Flybox APR1 Bedienungsanleitung
FLYBOX
®
FLYBOX
®
APR1
Automatic Propeller Regulator
User Manual
FLYBOX
REV 1.0
2
®
User Manual, Safety Instructions
and Warning Booklet
This product is not TSO’d and cannot be installed
into traditional FAA Part 23 and similarly Type-
Certicate Aircraft
Document A2021APR1
Revision#1.0, 09/2021
For rmware version 1.0
This booklet is suitable for printing in A5 format.
FLYBOX
SECTIONS
REV 1.0 3
®
APR1-User Manual,
Safety Instructions and Warning Booklet
INTRODUCTION
IMPORTANT NOTICE AND WARNINGS
INDEX
SYSTEM OVERVIEW
OPERATING INSTRUCTIONS
GENERAL SUGGESTIONS
TECHNICAL SPECIFICATIONS
WARRANTY
DISCLAIMER
FLYBOX Introduction
REV 1.0
4
®
APR1-User Manual,
Safety Instructions and Warning Booklet
Examples of available screens
Homepage: NORMAL
Homepage: IASTAB
Homepage: MAPTAB
FLYBOX
Introduction
REV 1.0 5
®
APR1-User Manual,
Safety Instructions and Warning Booklet
Thank you for purchasing a Flybox® APR1 instrument.
The APR1 instrument is available in 4 dierent models.
This manual describes the use of each of the 4 models.
APR1-LC (standard low current)
APR1-HC (standard high current)
APR1-M-LC (MAP - low current)
APR1-M-HC (MAP - high current)
All models are installable in a standard 2-1/8" (57mm)
hole.
Our intention in developing the APR1 family of
instruments was to create a product that is light and
compact, powerful and easy to use.
The APR1 family of instruments features a highly visible
display, a powerful 32-bit microcontroller and state-of-the-
art solid-state sensors to ensure reliability and accuracy
over time.
The owner has the option of keeping the instrument
software up-to-date by downloading the latest revision
available on www.yboxavionics.it and installing it via a
USB pen drive.
We are condent that our products will be satisfactory and
make your ying experience enjoyable.
FLYBOX Important notice & warnings
REV 1.0
6
®
APR1-User Manual,
Safety Instructions and Warning Booklet
Symbols used in the User Manual
NOTE: Used to highlight important information.
CAUTION: Used to warn the user, it indicates a potentially
hazardous situation or improper use of the product.
WARNING: Used to indicate a dangerous situation that
can cause personal injury or death if the instruction is
disregarded.
FAILURE TO DO SO MAY RESULT IN SERIOUS
INJURY OR DEATH.
FLYBOX
Important notice & warnings
REV 1.0 7
®
APR1-User Manual,
Safety Instructions and Warning Booklet
WARNING: These instructions must be provided to users
before use, and retained for ready reference by the user.
The user must read, understand (or have explained) and
heed all instructions and warnings supplied with this
product and with those products intended for use in
association with it. Always keep a copy of the Installation
and User Manual, Safety Instructions and Warning
Booklet on the aircraft. In case of change of ownership,
the Installation and User Manual, Safety Instructions and
Warning Booklet must be delivered together with all of the
other papers.
WARNING: Read the Installation and User Manual, Safety
Instructions and Warning Booklet before installing the
device on your aircraft and follow the procedure described
therein.
WARNING: This device is intended to be installed on
NON-TYPE CERTIFIED AIRCRAFT ONLY, as it does
NOT require any air operator’s certicate. Refer to your
national aviation authorities to check if this device can be
installed on your aircraft.
WARNING: It is the owner’s responsibility to test this
device before operating the aircraft and to make sure
nobody is using it unless properly instructed and
authorized to do so.
WARNING: Once the installation process is completed, it
is extremely important to test the device before taking o
to make sure it works properly. Therefore, we strongly
suggest to double check all of the electronic instruments
available on the aircraft and to turn them on to verify they
function correctly.
FLYBOX Important notice & warnings
REV 1.0
8
®
APR1-User Manual,
Safety Instructions and Warning Booklet
WARNING: This device is operated through a software
which from time to time can be updated and/or subject to
change. Please, always refer to the Installation and User
Manual, Safety Instructions and Warning Booklet for the
last updated version of the software available on
www.yboxavionics.it
WARNING: It is the responsibility of the installer to
properly install the device on the aircraft. In case of
calibration, or any technical or functional customization of
the device, the responsibility lies with the individual who
carried out such operation.
WARNING: If this product is not used correctly, or it is
subjected to additions or alterations, the eectiveness of
this device may be considerably reduced.
WARNING: Alterations, additions, or repairs not
performed by the instrument manufacturer or by a person
or organization authorized by the manufacturer shall
negate any warranty.
WARNING: The unit isn’t waterproof. Serious damage
could occur if the unit is exposed to water or spray jets.
WARNING: Installation and conguration of this
instrument should only be carried out by trained and
authorised professionals. See the Flyboxavionics website
for a list of authorised installers.
FLYBOX
Important notice & warnings
REV 1.0 9
®
APR1-User Manual,
Safety Instructions and Warning Booklet
NOTE: The consumer decides of his own free will if the
purchased product is suitable and safe for his need. If the
consumer does not agree with the notices contained in this
Installation and user Manual, Safety Instructions and Warning
Booklet, do not install this instrument in his aircraft.
NOTE: Flybox Avionics reserves the right to change or improve
its products as well as terms, conditions, and notices under
which their products are oered without prior notice.
NOTE: The Installation and User Manual, Safety Instructions
and Warning Booklet will be updated annually if needed.
All changes or updates will be published on our website
www.yboxavionics.com in the "support" section.
NOTE: Check the website www.yboxavionics.it periodically for
software and manual updates.
NOTE: For some products, registration may be required to
receive important news or information on available rmware
updates or to receive security information.
FLYBOX Index
REV 1.0
10
®
APR1-User Manual,
Safety Instructions and Warning Booklet
INDEX
Introduction………………………………………… 4
Important notice & warnings……………………… 6
1.0 System Overview……………………………… 12
2.0 Panel Indicators and Commands….………… 14
2.1 Setup Menu Navigation………………………. 15
3.0 Indication on the “Normal” screen.………….. 16
3.1 Indication on the “IASTAB” screen.…………. 18
3.2 Indication on the “MAPTAB” screen.………… 19
4.0 Main Menu……………………………………… 20
4.1 Propeller Test………………………………….. 20
4.2 Dimmer………………………………………… 21
4.3 SETUP………………………………………… 22
4.3.1 Control Submenu………………………….. 22
4.3.2 Manually Modify RPMs in ADV-ADV+ Mode 26
4.3.3 Home Submenu……………………………. 27
4.3.4 Backlight…………………………………….. 28
4.3.5 IAS Setup……………………………………. 29
4.3.6 Debug………………………………………… 31
4.4 Firmware Update……………………………… 32
4.5 Backup/Restore……………………………….. 33
4.6 Logger………………………………………….. 34
4.7 About…………………………………………… 35
