PROTRONIC Washbasin Sink Mixer

7612982085512 ......... for open low-level domestic hot water heaters

7612982085529 ......... with open 5 l-low-level domestic hot water heater

Please refer to the graphics in the German Installation and Operating Instructions.

0Table of Contents

1. Abbreviations and Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4. Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Description of Product

5. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

6. Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

7. Scope of Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

8. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

9. Installation Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation, Function and Commissioning

10. Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

11. Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

12. Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

13. Programmable function parameters . . . . . . . . . . . . . . . . . . . . . . . 8

Maintenance

14. Maintenance and Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

15. Replacing the Jet Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

16. Replacing the Grit Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

17. Replacing the Flow Rate Regulator . . . . . . . . . . . . . . . . . . . . . . . 9

18. Replacing the Solenoid Valve Cartridge . . . . . . . . . . . . . . . . . . . . 9

19. Fault Correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

20. Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

[email protected] - www.hygiene-shop.eu

18-05.389e-GB.fm

1. Abbreviations and Units

2. Key

Warning!

Failure to observe can result in injury or even death.

Caution!

Failure to observe can result in material damage.

☞Important!

Failure to observe can cause the product to malfunction.

☞Useful information for optimally handling the product.

3. Warranty

Liability is accepted according to the General Terms and Conditions of Business and

Supply.

Use original replacement parts only!

4. Important Notes

• Installation, commissioning and maintenance are to be performed only by a

qualified technician according to the instructions provided and in accordance with

legal requirements and acknowledged rules of technology.

• All technical connection regulations specified by the local water and electricity

supply utility companies must be complied with.

DN Nominal diameter in mm

SW Width A/F

TW Drinking water

TWW Hot drinking-water

EA-Nr.: European Article Number

FAR-Best.-Nr.: Franke Aquarotter Order Number

Conversion 1 mm = 0.03937 inches

1 inch = 25.4 mm

All length specifications in the graphics are in mm.

[email protected] - www.hygiene-shop.eu

18-05.389e-GB.fm

5. Application

2000067624

PROTRONIC - opto-electronically controlled washbasin mixer DN 15, for connection

to open low-level domestic hot water heaters 230 V AC.

2000100084

PROTRONIC - opto-electronically controlled washbasin mixer DN 15, with open 5 l

low-level domestic hot water heater for connection to cold water supply, 230 V AC.

6. Technical specifications

7. Scope of Delivery

8. Dimensions

9. Installation Example

Minimum flow pressure: 1.0 bar

Recommended flow

pressure:

1-5 bar

Maximum operating

pressure:

10 bar

Calculation flow rate: 0.08 l/s

Volumetric flow: 0.08 l/s at a flow pressure of 3 bar

Flow duration at 38°C 1-15 s adjustable

Operating voltage: 230 V AC

Power consumption:

only with 2000100084 ≤2,1 kW

Type of protection: tap IP44

Power supply/

Low-level domestic hot water heater IP20

Item Description Order No.: Items

1 PROTRONIC Washbasin Mixer 2000067624 1a, 2, 3, 4, 5, 6

2 Connection piece 2000100084 1b, 2, 3, 4, 5, 6, 7

3 Flow rate regulator

4 Grit filter

5 Fixing set, special wrench

6 Power supply

7 Low-level domestic hot water heater

Installation and Operating Instructions

[email protected] - www.hygiene-shop.eu

18-05.389e-GB.fm

10. Assembly Instructions

Warning!

Secure the electric connection with an earth leakage circuit breaker (RCD).

Failure to observe can mean risk of death or material damage, e. g. from electric

shock or fire.

Warning!

Operate this valve only in conjunction with the correct grit filter.

Failure to observe can lead to a damaged fitting.

☞Important!

Before installing, flush the pipes in compliance with DIN 1988.

The water outlet of the fitting must always be kept free. Do not use an aerator.

☞To protect the tiles, use masking tape when marking and drilling. Drill at low speed.

Depending on the composition of the wall, special wall dowels may have to be used

(to be provided by the customer).

10.1

The corner valves (a) must be provided by the customer.

10.2

Installing the hot water heater

☞Observe the operating instructions for the hot water heater.

☞When installing a new socket outlet, take into account the length of the power cable

of the hot water heater.

10.3

Install the fitting (b) on the washbasin (c).

10.4

Place the flow rate regulator (g) into the connector piece (f).

10.5

Place the seal (e) on the connector piece (f).

Screw the water supply hose (d) on to the connector piece (f). Loosen the connector

piece by unscrewing it 1-2 turns.

10.6

Connect the hoses between the hot water heater and the fitting.

1 Cold water (blue)

2 Hot water (red)

10.7

Place the grit filter (3) on the corner valve.

10.8

Screw the connection piece on to the corner valve.

10.9

Screw the water supply hose on to the connector piece.

10.10

Insert the power plug in the socket.

Connect the cable between the fitting and the power supply.

[email protected] - www.hygiene-shop.eu

18-05.389e-GB.fm

11. Commissioning

11.1

Open the water supply.

Caution!

First fill the hot water heater tank.

11.2

Insert the power plug in the socket.

☞Observe the operating instructions for the hot water heater.

The outlet temperature of the hot water heater is limited to approx 40°C.

11.3

FAR Order No. 2000067624: Set the fitting to max. temperature position.

11.4

Fill the hot water heater tank.

When water starts flowing out of the fitting, the hot water heater tank is full.

12. Function

12.1

Allow your hand to approach the sensor.

• Water flows.

12.2

Remove your hand from the sensor.

• Water flow stops automatically after a set flow duration.

☞The range of the sensor and the flow duration can be adjusted with the optional

remote control (FAR Order No. 2000101087).

☞Important!

Reflecting surfaces can influence the sensor. There is a risk of having permanent

reflections (see Chapter 13. for adjusting the sensor range).

Selecting the temperature

+hot

–cold

“Auto-flush” function

Caution!

When the “Auto flush” function is used, the flow of water must be ensured.

• The "Auto-flush" function ensures that forced flushing takes place to exchange the

water in the tap lines after 24 or 72 hours of non-use.

• The “Auto-flush” function can only be switched on with the optional remote control

(FAR-Order-No. 2000101087).

• This function is switched off at the factory.

[email protected] - www.hygiene-shop.eu

18-05.389e-GB.fm

13. Programmable function parameters

The optional remote control FAR-Order-No. 2000101087 offers the following

functions:

– Range can be set (3-20 cm)

– Turn-off delay can be set (0-10 s)

– Continuous flow can be switched between 3.5 min and 11 min.

– Fitting can be switched off

– Basic settings can be restored

– Test mode for simulation without water

– Automatic safety switch-off can be adjusted (2–210 s)

– Automatic flushing can be activated

☞Important!

Reflecting surfaces can influence the sensor. There is a risk of having permanent

reflections. The range must be reduced for installations on reflecting surfaces such

as stainless steel washbasins. If this is not sufficient, an additional base/spacing ring

is available (see Chapter 20.).

14. Maintenance and Servicing

Depending on the quality of the water, the local conditions and the rules and

regulations applicable on site, the fitting must be maintained and serviced at regular

intervals.

Perform maintenance on the following components:

• Jet controller (see Chapter 15.)

• Filters (see Chapter 16.)

• Flow rate regulator (see Chapter 17.)

Properly use suitable cleaning agents that are not harmful to the fittings and rinse

with water after use. High-pressure cleaners must not be used for cleaning.

14.1

Push up the cleaning clip (a) in front of the sensor.

The fitting is in sleep mode.

15. Replacing the Jet Controller

15.1

Use the special wrench (a; FAR Order No. 2000105960) to unscrew and remove the

anti-theft jet controller (b).

[email protected] - www.hygiene-shop.eu

18-05.389e-GB.fm

16. Replacing the Grit Filters

Filter for corner valve

16.1

Close the corner valve (c).

16.2

Trigger the valve.

16.3

Unscrew the connecting hose (a) together with the connector piece from the corner

valve.

16.4

Replace the filter (b).

16.5

Reassemble in the reverse order.

Filter for solenoid valve

16.6

Remove the solenoid valve cartridge (see Chapter 18.).

16.7

Use a flat nose pliers to pull the filter (d) out.

16.8

Replace the filter.

☞Important!

Ensure correct installation position. The rib of the filter must not lie on the flow-

through hole.

Reassemble in the reverse order.

17. Replacing the Flow Rate Regulator

17.1

Close the corner valve (c).

17.2

Trigger the valve.

17.3

Unscrew the connector hose (a) from the connector piece (b).

17.4

Unscrew the connector piece (b) from the corner valve (b).

17.5

Press the flow rate controller (d) out of the connector piece and replace it.

17.6

Reassemble in the reverse order.

18. Replacing the Solenoid Valve Cartridge

18.1

Close the corner valves.

18.2

Trigger the valve.

18.3

Loosen the screw (a) with a hollow hexagon wrench.

18.4

Pull the housing (b) from the base (c).

18.5

Remove the screws (d).

18.6

Remove the mounting bracket (e).

18.7

Remove and replace the solenoid valve cartridge (f).

18.8

Reassemble in the reverse order.

[email protected] - www.hygiene-shop.eu

18-05.389e-GB.fm

19. Fault Correction

If you are unable to correct a fault or if the fault is not described in the fault correction

section, please inform our customer service department!

20. Replacement Parts

Fault Cause Remedy

Water does not flow – Water supply interrupted ➯Restore it

– Voltage supply interrupted ➯Restore it

– Solenoid valve faulty ➯Replace it

– Grit filters are clogged with dirt ➯Replace them

– Flow rate regulator dirty ➯Replace it

– Cleaning clip in front of the fitting ➯Remove

– Electronic system in sleep mode ➯Shine bright light in

front of the sensor

Water flows

continuously

– Solenoid valve faulty ➯Replace it

Water is too cold – Heater not heating ➯Test (s e e

manufacturer

instructions)

– Grit filters are clogged with dirt ➯Replace them

Water flow too weak – Water inflow not fully opened ➯Open it

– Grit filters are clogged with dirt ➯Replace them

– Jet controller calcified ➯Replace it

– Heater calcified ➯Clean it

– Supply pressure too low ➯Check it

Designation Order No.

1 Jet controller, anti-theft . . . . . . . . . 2000109128

2 Special wrench . . . . . . . . . . . . . . 2000105960

3 Solenoid valve cartridge with

grit filter . . . . . . . . . . . . . . . . . . . . 2000104456

4 Cleaning clip. . . . . . . . . . . . . . . . . 2000105795

5 Base for installation

on stainless steel washbasin . 2000105834

6 Maintenance kit comprising:

O-rings

Screws

Filters . . . . . . . . . . . . . . . . . . . 2000104898

7 Mixing lever with screw. . . . . . . . . 2000105821

(only for Order No. 2000067624)

Designation Order No.

8 Power plug . . . . . . . . . . . . . . . . . . 2000105814

9 Connector piece with

Flow rate regulator

Grit filter . . . . . . . . . . . . . . . . . . 2000109480

10 Heater . . . . . . . . . . . . . . . . . . . . . 2000109483

Accessories Order No.

11 Remote control . . . . . . . . . . . . . . . 2000101087

Extension cable

3,0 m . . . . . . . . . . . . . . . . . . . . 2000101456

10,0 m . . . . . . . . . . . . . . . . . . . 2000101457

[email protected] - www.hygiene-shop.eu

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Franke Badezimmerarmatur Handbücher

Franke

Franke RH320 Bedienungsanleitung

Franke

Franke AQUALINE-THERM SWV AQLT0036 Bedienungsanleitung

Franke

Franke F5L-Mix 2030039446 Bedienungsanleitung

Franke

Franke ACXX2007 Bedienungsanleitung

Franke

Franke 7612210067174 Bedienungsanleitung

Franke

Franke AQUALINE WC AQRM553C Bedienungsanleitung

Franke

Franke ACLM2001 Bedienungsanleitung

Franke

Franke XINX687 Bedienungsanleitung

Franke

Franke AQUACONTACT AQCT0051 Bedienungsanleitung

Franke

Franke RODAN RODX605E Bedienungsanleitung

Franke

Franke D20161N Handbuch

Franke

Franke 7612210009501 Bedienungsanleitung

Franke

Franke FAID0008 Bedienungsanleitung

Franke

Franke AQCT0050 Bedienungsanleitung

Franke

Franke JASNA JND 711-100 Bedienungsanleitung

Franke

Franke RODX604E Bedienungsanleitung

Franke

Franke SANW SANW205 Bedienungsanleitung

Franke

Franke AQUAJET-COMFORT SHAC0008 Bedienungsanleitung

Franke

Franke Orion OID 621 -116 Bedienungsanleitung

Franke

Franke Protronic-S AQUA131 2000067774 Bedienungsanleitung

Franke

Franke RODX608 Bedienungsanleitung

Franke

Franke RODAN RODX607 Bedienungsanleitung

Franke

Franke F5LT2001 Bedienungsanleitung

Franke

Franke ZEXOS676 Bedienungsanleitung

Beliebte Badezimmerarmatur Handbücher anderer Marken

DURAVIT

DURAVIT C.1 C15240 0090 Handbuch

Heatstore

Heatstore HSTRL500WTN Bedienungsanleitung

Sunshower

Sunshower PURE SOLO Bedienungsanleitung

Delabie

Delabie Delabie Sporting 714700 Bedienungsanleitung

Kohler

Kohler K-13056 Montageanleitung

ESS

ESS Container TCL-11 Bedienungsanleitung

Mustee

Mustee 22C Bedienungsanleitung

VITRA

VITRA V-Flow Bedienungsanleitung

baliv

baliv DUK-80.30 T Bedienungsanleitung

Malmet

Malmet B105BT Bedienungsanleitung

bathstore

bathstore Transition H1690MM Leitfaden

BELLOSTA

BELLOSTA Edward 0800/M Bedienungsanleitung

baliv

baliv DU-5160 Bedienungsanleitung

Gessi

Gessi RILIEVO 59011 Bedienungsanleitung

noken

noken VITAE 100188525-N299998810 Bedienungsanleitung

Allen + Roth

Allen + Roth 1142VA-30-201 Bedienungsanleitung

Britex

Britex HBDA Bedienungsanleitung

GRE

GRE DSALC32W Bedienungsanleitung
