1. VGA INPUT
2. PC Audio input
3. DC / 12V input
OSD (On Screen Display) menu enables user to manipulate the image and settings OSD
main menu consists of source
OSD Menu Contrast, Brightness, Gamma Correct, Color Adjust, , Exit of Color, H. Position, V.
Position, Sharpness, Phase, Clock, Exit of Picture, Language, OSD H. Position, OSD V.
Position, OSD Time, Exit of OSD, Reset, Volume, Exit of Miscellaneous, Exit.
LCD OSD Setting
Auto Color：
：：
：Auto Color adjustment (Only for RD engineer mode)
Contrast：
：：
：Adjust light and dark level of the TFT display. Setting value from
0 ~ 100. Default value is 50.
Brightness：
：：
：Adjust shade and brightness level of TFT display. Setting
value from 0~ 100.Default value is 50.
Color Temp：
：：
：This function will adjust color temperature; more details
please refer to below menu.
Exit：
：：
：Back to main menu.
Color temperature
9300K：
：：
：Select cold color temperature (White and Blue color bias).
6500K：
：：
：Select normal temperature (Comprehensive color).
5800K：
：：
：Select warm color temperature (Yellow bias).
SRGB：
：：
：Special application for computer source (R=G=B=128) that setting
would be display
true color faithfully.
USER：
：：
：This function will provide user to adjust Red, Green and Blue gain
level.
Exit：
：：
：Back to main menu.
