Forma Scientific, Inc.
P.O. Box 649
Marietta, Ohio 45750
Telephone: (614) 373-4763
Telefax: (614) 373-4189
________________________________________
Models:
8516/8517 and
8523
Non-CFC Ultra-Low Temperature
Upright Storage Freezers
17.3 and 23.0 cubic foot
capacity
Manual No. 7008516 Rev. 6
IMPORTANT!
READ THIS INSTRUCTION MANUAL.
Failure to read, understand and follow the instructions in this manual may result in
damage to the unit, injury to operating personnel and poor equipment performance.
Caution: All internal adjustments and maintenance must be performed by
qualified service personnel.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Forma Scientific, Inc.
NOTE:
The material in this manual is for information purposes only. The contents and
the product it describes are subject to change without notice. Forma Scientific Inc.
makes no representations or warranties with respect to this manual. In no event shall
Forma Scientific Inc. be held liable for any damages, direct or incidental, arising out
of or related to the use of this manual.
MANUAL NO. 7008516
- SI-5679 4-25-96 Revised component locations to sides of Model 8523. heg
6 SI-317 10-23-95 Added Power Failure indicator to Enviro-Scan
5 FR-881 8/8/95 Clarified operation of the Power Line Voltage key
N/A FR-867 8/8/95 Revised temperature probe cover hardware
4 4-00784 2/13/95 Add Section 2.4, Moving the Model 8523 through a doorway
3 FR-781 12-2-94 250115 was 250111 (220V models only)
2 FR-765 11-1-94 214008 was 993102
1 9-1-94 Added optional double door freezer, Section 3.9, door heater to parts list.
0 12-1-93 New manual for new product
REV ECN DATE DESCRIPTION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Forma Scientific, Inc.
___________________________________________________________________________
GENERAL SAFETY NOTES USED IN THIS MANUAL
This symbol alerts the user to important operating and/or
maintenance instructions. It may be used alone or with other
safety symbols. Read the accompanying text carefully.
Potential electrical hazards. Only qualified persons should
perform the instructions and procedures associated with this
symbol.
Extreme temperature hazards, hot or cold. Instructions
associated with this symbol should only be carried out when
using special handing equipment or when wearing special,
protective clothing.
Potential biological hazards. Proper protective equipment and
procedures must be used when following instructions
associated with this symbol. Reference O.S.H.A.
Regulation 1910-1030.
Potentially hazardous energy. Equipment being maintained or
serviced must be turned off and locked off to prevent
possible injury. Reference O.S.H.A. Regulation 1910-147.
Remember:
√
√√
√Always use the proper protective equipment (clothing, gloves, goggles etc.).
√
√√
√Always dissipate extreme cold or heat, or wear protective clothing.
√
√√
√Always follow good hygiene practices.
√
√√
√Each individual is responsible for his/her own safety.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Forma Scientific, Inc.
___________________________________________________________________________
Do you need information or assistance on Forma
Scientific products?
If you do, contact us 8:00 A.M. to 5:00 P.M. (Eastern Standard Time) at:
1-614-373-4763
1-800-848-3080
1-614-373-4189
Direct
Toll Free, U.S. and Canada
FAX
International customers should contact your local sales group.
Forma's Inside Sales Support Group can provide information on pricing, give you
quotations, take your order and provide delivery information on major equipment items.
The Forma Product Service Group can supply technical information about proper setup,
operation or troubleshooting of your equipment and fill your needs for spare or replacement parts or
provide you with on-site service.
Whatever Forma products you need or use, we will be happy to discuss your applications. If
you are experiencing technical problems, working together, we will help you locate the problem and,
chances are, correct it yourself .... over the telephone without a service call.
When more extensive service is necessary, you can count on Life Sciences International
North America (LSI/NAS) for on-the-spot repairs by trained professional field technicians. In
addition to checking the reported problem, the technicians also check basic operation, such as:
Control Calibrations
Temperature
CO2Levels
Compressors
Electrical Circuits
Recorders
Blowers/Fans
R.H. Levels
The following cities and their surrounding areas are covered by LSI/NAS personnel.
Phoenix, AZ
Los Angeles, CA
San Diego, CA
San Francisco, CA
Denver, CO
Washington, DC
Atlanta, GA
Des Moines, IA
Chicago, IL
Boston, MA
Detroit, MI
St. Louis, MO
Raleigh/Durham, NC
Newington, NH
Newark, NJ
New York City, NY
Rochester, NY
Cincinnati, OH
Cleveland, OH
Philadelphia, PA
Washington, PA
Pittsburgh, PA
Memphis, TN
Austin, TX
Dallas/Ft. Worth, TX
Houston, TX
Seattle, WA
Within the continental United States, service coverage is by Life Sciences
International North America (LSI/NAS). They offer a Bi-Annual Performance Check which provides a
complete checkout of your equipment twice a year. This keeps minor problems from becoming major
ones. If you would like to know more about the Bi-Annual Performance Check, contact LSI/NAS,
Toll-free, at 1-800-467-4627.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Forma Scientific, Inc.
___________________________________________________________________________
TABLE OF CONTENTS
SECTION 1 - RECEIVING
1.1 Preliminary Inspection
1.2 Visible Loss or Damage
1.3 Responsibility for Shipping Damage
SECTION 2 - INSTALLATION
2.1. Introduction
a. Enviro-Scan Microprocessor Monitoring System
b. Non-CFC, non-HCFC and non-Flammable
Refrigerants
c. Peak Control System
d. "Smart" Condenser Fans
e. Built-In Automatic Voltage Compensation
2.2. Unpacking List
2.3. Installing the Wall Bumpers
2.4 Moving the Model 8523 through a Doorway
2.5 Location
2.6 Connecting Power to the Freezer
2.7 Deactivating the Enviro-Scan Monitor for Storage
2.8 RS-232 Output Interface
2.9 Remote Alarm Connector
SECTION 3 - ENVIRO-SCAN MONITOR
3.1 The Enviro-Scan Monitor
3.2 Enviro-Scan Monitor Description
3.3 Main Power Switch
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Forma Scientific, Inc.
___________________________________________________________________________
SECTION 3 - ENVIRO-SCAN MONITOR (continued)
3.4 Key Functions Requiring No Access Code
a. Access Keys
3.5 Key Functions Requiring the Access Code
a. Set Point Adjustment Screw
3.6 Audible Alarm and Control Panel Indicators
3.7 Set Point Adjustment Screwdriver
3.8 Automatic Voltage Compensation System
3.9 Double Door Freezer (Factory-Built Option)
SECTION 4 - START UP
4.1 Setting the Operating Temperature
4.2 Setting the Low and High Limit Set Points
4.3 General Recommendations
4.4 Operation of the Weksler Temperature Recorder (Optional)
SECTION 5 - CALIBRATION
5.1 Calibration Description
5.2 Calibrating the Alarm Monitor Temperature Probe
5.3 Calibrating the Control Set Point Temperature Probe
5.4 Changing the Access Code
SECTION 6 - ROUTINE MAINTENANCE
6.1 Cleaning the Condenser
6.2 Cleaning the Air Filter
6.3 Defrosting the Chamber
6.4 Cleaning the Door Gasket
6.5 Cleaning the Vacuum Relief Port
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Forma Scientific, Inc.
___________________________________________________________________________
SECTION 7 - SERVICE
7.1 Servicing the Refrigeration System
7.2 Troubleshooting Guide
SECTION 8 - SPECIFICATIONS
SECTION 9 - PARTS LIST
SECTION 10 - REFRIGERATION DRAWINGS
SECTION 11 - ELECTRICAL SCHEMATICS
SECTION 12 - SUPPLEMENTS AND WARRANTY INFORMATION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Forma Scientific, Inc.
1-1
SECTION 1 - RECEIVING
1.1 Preliminary Inspection
This item was thoroughly inspected and carefully packed prior to shipment and all
necessary precautions were taken to ensure safe arrival of the merchandise at its
destination. Immediately upon receipt, before the unit is moved from the receiving area,
carefully examine the shipment for loss or damage. Unpack the shipment and inspect
both interior and exterior for any in-transit damage.
1.2 Visible Loss or Damage
If any loss or damage is discovered, note any discrepancies on the delivery receipt.
Failure to adequately describe such evidence of loss or damage may result in the carrier
refusing to honor a damage claim. Immediately call the delivering carrier and request
that their representative perform an inspection. Do not discard any of the packing
material or move the shipment from the receiving area.
1.3 Responsibility for Shipping Damage
For products shipped F.O.B. Marietta, Ohio, the responsibility of Forma Scientific,
Inc. ends when the merchandise is loaded onto the carrier's vehicle.
On F.O.B. Destination shipments, Forma Scientific's and the carrier's responsibility
ends when your Receiving Department personnel sign a free and clear delivery receipt.
Whenever possible, Forma Scientific, Inc. will assist in settling claims for loss or
in-transit damage.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Forma Scientific, Inc.
2-1
SECTION 2 - INSTALLATION
2.1 Introduction
The 8500 Series Forma Scientific non-CFC, Ultra-Low Temperature Freezers
feature front-to-back air circulation for cooler compressor temperatures, increased
performance and reliability and longer compressor life. In this unique system, ambient
air enters the front grill of the freezer and passes through the filter, condenser and
compressor housing, exiting out of the rear of the unit.
An enlarged condenser and two cooling fans contribute to better efficiency, even in
high ambient conditions. Oversize condensers also help extend compressor life.
Cleaning the air filter and condenser fins is done from the front of the unit.
Other important features of the Forma Scientific 8500 Series Freezers are:
a. Enviro-Scan Microprocessor Monitoring System
Enviro-Scan uses a digital display, audible and visual indicators and a touch
sensitive key pad to provide total control of all freezer functions. The module digitally
displays chamber temperature and control setpoint, to the nearest degree C. High and
low alarm set points are easily programmed. A back-up battery system supplies power to
the monitoring system during electrical outages.
An RS-232 port provides a computer interface and monitoring of temperatures and
alarms. A remote alarm connector is also a standard feature.
b. Non-CFC, non-HCFC and non-Flammable Refrigerants
Committed to a safer, healthier environment, Forma Scientific has phased out the
use of ozone depleting CFC (chlorofluorocarbons) in all of the company's refrigerated
products. Forma also uses non-CFC foamed-in-place urethane insulation and all
packaging used in shipping are non-CFC.
c. Peak Control System
Due to the increased demands on today's refrigeration systems, Forma Scientific has
engineered a compressor protection system called PEAK Control. In this system, a
pressure switch senses excessive compressor discharge pressure. When the discharge
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Andere Handbücher für 8500 Series
1
Dieses Handbuch passt für folgende Modelle
3
Inhaltsverzeichnis
Andere Forma Scientific Gefrierschrank Handbücher
