for Living 16335 Bedienungsanleitung
Solar Powered
10-Pack Stake Lights
Product No. 052-8008-2
Model No. 16335
Operating Instructions
Toll free: 1-877-483-6759
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
2Product No. 052-8008-2 •Model No. 16335
Parts List 3
Overview 4
About Your Solar Light 4
Important 5
Getting Started 5
Installation & Operation 6
Battery Replacement 7
Troubleshooting Tips 8
Care Information 9
Warranty 10
Table of Contents
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
1-877-483-6759
If you have questions regarding your product, require warranty assistance, or have damaged
or missing parts, please call our customer service toll-free helpline. Contact us for assistance,
we’re here to help.
3
Parts List
Solar Garden Light - 10 AAA Ni-CD Rechargeable Battery - 10
1 2
IMPORTANT: Please read and understand this manual before any assembly. Before beginning assembly of
product, make sure all parts are present. Compare parts with packaging contents list. If any part is missing,
or if you have any questions, contact the service centre at 1-877-483-6759 (toll free).
4Product No. 052-8008-2 •Model No. 16335
Overview
This product is designed to the highest technical specifications and standards. It will supply years of
maintenance-free use. Please read these instructions thoroughly prior to installation, then store in a safe
place for future reference.
About Your Solar Light
During the day, your solar panel will convert the sun’s light and/or UV rays into electrical power that will
charge the rechargeable battery. When it becomes dark, the solar light will turn on using the power stored
in the rechargeable battery. The unit’s light-output strength and time depends on how much sunlight and/or
UV rays your panel has absorbed throughout the day.
For maximum output, place the solar panel in an area where there is direct sunlight for at least 8 hours per
day. Do not install your solar light in a shaded area. The selected location should not be near nighttime
light sources such as porch lights, street lights or pool lights, as these may cause the solar light to turn off
prematurely.
Overview
5
Important
• Fully charge the battery before first use. Charge under direct sunlight for 2 days.
• For best results, locate your solar lamp in a position where it can get direct sunlight on the solar panel and
is generally free from cover and shade.
• Keep your solar lights away from other nighttime light sources, such as street lights.
• Make sure the solar panels are not covered by dust, snow and debris. Clean with a soft, damp cloth or
paper towel periodically. Avoid the use of abrasive cleaning agents.
• Use only solar rechargeable AAA batteries for your solar lights. Replace with new batteries yearly for
optimum performance.
• If there is a protective film on the solar panel, carefully remove this.
Getting Started
Please do not throw away any packing material until all parts are verified as present.
Important
6Product No. 052-8008-2 •Model No. 16335
1. Carefully twist off the Solar Cap Afrom the
Lens B.
2. Remove the pull tab from the battery
compartment.
3. Insert Pole Cover base of Lens Buntil secure.
4. Remove preinstalled Ground Spike Dfrom base
of Pole C. Insert base of Ground Spike Dso that
spiked end now faces downward.
5. Assembled light should now appear as shown in
image.
6. Complete steps 1-4 for all 10 lights.
7. Stake fixture into ground in an area that receives
direct sunlight for (2) full sunny days.
8. Your solar-powered light will automatically turn on
when it becomes dark.
Installation & Operation
1
A
3
5
C
D
A
B
B
7
For best results, the solar battery should be replaced every 12 months. ONLY replace the battery with a
similar solar rechargeable battery of the same or greater mAh rating.
DO NOT use alkaline batteries.
Caution: Rechargeable batteries contain Nickel-Cadmium or Nickel-Metal Hydride and must be
recycled or disposed of properly. Do not mix old and new batteries. Do not mix alkaline, standard
(carbon-zinc), or rechargeable batteries. Do not dispose of batteries in fire. Batteries may explode
or leak.
DO NOT mix old and new batteries.
1. Carefully twist off the Solar Cap Afrom the Lens B.
2. Carefully remove the old battery from the battery compartment.
3. Replace battery with an equivalent new solar rechargeable battery,
ensuring the correct polarity is observed.
4. Re-assemble the unit by reversing the above procedure.
5. Allow the unit to charge for up to (2) days in an area that receives direct
sunlight.
6. Your solar-powered light will automatically turn on when it becomes dark.
1
A
B
Battery Replacement
8Product No. 052-8008-2 •Model No. 16335
Troubleshooting Tips
If your solar light does not come on at dusk despite following all instructions please try the following steps:
1. Make sure that the solar light is not affected by any other light source.
2. Ensure the solar light does not stand in the shade all day.
3. Remove the pull tab from the battery compartment.
4. Check to see if the batteries are installed correctly.
5. Battery may need to be replaced.
Troubleshooting Tips
Dispose of used batteries per municipal or provincial law.
Caution! Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries.
Do not dispose of batteries in fire. Batteries may explode or leak.
9
Care Information
1. Clean any dirt and debris from the solar panel. The panel cannot recharge if the light is obstructed. Use
a soft cloth to clean the panel. Do not use abrasives or chemicals that might scratch or damage the UV
coating.
2. In a region where snow and ice are likely, and the light assembly is covered with snow for an extended
period of time, the batteries will require recharging for at least 8 hours.
Care Information
10 Product No. 052-8008-2 •Model No. 16335
Warranty
This For Living®product carries a one (1) year warranty against defects in workmanship and materials.
Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty
period, when returned by the original purchaser with proof of purchase. This product is not guaranteed
against wear or breakage due to misuse and/or abuse.
Made in China.
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
