0English

AQUATIMER - A3000 open

Shower Panel made of Stainless Steel, 24 VDC

AQUA623

AQUA621................... with integrated tray for shower gel

Please refer to the graphics in the German Installation and Operating Instructions.

0Table of Contents

1. Abbreviations and Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4. Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Description of Product

5. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

6. Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

7. ID 06200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

8. Scope of Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

9. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

10. Installation Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

11. Jet dispersion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installation, Function and Commissioning

12. Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

13. Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

14. Adjusting the Flow Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

15. Setting Hygiene Flushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Maintenance

16. Maintenance and Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

17. Cleaning the Jet Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

18. Replacing the Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

19. Replacing the Flow Rate Regulator . . . . . . . . . . . . . . . . . . . . . . . 11

20. Fault Correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

21. Spare Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

ZMI_001_2000100799-AQUA623_#SEN_#AQU_#V6.fm

- 4 -

1. Abbreviations and Units

2. Key

Warning!

Failure to observe can result in injury or even death.

Caution!

Failure to observe can result in material damage.

☞Important!

Failure to observe can cause the product to malfunction.

☞Useful information for optimally handling the product.

3. Warranty

Liability is accepted according to the General Terms and Conditions of Business and

Supply.

Use original replacement parts only!

DN Nominal diameter in mm

RCD Residual Current Protective Device,

Earth leakage circuit breaker

SELV Safety Extra Low Voltage

EA-Nr. European Article Number

FAR-Best.-Nr. Franke Aquarotter Order Number

Conversion 1 mm = 0.03937 inches

1 inch = 25.4 mm

All length specifications in the graphics are in mm.

- 5 -

ZMI_001_2000100799-AQUA623_#SEN_#AQU_#V6.fm

4. Important Notes

• Installation, commissioning and maintenance are to be performed only by a

qualified technician according to the instructions provided and in accordance with

legal requirements and acknowledged rules of technology.

• All technical connection regulations specified by the local water and electricity

supply utility companies must be complied with.

• When using the device for paid water distribution with AQUAPAY coin-activated

switches, carefully observe the connection guide provided in the instructions for

the AQUAPAY coin-operated switch.

5. Application

AQUATIMER - A3000 open shower panel made of stainless steel, for on-wall instal-

lation, with electronic time-control and a facility for paid water distribution via

AQUAPAY coin-activated switch, and a feature for externally controlling options such

as fitting settings and communication via ECC function controller. For connecting to

pre-mixed warm or cold water supply. Split-second adjustment of flow duration.

Control functions:

– Optional temperature sensor on the hot water side; the temperature is

measured and a protocol is saved every 60 seconds, during thermal disin-

fection every 10 seconds

– Time-controlled hygiene flushing, optionally with fixed interval or after a certain

defined time after last usage

– Peak load program for demand-oriented fitting functions

Additional functions with ECC function controller (Ethernet):

– Automatic thermal disinfection according to DVGW work sheet W 551 as well

as safety switch-off

– Cleaning switch-off

ZMI_001_2000100799-AQUA623_#SEN_#AQU_#V6.fm

- 6 -

6. Technical Specifications

7. ID 06200

8. Scope of Delivery

9. Dimensions

10. Installation Example

11. Jet dispersion

Minimum flow pressure: 1.0 bar

Recommended flow pressure: 1–5 bar

Maximum operating pressure: 10 bar

Calculation flow rate: 0.20 l/s

Volumetric flow: 0.20 l/s for 3 bar flow pressure

Flow duration at 38 °C: 30 s (adjustable from 1 – 6500 s)

Operating voltage: 24 V DC

Power consumption: 2.5 W

Communication: Ethernet via ECC function controller

Type of protection: IP 68

Quantity Description

1 Stainless-steel casing with:

AQUAJET-Slimline shower head, Piezo-button,

electronic module M1, lockable water volume regulator

with filter, solenoid valve und connecting hose

4 Wood screw, dowel

1 Hook-in strip

1 Connection bracket

1 Flow rate regulator 0.15 l /s

1 Circlip

1 Installation and Operating Instructions

- 7 -

ZMI_001_2000100799-AQUA623_#SEN_#AQU_#V6.fm

12. Assembly Instructions

Warning!

Operate this valve only in conjunction with the correct filter.

Failure to observe can lead to a damaged fitting.

Warning!

• Operate the product only with safety extra low voltage (SELV). Do not earth the

components.

• The power supply (not included in the scope of delivery, see accessories,

Chapter 21) must be set up outside of the wet area, in a separate room.

• Secure the electric connection with an earth leakage circuit breaker (RCD).

Failure to observe can mean risk of death or material damage, e. g. from electric

shock or fire.

☞Important!

Before installing, flush the pipes in compliance with DIN 1988.

☞The system line (not included in scope of delivery) for connecting the power supply

to the fittings must be installed in a conduit (to be supplied by customer) and looped

through.

☞To protect the tiles, use masking tape when marking and drilling. Drill at low speed.

☞Depending on the composition of the wall, special wall dowels may have to be used

(to be provided by the customer).

Installing the electric T-junction

☞Important!

The components of the electronic T-junction must be installed only when they are in

a dead condition.

☞Recommended system lines see Chapter 21., Accessories.

When using other cables for the system line, note the different colour coding. The

outer diameter must not exceed 7.5 mm.

Fig. A: Water connection from above

Fig. B: Water connection from rear

12.1

Only when the water connection is from the rear: Install the connection bracket (a)

leaktight.

12.2

Screw-in the water volume regulator (b) leak-tight.

12.3

Align the water volume regulator in such a way that the screw plug and the operating

element are freely accessible.

12.4

For a shower head height (c) of 2.10 m to 2.30 m, mark the drill holes for the

attachment at a height of 2.14 m to 2.34 m from the upper edge of the prefabricated

foot base.

12.5

Drill according to the markings.

Insert the dowels.

ZMI_001_2000100799-AQUA623_#SEN_#AQU_#V6.fm

- 8 -

12.6

Screw on the hook-in strip.

12.7

Hook-in the stainless steel housing.

12.8

Mark the other drill holes.

12.9

Remove the stainless steel housing.

12.10

Drill according to the markings.

Insert the dowels.

12.11

Strip the shielding (a) off from the system lines (approx. 40 mm).

12.12

Place the union nut (c) on the system line (b) up to the stop.

☞The cable cores are marked with numbers 1 through 4.

A: Union nut

B: FAR Order No. 2000104272

FAR Order No. 2000104274

FAR Order No. 2000100801

FAR Order No. 2000100852

12.13

Latch the cable cores (d) into the cable core guides (e) according to their colours.

12.14

Cut off the protruding ends of the cable core so that they are flush, i. e. so that they

do not protrude.

12.15

Install the line connections between the electronic module, the solenoid-valve

cartridges and the Piezo-button.

A: Solenoid valve cartridge mixed water (Actuator 1)

B: Not used

C:Analogue output 0-10 V

D:Not used

E: Temperature sensor mixed water (optional)

F: AQUAPAY coin-operated switch (optional)

G:Piezo-button

H:Electrical T-junction, system lines (Power)

K: Electronic module

12.16

Remove the protective film from the shower panel.

12.17

Seal the shower panel (e.g. with Chromol, not part of the scope of delivery, see

Accessories, Chapter 21).

12.18

Only when the water connection is from the rear: Bring forward work steps 2.13

through 2.15.

1 brown red

2white white

3 blue blue

4 black black

- 9 -

ZMI_001_2000100799-AQUA623_#SEN_#AQU_#V6.fm

12.19

Hook the stainless steel housing into the hook-in strip and fasten with screws.

12.20

Connect the connecting hose with the water volume regulator to the mixed-water

line or the cold-water line.

12.21

Open the water volume regulator with a hollow hexagon wrench.

d: closed

e: open

12.22

Check the water connections for leaks.

13. Function

Triggering water flow

13.1

Press the Piezo-button.

• Water flows.

• Water flow stops automatically after the set flow duration time has passed or

when the Piezo-button is pushed again.

Flow duration

The flow duration has been factory-set to 30 s. The flow duration can be altered in

steps of 0.1 seconds, from 1 – 6500 s.

14. Adjusting the Flow Duration

Flow duration can be adjusted with a free program available from Franke.

15. Setting Hygiene Flushing

Hygiene flushing can be adjusted with a free program available from Franke.

16. Maintenance and Servicing

Depending on the quality of the water, the local conditions and the rules and regula-

tions applicable on site, the fitting must be maintained and serviced at regular

intervals.

Perform maintenance on the following components:

• Shower head (see Chapter 17.)

• Filters (see Chapter 18.)

Use suitable cleaning agents that are not harmful to the fittings in a proper manner

and rinse with water after use. High-pressure cleaners must not be used for

cleaning.

ZMI_001_2000100799-AQUA623_#SEN_#AQU_#V6.fm

- 10 -

Removing the stainless steel housing

Some maintenance work requires that the stainless steel housing be removed.

16.1

Only when the water connection is from the top:

Close the flow volume regulator.

a: closed

b: open

16.2

Only when the water connection is from the top:

Trigger the valve.

Disconnect the connecting hose for mixed water or cold water from the water volume

regulator.

16.3

Loosen the screws on the stainless steel housing.

☞Do not let the stainless steel housing hang by the connecting hose.

16.4

Unhinge the stainless steel housing.

16.5

Only when the water connection is from the rear:

Close the flow volume regulator (see Work step 16.1).

16.6

Only when the water connection is from the rear:

Trigger the valve.

Disconnect the connecting hose for mixed water or cold water from the water volume

regulator.

17. Cleaning the Jet Plate

17.1

Loosen the screw with a hollow hexagon wrench.

17.2

Using a screwdriver, carefully lift out the jet plate.

17.3

Clean the jet-plate.

17.4

Reassemble in the reverse order.

18. Replacing the Filter

Filter for water volume regulator

18.1

Remove the stainless steel housing (see Chapter 16.).

18.2

Unscrew the screw plug (a) on the water volume regulator.

18.3

Replace the filter (b).

☞Important!

Ensure that the filter is positioned the right way round.

18.4

Reassemble in the reverse order.

Andere Handbücher für AQUATIMER A3000

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Franke Badezimmerarmatur Handbücher

Franke

Franke MIRANIT F5SM2024 Bedienungsanleitung

Franke

Franke Orion OID 621 -116 Bedienungsanleitung

Franke

Franke 7612210067174 Bedienungsanleitung

Franke

Franke ZEXOS676 Bedienungsanleitung

Franke

Franke FAID0004 Bedienungsanleitung

Franke

Franke KWC 2030036195 Bedienungsanleitung

Franke

Franke EXOS611X Bedienungsanleitung

Franke

Franke RODAN RODX607TT Bedienungsanleitung

Franke

Franke F5ST2020 Bedienungsanleitung

Franke

Franke STRATOS STRX611 Bedienungsanleitung

Franke

Franke F5ST2021 Bedienungsanleitung

Franke

Franke F5 ACDR0001 Bedienungsanleitung

Franke

Franke Maris MRG 210-37 Bedienungsanleitung

Franke

Franke AQRE133 Bedienungsanleitung

Franke

Franke F5LT2001 Bedienungsanleitung

Franke

Franke F5LT2022 Bedienungsanleitung

Franke

Franke AQUA205 Bedienungsanleitung

Franke

Franke 2152 00 23 Bedienungsanleitung

Franke

Franke MIRANIT F5 Series Bedienungsanleitung

Franke

Franke MIRANIT F5LT2027 Bedienungsanleitung

Franke

Franke HDTX674 Bedienungsanleitung

Franke

Franke RODAN RODX605E Bedienungsanleitung

Franke

Franke AQRM650 Bedienungsanleitung

Franke

Franke MIRANIT F5SM2025 Bedienungsanleitung

Beliebte Badezimmerarmatur Handbücher anderer Marken

DURAVIT

DURAVIT C.1 C15240 0090 Handbuch

Heatstore

Heatstore HSTRL500WTN Bedienungsanleitung

Sunshower

Sunshower PURE SOLO Bedienungsanleitung

Delabie

Delabie Delabie Sporting 714700 Bedienungsanleitung

Kohler

Kohler K-13056 Montageanleitung

ESS

ESS Container TCL-11 Bedienungsanleitung

Mustee

Mustee 22C Bedienungsanleitung

VITRA

VITRA V-Flow Bedienungsanleitung

baliv

baliv DUK-80.30 T Bedienungsanleitung

Malmet

Malmet B105BT Bedienungsanleitung

bathstore

bathstore Transition H1690MM Leitfaden

BELLOSTA

BELLOSTA Edward 0800/M Bedienungsanleitung

baliv

baliv DU-5160 Bedienungsanleitung

Gessi

Gessi RILIEVO 59011 Bedienungsanleitung

noken

noken VITAE 100188525-N299998810 Bedienungsanleitung

Allen + Roth

Allen + Roth 1142VA-30-201 Bedienungsanleitung

Britex

Britex HBDA Bedienungsanleitung

GRE

GRE DSALC32W Bedienungsanleitung
