Fopo S12 Bedienungsanleitung
Toll-free: +1 833 637 2188
(09:00-18:00 (Monday to Friday) EST;
11:00-20:00 (Saturday to Sunday) EST
Portable Monitor
Triple Portable MonitorModel:S12
Toll-free: +1 833 637 2188
(09:00-18:00 (Monday to Friday) EST;
11:00-20:00 (Saturday to Sunday) EST
Contents1. Overview2. Package Contents3. Inputs and Buttons4. Set It Up5. Connect the Monitor with Your Laptop6. Choose Your cables7. Connection Methods 7.1 Two Type-C or Thunderbolt 3/4 Ports 7.2 One Full Functioned Type-C and HDMI Port Connection 7.3 Other Connection Type (Extra Adapter Needed)8. Laptop Display Configuration 8.1 PC/WINDOWS 8.2 MAC9. OSD Function Introduction10. OSD Setting11. Supported Brands & Models12. Tech Specs13. Cleaning & Maintenance14. FAQ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------12356788101112121314151822232415. Contact Us--------------------------------------------------------------------------------26
1. Overview1Triple Monitor 2* Screen Protectors1* Laptop Bag1* Cleaning Cloth1* Hook-and-loop Fastener1*Power Adapter2*USB-C to USB-A CablesPOWER ONLY2*Mini HDMI to HDMI CablesVIDEO ONLY2*USB-C to USB-C (90-degree) CablesVIDEO & POWER6* Protective Caps
1* Portable Triple Monitor2* USB-C to USB-C cables2* USB-C to USB-A Cables2* HDMI Cables1* Laptop Bag1* Cleaning Cloth1* Hook-and-loop Fastener1* Power Adapter6* Protective Caps2* Screen Protectors2. Package Contents2Note:Please kindly check out all the accessories in the package. If you find anything missing, please don't hesitate to contact us via toll free +1 833 637 2188 or via the email address [email protected] and we will help you solve the problems.
33. Inputs and Buttons*It only displays the interfaces and buttons function. The sequence of inputs and buttons is different on the left screen and right screen. Please check the actual machine for the specific position of interfaces and buttons.
Decrease the brightness; Return to the previous page; Decrease the valueIncrease the brightness; Enter the Menu, and press it to turn to the next selection; Increase the valuePress the Menu to enter the OSD (On-Screen Display) menuMini HDMI Port (No Power Supply): Video Signal TransmissionType-C Full Function Port: Power Supply, Video Signal Transmission
- /Return
+/Next
Menu/Enter
Mini HDMI
(Video Only)
Type-C
(Video&Power)
Type-C
(Video&Power)
- /Return
+/Next
Menu/Enter
Mini HDMI
(Video Only)
Type-C
(Video&Power)
Type-C
(Video&Power)
Left Screen Right Screen
Warning4Turning Angle of ScreensRight screen(0° - 180°)Left Screen(0°-235°)Note:Please handle the triple monitor with care and do not press the screens to avoid damages. Do not unfold it to exceed its maximum turning angle showing as above.Using the protective cap if your laptop is an ultra-thin style(laptop screenthickness ≤6mm), it helps to reduce the shaking.Protective cap
Protective cap
4. Set It Up5Unpack the triple monitor.Open two screens in the directions as shown in Fig. 2.Place the bracket at the back of the laptop screen and install it well with the bracket clamping the screen firmly.Lift up the stand and stretch to its end. Press and hold the button to adjust the stand.(The stand is embedded at the back of the triple monitor, which can offer extra support to the triple monitor. )Using the necessary cables, plug one end of the cable into the triple moni-tor and the other into your laptop. 3 egap no ”snottuB dna stupnI“ eeS(for the input diagram. )1) 2) 3) 4) 5) 13524
Length：262-375mm（10.3-14.76 inch）Height：≥190mm（≥7.48 inch）Thickness：≤8.5mm（≤0.33 inch）5. Connect the Monitor with Your Laptop6
262-375mm
190mm
Please measure the length, height and thickness of the laptop first to make sure it can be compatible with the monitor.Compatibility of Laptops for the Triple Monitor: Notes: If laptop size is not within this range, please feel free to contact us via toll free+1 833 637 2188 or via the email address [email protected] , and we will help you solve the problems as soon as possible.
7To determine which cables you will use, first identify your laptop’s ports accord-ing to the figure below or your laptop’s user manual.*Make sure your USB-C port on the laptop is full-functioned port. Please refer to your laptop's user manual.Notes: VIDEO & POWER:VIDEO ONLYPOWER ONLY6. Choose Connecting Cables
4
