Fortinet FortiGate 40F Series Bedienungsanleitung
QuickStart Guide
FortiGate 40F & 60F Series
Product Registration
Thank you for purchasing a FortiGate. To access:
http://support.fortinet.com
▪ Cloud Management ▪FortiGuard Updates ▪Firmware Upgrades
▪Technical Support ▪Warranty Coverage
Please register your FortiGate:
Vous devez enregistrer le produir:
Debe registrar el producto:
登録のお願い:
请马上注册:
3
April 13, 2020
Copyright© 2019 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks
of Fortinet, Inc., in the U.S. and other jurisdictions, and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All
other product or company names may be trademarks of their respective owners. Performance and other metrics contained herein were attained in internal
lab tests under ideal conditions, and actual performance and other results may vary. Network variables, different network environments and other conditions
may affect performance results. Nothing herein represents any binding commitment by Fortinet, and Fortinet disclaims all warranties, whether express or
implied, except to the extent Fortinet enters a binding written contract, signed by Fortinet’s General Counsel, with a purchaser that expressly warrants that
the identified product will perform according to certain expressly-identified performance metrics and, in such event, only the specific performance metrics
expressly identified in such binding written contract shall be binding on Fortinet. For absolute clarity, any such warranty will be limited to performance
in the same ideal conditions as in Fortinet’s internal lab tests. In no event does Fortinet make any commitment related to future deliverables, features or
development, and circumstances may change such that any forward-looking statements herein are not accurate. Fortinet disclaims in full any covenants,
representations, and guarantees pursuant hereto, whether express or implied. Fortinet reserves the right to change, modify, transfer, or otherwise revise this
publication without notice, and the most current version of the publication shall be applicable.
2
54
Table of Contents
Product Series
Installation
Licensing & Services
About Fortinet
Setup
FortiGate 40F Series..................................................................................... 6
3G4G Series........................................................ 10
FortiGate60F Series ................................................................................... 14
Basic Connections ..................................................................................... 17
Wall Mount Option...................................................................................... 18
Desktop Option .......................................................................................... 19
Rack/Rail Mount Option............................................................................. 20
Setup Options............................................................................................. 21
GUI .............................................................................................................. 22
FortiGate Cloud .......................................................................................... 24
FortiExplorer ............................................................................................... 25
Command Line Interface (CLI) ................................................................... 26
Resources................................................................................................... 27
Free Licences & Services........................................................................... 28
FortiCare Subscriptions ............................................................................. 30
Bundled Services with FortiCare ............................................................... 32
Fortinet Security Fabric.............................................................................. 34
FortiGate Security Fabric Integration ........................................................ 36
Solution Spotlight: Secure SD-WAN.......................................................... 38
Fortinet Security Processors ..................................................................... 40
Corporate Overview ................................................................................... 42
Regulatory Compliance Information.......................................................... 44
76
QuickStart Guide
A
40F
FortiGate 40F/ 41F Series
Package Contents - FG 40F
Ethernet Cable
Wall Mount Hardware
(Optional)
Wall Mount Kit
(Optional)
Back Panel - FG 40F
3
4
1
2
2
3
5
4
6
1
Ethernet Ports 1 to 3 (RJ-45) 1 Gbps Ethernet connections
Power 12V DC, 100-240V AC 50/60Hz adapter
Console (RJ-45) CLI management computer interface
WAN (RJ-45) 1 Gbps Ethernet interface
FortiLink Port A (RJ-45) 1 Gbps Ethernet interface (FortiLink interface)
56
USB (USB A) USB 3.0 server port
40F/41F40F/41F
DC Power AdapterAdapter Plugs
98
A
40F
2
3
6
5
4
1
FortiGate
Green: The device is on
Off: The device is off
Green: Power is on
Off: Power is off
: FortiLink interface
Green: Normal
Flashing Green: Booting up
LOGO
PWR
STATUS
HA
PORT
LINK/ACT
PORT
SPEED
FortiLink
4
Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
Green: Connected at 1Gbps
Amber: Connected at 100Mbps
Off: Not connected or 10Mbps
Green: Connected
Flashing Green:Transmitting data
Off: No link established
1235 6
Front Panel - FG 40F
40F/41F
1110
Wall Mount Kit with Hardware
(Optional)
QuickStart Guide
A
40F-3G4G
3G/4G 3G/4G
SVC
3G/4G
FortiGate 40F/41F 3G4G Series
Package Contents - FG 40F-3G4G
Ethernet Cable
3x 3G4G Antennas
(40F 3G4G models only)
Back Panel- FG 40F-3G4G
40F/41F 3G4G
DC Power AdapterAdapter Plugs
3
4
1
2
2
3
5
4
6
1
Ethernet Ports 1 to 3 (RJ-45) 1 Gbps Ethernet connections
Power 12V DC, 100-240V AC 50/60Hz adapter
Console (RJ-45) CLI management computer interface
WAN (RJ-45) 1 Gbps Ethernet interface
FortiLink Port A (RJ-45) 1 Gbps Ethernet interface (FortiLink interface)
56
USB (USB A) USB 3.0 server port
1312
A
40F-3G4G
3G/4G 3G/4G
SVC
3G/4G
Antenna Connection (3x SMA) WWAN antenna connections
8
2
3
6
5
4
1
Green: Power is on
Off: Power is off
: FortiLink interface
Green: Normal
Flashing Green: Booting up
PWR
STATUS
HA
PORT
LINK/ACT
SVC
3G/4G
PORT
SPEED
FortiLink
4
Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
Green: Connected at 1Gbps
Amber: Connected at 100Mbps
Off: Not connected or 10Mbps
Green: Connected
Flashing Green:Transmitting data
Off: No link established
Green: SVC is on
Flashing Green:SVC activity
Off: SVC is off
Green: 3G4G is on
Flashing Green:3G4G activity
Off: 3G4G is off
1237 85 6
7
Front Panel- FG 40F-3G4G SIM Card Installation
231
2 SIM 1
NOTE: For more information on Wireless WAN Configuration, please refer to the FortiOS
Handbook at docs.fortinet.com
Secondary(2) Primary(1)
40F/41F 3G4G
1514
QuickStart Guide
A B
60F
FortiGate 60F/61F Series
Package Contents - FG 60F
12V DC Power AdapterPower Cable
Ethernet Cable
Wall Mount HardwareWall Mount Kit
3
4
1
2
2
3
4
5
5
6
1
Ethernet Ports 1 to 5 (RJ-45) 1 Gbps Ethernet connections
Power 12V DC, 100-240V AC 50/60Hz adapter
Console (RJ-45) CLI management computer interface
DMZ (RJ-45) 1 Gbps Ethernet interface
WAN1 & WAN2 (RJ-45) 1 Gbps Ethernet interfaces
FortiLink Ports A & B (RJ-45) 1 Gbps Ethernet FortiLink auto-detect connections
7
6
USB (USB A) USB 3.0 server port
Back Panel - FG 60F
7
60F/61F
Installation
1716
A B
60F
2
3
6
5
4
1
FortiGate
Green: The device is on
Off: The device is off
Green: Power is on
Off: Power is off
: FortiLink interfaces
Green: Normal
Flashing Green: Booting up
LOGO
PWR
STATUS
HA
PORT
LINK/ACT
PORT
SPEED
FortiLink
4
Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
Green: Connected at 1Gbps
Amber: Connected at 100Mbps
Off: Not connected or 10Mbps
Green: Connected
Flashing Green:Transmitting data
Off: No link established
12356
Front Panel - FG 60F Installation
Your FortiGate includes a wall mount kit and connection cables. Desktop
installation, rack mount and slide-rail kits are also available.
1. Plug in your device to a power outlet using the provided power cable
a. The 60F series uses a desktop power adapter and cable
b. The 40F series uses a wall mount adapter with US, EU or UK plugs
2. Connect a WAN port to the internet using the supplied Ethernet cable
Power Outlet
or UPS
Internet
Power Connection
Power Adapter & Cable
(60F Series)
Ethernet Cable
WAN port
Note: We recommend connecting your FortiGate to an uninterruptible power
supply (UPS) in case of a power outage
Basic Connections
Installation
1918
Wall Mount Option
1. Mark the location of the holes using the mounting bracket
2. Drill holes for the anchors
3. Insert the anchors and then screw in the screws with 2mm exposed
4. Fasten the mounting bracket
5. Position the device and slide into place
6. Plug the provided power cable into the rear of the unit and then into a grounded
electrical outlet or separate power source
Desktop Option
1. Place the unit on a flat, clean and stable surface
2. Ensure there is at least 1.5in of clearance for adequate airflow
3. Plug the provided power cable into the rear of the unit and then into a grounded
electrical outlet or separate power source
1.5in
1.5in
1.5in
1.5in
