BK AND BKT BLOWER ACCESSORY

INSTALLATION INSTRUCTIONS

MODEL BK

MANUALLY CONTROLLED

BLOWER

MODEL BKT

THERMOSTATICALLY

CONTROLLED BLOWER

WARNING: ELECTRICAL GROUNDING INSTRUCTIONS This

appliance is equipped with a three-prong (grounding) plug for your

protection against shock hazard and should be plugged directly into

a properly grounded three-prong receptacle.

(Check your appliance owner's manual for specic applications and additional instructions.)

Parts included with this kit.

Tools required

Pliers•

Phillips Screwdriver•

Flat Blade Screwdriver•

If any of these pieces are missing or damaged, or if the installation instructions for your re-

place or stove are not included in this manual, contact the dealer where you purchased this

kit or FMI PRODUCTS, LLC at 1-866-328-4537 for referral information.

PART NO. DESCRIPTION QTY

119943-01 Blower assembly with speed

control and 6 foot cord

• • 1

104901-01 Wire assembly • 1

103650-01 Control Knob • • 1

103651-01 Lock Nut • • 1

11125 #8- 1/2'' Phillips Head Screw • • 1

101378-01 Thermodisc Switch, 100

° Limit

• 1

104902-02 Switch Mounting Bracket • 1

109892-01 Speed Control Bracket

(Stamped Face Models)

• 1

109892-02 Speed Control Bracket (Panel

Louver Models)

• 1

BKT

www.fmiproducts.com 108998-01G2

Figure 2: Accessing Duplex Electrical Outlet installed in Bottom Right

Side of Firebox

Figure 1: Accessing Blower Compartment (Controls Not Shown for Clarity) B-vent,

Wood and Vent-Free Models

The BK and BKT blowers utilize the same

rotary squirrell cage type blower with magnetic

attachment and variable speed control. The

BKT also includes an additional thermostati-

cally controlled feature for use on some direct-

vent models only.

The BK blower can be installed in wood burn-

ing, B-vent and vent-free model replaces.

Both the BK and BKT blowers can be installed

in direct-vent model replaces. Blowers are

installed by accessing the blower compart-

ment through the lower louver panel or, on

some models, through the control access

cover under the front refractory panel (see

Figure 1). The lower front louver panel can be

removed easily, see removing louver panel,

page 3 for instructions.

WARNING: Ifthereisaduplex

electrical outlet installed in the

right side of the bottom of the

replace base area (see Figure

2), be sure that the electrical

power to the outlet is turned off

before proceeding with blower

installation. Failure to do this

may result in serious injury.

Duplex

Electrical

Outlet

Front Refractory

Panel

Control

Access

Cover

Knockout

plug

Lower Louver Panel

www.fmiproducts.com

108998-01G 3

Figure 3: Removing Louver Panel with Spring Latches

(Direct-Vent Models)

Figure 4: Removing Louver Panel with Bullet-Style Clips

(Direct-Vent Models)

REMOVING LOUVER PANEL

Louver

Panel

Bullet-Style

Clips

Locating

Holes

WOOD, B-VENT AND VENT-FREE

MODELS

For models other than direct-vent, remove

panel or stamped face louver by snapping

out the front with a at blade screwdriver (see

Figure 1, page 2). Use caution not to scratch

any surfaces. These panels can also be re-

moved by inserting ngertips between slots

and gently pulling out. DO NOT FORCE. The

panels are actually held in place by means of

a retention dimple embossed on the edge of

the panel. To reinstall, place louver into cavity

and push gently.

DIRECT-VENT MODELS

There are two different types of direct vent

louvers: spring latch and bullet-style clip.

Spring Latch: Remove louver with spring

latches by simultaneously pulling both top

spring latches toward the center of the appli-

ance until they are disengaged from the latch-

ing holes. Repeat for bottom spring latches

and pull louver outward (see Figure 3). To

reinstall, simple reverse procedure.

Bullet-Style Clip: Remove louver with bullet-

style clips by using a at blade screwdriver and

snapping louver forward. Use caution not to

scratch any surfaces. These panels can also be

removed by inserting ngers between slots on

louver and gently pulling out. DO NOT FORCE

(see Figure 4). To reinstall, align bullet-style

clips with locating holes on inside of rebox

and push gently.

Rolled

Louver

Panel

Spring

Latch

www.fmiproducts.com 108998-01G4

Note: The BKT blower is for application into

direct-vent models only. When installing the

BKT thermostatically-controlled blower, you

must rst secure the thermal switch bracket

to the blower if it has not already been fac-

tory installed.

Place the green ground wire with ring 1.

terminal between the bottom hole on the

thermal switch bracket and the top ear

hole on the blower assembly. Insert the

phillips screw into all three pieces and

tighten securely (see Figure 6).

Connect wire harness and power cord 2.

terminals. Connect the jumper wire to the

blower motor terminal and the right side

terminal of the thermal switch. Connect

one wire to the left side of the thermal

switch and one wire to the other remain-

ing blower motor terminal.

Note: Speed control switches can not be

installed into ligree panels. Installing a wall

switch or thermostat in the wall outside of

replace will eliminate removing bottom louver

to adjust operation of blower.

Attach the power cord to the blower 1.

motor by rmly pushing the two female

terminals at the end of the power cord

onto the two spade terminals on the

blower motor (see Figure 5).

Attach green ground wire from power 2.

cord to blower housing using screw

provided (see Figure 5) Tighten screws

securely with a phillips screwdriver.

Place the blower against the lower rear 3.

wall of the rebox outer wrapper with

the exhaust port directed upward. De-

pending on your model, you may have

to carefully route the blower assembly

past the controls and brackets, and

position the blower inside the back open-

ing. The blower will be held in position

against the back wall by the magnets

incorporated onto the blower housing

(see Figure 5).

Be certain that all wire terminals are 4.

securely attached to terminals on blower

motor and that the screw retaining the

green ground wire is tight.

Figure 5: Blower Model BK Figure 6: Blower Model BKT

MODEL BK WIRE

ASSEMBLY

MODEL BKT WIRE

ASSEMBLY

Blower

Location

Blower Installed

After Lower Panel

Removed

Air Flow

Direction

Magnetic strips

Green

Ground

Wire

Spade

Terminals

Screw

Magnets

Side view Firebox Bottom

Route BKT Blower

Through this Area

Ring

Therminal

on Green

Wire

Jumper Wire

To Blower

Motor Terminal

Thermal

Switch

Bracket

Thermal

Switch

Thermal

Switch

Blower

Location

Air Flow

Direction

Air Flow

Direction

Exhaust

Port

Magnetic strips

Phillips

Screw

Power Cord

Magnets

Thermodisc

Side view Firebox Bottom

Note: The power cord outer insulation sleeve

may have to be stripped slightly to allow

enough wire length to reach and make all

connections. DO NOT trim excessive length

away. Just anable enough to make all con-

nections securely.

www.fmiproducts.com

108998-01G 5

Figure 7: Attaching Speed Control to

Direct-Vent Firebox

MOUNTING SPEED

CONTROL

Figure 8: Attaching Speed Control to

Firebox with Panel Louvers Using Speed

Control Bracket 109892-02

MODEL BKT WIRE

ASSEMBLY

Continued

DIRECT-VENT MODELS

Mount the speed control box by placing the

plastic control shaft forward through the

mounting opening on the pre-installed bracket

(see Figure 7).

While supporting the speed control in the

vertical position, secure the control shaft by

pushing and turning the lock nut with pliers

until it is tight against the mounting bracket.

Place control knob provided on the control

shaft (see Figure 7).

MODELS WITH STAMPED PANEL LOU-

VERS

Wood, B-Vent, and Vent-Free models

Position speed control bracket by insert-1.

ing ange of bracket between hearth

pan and upper ange of louver opening,

then seat bottom end of bracket onto

lower flange of louver opening (see

Figure 8).

Mount speed control box by placing 2.

plastic control shaft through bottom hole

on speed control bracket. Top screw

head on control box will t inside top

hole on bracket (see Figure 8). Secure

speed control to bracket with lock nut

by pushing and turning lock nut with

pliers clockwise until it is tight against

bracket.

Remove knockout plug from louver panel 3.

by depressing top and bottom retaining

clips (see gure 1, page 2).

Place louver panel, louvers pointing up, 4.

back into framed opening. Align control

shaft with rectangular opening by slid-

ing control bracket along ange (see

Figure 8).

Fully seat louver panel into frame open-5.

ing by gently pressing along ends until

all dimpled retainers have snapped in

place.

Place control knob, provided, onto con-6.

trol shaft (see Figure 8).

Control

Shaft

Control

Knob

Lock Nut

Pre-installed

Bracket

(Direct-Vent

Only)

Bottom Front Refractory

Bottom Rear

Refractory

Lower Louver Panel

Control

Shaft

Firebox

Face

Hearth Pan

Flange

Speed

Control

Speed

Control

Bracket

Lower

Flange

Control Knob

Lock Nut

Place the blower against the lower rear 3.

wall of the rebox outer wrapper with

the exhaust port directed upward and

the thermodisc position up near the

replace bottom. The thermodisc must

be oriented near the replace bottom

as shown in Figure 6 in order to sense

temperature and properly operate. The

blower will be held in position against the

back wall by the magnets incorporated

onto the blower housing (see Figure 6,

page 4).

Be certain thet all wire terminals are 4.

securely attached to terminals on blower

motor and thermal switch, and that the

screw for the thermodisc bracket and

green ground wire is tight.

To mount speed controls, see 5. Mounting

Speed Control for All Direct Vent Models

(below), Mounting Speed Control for All

Models with Panel Louvers (colum 2) or

Mounting Speed Control for All Models

with Stamped Face Louvers (page 5),

depending on your model.

www.fmiproducts.com 108998-01G6

MODELS WITH STAMPED FACE LOUVERS

(B36, VB36 WOOD BURNING UNITS)

Using pliers, bend two retaining tabs on 1.

speed control bracket 90 degrees to front

of bracket (see Figure 9).

Mount speed control box by placing 2.

plastic control shaft through bottom hole

on speed control bracket. Top screw

head on control box will t inside top

hole on bracket (see Figure 9). Secure

speed control to bracket with lock nut

by pushing and turning lock nut with

pliers clockwise until it is tight against

bracket.

Remove knockout plug from louver panel 3.

by depressing top and bottom retaining

clips (see Figure 1, page 2).

Position speed control assembly over 4.

ange on hearth pan by sliding bracket

up between the face and ange, then

down until the control shaft is aligned

with the opening in the louver panel

(see Figure 9).

Lock two retaining tabs onto lower louver 5.

by pressing down on bracket assembly

while sliding control knob through rect-

angular opening on louver and onto the

control shaft (see Figure 9).

Speed Control

Bracket with

Assembly

Srew Head

and Top Hole

on Bracket

Control

Shaft

Control Shaft

Hearth Pan

Flange

Firebox Face

Speed

Control

Bracket

Retaining

Tabs

Retaining Tab

Control Knob

Louver Panel

Lock Nut

Figure 9: Attaching Speed Control to Firebox with Stamp Faced Louvers (B36 and

VB36 Models) Using Speed Control Bracket 109892-01

MOUNTING SPEED

CONTROL

Continued

www.fmiproducts.com

108998-01G 7

Check to make sure that the power cord 1.

is completely clear of the blower wheel

and that there are no other foreign ob-

jects in blower wheel. Also double check

all wire leads and make sure wire routing

is not pinched or in a precarious position.

Correct accordingly.

CAUTION: Never touch the

blower wheel while in operation.

CONNECTING POWER AND

OPERATING BLOWER

Turn on power to duplex outlet if previ-2.

ously turn off per the warning on page

Plug in blower power cord to duplex 3.

outlet (see Figure 2, page 2).

BK Model: Turn blower on and check 4.

for operation. Turn blower off by turn-

ing knob fully counterclockwise before

continuing.

BKT Model: The blower will only run 5.

when the speed control knob is in the ON

position and the Thermal switch senses

temperature after the replace begins

to heat up. The blower speed can be

adjusted by rotating the control knob. To

turn off, turn knob fully counterclockwise

until it clicks off. If the blower is ON and

has been running with the fireplace

operating, the blower will continue to

run for a short time after the replace

has been turn off. As the thermal switch

cools down, the blower shuts down

automatically.

Peel off the backing paper and stick the 6.

supplied wiring diagram decal on the

rebox bottom approximately 12'' in front

of the blower (see Figure 10).

Replace all panels and/or brick bottom 7.

if previously removed.

Figure 10: Location of Wiring Diagram Decal (Model May Vary From Illustration)

Figure 11: Wiring Diagram

Variable

FanSwitch

White

Black

Green

110/115

V.A.C.

Blower

Motor

Black

Off

Wiring Diagram Decal

12'' in Front of Blower

Red

Va riable

Fan Switch Fan Switch

(N.O.)

Green

White

11 0/115

V . A.C.

Blower

Motor

Black

Off

Black

Blue

(BKT Model Only)

108998-01

Rev. G

07/10

2701 S. Harbor Blvd.

Santa Ana, CA 92704

1-866-328-4537

www.fmiproducts.com

Dieses Handbuch passt für folgende Modelle

Andere FMI Gebläse Handbücher

FMI

FMI BKT Kurzanleitung

Beliebte Gebläse Handbücher anderer Marken

Weed Eater

Weed Eater VS2000BV Bedienungsanleitung

KRAUSMANN

KRAUSMANN U37020-00 Bedienungsanleitung

Bosch

Bosch ALB 36 LI Bedienungsanleitung

Cub Cadet

Cub Cadet HB425 Bedienungsanleitung

GreenWorks Pro

GreenWorks Pro BLB482 Bedienungsanleitung

ARIETE

ARIETE 2768 Bedienungsanleitung

NuTone

NuTone 331H Bedienungsanleitung

GÜDE

GÜDE GLB 200 18 Li-Ion Bedienungsanleitung

I.VA.CO.

I.VA.CO. SC Series Betriebsanleitung

DeWalt

DeWalt DCE100 Bedienungsanleitung

Becker

Becker SV 7.330 Bedienungsanleitung

Metabo

Metabo AG 18 Pro Bedienungsanleitung

Desa

Desa GA3650TB Bedienungsanleitung

Echo

Echo Power Blower PB-230LN Bedienungsanleitung

Echo

Echo PB-413H Bedienungsanleitung

Black & Decker

Black & Decker BV3100 Bedienungsanleitung

Ryobi

Ryobi RY08570 Bedienungsanleitung

Haaga

Haaga 355 Bedienungsanleitung
