Fostex FE103En Bedienungsanleitung

Features

Frequency Response / Impedance

Dimensions & Mounting Information

Overall Diameter :

Bafe Hole Diameter

Depth :

mm / in

Specications

Thiele/Small Parameters

Size :

Voice Coil Diameter

Cast / Stamped :

Impedance :

Reproduction Frequency Response

:fs -

Sound Pressure Level

Rated Input :

Music Power :

Magnet Material :

Magnet Weight

(main) :

(cancel) :

Net Weight

mm / in

Ω

kHz

dB/W(m)

g / lb

a :

Sd :

Zn :

Fs :

Re :

Le :

Qms :

Qes :

Qts :

Mms :

BL :

Vas :

Xmax :

Eff/η0 :

Cms :

EBP :

Ω

Telsa/m

m/N

FE103En

FULL RANGE SPEAKER UNIT

100 3.9

20 0.8

Stamped

Ferrite

193 0.425

580 1.279

107 4.2

93 3.7

45.5 1.8

• ES cone and center cap are adapted.

This new diaphragm material has the

fine, supple and high density fiber, and

its characteristics successfully improve

the mid-high frequency reproduction.

• ø 80mm strong ferrite magnet is em-

ployed.

• Well tuned Qts / Mms values for ease of

use in small bass reex type enclosures

to folded horn enclosures.

0.005

7.5

0.0398

2.747

0.377

0.33

2.55

4.99

5.95

0.6

0.72

1.65

220.16

φ115

4-5x7

23.3 2.5

45.5

φ80

φ92

107

Recommended Back Loaded Horn Type Enclosure

Example of

FE103En

s t a n d a r d

bass reflex

type enclo-

sure. Inter-

nal volume

i s 6 l i t e r s

tuned to

95Hz (Fb).

• Shown is an example of a FE103En

back loaded horn type enclosure.

• The horn length is designed a little

longer to 2m, and cutoff frequency is

set at 50Hz for extended low frequency

reproduction.

Recommended Standard Bass Reex Type Enclosure

(190)

160

ø93

ø50

(190)

(300)

270

130

unit:mm / 15mm thick

840

150

180

ø93

405

400

250

200

150

100

150

375

380

155

190

250

385

250

340

(240)

245

810

235

(25)

unit:mm / 15mm thick

840

810

400

385

380

375

340

200

190

180

250

245

235

155

150

100

405 150 150 150

Distributor / Authorised Dealer

www.fostex.jp

In accordance with our policy of continuous development, we reserve the right to change specifica tions without notice.

Fostex Co. ,3-2- 35 Musa shino, Akishima,T okyo,J apa n 196-0 021

Tel :+81(0) 42-546-497 4 Fax:+8 1(0)42 -546 -9222

Printed in China 500283
