLUKE (1-800-443-5853)
•Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
•Canada: 1-800-36-FLUKE (1-800-363-5853)
•Europe: +31 402-675-200
•Japan: +81-03-6714-3114
•Singapore: +65-6799-5655
•Anywhere in the world: +1-425-446-5500
62 MAX/62 MAX +
Users Manual
2
Or, visit Fluke's website at www.fluke.com.
To register your product, visit http://register.fluke.com.
To see, print, or download the latest manual supplement, visit
http://us.fluke.com/usen/support/manuals.
Safety Information
A Warning identifies conditions and procedures that are dangerous to the user. A Caution
identifies conditions and procedures that can cause damage to the Product or the equipment
under test.
Table 1 tells you about symbols used on the Product and in this manual.
Warning
To prevent eye damage and personal injury:
•Read all safety Information before you use the Product.
•Do not use the Product if it operates incorrectly.
•Use the Product only as specified, or the protection supplied by the
Product can be compromised.
•Before you use the Product, inspect the case. Do not use the Product if it
appears damaged. Look for cracks or missing plastic.
Infrared Thermometer
Safety Information
3
•See emissivity information for actual temperatures. Reflective objects
result in lower than actual temperature measurements. These objects
pose a burn hazard.
•Do not look directly into the laser with optical tools (for example,
binoculars, telescopes, microscopes). Optical tools can focus the laser
and be dangerous to the eye.
•Do not look into the laser. Do not point laser directly at persons or
animals or indirectly off reflective surfaces.
•Replace the batteries when the low battery indicator shows to prevent
incorrect measurements.
•Do not use the Product around explosive gas, vapor, or in damp or wet
environments.
•Use the Product only as specified or hazardous laser radiation exposure
can occur.
62 MAX/62 MAX +
Users Manual
4
Table 1. Symbols
Symbol Meaning Symbol Meaning
Risk of danger. Important
information. See Manual.
This product complies with the
WEEE Directive (2002/96/EC)
marking requirements. The
affixed label indicates that you
must not discard this
electrical/electronic product in
domestic household waste.
Product Category: With
reference to the equipment types
in the WEEE Directive Annex I,
this product is classed as
category 9 "Monitoring and
Control Instrumentation” product.
Do not dispose of this product as
unsorted municipal waste. Go to
Fluke’s website for recycling
information.
Infrared Thermometer
Safety Information
5
Table 1. Symbols (cont.)
Symbol Meaning Symbol Meaning
Warning. Laser. Conforms to European Union
directives.
Battery Conforms to relevant Australian
standards.
Conforms to China Metrology Certification
62 MAX/62 MAX +
Users Manual
6
Maintenance
Caution
To avoid damage to the Product, do not leave the thermometer on or near
objects of high temperature.
How to Change the Battery
To install or change the AA IEC LR06 battery, open the battery compartment and replace the
battery as shown in Figure 16.
How to Clean the Product
Use soap and water on a damp sponge or soft cloth to clean the Product case. Carefully wipe
the surface with a moist cotton swab. The swab may be moistened with water. See Figure 17.
