Fröling TI 350 Bedienungsanleitung

Installation Instructions

TI 350

Translation of the original German installation instructions for technicians

Read and follow the instructions and safety information!

Technical changes, typographical errors and omissions reserved!

M1830521_en | Edition 18/02/2021

Fröling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Table of Contents

1 General 5

2 Safety 6

2.1 Hazard levels of warnings 6

2.2 Qualification of assembly staff 7

2.3 Personal protective equipment for assembly staff 7

3 Design Information 8

3.1 Notes on standards 8

3.1.1 General standards for heating systems 8

3.1.2 Standards for structural and safety devices 8

3.1.3 Standards for heating water 8

3.1.4 Regulations and standards for permitted fuels 9

3.2 Installation and approval of the heating system 9

3.3 General information for installation room (boiler room) 9

3.4 Requirements for central heating water 10

3.5 Notes for using pressure maintenance systems 12

3.6 Return lift 12

3.7 Use with storage tank 13

3.8 Chimney connection/chimney system 13

3.8.1 Draught limiter 13

4 Technology 14

4.1 Dimensions 14

4.2 Components and connections 15

4.3 Technical data 16

4.3.1 Boiler data for planning the flue gas system 18

5 Assembly 19

5.1 Transport 19

5.2 Temporary storage 19

5.3 Positioning 19

5.4 Setting up in the boiler room 20

5.4.1 Moving the boiler in the boiler room 20

5.4.2 Operating and maintenance areas of the equipment 21

5.5 Installing the boiler 22

5.5.1 General information 22

5.5.2 Installing the grate drive 23

5.5.3 Installing the stoker unit 24

5.5.4 Bolting together the combustion chamber and heat exchanger 24

5.5.5 Repositioning the WOS lever (if required) 26

5.5.6 Fitting the WOS drive 27

5.5.7 Installing the air controllers 28

5.5.8 Installing the ash removal chamber 28

5.5.9 Installing the heat exchanger ash removal unit 30

Table of Contents

2 Fröling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

5.5.10 Installing the air ducts 32

5.5.11 Installing the adapter flange und pump assembly (optional) 32

5.5.12 Installing the igniter tube and undergrate temperature sensor 33

5.5.13 Installing the spacer plate on the combustion chamber 33

5.5.14 Positioning two-layer thermal insulation on the combustion chamber 34

5.5.15 Positioning thermal insulation on the heat exchanger 35

5.5.16 Installing the frames 36

5.5.17 Preparing the cooling piping (optional) 41

5.5.18 Installing the cooling piping (optional) 41

5.5.19 Installing the piping of the safety battery 42

5.5.20 Fit sensor and wire components 43

5.5.21 Installing the cladding 45

5.5.22 Fitting the control cabinet 48

5.5.23 Installing the combustion chamber door components 49

5.5.24 Installing the ash container limit switch 50

5.5.25 Installing the combustion chamber temperature sensor and ignition 51

5.5.26 Installing the underpressure controller 52

5.5.27 Installing remaining covers 53

5.5.28 Installing the broadband probe and flue gas temperature sensor 54

5.5.29 Installing the induced draught fan 54

5.5.30 Installing the flue gas recirculation (FGR) 55

5.5.31 Positioning the ash container 59

5.5.32 Flue gas piping 60

5.6 Power connection and wiring 60

5.6.1 Potential equalisation 61

5.6.2 Installing the cable duct covers 61

5.7 Connecting the hydraulic safety devices 62

5.8 Cooling connection 64

5.9 Final installation steps 65

5.9.1 Setting and checking the seal on the door 65

5.9.2 Adjusting the door 66

6 Commissioning 67

6.1 Before commissioning / configuring the boiler 67

6.2 Initial startup 68

6.2.1 Permitted fuels 68

Wood chips

Wood pellets

Wood shavings

Miscanthus

Changing the fuel

6.2.2 Non-permitted fuels 69

6.3 Heating up for the first time 70

6.3.1 Screed drying 71

7 Decommissioning 73

7.1 Out of service for long periods 73

7.2 Disassembly 73

7.3 Disposal 73

8 Notes 74

9 Appendix 76

Table of Contents

Installation Instructions TI 350 | M1830521_en 3

9.1 Addresses 76

9.1.1 Address of manufacturer 76

Customer service

9.1.2 Address of the installer 76

Table of Contents

4 Fröling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

1 General

Thank you for choosing a quality product from Froling. The product features a state-of-

the-art design and conforms to all currently applicable standards and testing

guidelines.

Please read and observe the documentation provided and always keep it close to the

system for reference. Observing the requirements and safety information in the

documentation makes a significant contribution to safe, appropriate, environmentally

friendly and economical operation of the system.

The constant further development of our products means that there may be minor

differences from the pictures and content. If you discover any errors, please let us

know: [email protected].

Subject to technical change.

The EC Declaration of Conformity is only valid in conjunction with a delivery certificate,

which has been filled in correctly and signed as part of the commissioning process.

The original document remains at the installation site. Commissioning installers or

heating engineers are requested to return a copy of the delivery certificate together

with the guarantee card to Froling. On commissioning by FROLING Customer Service

the validity of the delivery certificate will be noted on the customer service record.

Issuing a delivery

certificate

General 1

Installation Instructions TI 350 | M1830521_en 5

2 Safety

2.1 Hazard levels of warnings

This documentation uses warnings with the following hazard levels to indicate direct

hazards and important safety instructions:

DANGER

The dangerous situation is imminent and if measures are not observed it will lead

to serious injury or death. You must follow the instructions!

WARNING

The dangerous situation may occur and if measures are not observed it will lead

to serious injury or death. Work with extreme care.

CAUTION

The dangerous situation may occur and if measures are not observed it will lead

to minor injuries.

NOTICE

The dangerous situation may occur and if measures are not observed it will lead

to damage to property or pollution.

2Safety

Hazard levels of warnings

6 Fröling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

2.2 Qualification of assembly staff

CAUTION

Assembly and installation by unqualified persons:

Risk of personal injury and damage to property

During assembly and installation:

❒ Observe the instructions and information in the manuals

❒ Only allow appropriately qualified personnel to work on the system

Assembly, installation, initial startup and servicing must always be carried out by

qualified personnel:

- Heating technician / building technician

- Electrical installation technician

- Froling customer services

The assembly staff must have read and understood the instructions in the

documentation.

2.3 Personal protective equipment for assembly staff

You must ensure that staff have the protective equipment specified by accident

prevention regulations.

▪ For transportation, setup and assembly:

- suitable work wear

- protective gloves

- sturdy shoes (min. protection class S1P)

Safety 2

Qualification of assembly staff

Installation Instructions TI 350 | M1830521_en 7

3 Design Information

3.1 Notes on standards

The system must be installed and commissioned in accordance with the local fire and

building regulations. Unless contrary to other national regulations, the latest versions

of the following standards and guidelines apply:

3.1.1 General standards for heating systems

EN 303-5 Boilers for solid fuels, manually and automatically fed

combustion systems, nominal heat output up to 500 kW

EN 12828 Heating systems in buildings - design of water-based heating

systems

EN 13384-1 Chimneys - Thermal and fluid dynamic calculation methods

Part 1: Chimneys serving one appliance

ÖNORM H 5151 Planning of central hot water heating systems with or without hot

water preparation

ÖNORM M 7510-1 Guidelines for checking central heating systems

Part 1: General requirements and one-off inspections

ÖNORM M 7510-4 Guidelines for checking central heating systems

Part 4: Simple check for heating plants for solid fuels

3.1.2 Standards for structural and safety devices

ÖNORM H 5170 Heating installation - Requirements for construction and safety

engineering, as well as fire prevention and environmental

protection

TRVB H 118 Technical directives for fire protection/prevention (Austria)

3.1.3 Standards for heating water

ÖNORM H 5195-1 Prevention of damage by corrosion and scale formation in

closed warm water heating systems at operating temperatures

up to 100°C (Austria).

VDI 2035 Prevention of damage hot water heating systems (Germany)

SWKI BT 102-01 Water quality for heating, steam, cooling and air conditioning

systems (Switzerland)

UNI 8065 Technical standard regulating hot water preparation.

DM 26.06.2015 (Ministerial Decree specifying the minimum

requirements)

Follow the instructions of this standard and any related updates.

(Italy)

3Design Information

Notes on standards

8 Fröling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

3.1.4 Regulations and standards for permitted fuels

1. BImSchV First Order of the German Federal Government for the

implementation of the Federal Law on Emission Protection

(Ordinance on Small and Medium Combustion Plants) in the

version published on 26 January 2010,

BGBl. JG 2010 Part I No. 4.

EN ISO 17225-2 Solid bio-fuel - Fuel specifications and classes

Part 2: Wood pellets for use in industrial and domestic systems

EN ISO 17225-4 Solid bio-fuel - Fuel specifications and classes

Part 4: Wood chips for non-industrial use

3.2 Installation and approval of the heating system

The boiler should be operated in a closed heating system. The following standards

govern the installation:

EN 12828 - Heating Systems in Buildings

NOTICE! Each heating system must be officially approved.

The appropriate supervisory authority (inspection agency) must always be informed

when installing or modifying a heating system, and authorisation must be obtained

from the building authorities:

Austria: report to the construction authorities of the community or magistrate

Germany: report new installations to an approved chimney sweep / the building

authorities.

3.3 General information for installation room (boiler room)

Boiler room characteristics

▪ The floor must be even, clean and dry and have an adequate load-bearing

capacity.

▪There must not be a potentially explosive atmosphere in the boiler room as the

boiler is not suitable for use in such an environment.

▪ The boiler room must be frost-free.

▪ The boiler does not provide any light, so adequate lighting must be ensured in the

boiler room in accordance with national workplace design regulations.

▪ When using the boiler above 2000 metres above sea level you should consult the

manufacturer.

▪ Danger of fire due to flammable materials.

The floor of the boiler room must not be flammable. No flammable materials

should be stored near the boiler. Never place flammable objects (e.g. clothing,

etc.) on the boiler to dry.

Note on standards

Design Information 3

Notes on standards

Installation Instructions TI 350 | M1830521_en 9

▪ Damage due to impurities in combustion air.

Do not use any solvents or cleaning agents containing chlorine and hydrogen

halides in the room where the boiler is installed (e.g. chlorination units for

swimming pools).

▪Keep the air suction opening of the boiler free of dust.

▪ The system must be protected against the chewing or nesting of animals (e.g.

rodents etc.).

Ventilation of the boiler room

Ventilation air for the boiler room should be taken from and expelled directly outside,

and the openings and air ducts should be designed to prevent weather conditions

(foliage, snowdrifts, etc.) from obstructing the air flow.

Unless otherwise specified in the applicable building regulations for the boiler room,

the following standards apply to the design and dimensions of the air ducts:

ÖNORM H 5170 - Construction and fire protection requirements

TRVB H118 - Technical directives on fire protection/prevention

3.4 Requirements for central heating water

Unless contrary to other national regulations, the latest versions of the following

standards and guidelines apply:

Austria:

Germany:

ÖNORM H 5195

VDI 2035

Switzerland:

Italy:

SWKI BT 102-01

UNI 8065

Observe the standards and also follow the recommendations below:

❒Aim for a pH value of between 8.2 and 10.0. If the central heating water comes

into contact with aluminium, the pH value must be between 8.0 and 8.5

❒ Use prepared water which complies with the standards cited above for filling and

make-up water

❒ Avoid leaks and use a closed heating system to maintain water quality during

operation

❒ When filling with make-up water, always bleed the filling hose before connecting,

in order to prevent air from entering the system

Note on standards

3Design Information

General information for installation room (boiler room)

10 Fröling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com

Andere Handbücher für TI 350

Inhaltsverzeichnis

Andere Fröling Kessel Handbücher

Fröling

Fröling S3 Turbo Bedienungsanleitung

Fröling

Fröling S3 Turbo 18 Bedienungsanleitung

Fröling

Fröling SP Dual compact Bedienungsanleitung

Fröling

Fröling PEI Pellet 7-35 Bedienungsanleitung

Fröling

Fröling PE1e Bedienungsanleitung

Fröling

Fröling Lambdatronic S 3100 Bedienungsanleitung

Fröling

Fröling PT4e 200 Bedienungsanleitung

Fröling

Fröling TI 350 Bedienungsanleitung

Fröling

Fröling T4e 20 Bedienungsanleitung

Fröling

Fröling PE1 Pellet 7 Bedienungsanleitung

Fröling

Fröling T4e Bedienungsanleitung

Fröling

Fröling PT4e 200 Bedienungsanleitung

Fröling

Fröling S3 Turbo 15 Bedienungsanleitung

Fröling

Fröling Turbomat 320 Bedienungsanleitung

Fröling

Fröling PE1c Pellet 16-22 Bedienungsanleitung

Fröling

Fröling S4 Turbo (F) Bedienungsanleitung

Fröling

Fröling PE1c Pellet 16-22 Bedienungsanleitung

Fröling

Fröling S1 Turbo 15-20 (F) Bedienungsanleitung

Fröling

Fröling Lambdamat LM 650 KOM Bedienungsanleitung

Fröling

Fröling PE1c Pellet 16-22 Bedienungsanleitung

Fröling

Fröling PE1e Bedienungsanleitung

Fröling

Fröling T4e 200 Bedienungsanleitung

Fröling

Fröling Lambdamat LM 800 Bedienungsanleitung

Fröling

Fröling S3 Turbo Bedienungsanleitung

Beliebte Kessel Handbücher anderer Marken

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Bedienungsanleitung

Radijator

Radijator BIO max 23.1 Bedienungsanleitung

Brunner

Brunner BSV 20 Bedienungsanleitung

Buderus

Buderus Logamax GB062-24 KDE H V2 Bedienungsanleitung

Potterton

Potterton 50e Datenblatt

UTICA BOILERS

UTICA BOILERS TriFire Bedienungsanleitung

Joannes

Joannes LADY Series Handbuch

ECR International

ECR International UB90-125 Gebrauchsanweisung

Froling

Froling FHG Turbo 3000 Bedienungsanleitung

Froling

Froling P4 Pellet 8 - 105 Bedienungsanleitung

U.S. Boiler Company

U.S. Boiler Company K2 Bedienungsanleitung

Henrad

Henrad C95 FF Bedienungsanleitung

NeOvo

NeOvo EcoNox EF 36 Bedienungsanleitung

Potterton

Potterton PROMAX SL 12 Bedienungsanleitung

Eco Hometec

Eco Hometec EC 25 COMPACT Bedienungsanleitung

Viessmann

Viessmann VITODENS 200 Leitfaden

Baxi

Baxi Prime 1.24 Bedienungsanleitung

REXNOVA

REXNOVA ISA 20 BITHERMAL Bedienungsanleitung
