Franklin HAL-3004 Bedienungsanleitung



HAL-3004

Medical Book Card

User’s Guide



Medical Book System™

MBS

Quick Reference Guide

To Use Notes

1. When the text of the book is on

screen, press

LIST

2. Press

ENTER

to select

Add note

3. Press

ENTER

, or type your own

note title, and then press

ENTER

4. To find a note in the text, press

LIST

, highlight a note title, and

then press

ENTER

5. To remove a note, find the note in

the text, press

LIST

, and then

press

ENTER

to select

Remove note

To Search for Words

1. Press

2. Type one or more words.

3. Press

ENTER

4. Hold

✩

and press

to see

the locations of the matches.

5. Press

ENTER

to see a match, or

press

to see the matches

listed on the menus.

6. To expand the search, press

7. To clear the search, press

CLEAR

To Use the Menus

1. Press

and highlight the

Outline menu or the Index menu.

2. Highlight an entry by typing its

name or pressing or .

3. Press

ENTER

4. Select subitems, if needed, by

highlighting them and pressing

ENTER

5. Use ,

, or

SPACE

to scroll.

To Start Using a Book Card

1. Install the book card in a slot in

the back of the Medical Book

System platform.

2. Turn the platform on.

3. If needed, press

CARD

and then

use the or to highlight its

icon.

4. Press

ENTER

to select it.

READ THIS LICENSE AGREEMENT BEFORE USING THE MEDICAL BOOK

SYSTEM.

YOUR USE OF THE MEDICAL BOOK SYSTEM DEEMS THATYOU ACCEPT

THE TERMS OF THIS LICENSE. IFYOU DO NOT AGREE WITH THESE

TERMS,YOU MAY RETURN THIS PACKAGE WITH PURCHASE RECEIPT TO

THE DEALER FROM WHICHYOU PURCHASED THE MEDICAL BOOK SYS-

TEM ANDYOUR PURCHASE PRICE WILL BE REFUNDED. The MEDICAL

BOOK SYSTEM means the software product, hardware, and documentation found in

this package and FRANKLIN means Franklin Electronic Publishers, Inc.

LIMITED USE LICENSE

All rights in the MEDICAL BOOK SYSTEM remain the property of FRANKLIN. Through

your purchase, FRANKLIN grants you a personal and nonexclusive license to use the MEDI-

CAL BOOK SYSTEM.You may not make any copies of the MEDICAL BOOK SYSTEM

or of the preprogrammed data stored therein, whether in electronic or print format. Such copy-

ing would be in violation of applicable copyright laws. Further, you may not modify, adapt,

disassemble, decompile, translate, create derivative works of, or in any way reverse engineer

the MEDICAL BOOK SYSTEM. You may not export or re-export, directly or indirectly, the

MEDICAL BOOK SYSTEM without compliance with appropriate governmental regula-

tions. The MEDICAL BOOK SYSTEM contains Franklin’s confidential and proprietary in-

formation which you agree to take adequate steps to protect from unauthorized disclosure or

use. This license is effective until terminated. This license terminates immediately without no-

tice from FRANKLIN if you fail to comply with any provision of this license.

This book card was developed for use by medical professionals. No other use of this

book card can substitute for consultation with your physician.

License Agreement

Contents

➤

About Book Card Compatibility

IMPORTANT This book card can be

used only with the Medical Book Sys-

tem™platform and will not function in

any other Franklin BOOKMAN®plat-

form.

The Medical Book System platform

can use Franklin BOOKMAN book

cards as well as Medical Book System

book cards. However, Franklin BOOK-

MAN platforms cannot use Medical

Book System book cards.

➤

For More Information

To learn more about the Medical Book

System or other products from Frank-

lin Electronic Publishers, call 800-665-

5450 or visit the Franklin Web site at

www.franklin.com.

➤

About Screen Illustrations

Some screen illustrations in this User’s

Guide may vary slightly from what you

see on screen. This does not mean that

your Medical Book System platform or

this book card is malfunctioning.

Key Guide..................................... 3

Installing Book Cards .................. 4

Selecting a Book .......................... 4

Changing the Settings ................. 5

Viewing a Demonstration ............ 5

Using the Outline ......................... 6

Using the Index ............................ 7

Searching for Words.................... 8

Highlightig Search Words ......... 10

Expanding Your Searches ......... 10

Reading Special Markers........... 11

Using Notes................................ 12

Looking Up Words

in Other Book Cards .................. 13

Resetting the Platform............... 14

Book Card Care.......................... 14

Specifications and Patents ....... 16

Limited Warranty (U.S. only) ..... 17

Appendix .................................... 18

Index ........................................... 35

Color Keys

(red)Expands a word search.

SPEC

(green)Displays the Outline loca-

tion of the current text.

(

yellow

)Displaysthewordsearchscreen.

LIST

(blue) Lets you add, find, or remove

a note.

Function Keys

BACK

Erases typed letters, or backs up to

the previous screen.

CAP

Shiftskeystotypecapitalsorpunctuation.

CARD

Exits the currently selected book.

CLEAR

Clears an entry or search and goes

to the default state.

ENTER

Enters a word, selects a menu item,

or starts the highlight in text.

HELP

Displays help messages.

Displays the main menus.

ON/OFF

Turns the platform on or off.

SPACE

At entry screens, types a space.At

menus and text, pages down.

? ✻

At menus, displays the title of a high-

lighted item.With

CAP

,types an

asterisk (✽) to stand for letters in a

word.At text, displays the current Out-

line location of the text.

Direction Keys

Pages up or down.

Moves the cursor, text, or highlight.

Key Combinations*

✩

BACK

Goes to the top level of

a menu from a lower level.

✩

CARD

Transfers a highlighted word

between installed book cards.

✩

ENTER

At a highlighted menu item, dis-

plays the related text. At text,

highlights special markers (e.g.,

footnotes, cross-references, etc.).

✩

+Q-P Types numbers.

✩

At text, displays the next or

previous paragraph, table row,

or search match.

CAP

Goes to the top or bottom of

a menu or list. At text,goes to

the next or previous Outline title.

Key Guide

* Hold the first key while pressing the second.

CAUTION Never install or remove a

book card when the platform is turned on.

If you do, information entered in the in-

stalled book card(s) may be erased.

1. Turn the platform off.

2. Turn the platform over.

3. Align the book card tabs with the

notches in a card slot.

4. Press the book card until it snaps

into the slot.

Installing Book Cards

➤

Removing Book Cards

CAUTION When you remove a book

card from a platform, user-entered in-

formation in that book card will be

erased.

If you have installed two book cards in

the platform, you can select which book

you want to read.

1. Turn the platform on.

2. Press

CARD

3. Use or to highlight the book

you want to use.

4. Press

ENTER

to select it.

Selecting a Book

➤

Auto-Shutoff and Auto-Resume

If the platform shuts off automatically

when this book card is selected, you can

return to the last screen that you viewed

simply by turning on the platform.

Changing the Settings

Using the Setup menu, you can adjust the

type size, default state, shutoff time, and

screen contrast of this book.

The type size sets how large the charac-

ters appear on screen. The default state

sets the screen that appears when

CLEAR

pressed. The shutoff time sets how long

the Medical Book System platform stays

on if no one turns it off.

1. Press

2. Use the arrow keys to highlight

Set Type Size, Set Default State,

Set Shutoff

, or

Set Contrast

on the

Setup menu.

3. Press

ENTER

4. Use or to change the setting

and then press

ENTER

. Or press

BACK

to leave the setting un-

changed.

Before you start using this book, you may

want to see a brief demonstration.

1. Press

until the main menus

appear.

2. Use the arrow keys to highlight

View Demo

on the Setup menu.

3. Press

ENTER

to start the demon-

stration.

4. To stop the demonstration, press

CLEAR

Viewing a Demonstration

➤

Help is Always at Hand

You can view a help message at virtu-

ally any screen by pressing

HELP

. To

exit help, press

BACK

To read a tutorial about this book, se-

lect Tutorial from the Setup menu.

➤

Follow theArrows

The flashing arrows at the right of the

screen show which arrow keys you can

press to move through menus or view

more text.

Using the Outline

You can read any chapter, subchapter, or

section of this book by selecting it from

the Outline.

1. Press

CLEAR

2. If needed, press

and high-

light the Outline menu.

3. Highlight a chapter

(e.g., 2

Diagnostic and Therapeutic

Information

), by typing its number

or by using the arrow keys.

The slanted arrow indicates a sub-

menu.

To type a number, hold

✩

and press a

numbered key. To delete a letter, press

BACK

.You can also highlight a menu

item by using or .

4. Press

ENTER

to select it.

Note:You can go directly to the text

by holding

✩

and pressing

ENTER

5. Highlight a subchapter (e.g.,

Cystic

Fibrosis)

and then press

ENTER

6. Highlight a section and press

ENTER

7. Use ,

, or

SPACE

to scroll.

8. To go to the next or previous Out-

line title, hold

✩

and press

9. Press

CLEAR

when finished.

Using the Outline

➤

Where in the Book Am I?

When the text of the book is on the

screen, you can see the Outline loca-

tion of the current text by pressing

SPEC

(green) or

? ✻

To display the full title of a highlighted

item, press

✻

. This is useful when a

title ends in ellipses.

To go to the text associated with a

highlighted item, press

ENTER

. To go

back to the text that you were reading,

press

BACK

You can quickly find a specific topic by

selecting it from the Index.

1. Press

CLEAR

2. If needed, press

and high-

light the Index menu.

3. Start typing a word or phrase (e.g.,

Asthma

You do not need to type spaces. To de-

lete a letter, use

BACK

.You can also use

or to highlight an index entry.

4. When the Index entry is high-

lighted, press

ENTER

5. Highlight a subentry (e.g.,

chronic...

), if needed, and then

press

ENTER

Using the Index

6. Use ,

, or

SPACE

to scroll

down.

7. To go to the next or previous Out-

line title, hold

✩

and press

8. Press

CLEAR

when finished.

Using the Index

Word searches find all the occurrences, or

matches, of a word or phrase in this book.

You can type both letters and numbers,

but you cannot search for short, common

words such as the and is.

1. Press

(yellow).

2. Type your search words (e.g.,

car-

diac arrest

You do not need to type capitals or punc-

tuation.To delete a letter, press

BACK

3. Press

ENTER

to search.

This is the Outline location of the first

match of your search words.

Searching for Words

➤

Viewing Abbreviation Meanings

Abbreviations (e.g., DNA, IU)appear

throughout the text of this book.

To view the expansion of an abbrevia-

tion, first press

ENTER

to start a high-

light and then use the arrow keys to

highlight the abbreviation in the text.

Then press

ENTER

to view its meaning,

if available. To go back to the text,

press

BACK

. To turn off the highlight,

press

BACK

again.

Inhaltsverzeichnis

Andere Franklin Elektronisches Wörterbuch Handbücher

Franklin

Franklin IC-126 Bedienungsanleitung

Franklin

Franklin IC-156 Bedienungsanleitung

Franklin

Franklin LM-6000SEV Bedienungsanleitung

Franklin

Franklin CST-180 Bedienungsanleitung

Franklin

Franklin BOOKMAN SCD-770 Bedienungsanleitung

Franklin

Franklin Collins Crossword Solver CWM-109 Bedienungsanleitung

Franklin

Franklin Language Master LM-5000 Bedienungsanleitung

Franklin

Franklin BOOKMAN COL-2010 Bedienungsanleitung

Franklin

Franklin IC-117 Bedienungsanleitung

Franklin

Franklin Spanish Professor BES-1840 Bedienungsanleitung

Franklin

Franklin CSB-1470U Bedienungsanleitung

Franklin

Franklin Language Master LM-3500 Bedienungsanleitung

Franklin

Franklin IC-139 Bedienungsanleitung

Franklin

Franklin Professor PRO DBD-3040 Bedienungsanleitung

Franklin

Franklin Deutsch/English Professor PRO BDS-1860 Bedienungsanleitung

Franklin

Franklin NCS-101 Bedienungsanleitung

Franklin

Franklin IC-147 Bedienungsanleitung

Franklin

Franklin Merriam-Webster Dictionary MWD-400 Bedienungsanleitung

Franklin

Franklin DMQ-118 Bedienungsanleitung

Franklin

Franklin BOOKMAN III MWD-1450 Bedienungsanleitung

Franklin

Franklin OPD-540 Bedienungsanleitung

Franklin

Franklin Central European Translator TCE-100 Bedienungsanleitung

Franklin

Franklin BOOKMAN MWS-2018 Bedienungsanleitung

Franklin

Franklin BOOKMAN MWD-440 Bedienungsanleitung

Beliebte Elektronisches Wörterbuch Handbücher anderer Marken

Ectaco

Ectaco SAT-1600 Bedienungsanleitung

Sharp

Sharp PW-E310 Bedienungsanleitung

Eaton

Eaton DNP MINT Kurzanleitung

Ectaco

Ectaco Language Teacher ECz600T Bedienungsanleitung

Besta

Besta cd 739p Gebrauchsanweisung

LEGRAND

LEGRAND tynetec ZXT360 Bedienungsanleitung

HORITA

HORITA RLT-50 Bedienungsanleitung

Language Teacher

Language Teacher ES400T Bedienungsanleitung

Accent

Accent 800 Bedienungsanleitung

SUPREME

SUPREME BTLT200 Bedienungsanleitung

KMC Controls

KMC Controls KMD-5551E Benutzerhandbuch

Ectaco

Ectaco SpeechGuard TL-4 Bedienungsanleitung

Sharp

Sharp PW-AM700 Bedienungsanleitung

Ectaco

Ectaco Language Teacher ET200D Bedienungsanleitung

Bosch

Bosch LTC 8782 Series Bedienungsanleitung

Vasco

Vasco Mini Bedienungsanleitung

Ectaco

Ectaco Partner PW800 Bedienungsanleitung

Ectaco

Ectaco Language Teacher ERm600T Bedienungsanleitung
